Our Products
We offer wide range of Ball Valve in the market. Ball Valve is manufactured for High Pressure & temperature, steam and cryogenic service. Ball Valve (floating ball) can be integrated with a consistent range of manual, electrical, pneumatic actuators to create complete flow control packages. Ball Valve is available in various designs with or without top mounting flange. Pressure rating of Ball Valve is from full Vaccum to high pressure. Temperature range from -50oC to +500oC, connections available are socket and butt-welding, flanged according to ISO PN or ANSI and threaded. Availability
Technical Specifications
| Size Range | 1/2" to 24" |
|---|---|
| Pressure Class | 150 # to 4500# and higher |
| Material | WCB, LCB,LC1, LC2, LC3, LCC, WC1, WC5, WC6, WC9, WCC, C5, C12, CF8, CF8M, CF3, CF3M, CG8M, CG3M, CN7M, CD4MCu, Hastelloy, Inconel, Duplex Stainless Steel, Super Duplex, Monel, Alloy20, Alloy400, Alloy625, Alloy825, Titanium, SS904L, Nickel, Gun Metal. |
inconel 625 (uns n06625) valves is designed and manufactured for corrosion and oxidation resistance properties in various environments. this alloy resists a wide range of severely corrosive environments and is especially resistant to pitting and crevice corrosion.
inconel 625 material grades
specifications
following type of valves are manufactured by falcon
characteristics of inconel 625
inconel 625 is widely used in seawater lines due to excellent pitting and crevice corrosion resistant properties. oxidation resistant upto 1000°c. inconel 625 is non-magnetic.
application of inconel 625 valves
Duplex 2205 ( UNS S31803) is a nitrogen enhanced duplex stainless steel that is designed to combat common corrosion problems encountered with the SS316/SS304 stainless steel grades. Falcon Duplex 2205 stainless steel valves has good resistance to chloride pitting and crevice corrosion. This resistance is extremely important for services such asOffshore plants, desalination plants, brackish water, bleaching operations, chemical processing, oil and gas productions and some food processing applications.
Specifications
Following type of Valves are manufactured by Falcon
Characteristics of duplex stainless steel
Duplex stainless steel has high strength and excellent ductility. It provide better resistance to pitting and crevice corrosion. Pitting resistance equivalent (PREN) range is 28-38.
Application of Duplex stainless steel valves
254 SMO (CK3MCuN) is a high-alloy austenitic stainless steel developed for use in seawater and other chloride containing fluids. Falcon 254 SMO valves are designed with a combination of high impact toughness resistance to chloride stress corrosion (SCC), and pitting and crevice corrosion with strength that is twice that of SS316/SS304 stainless steel.
Casting Grade : A351 CK3MCuN
Forging Grade : A182 F44
Wrought UNS : S31254
Cast UNS : J93254
Specifications
Following type of Valves are manufactured by Falcon
Characteristics of 254 SMO valves
254 SMO has a very low carbon content. Pitting resistance equivalent number (PREN) is above 42.5 hence it provides good corrosion resistance in water containing chlorides.
Application of 254 SMO valves
Falcon Valves & Flanges Pvt Ltd is one of India's most credible stainless steel gate valve manufacturers. Because of their high durability, tensile strength, and resistance to adverse conditions, stainless steel gate valves are suitable for a wide range of industrial applications. Get Best Quote Stainless Steel Globe Valves from us for valves which are also available in a variety of shapes and specifications that meet the requirements. Our specially designed Stainless steel globe valves operating process provides shock-proof, stress-free procedure as well as longer life.
The collection is made of high-quality components like stainless steel, cast carbon steel, and crafted steels, among others, and is highly resilient and simple to use. It is small in size, and the gate has a knife edge for cutting through fibrous medium.
Technical Specification
| Cast | Forging | |||
| ASTM | EN | SAF Alloy | ASTM | EN |
| A351 CF8 | 10213-4 1.4308 | 304 | A182 F304 | 10088 1.4301 |
| A351 CF3 | 10213-4 1.4309 | 304L | A182 F304L | 10088 1.4307 |
| A351 CF8M | 10213-4 1.4408 | 316 | A182 F316 | 10088 1.4401 |
| A351 CF3M | 10213-4 1.4409 | 316L | A182 F316L | 10088 1.4004 |
| A351 CF10MC | 10213-4 1.4581 | 316MB | -- | 10088 1.4580 |
| - | - | 321 | A182-F321 | 10088 1.4541 |
Technical Specification
| Cast | Forging | |||
| ASTM | EN | SAF Alloy | ASTM | EN |
| - | - | 430 | EN 10088 1.4016 | |
Technical Specification
| Cast | Forging | |||
| ASTM | EN | SAF Alloy | ASTM | EN |
| A 743 CA-15 | 1.4008 | 410 | 10088 1.4006 | |
| - | - | 420 | 10088 1.4021 | |
| A 743 CA-40 | 1.4028 | 420 | 10088 1.4034 | |
Hastelloy C22 (UNS N06022) has enhanced resistance to pitting, crevice corrosion and stress corrosion cracking. Hastelloy C22 valves work in both oxidizing and reducing environments.Hastelloy C22 is used in seawater, brine, wet chlorine, formic and acetic acids, ferric and cupric acids. .
