Salient Features
•
Available in 1/1.2/2/2.5/3.5/4 m3 Capacity.
•
Operation is user friendly.
•
Excellent quality of materials and components gives long life with less....
Excellent quality of materials and components gives long life with less economy.
•
The design of devices allow concrete consistently with high speed.
•
4 Wheel drive & 4 wheel steering.
•
180° reversible driving post.
•
Electronic weigh batching unit.
•
35% Gradeability.
•
Efficient and reliable after sale – service round the clock.
•
Manufactured under license from “DUMEC S.R.L.”
Optionals
•
Extra Chute.
•
High Pressure Washing System.
•
Printer.
•
Slewing Drum Arrangement.
Technical Specification
Description
2 m3
4 m3
Engine
Direct injection natural aspirated Water Coolled four Stroke turbo charged diesel engine 44.01Kw/59HP at 2300 rpm Kirloskar - 4R810T2
Direct injection natural aspirated Water Coolled four Stroke turbo charged diesel engine 80.90Kw/109HP at 2500 rpm Kirloskar - 4R1040TA4
Traction
4 Wheel Drive
4 Wheel Drive
4 Wheel Steering
4 Wheel Steering
Transmission
Hydrostatics 4 Speeds
Hydrostatics 4 Speeds
Steering
Power Assisted
Power Assisted
Differentials
Totally enclosed oil-bath disc brakes
Totally enclosed oil bath disc brakes
Parking Brake
Mechanical
Mechanical
Starting
Electric 12 V
Electric 12 V
Effective Yield
2000 Lit.
4000 Lit.
Loading
Self Loading Shovel Capacity 600 Lit.
Self Loading Shovel Capacity 800 Lit.
Discharge Concrete
Rapid discharge of the Concrete by hydraulic drum tilting
Rapid discharge of the Concrete by hydraulic drum tilting
Adjustment Of Drum Rotation
By Electronic Control
By Electronic Control
Water Equipment
Self Priming hydraulic pump 220 Lt./min.
Self Priming hydraulic pump 220 Lt./min.
Water Tank
600 Lit.
900 Lit.
Drive Seat
Rotating 180 protection cabin
Rotating 180 protection cabin
Tyres
Front & Rear type 12.0/75-18,12 PR, Rim Size 11" x 18"
Front & Rear type 405/70-20 14 PR, Rim Size 13" x 20.1"
Lights Equipment
Complete with head / tail lights, rotating light and emergency lights.
Complete with head / tail lights, rotating light and emergency lights.
Empty Weight
5660 Kg.
7950 Kg.
Leaning Grade
35%
35%
Speed
20 Km/h Maximum
30 Km/h Maximum
Dimensions
Model
MST-2
MST-4
A
2820
2710
B
2250
2700
C
1430
1400
D
6500
6810
E
1600
1900
F
1870
2250
G
2800
3140
H
4200
4320
I
30°
32°
J
2830
2940
K
5000
5460
L
1770
1970
M
2130
2360
N
330
355
O
R-4250
R-5100
P
R-1680
R-2000
Q
R-4300
R-5000
R
2880
3300
