Filtration pump: 1><2HP • Dual»speed pump (1HP»2HP): Optional • Ozone generator: 500 mg/h • Swimjet (pc): 2 • Filtration bagsSu (pc): 2 • Chemical feeding basket (pc): 2 • Underwater LED light (pc): 1 • RF waterproof remote control: Optional • Saltwater pool chlorinator: Optional • Power comsumption: 1.6kw • Dimensions (mm): 1450x760x103O

One piece blow-molded filters made in PE-HD with side or top mounted valves.
• Including pressure gauge, manual air vent and water purge.
• Maximum working pressure 2.5 bar, Test pressure 4 bar.
• Very durable and rigid structure.
• Warranty: 5 years. Model

CODE DESCRIPTION

FRL-400 BLOW MOULDED “EC3000″ DIA 400MM WITH SIDE MOUNTED VALVE 1.5”

FRL-500 BLOW MOULDED “EC3000″ DIA 500MM WITH SIDE MOUNTED VALVE 1.5”

FRL-600 BLOW MOULDED “EC3000″ DIA 600MM WITH SIDE MOUNTED VALVE 1.5”

FTS-400 BLOW MOULDED “EC3000″ DIA 400MM WITH TOP MOUNTED VALVE 1.5”

FTS-500 BLOW MOULDED “EC3000″ DIA 500MM WITH TOP MOUNTED VALVE 1.5”

FTS-600 BLOW MOULDED “EC3000″ DIA 600MM WITH TOP MOUNTED VALVE 1.5”

Bobbin-wound ber glass reinforced tank with UV-resistant surface nish
• Max operating pressure 2.5 bar, Test pressure 4 bar
• Fitted with pressure gauge, manual air and water purges
• Fitted with collector arms & diffuser made in UPVC
• Top mount lter comes with closure & screw
• Side mount lter 450, 550, 600, 700, comes with glass top cover seal clamps with buttery valve 7 nuts
• Side mount lter 800 & 900 comes with top cover made of (Abs and mix poly carbonate) & Side screw closure
• Side mount lter 1000 & 1200 comes with top cover & center clamp closure
• Fitters are equipped with a six -position mulport valve
• Warranty: 5 years Model

CODE DESCRIPTION

MU-450-VT BOBBIN FILTER “MUNICH” SERIES DIA. 450MM WITH TOP 6 WAY VALVE 1.5″ CONNECTION

MU-550-VT BOBBIN FILTER “MUNICH” SERIES DIA. 550MM WITH TOP 6 WAY VALVE 1.5″ CONNECTION

MU-650-VT BOBBIN FILTER “MUNICH” SERIES DIA. 650MM WITH TOP 6 WAY VALVE 1.5″ CONNECTION

MU-700-VT BOBBIN FILTER “MUNICH” SERIES DIA. 700MM WITH TOP 6 WAY VALVE 1.5″ CONNECTION

MU-450-VS BOBBIN FILTER “MUNICH” SERIES DIA. 450MM WITH SIDE 6 WAY VALVE 1.5″ CONNECTION

MU-550-VS BOBBIN FILTER “MUNICH” SERIES DIA. 550MM WITH SIDE 6 WAY VALVE 1.5″ CONNECTION

MU-650-VS BOBBIN FILTER “MUNICH” SERIES DIA. 650MM WITH SIDE 6 WAY VALVE 1.5″ CONNECTION

MU-700-VS BOBBIN FILTER “MUNICH” SERIES DIA. 700MM WITH SIDE 6 WAY VALVE 1.5″ CONNECTION

MU-800-VS BOBBIN FILTER “MUNICH” SERIES DIA. 800MM WITH SIDE 6 WAY VALVE 2″ CONNECTION

MU-900-VS BOBBIN FILTER “MUNICH” SERIES DIA. 900MM WITH SIDE 6 WAY VALVE 2″ CONNECTION

MU-1000-VS BOBBIN FILTER “MUNICH” SERIES DIA. 1000MM 2.5″ CONNECTION WITHOUT VALVE

MU-1200-VS BOBBIN FILTER “MUNICH” SERIES DIA. 1200MM 3″ CONNECTION WITHOUT VALVE

Bunker made in reinforced fiberglass with walkable lid mad in 2 pieces with hinges and gas piston on lid opening side.
Bunker pre-assembled with sand filter, selector valve, circulation pump, fittings and ball valves for every suction or injection line, fittings for external connection to the pipe, electric control box and transformer.
The design characteristics of the bunker are unique on the market, as they enable you to carry out routine maintenance operation, like filter or pump cleaning, without entering the bunker.Model