Hastelloy C22 Material grades
Specifications
Following type of Valves are manufactured by Falcon
Applications of Hastelloy C22 valves
Inconel 601 (UNS N06601) valves are designed and manufactured for application that require resistance to corrosion and heat. Inconel 601 is used in various industries such as thermal processing, chemical plants, pollution control and nuclear thermal power plants.
Inconel 601 Material Grades
Specifications
Following type of Valves are manufactured by Falcon
Characteristics of Inconel 601
Inconel 601 has outstanding oxidation properties at 1200°C. Alloy 601 Valves are due to high resistance to carburization and good creep rupture strength.
Applications of Inconel 601 valves
Inconel 825 (Incoloy 825) also known as Alloy 825 is a nickel-iron-chromium alloy with additions of molybdenum, copper and titanium. This alloy provide good resistance to many corrosive environments. It has excellent resistance to both reducing and oxidizing acids. Incoloy 825 valves are used in chemical processing, pollution-control equipment’s, oil and gas well piping’s, nuclear fuel plants, acid plants and pickling equipment’s.
Inconel 825 Material Grades :
Specifications :
Following type of Valves are manufactured by Falcon
Characteristics of Incoloy 825
Incoloy 825 valves provides good resistance to reducing and oxidizing acids. Very resistant to sulfuric and phosphoric acids. Good resistance to stress-corrosion cracking and excellent mechanical properties at room and elevated temperatures.
Application of Incoloy 825 valves
monel 400 (uns n04400) is resistant to seawater and steam at high temperatures as well as to salt and caustic solutions. falcon monel 400 valves is used in hydrochloric and hydrofluoric acid environments.
monel 400 material grades
following type of valves are manufactured by falcon
application of monel 400 valves
Material Grades
| Cast | Forging | |||
| ASTM | EN | SAF Alloy | ASTM | EN |
| A995 Gr. 5A | - | SAF 2507 | #NULL! | - |
| A995 Gr. 6A | A182 F55 | |||
Inconel 800, Inconel 800H and Inconel 800HT are nickel-iron-chromium alloys with good strength and excellent resistance to oxidation and carburization in high-temperature exposure. These alloys are used in high temperature applications and is highly resistant chloride stress corrosion cracking.
Inconel 800/800H/800HT Material grades
Specifications
Following type of Valves are manufactured by Falcon
Characteristics of Incoloy 800, Incoloy 800H &Incoloy 800HT
Incoloy 800, Incoloy 800H &Incoloy 800HT provides high temperature strength and high creep strength. These valves are used where resistant to oxidation and carburization in high temperature environments is required. It provides good corrosion resistance in many acidic environments and sulfur containing atmospheres.
Application of Incoloy 800, Incoloy 800H &Incoloy 800HT valves
Hastelloy C276 (UNS N10276) is designed to have excellent corrosion resistance in wide range of severe environments. Falcon Alloy C-276 valves are mostly used in severe environments such as chemical processing, pollution control, Oil and gas fields and Waste water treatment plants.
Hastelloy C276 Material grades
Casting Grade : A494 CW-12MW
Cast UNS : N30002
Wrought UNS : N10276
Specifications
Following type of Valves are manufactured by Falcon
Characteristics of Hastelloy C276 (Alloy C276, Hastelloy C, Inconel® C-276)
Hastelloy C276 provides excellent resistance properties in a wide variety of chemical process environments.Hastelloy C276 valves has excellent resistance to pitting and stress corrosion cracking. It has best properties both in oxidizing and reducing environments. Hastelloy C276 valves has long life when used in wet chlorine gas, hypochlorite and chlorine dioxide.
Applications of Hastelloy C276 valves
We at Falcon Valves & Flanges Pvt Ltd are one of the most reputable Stainless steel gate valve Manufacturers in India. The Stainless steel gate valves are suitable for different types of industrial applications due to its high sturdiness, tensile strength, and resistance to adverse conditions. Stainless steel gate valve is also accessible in various of sizes and dimensions that meet the specifications. Because there are few moving parts, our specially designed S valve operating system will ensure shock-proof and stress-free operation, as well as longer life.
The range is made of high-quality materials such as stainless steel, cast carbon steel, and forged steels, among others, and is extremely durable and simple to use. It has a minimalistic size, and the gate has a knife edge to cut through fibrous medium.
