Side Channel Vacuum Pumps

Sold By : Shree Siddhivinayak Industries

Product Specifications

Capacity50-1100m3/hr
Supply TypeManufacturer, Exporter, Supplier, Retailer

Preferred Buyer From : All over the world

Product Overview

Minivac SVR & SVRD series Side Channel Blowers are well known names in fields like Plastics, Printing, Packaging, Pharmaceuticals, Foods, SPM and many more.

The impeller rotors without any contact with the casing thus, eliminating wear & has thereby making their models.

Any lubrication 100 % maintenance free & ideas for round the clock operations.

SVR & SVRD Series & Blowers do not requires any lubrication thereby making them environmental friendly.

Blowers available with single & double stage opinion.

Flameproof models available at request of the clients.

Additional accessories like air filters, tape, starters, vacuum & pressure relief valves available.

Single Stage

Model	Nominal Pumping Speed		Pressure		Vacuum		H.P/Kw	Weight (Kg.)
Model	C.F.M	m3/hr	mbar	M3/HR			H.P/Kw	Weight (Kg.)
SVR-25N	25	45	63	49	60	46	0.25/0.18	8.5
SVR-35N	35	60	72	95	79	60	0.50/0.37	13.5
SVR -70N	70	119	118	90	105	80	0.50/0.37	16
SVR-100N	90	152	160	122	140	106	1/0.75	19
SVR-125N	125	212	187	140	173	130	1.5/1.1	25
SVR-180N	188	320	340	258	300	228	5/3.7	45
SVR-70	70	118	165	125	155	118	1/0.75	28
SVR-100	120	204	211	160	190	144	2/1.5	46
SVR-200	200	340	350	266	265	201	5/3.7	55

Model	Nominal Pumping Speed		Pressure		Vacuum		H.P/Kw	Weight (Kg.)
Model	C.F.M	m3/hr	mbar	M3/HR			H.P/Kw	Weight (Kg.)
SVRD-50	50	85	85	65	75	57	0.5/0.37	16
SVRD-100	117	200	140	106	130	100	1/0.75	26
SVRD-125	165	280	170	129	145	110	2/1.5	40
SVRD-150	235	400	200	152	180	137	3/2.2	45
SVRD-175	294	500	230	175	200	152	5/3.7	58
SVRD-200	352	600	260	198	250	190	7.5/5.5	70
SVRD-250	470	800	340	258	300	228	10/7.5	100
SVRD-300	645	1100	400	304	350	266	15/11	130

Double Stage

Model	Nominal Pumping Speed		Pressure		Vacuum		H.P/Kw	Weight (Kg.)
Model	C.F.M	m3/hr	mbar	M3/HR			H.P/Kw	Weight (Kg.)
SVRD-50S	23	40	140	106	120	91	0.5/0.37	16
SVRD-100S	59	100	225	171	200	152	1/0.75	26
SVRD-125S	82	140	270	205	240	182	2/1.5	40
SVRD-150S	118	200	330	251	300	228	3/2.2	45
SVRD-175S	147	250	390	296	360	274	5/3.7	58
SVRD-200S	175	300	450	342	410	312	7.5/5.5	70
SVRD-250S	235	400	526	400	460	350	10/7.5	100
SVRD-300S	294	500	550	418	500	380	15/11	130
