| Material | Mild Steel |
| Job Material | Stone |
| Max Job Size | 4x8 Feet |
| Spindle Power | 5.5 kw |
| Operation Mode | Automatic |
| Spindle Speed | 24000 RPM |
| Voltage | 415 V |
| Reposition Accuracy | 0.2 mm |
| Weight | 1600 kg |
| Table Size | 1500 x 3000 x 300 mm |
| Warranty | 1 Year |
| Diameter Of Cutter | 3 - 12 mm |
| Max Cutting Speed | 8000 mm/min |
| Drilling Capacity | 12 mm |
| Machine | 1325 cnc router woodworking |
| Working table | Vacuum table +T-slot table |
| Workable size | 1300x2500x200mm |
| Spindle motor | 6KW air cooling spindle |
| Max. Travel ling speed | 35m/min |
| Max. working speed | 25m/min |
| Spindle Rotation Speed | 0-24,000rpm |
| Operating system | DSP NK105 control system, more easy to operate and use |
| Command | G Code |
| Driver & motor | Stepper motor and drivers |
| X,Y,Z Transmission | Z---Taiwan TBI Ball Screw; X,Y---Rack Gears |
| X,Y,Z Guide Rail | Taiwan HIWIN Square Rail |
| Dust Collecting System | 3KW double bags dust collect |
| Working Voltage | 380v,50hz,3ph |
| NW | 900KG |
| GW | 1000KG |
