| Alloy Steel Work Spindle Hardened & Ground Diameter | 80 | 100 | 110 | 125 |
|---|---|---|---|---|
| Morse Taper Number | 5 | 6 | 6 | 6 |
| Max. Longitudinal Movement of working Spindle(Z-Axis) | 510 | 510 | 510 | 600 |
| No. of Spindle Speeds | 9 | 9 | 9 | 9 |
| Range of Spindle Speeds-R.P.M | 20to300 | 15to250 | 15to250 | 15to250 |
| Longitudinal Work Spindle Feeds Nos. | 9 | 9 | 9 | 9 |
| Max. Height of Spindle Axis from Table Surface(Y- Axis) | 925 | 1000 | 1100 | 1250 |
| Min. Height of the Spindle Axis from Table Surface | 25 | 35 | 35 | 35 |
| Dimensions of the rotary table | 900*1105 | 1030*1375 | 1100*1450 | 1225*1675 |
| Longitudinal Table Traverse(W-Axis) | 1625 | 1775 | 1925 | 2050 |
| Long Table Travel Feeds(including one rapid) | 10 | 10 | 10 | 15 |
| Transversal Table Travel Feeds | 10 | 10 | 10 | 15 |
| Vertical Head Stoke Travel feeds | 4 | 4 | 4 | 15 |
| Rotary Table Automatic feeds | 10 | 10 | 10 | 15 |
| Max. Cross Movement of the table(X-Axis) | 1000 | 1100 | 1300 | 1550 |
| Max. Distance b/w Stay Bearing & Facing Head | 2400 | 2690 | 2800 | 2950 |
| Facing Head Diameter | 505 | 555 | 600 | 650 |
| Weight Approx in Kgs.(without packing & accessories | 8500 | 10000 | 11000 | 16500 |