CODE DESCRIPTION

107100529DI PACKAGE 1 PRE ASSEMBELED UNDERGROUND PUMP ROOM FOR POOLS UP TO 6M3/HR

107100530DI PACKAGE 2 PRE ASSEMBELED UNDERGROUND PUMP ROOM FOR POOLS UP TO 10M3/HR

107100560DI PACKAGE 3 PRE ASSEMBELED UNDERGROUND PUMP ROOM FOR POOLS UP TO 14M3/HR

107100527DI PACKAGE 4 PRE ASSEMBELED UNDERGROUND PUMP ROOM FOR POOLS UP TO 22M3/HR

107100578DI PACKAGE 5 PRE ASSEMBELED UNDERGROUND PUMP ROOM FOR POOLS UP TO 30M3/HR

Big One is a unique polypropylene housing for professional applications where high performances and reliable products are needed.
Designed to treat high quantity of water, its a two-pieces compact container, that can fit 23 and 40 filtering elements.
The housing is made with 3 female In-Out threading without brass inserts, and its equipped with, plastic drain plug and plastic relief valve.
Big One is provided with a stainless steel clamp that enable to open and close (easily and quickly) the housing during maintenance operations.
Max. working pressure: 6 bar.
Burst pressure: 20 bar.
Max. working temperature: 40 C.
Capacity (empty) at 2 bar: 60m/h.
Filtration grade: 40 micron
5 years warrantyModel

CODE DESCRIPTION

A1150110 CARTRIDGE FILTER BIG ONE POLYPROPYLENE 23

A1150120 CARTRIDGE FILTER BIG ONE POLYPROPYLENE 40

A4088010 CARTRIDGE 23 FON PL3M BIG ONE

A4088020 CARTRIDGE 23 FON PL20M BIG ONE

A4088030 CARTRIDGE 23 FON PL50M BIG ONE

A4088040 CARTRIDGE 40 FON PL3M BIG ONE

A4088050 CARTRIDGE 40 FON PL20M BIG ONE

A4088060 CARTRIDGE 40 FON PL50M BIG ONE

An exclusive and unique design built with state of the art technology, fully injected 100% food grade Polypropylene guaranteeing maximum reliability and performance. The Aquarius range sand filters have been designed and manufactured using only first grade raw materials.
100% polypropylene, ball-shaped body with micro-hole pipe distribution. Supporting base of the double-ring filter to en- sure stability.
Polished and glazed wedges finish
Filtration system with a 6 way top selector valve assembled on a base with pump and prefilter.
Draining micro-hole pipe distribution
Max. working pressure: 2.5 bar, Test pressure 4 bar.
Connection filter-valve with clamping collars.
3/4 filter discharge
Standard: UNI 10637:2006 regulation for TYPE D categories
Warranty: 5 years.Model

CODE DESCRIPTION

100100977 FILTRATION SYSTEM AQUARIUS TOP VALVE DN 50 FLOW 6 M/H

100100978 FILTRATION SYSTEM AQUARIUS TOP VALVE DN 50 FLOW 10 M/H

100100979 FILTRATION SYSTEM AQUARIUS TOP VALVE DN 50 FLOW 14 M/H

Sand filter with 6 way selector side valve.
Totally injection molded in polypropylene.
Polypropylene spherical body; distribution with micro-hole pipe, anti-slip features with nozzles to ease the maintenance opera-tins.
Automatic air bleed with upper filter base for double-ring filter to guarantee stability lid with pressure gauge seat and manual air bleed.
Seal is guaranteed by clamps with butterfly valves and nut maintenance does not require tools.
Polished and glazed wedges finish
Draining micro-hole pipe distribution
Working pressure max. 2.5 bar, Test pressure 4 bar.
Lateral side connectors 50 mm (for 1 valve) and 63 mm (for 2 valve).
3/4 filter discharge
Standard: UNI 10637:2006 regulation for TYPE D categories
Warranty: 5 years.Model

