RSO Trading

Qom,

Jaw Crusher  110 * 95

• High power and capacity in crushingcopy-of-ttrr-109
• Abrasion Parts made of Mn Steel
• Tenacious Structure &high resistance
• High &Equal Output
• Pretty Designing &Confident Operation
• Quick &easy replacements of Spare Parts
• Less Abrasion & more resistance compare to the similar Crushers

110*95 Specifications:

• Model : 110*95
• Dimension(m): L 3150 * W 2610 * H 3225
• Weight(kg) : 36.000
• Capacity(t/h) : 200
• Feed opening(mm): 1100-950
• Motor : 110 K.w , 900 Rpm

Con Crusher 4 *36

• Used As Primary And/or Secondary Crusher In Mineshydrocone
• High Ability To Crush Hard Rocks
• Suitable For Producing
• The Large Input Opening
• Very Strong And High Resistance Structure During Crushing Operation
• Friction Parts Made Of Mn Steel
• Easy Carrying &Installation Caused By Low Weight

C 4 * 36 Specifications:

• Model :  C 4 * 36
• Dimension(m) : 2 * 3 * 3.7
• Weight (kg) : 10000
• Capacity(t/h) : 100
• Max-feed(mm) : 80 * 80 * 95
• Motor : 125 Hp , 90 K.W , 1400 Rpm

Con Crusher 5  *  36

• Used As Primary And/or Secondary Crusher In Mineshydrocone
• High Ability To Crush Hard Rocks
• Suitable For Producing
• The Large Input Opening
• Very Strong And High Resistance Structure During Crushing Operation
• Friction Parts Made Of Mn Steel
• Easy Carrying &Installation Caused By Low Weight

C 5 * 36 Specifications:

• Model : C 5 * 36
• Dimension(m) : 2 * 3 * 3.7
• Weight(kg) : 10, 500
• Capacity(t/H) : 115 T/H
• Max-feed(mm) : 100 * 100 * 125
• Motor : 125 Hp , 90 K.W , 1400 Rpm

Con Crusher  8 *36

• Used As Primary And/or Secondary Crusher In Mineshydrocone
• High Ability To Crush Hard Rocks
• Suitable For Producing
• The Large Input Opening
• Very Strong And High Resistance Structure During Crushing Operation
• Friction Parts Made Of Mn Steel
• Easy Carrying &Installation Caused By Low Weight

C 8 * 36 Specifications:

• Model: C 8 * 36
• Dimension(m): 2 * 3 * 3.7
• Weight (kg) : 10, 700
• Capacity(t/h): 170
• Max-feed(mm): 190 * 190 * 210
• Motor : 125 Hp , 90 K.W , 1400 Rpm

Vibrating Screen

• Tenacious &High Resistance Structurescreen
• Body Made Of Plates Without Suture Weld
• Shafts Made Of Alloy Steel
• Vibration Amplitude Adjustment
• Perfect Lubricant System & Use Of Caulk Tools
• Use Of Double Spherical Roller Bearing For Revolving Movement Quick &Easy Installation and Replacement

6 * 2 Specifications:

• Model : 6 * 2
• Dimension(m) : L 7064 * W 3408 * H 4790
• Weight(kg) : 5350
• Capacity(t/H) : 180-300
• No Of Decks: 3
• Motor : 20 Hp , 15 K.W , 900 Rpm

Horizontal Feeder

• Suitable For Mountain Mines With Large Stoneshorizontal-feeder-1
• Tenacious &High Resistance Structure
• Includes Grizzly System In Front Of The Structure
• Includes Very Great Storage With 60 Tons Capacity
• Using Double Spherical Roller Bearing For Revolving Movement
• Shafts Made Of Alloy Steel
• Movement Amplitude Adjustment In Locomotive
• Use Of Anti-friction Plates For The Body And The Bottom
• Perfect Lubricant System &Caulk Tools

HF 4.8 * 1.2 Specifications

• Model : HF 4.8 * 1.2
• Dimension(m) : 3100 * 1700* 806
• Weight(kg) : 24, 000
• Capacity(t/H) : 550
• Motor : 37 K.W , 900 Rpm

Conveyor Belt (254 m)

• Includes frame contains spar
• Various length to be m used in any plant
• Includes SN 516 bearings and K 61222-2T roller bearings
• Easily vise or replaceable rollicks
• Contains Bolt & Nut junctions in parts such as conveyor structure engine prop, gear box prop , rollick prop , preservatives

Power Panel

• Power distributer frame and piano shape control with electrostatic color, Siemens and in bolt and nut shape.Power Panel
• Using of bimetals with appropriate range for protecting contactors against extra power
• Hydro-con controller system with the capability of sensitive and accurate function from Techno-Electric Engineering
• Using of start chaste and Taiwan step

Cable Layout

• 1-1800 m : 3 * 6cable-layout
• 2-300 m : 3 * 35
• 3-200 m : 16*1.5
• 4-100 m : 2 *1.5
• 5-25 m : 30*135+120

Jaw Crusher  110*95

• High power and capacity in crushingcopy-of-ttrr-109
• Abrasion Parts made of Mn Steel
• Tenacious Structure &high resistance
• High &Equal Output
• Pretty Designing &Confident Operation
• Quick &easy replacements of Spare Parts
• Less Abrasion &more resistance compare to the similar Crushers

110*95 Specifications:

• Model : 110*95
• Dimension(m): L 3150 * W 2610 * H 3225
• Weight(kg) : 36.000
• Capacity(t/h) : 200
• Feed opening(mm): 1100-950
• Motor : 110 K.w , 900 Rpm

Con Crusher  4 * 36

• Used As Primary And/or Secondary Crusher In Mineshydrocone
• High Ability To Crush Hard Rocks
• Suitable For Producing
• The Large Input Opening
• Very Strong And High Resistance Structure During Crushing Operation
• Friction Parts Made Of Mn Steel
• Easy Carrying &Installation Caused By Low Weight

C 4 * 36 Specifications:

• Model :  C 4 * 36
• Dimension(m) : 2 * 3 * 3.7
• Weight(kg) : 10000
• Capacity(t/H) : 100
• Max-feed(mm) : 80 * 80 * 95
• Motor : 125 Hp , 90 K.W , 1400 Rpm

Con Crusher 5 * 36

• Used As Primary And/or Secondary Crusher In Mineshydrocone
• High Ability To Crush Hard Rocks
• Suitable For Producing
• The Large Input Opening
• Very Strong And High Resistance Structure During Crushing Operation
• Friction Parts Made Of Mn Steel
• Easy Carrying &Installation Caused By Low Weight

C 5 * 36 Specifications:

• Model : C 5 * 36
• Dimension(m) : 2 * 3 * 3.7
• Weight(kg) : 10, 500
• Capacity(t/H) : 115 T/H
• Max-feed(mm) : 100 * 100 * 125
• Motor : 125 Hp , 90 K.W , 1400 Rpm

Con Crusher  8 * 36

• Used As Primary And/or Secondary Crusher In Mineshydrocone
• High Ability To Crush Hard Rocks
• Suitable For Producing
• The Large Input Opening
• Very Strong And High Resistance Structure During Crushing Operation
• Friction Parts Made Of Mn Steel
• Easy Carrying &Installation Caused By Low Weight

C 8 * 36 Specifications

• Model: C 8 * 36
• Dimension(m): 2 * 3 * 3.7
• Weight: 10, 700
• Capacity(t/H): 170
• Max-feed(mm): 190 * 190 * 210
• Motor : 125 Hp , 90 K.W , 1400 Rpm

Superior gyratory crusher

• Suitable for High Gravel-Sand Productionsuperio
• Utilization as Primary & Secondary Crusher in Mines
• High Capacity due to Wide Input Nozzle for Loads
• Very Firm Structure & High Resistance in Crushing
• Manufacture of Frictional Parts from Manganese Steel
• High Efficiency & Reduction of Preservation Expenditure via Three Independent Lubricating Systems
• Ease of Transportation & Installation due to Low Weight
• Quick & Easy Exchange of Parts

13 * 36 Specifications

• Model : 13 * 36
• Dimension(m): 2 * 3 *4.5
• Weight(kg) : 12, 500
• Capacity(t/h): 260
• Feed opening(mm): 200 * 200 * 300 (mm)
• Motor : 125 Hp , 90 K.w , 1400 Rpm

Vibrating Screen(3)

• Tenacious &High Resistance Structurescreen
• Body Made Of Plates Without Suture Weld
• Shafts Made Of Alloy Steel
• Vibration Amplitude Adjustment
• Perfect Lubricant System & Use Of Caulk Tools
• Use Of Double Spherical Roller Bearing For Revolving Movement Quick &Easy Installation and Replacement

6 * 2 Specifications:

• Model : 6 * 2
• Dimension(m) : L 7064 * W 3408 * H 4790
• Weight(kg) : 5350
• Capacity(t/H) : 180-300
• No Of Decks: 3
• Motor : 20 Hp , 15 K.W , 900 Rpm

Horizontal Feeder

• Suitable For Mountain Mines With Large Stoneshorizontal-feeder-1
• Tenacious &High Resistance Structure
• Includes Grizzly System In Front Of The Structure
• Includes Very Great Storage With 60 Tons Capacity
• Using Double Spherical Roller Bearing For Revolving Movement
• Shafts Made Of Alloy Steel
• Movement Amplitude Adjustment In Locomotive
• Use Of Anti-friction Plates For The Body And The Bottom
• Perfect Lubricant System &Caulk Tools

HF 4.8 * 1.2 Specifications

• Model : HF 4.8 * 1.2
• Dimension(m) : 3100 * 1700* 806
• Weight(kg) : 24, 000
• Capacity(t/H) : 550
• Motor : 37 K.W , 900 Rpm

Conveyor Belt ( 304 m)

• Includes frame contains spar
• Various length to be m used in any plant
• Includes SN 516 bearings and K 61222-2T roller bearings
• Easily vise or replaceable rollicks
• Contains Bolt & Nut junctions in parts such as conveyor structure engine prop, gear box prop , rollick prop , preservatives,

Power  Panel

• Power Distributer Frame And Piano Shape Control With Electrostatic Color, Siemens And In Bolt And Nut Shape.picture120
• Using Of Bimetals With Appropriate Range For Protecting Contactors Against Extra Power
• Hydro-con Controller System With The Capability Of Sensitive And Accurate Function From Techno-electric Engineering
• Using Of Start Chaste And Taiwan Step

Cable Layout:

• 1-400  M : 3 * 35
• 2-400  M : 3 * 2.5cable-layout
• 3-400 M : 2*25
• 4-2400m : 4*6
• 5.250 M: 16*1.5
• 6-25 M : 3*135+120