Custom valves manufacturing for Oxygen services
Falcon is one of the leading oxygen service valves manufacturer and exporter in India. Our valves are designed and manufactured against the latest industrial standards with proven designs. For oxygen valve services and applications, limitations are set on sharp edges and the degreasing of valves. We clean all valves according to proven cleaning procedures.
Oxygen applications
Why choose us
Our valves are designed and manufactured to ensure safety, quality and regulatory compliance of users and patients
We've served industries for over a decade, developing solutions based on your evolving oxygen needs.
We help you ensure your facility's medical equipment is serviced and fully compliant with Industries standards
Safety valves also known as Safety relief valves (SRV) or Pressure Safety valves (PRV). The primary function of safety valves is to protect environment, property and life by venting fluid from an over pressurized vessel or line. An overpressure event refers to any condition which would cause pressure in a pipeline, vessel or system to increase beyond the specified design pressure. A pressure Relief valve is a critical valve hence it must be designed and capable of operating at all times.
Falcon manufacturers following types of Pressure safety valves
Application of safety valves
We are also able to arrange third party testing, inspection and certification from several independent authorities such as: TUV, DNV, BV, ABS, LR, GL, SGS and others
Recently Completed Project
| Client | Nigerian AGIP Oil Company Ltd |
| Project Owner | ENI Italy |
| Project Details | Gas Plant Onshore- Obiafu/Obrikom |
| Project Location | Rivers State, Nigeria |
| Third Party Inspector | SGS, India |
| No of Safety Valves | 140 |
| Status | Successfully Completed |
Inconel 600 (UNS N06600) valves are designed and manufactured in applications where high temperature and corrosion resistance is required.This nickel alloy is developed for service tempertures from cryogenic to elevated temperatures in the range of 1100°C. It also provides excellent corrosion resistant to organic and inorganic compounds, chloride ion stress corrosion cracking and alkaline solutions.
Inconel 600 Material grades
Specifications
Following type of Valves are manufactured by Falcon
Characteristics of Inconel 600
Inconel 600 is resistant to wide range of corrosive media. It’s non-magnetic and has excellent mechanical properties under wide range of temperatures
Application of Inconel 600 valves
Monel 500 (UNS N05500) is also known as Monel K500 which is designed to combine the excellent corrosion resistance properties of Monel 400 with the added benefit of greater strength and hardness. Alloy K-500 has approximately three times the yield strength and double the tensile strength when compared with alloy 400 hence it provides better tendency towards stress-corrosion cracking in various environments.
Monel K500 Material grades
Specifications
Following type of Valves are manufactured by Falcon
Characteristics of Monel 500
Monel 500 valves are designed and suitable to use in marine and chemical environments such as pure water, non-oxidizing mineral acids, salts and Alkalis. It has good resistant to sour-gas service. Provides excellent mechanical properties from sub-zero temperatures upto 500C.
Application to Monel 500 valves
Falcon Valves & Flanges Pvt Ltd specialises in manufacturing and supplying a wide range of Forged steel Ball valves. Our Forged steel gate valves, which are made from high-quality raw resources, are highly regarded by our clients from all over the country. We provide a high-quality range of forged steel three-piece ball valves at rock-bottom prices inside one specified time frame.
Our Forged steel Globe valves outperform other valves on the market in terms of speed efficiency. Furthermore, we can easily handle bulk orders of Forged steel check valves as needed by the clients. Our forged steel valves are used in a variety of industries and applications. Our provided forged steel valve has many advanced features and was designed with the utmost precision.
Specification Forged Steel Ball Valves
| PART | SPECIFICATION |
|---|---|
| BODY | ASTM A105 / ASTM A351 GR CF8 / CF 8M |
| END CONNECTOR | ASTM A105 / ASTM A351 GR CF8 / CF 8M |
| BALL | AISI 304/316 |
| SEAT | PTFE / REINFORCED |
| STEM | SS304 / SS316 |
| BODY SEAL | VIRGIN PTFE |
| GLAND PACKING | PTFE / REINFORCED |
| STEM SEAL | PTFE / REINFORCED |
| GLAND | SS304 / SS316 |
| FASTENERS | ASTM A 193-B7 / A194 – 2H / SS316 |
| STOPPER | STEEL – Cad. plated |
| HAND LEVER | STEEL – Cad. plated WITH SLEEVE |
Alloy 904L is a super austenitic stainless steel that is developed for moderate to high corrosion resistance in various process environments. Falcon manufactured SS904L valves are designed to withstand environments containing sulfuric acid. It also offers good resistance to other inorganic acids such as hot phosphoric acid as well as most organic acids. We have supplied SS904L valves to MAADEN in Saudi Arabia, CHEMAF in Congo, JIFCO in Jordan and many more plants worldwide.
Specifications
Following type of Valves are manufactured by Falcon
Characteristics of SS904L valves
Application of SS904L valves
