Our Products
Our product range contains a wide range of CE Relay
RELAY TYPE:GP Relay
16A switching capability
Standard PCB layout
Dielectric strength between coil and contact 5KV
Various of contact forms available
Option for sealed and flux-tight type
UL insulation gradeClass F
Environmental friendly product
Power Relays, High Power Relays, Power Relays Factory, China
| Contact Ratings | |
| Contact Form: | 1A, 1C; 2A, 2C |
| Contact Material: | AgCdO, AgSnO2 |
| Contact Load Capacity: | 1A, 1C:16A/250VAC |
| 2A, 2C:5A/250VAC | |
| Max. Switching Current: | 16A |
| Max. Switching Power: | 4000VA |
| Mechanical Endurance: | 1*107OPS |
| Electrical Endurance: | 1*105OPS |
Outline dimension: 29 x 12.6 x 20.6mm
| TechnicalRatings | |
| InsulationResistance: | 1000M |
| DielectricStrength(Betweencoil&contact): | 5000VAC |
| OperateTime(Max.): | 15ms |
| ReleaseTime(Max.): | 5ms |
| AmbientTemperature: | -4070 |
| TerminalType: | THT |
| CoilRatings | |
| NominalVoltage | (5-48)VDC |
| NominalCoilPower | 0.54W, 0.72W |
Additional Information:
Payment Terms : T/T
Packaging Details : Carton
Delivery Time : Normally 10-15 days
