Power Coated Steam Sterilizers, Color : White-Golden

Specifications

• Operating Temperature range
• Sterilizing - 121 °C
• Warming -  45-95 °C
• Purging - Upto 99 °C
• Maximum Operating Pressure - 15 PSI
• Temperature Display – Digital
• Pressure  Display – Analogue
• Analog Pressure Gauge Max value - 35 PSI
• Heat Source  Load  - 3 KW
• Safety Devices - *Water Level Sensor *LID Interlock *Over temperature protection *Over Pressure Protection *Pressure Safety Valve
• Time Display – Digital
• Time Range - 0 to 999 Mins
• Chamber Dimension : Dia (mm) x Depth (mm) - 400 x 600
• Chamber Busket Dimension  - 355 x 500
• Capacity – 75 ltrs
• ​Outer body material - GI sheet powder coated
• Inner body material - SS 304 sheet
• Gross weight- 100 kgs
• Voltage – 220 va
• Environmental Conditions - Ambient temperature 15 to 45 deg Cel
• Ambient Pressure - Atmospheric
• Relative Humidity - 30 to 70 %
• Tank Size : Internal Dia - 400 mm , Height - 600 mm
• Basket Size :  Internal Dia   - 355 mm , Internal Height - 500 mm
• Outer Dimension - Height -  1095.45  mm, Width  -   587.76 mm , Depth  -   620  mm
•  Shipping Dimension - Height  -   1400.45 mm, Width   -   892.76 mm, Depth   -   925 mm
