Reverse Hexagonal Wire Mesh Machine, Packaging Type : green

We are offering straight and reverse hexagonal wire mesh machine.
this machine can produce the hexagonal wire mesh with two ways twists.the mesh size can be 3/4, 1, 2, 3inch and so on .the wire diameter can be 0.52 mm to 1.5mm, and this machine can also produce the double width.
to compared with normal hexagonal wire mesh machine, it’s more advanced. And it only include one main machine and a spool winding machine, no spring winding machine.
1.main machine:
mesh size: 3/4, 1, 2, 3
mesh width: 2.5-3m
wire diameter: 0.52mm-1.5mm
main machine overall dimension: 4.7/5.7m*1.0m*1.65m(length*width*height)
weight: 4/4.5t
motor: 2.2kw
2.spool winding machine
overall size:1.0*1.5*0.7m
weight:75kg
motor:0.75kw