CODE DESCRIPTION

100100913 INJECTED SAND FILTERS AQUARIUS SIDE VALVE DIA 450MM WITH SIDE 6 WAY VALVE 1.5

100100902 INJECTED SAND FILTERS AQUARIUS SIDE VALVE DIA 530MM WITH SIDE 6 WAY VALVE 1.5

100100904 INJECTED SAND FILTERS AQUARIUS SIDE VALVE DIA 620MM WITH SIDE 6 WAY VALVE 1.5

100100906 INJECTED SAND FILTERS AQUARIUS SIDE VALVE DIA 790MM WITH SIDE 6 WAY VALVE 2

Sand filter with 6 way selector top valve.
Totally injection molded in polypropylene.
100% polypropylene, ball-shaped body with micro-hole pipe distribution. Supporting base of the double-ring filter to ensure stability.
Polished and glazed wedges finish
Draining micro-hole pipe distribution
Working pressure max. 2.5 bar, Test pressure 4 bar.
Connection filter-valve with clamping collars.
Lateral side connectors 50 mm (for 1 valve).
3/4 filter discharge
Constant re-productivity.
Standard: UNI 10637:2006 regulation for TYPE D categories
Warranty: 5 years.Model

CODE DESCRIPTION

100100968 INJECTED SAND FILTERS AQUARIUS TOP VALVE DIA 450MM WITH TOP 6 WAY VALVE 1.5

100100971 INJECTED SAND FILTERS AQUARIUS TOP VALVE DIA 530MM WITH TOP 6 WAY VALVE 1.5

100100974 INJECTED SAND FILTERS AQUARIUS TOP VALVE DIA 620MM WITH TOP 6 WAY VALVE 1.5

6-way selector valve for filtering, washing, rinsing, recirculating, emptying and
closing operations.
Made of premium, UV resistant, impact resisting ABS material.
Manufactured with extremely long-lasting sealing materials & pressure springs,
which are mounted at the valve plateModel

CODE DESCRIPTION

SV-15 SIX-WAY SELECTOR VALVE 1.5 SIDE MOUNT

SV-20 SIX-WAY SELECTOR VALVE 2 SIDE MOUNT

SV-25 SIX-WAY SELECTOR VALVE 2.5 SIDE MOUNT

SV-30 SIX-WAY SELECTOR VALVE 3 SIDE MOUNT

TV-15 AQUARIS SIX-WAY SELECTOR VALVE 1.5 TOP MOUNT

TV-15 MUNICH SIX-WAY SELECTOR VALVE 1.5 TOP MOUNT

TV-15 EC-3000 SIX-WAY SELECTOR VALVE 1.5 TOP MOUNT

TV-15 OCEAN SIX-WAY SELECTOR VALVE 1.5 TOP MOUNT

Bobbin wound ber glass reinforcement with polyester resin
Mult-construcon layers: non-corrosive and chemical protective
UV resistance, suitable for operation under prolong sunlight
Available in laterals or nozzles plate system for air scouring capabilities
Optional accessories includes sight glass, manhole, and air purge
Deign ltration velocity maximum: 50m3/h/m2
Max operating pressure 2.5 / 4 bar, test pressure 4/6 bar
Manifold & valves not included
Warranty: 5 yearsModel

