Contact SupplierDesigned for smaller milling machines.
Table diameter 100 mm
table is graduated 360 degrees.
Worm gear ratio -1:36, which means that the 1 handle rotation shall turn the table by 10 degrees.
Center height in vertical position: 2-116" (50 mm approx)
hand wheel is graduated in divisions of 10 min & can be set to zero.
Can be mounted both in horizontal & vertical position.
Description of the chuck
a high quality 4 jaw independent chuck, the body of which is made from sg iron & jaws are of tool steel hardened & ground.
Same jaws are reversible as well.
Supplied with a mounting back plate & fixing tee nuts with screws.
The back plate has been drilled in a manner that it will fit to a 3 slot or a 4 slot rotary table.
The chuck mounting is standard unimat thread m14 x 1
