Our Product / Services
Our product range contains a wide range of Process Indicator Controller and Digital Process Controller
process indicator and controller - (universal input)
4 digit single display
aux supply - 85-230vac, 50hz
input - j/k tc, pt100(rtd) 0-5vdc/0-10 vdc / 0-20ma/4-20ma selectable
output - relay-1, 24vdc transmitter supply, 4-20ma retransmission
model no.- ptc-4912
size (hxwxd)mm - 48 x 96 x 85
Additional Information:
Payment Terms : L/C, D/A, D/P, T/T
Delivery Time : 2-3 day
PROCESS CONTROLLER -
Input: 0-10V DC, 0-20mA DC, 4-20mA DC (Configurable), Output: 2 Relay, 24VDC Transmitter SupplyRange: -999 to 9999 User Selectable, DP Selectable, Correction Factor, Filter Time, Offset Setting
1) MODEL - PIC-9611A
Panel Cutout (mm) - 92 X 92
Display - Single display : 7 segment, 4 digit, 0.56", RED LED display.
2) MODEL - PIC4911A
Panel Cutout (mm) - 48 X 96
Display - Single display : 7 segment, 4 digit, 0.56", RED LED display.
INPUT - Signal input - 010 V DC / 0-20mA / 420 mA (Factory Set)
Range - 0 - 9999 (Configurable) Output (Optional) - Control Output - 24VDC Supply, 2-Relay Excitation - 24 V DC
SPECIFICATION -
Set point - 1 or 2 - Set point (Factory Set) Control Action - ON-OFF
Resoulation - 0.000 / 00.00 / 000.0 / 0000 (Configurable) Accuracy - ±1% of FSD
Power Supply - 230 V AC, ±10 %, 50 Hz (Linear Power Supply)
Indication - "OVER" - If
Input Signal is more than Maximum Input "LOW" - If Input Signal is less than Minimum Input "0000" - If there is No Input Sign
Additional Information:
Payment Terms : L/C, D/A, D/P, T/T
Delivery Time : 2-3 day