CODE DESCRIPTION

FB-1200-2.5-LAT BOBBINED FILTERS DIA.1200MM, FILTERATION RATE 55M3/H/M2 CONNECTION 90MM, WORK PRESSURE 2.5KG/CM2

FB-1400-2.5-LAT BOBBINED FILTERS DIA.1400MM, FILTERATION RATE 77M3/H/M2 CONNECTION 100MM, WORK PRESSURE 2.5KG/CM2

FB-1600-2.5-LAT BOBBINED FILTERS DIA.1600MM, FILTERATION RATE 102M3/H/M2 CONNECTION 125MM, WORK PRESSURE 2.5KG/CM2

FB-1800-2.5-LAT BOBBINED FILTERS DIA.1800MM, FILTERATION RATE 125M3/H/M2 CONNECTION 140MM, WORK PRESSURE 2.5KG/CM2

FB-2000-2.5-LAT BOBBINED FILTERS DIA.2000MM, FILTERATION RATE 147M3/H/M2 CONNECTION 160MM, WORK PRESSURE 2.5KG/CM2

FB-2200-2.5-LAT BOBBINED FILTERS DIA.2200MM, FILTERATION RATE 190M3/H/M2 CONNECTION 200MM, WORK PRESSURE 2.5KG/CM2

FB-2500-2.5-LAT BOBBINED FILTERS DIA.2500MM, FILTERATION RATE 240M3/H/M2 CONNECTION 225MM, WORK PRESSURE 2.5KG/CM2

FB-1200-4-LAT BOBBINED FILTERS DIA.1200MM, FILTERATION RATE 55M3/H/M2 CONNECTION 90MM, WORK PRESSURE 4KG/CM2

FB-1400-4-LAT BOBBINED FILTERS DIA.1400MM, FILTERATION RATE 77M3/H/M2 CONNECTION 100MM, WORK PRESSURE 4KG/CM2

FB-1600-4-LAT BOBBINED FILTERS DIA.1600MM, FILTERATION RATE 102M3/H/M2 CONNECTION 125MM, WORK PRESSURE 4KG/CM2

FB-1800-4-LAT BOBBINED FILTERS DIA.1800MM, FILTERATION RATE 125M3/H/M2 CONNECTION 140MM, WORK PRESSURE 4KG/CM2

FB-2000-4-LAT BOBBINED FILTERS DIA.2000MM, FILTERATION RATE 147M3/H/M2 CONNECTION 160MM, WORK PRESSURE 4KG/CM2

FB-2200-4-LAT BOBBINED FILTERS DIA.2200MM, FILTERATION RATE 190M3/H/M2 CONNECTION 200MM, WORK PRESSURE 4KG/CM2

FB-2500-4-LAT BOBBINED FILTERS DIA.2500MM, FILTERATION RATE 240M3/H/M2 CONNECTION 225MM, WORK PRESSURE 4KG/CM2

FB-1200-2.5-NOZ BOBBINED FILTERS DIA.1200MM, FILTERATION RATE 55M3/H/M2 CONNECTION 90MM, WORK PRESSURE 2.5KG/CM2

FB-1400-2.5-NOZ BOBBINED FILTERS DIA.1400MM, FILTERATION RATE 77M3/H/M2 CONNECTION 100MM, WORK PRESSURE 2.5KG/CM2

FB-1600-2.5-NOZ BOBBINED FILTERS DIA.1600MM, FILTERATION RATE 102M3/H/M2 CONNECTION 125MM, WORK PRESSURE 2.5KG/CM2

FB-1800-2.5-NOZ BOBBINED FILTERS DIA.1800MM, FILTERATION RATE 125M3/H/M2 CONNECTION 140MM, WORK PRESSURE 2.5KG/CM2

FB-2000-2.5-NOZ BOBBINED FILTERS DIA.2000MM, FILTERATION RATE 147M3/H/M2 CONNECTION 160MM, WORK PRESSURE 2.5KG/CM2

FB-2200-2.5-NOZ BOBBINED FILTERS DIA.2200MM, FILTERATION RATE 190M3/H/M2 CONNECTION 200MM, WORK PRESSURE 2.5KG/CM2

FB-2500-2.5-NOZ BOBBINED FILTERS DIA.2500MM, FILTERATION RATE 240M3/H/M2 CONNECTION 225MM, WORK PRESSURE 2.5KG/CM2

