Wdw Computer Controlled Electronic Universal Testing Machine

model wdw-5 wdw-10/20 wdw-50 wdw-100 wdw-200 wdw-300
capacity 5kn 10/20kn 50kn 100kn 200kn 300kn
features adopting speed-adjusting system and ac servo motor, full digital measuring and controlling system
load capacity 2%--100% of the max. test load
load accuracy within ±1%
deformation accuracy within ±1%
displacement resolution better than 0.01mm
crosshead velocity 0.05 - 500 mm/min stepless setting 0.05 -300mm/min stepless setting 0.01-200mm/min stepless setting
test stroke (mm) 800 600
dimension(mm) 760x660x1850 800x660x1980 900x660x2150
clamps wedge, plate and other clamps designed according to the clients
weight(kg) 350kg 600kg 1000kg
type of machine floor
