Digital Readout System (SW-4000)

Digital Readout System (SW-4000) is easy to operate and comes with multiple functions for metrology and position. This Digital Readout System is best suited for various machine tools. We are ranked among the reliable Suppliers of this Digital Readout System.

Specifications :

• Hardware Specifications :
• Input voltage : AC 90V - 240V
• Power Consumption : Max. 15W
• Dimension : 295 mm x 185 mm x 45 mm
• Weight : 1.45 kg
• Linear Scale Signals : Orthogonal TTL square wave, frequency 2 MHZ,
• Current : 1 mA
• Resolution Selection : 0.1µm, 0.2µm, 0.5µm, 1µm, 2µm, 5µm, 10µm, 20µm, 50µm
• Software Functions : Coordinate zero setting ½ calculation to locate work piece center
• Error Compensation : linear compensation ABS/ INC conversion, diameter/ radius selection Shrink function
• DIR : Setting the coordinate direction, Rotary Encoder : 10.0001 Instant power failure memory,
• RI Detection : setting and recalling a datum for machining Multiple machining functions bolt circle machining R-angle divide holes on an oblique line machining on an oblique line
• Order number : Arc Machining, Ramp machining (SW4000-2, SW4000-3), EDM machining (SW-4000-E), Edge detecting, Lathe function (optional)