FB-1200-4-NOZ BOBBINED FILTERS DIA.1200MM, FILTERATION RATE 55M3/H/M2 CONNECTION 90MM, WORK PRESSURE 4KG/CM2

FB-1400-4-NOZ BOBBINED FILTERS DIA.1400MM, FILTERATION RATE 77M3/H/M2 CONNECTION 100MM, WORK PRESSURE 4KG/CM2

FB-1600-4-NOZ BOBBINED FILTERS DIA.1600MM, FILTERATION RATE 102M3/H/M2 CONNECTION 125MM, WORK PRESSURE 4KG/CM2

FB-1800-4-NOZ BOBBINED FILTERS DIA.1800MM, FILTERATION RATE 125M3/H/M2 CONNECTION 140MM, WORK PRESSURE 4KG/CM2

FB-2000-4-NOZ BOBBINED FILTERS DIA.2000MM, FILTERATION RATE 147M3/H/M2 CONNECTION 160MM, WORK PRESSURE 4KG/CM2

FB-2200-4-NOZ BOBBINED FILTERS DIA.2200MM, FILTERATION RATE 190M3/H/M2 CONNECTION 200MM, WORK PRESSURE 4KG/CM2

FB-2500-4-NOZ BOBBINED FILTERS DIA.2500MM, FILTERATION RATE 240M3/H/M2 CONNECTION 225MM, WORK PRESSURE 4KG/CM2

FBH-1200-2.5-LAT BOBBINED FILTERS DIA.1200MM, FILTERATION RATE 45M3/H/M2 CONNECTION 90MM, WORK PRESSURE 2.5KG/CM2

FBH-1400-2.5-LAT BOBBINED FILTERS DIA.1400MM, FILTERATION RATE 61M3/H/M2 CONNECTION 100MM, WORK PRESSURE 2.5KG/CM2

FBH-1600-2.5-LAT BOBBINED FILTERS DIA.1600MM, FILTERATION RATE 80M3/H/M2 CONNECTION 125MM, WORK PRESSURE 2.5KG/CM2

FBH-1800-2.5-LAT BOBBINED FILTERS DIA.1800MM, FILTERATION RATE 101M3/H/M2 CONNECTION 140MM, WORK PRESSURE 2.5KG/CM2

FBH-2000-2.5-LAT BOBBINED FILTERS DIA.2000MM, FILTERATION RATE 125M3/H/M2 CONNECTION 160MM, WORK PRESSURE 2.5KG/CM2

FBH-2300-2.5-LAT BOBBINED FILTERS DIA.2200MM, FILTERATION RATE 175M3/H/M2 CONNECTION 200MM, WORK PRESSURE 2.5KG/CM2

FBH-2500-2.5-LAT BOBBINED FILTERS DIA.2500MM, FILTERATION RATE 2000M3/H/M2 CONNECTION 225MM, WORK PRESSURE 2.5KG/CM2

FBH-1200-4-LAT BOBBINED FILTERS DIA.1200MM, FILTERATION RATE 45M3/H/M2 CONNECTION 90MM, WORK PRESSURE 4KG/CM2

FBH-1400-4-LAT BOBBINED FILTERS DIA.1400MM, FILTERATION RATE 61M3/H/M2 CONNECTION 100MM, WORK PRESSURE 4KG/CM2

FBH-1600-4-LAT BOBBINED FILTERS DIA.1600MM, FILTERATION RATE 80M3/H/M2 CONNECTION 125MM, WORK PRESSURE 4KG/CM2

FBH-1800-4-LAT BOBBINED FILTERS DIA.1800MM, FILTERATION RATE 101M3/H/M2 CONNECTION 140MM, WORK PRESSURE 4KG/CM2

FBH-2000-4-LAT BOBBINED FILTERS DIA.2000MM, FILTERATION RATE 125M3/H/M2 CONNECTION 160MM, WORK PRESSURE 4KG/CM2

FBH-2300-4-LAT BOBBINED FILTERS DIA.2200MM, FILTERATION RATE 175M3/H/M2 CONNECTION 200MM, WORK PRESSURE 4KG/CM2

FBH-2500-4-LAT BOBBINED FILTERS DIA.2500MM, FILTERATION RATE 200M3/H/M2 CONNECTION 225MM, WORK PRESSURE 4KG/CM2

