Xinyao Machinery fuuly automatic Pin Machine, Power : 220V

₹ 4.55 Lakh / Set

MOQ1 Set(s)
Automatic Gradefuuly automatic
BrandXinyao Machinery
Packaging Typeas the picture show
Power220V
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

Product Details

Automatic Gradefuuly automatic
Packaging Typeas the picture show
Availability1000kg
Power220V
BrandXinyao Machinery
Country of OriginChina
Namepin machine
DimensionsL113*W68*H164CM
Applicationpcb board
After-sales Service Provided1Year
Warranty1year
Model NumberXY-xd660

The Fully automatic pin machine is designed for PCB to NC drilling and install pin. Drilling and install pin are performed at one-stage. Drilling shaft adopted by MF HSmain-shaft which has high rotation speed, low noise, good drilling accuracy and service life long characteristics. These machines are widely known for its durability and quality. For more details, please contract us.
Feature .
. Energy saving, Environmental protection, Low pollution level
. Miniature and light weight, Economic Space Occupation, Easy installation
.High working accuracy
.Low noise operation
.Easy to operate, be equipped with PLC controller
. Perfect and complete protection functions, increasing machine's reliability & stability
Technical parameter
Rotation speed of main saw blade 24000r/min stepless adjustable
Spindle spring clip 3.175
Production specification Max 660x560mm
Min 200x150mm
Work power supply& Power 1ph 220V 50Hz 0.5kw Air pressure 5kgf/cmÃ�Â²
Machine size (L*W*H) 1130x680x1640mm