FBH-1200-2.5-NOZ BOBBINED FILTERS DIA.1200MM, FILTERATION RATE 45M3/H/M2 CONNECTION 90MM, WORK PRESSURE 2.5KG/CM2

FBH-1400-2.5-NOZ BOBBINED FILTERS DIA.1400MM, FILTERATION RATE 61M3/H/M2 CONNECTION 100MM, WORK PRESSURE 2.5KG/CM2

FBH-1600-2.5-NOZ BOBBINED FILTERS DIA.1600MM, FILTERATION RATE 80M3/H/M2 CONNECTION 125MM, WORK PRESSURE 2.5KG/CM2

FBH-1800-2.5-NOZ BOBBINED FILTERS DIA.1800MM, FILTERATION RATE 101M3/H/M2 CONNECTION 140MM, WORK PRESSURE 2.5KG/CM2

FBH-2000-2.5-NOZ BOBBINED FILTERS DIA.2000MM, FILTERATION RATE 125M3/H/M2 CONNECTION 160MM, WORK PRESSURE 2.5KG/CM2

FBH-2300-2.5-NOZ BOBBINED FILTERS DIA.2200MM, FILTERATION RATE 175M3/H/M2 CONNECTION 200MM, WORK PRESSURE 2.5KG/CM2

FBH-2500-2.5-NOZ BOBBINED FILTERS DIA.2500MM, FILTERATION RATE 2000M3/H/M2 CONNECTION 225MM, WORK PRESSURE 2.5KG/CM2

FBH-1200-4-NOZ BOBBINED FILTERS DIA.1200MM, FILTERATION RATE 45M3/H/M2 CONNECTION 90MM, WORK PRESSURE 4KG/CM2

FBH-1400-4-NOZ BOBBINED FILTERS DIA.1400MM, FILTERATION RATE 61M3/H/M2 CONNECTION 100MM, WORK PRESSURE 4KG/CM2

FBH-1600-4-NOZ BOBBINED FILTERS DIA.1600MM, FILTERATION RATE 80M3/H/M2 CONNECTION 125MM, WORK PRESSURE 4KG/CM2

FBH-1800-4-NOZ BOBBINED FILTERS DIA.1800MM, FILTERATION RATE 101M3/H/M2 CONNECTION 140MM, WORK PRESSURE 4KG/CM2

FBH-2000-4-NOZ BOBBINED FILTERS DIA.2000MM, FILTERATION RATE 125M3/H/M2 CONNECTION 160MM, WORK PRESSURE 4KG/CM2

FBH-2300-4-NOZ

cl-100f in-line: with direct pipe connections of 1.5 inside and 2 outside
cl-120f off-line: for bypass connections via flexible tubing, with fittings.
cl-200f in-line: with direct connections of 1.5 inside and 2 outside.
cl-220f off-line: for by-pass connections via flexible tubing, with fittings.model

code description

cl-100f chlorine feeder in line loading capacity 1.8kgs

cl-120f chlorine feeder off line loading capacity 1.8kgs

cl-200f chlorine feeder in line loading capacity 4.5kgs

cl-220f chlorine feeder off line loading capacity 4.5kgs

complete panel with proportional control of ph & free chlorine for swimming pool up to 500 m comprises:
1 aquapool pump ph-clj pvdf-ptfe-vt.
modular probe holder with pre-filter, water check valve and flow sensor.
ph and cl electrodes (adelclj25) & ph buffer solutions.
2 low level switches.standards

no. 2004/108/ce emc directive
no. 2006/95/ce dbt low voltage directive
no. 2011/65/ue , 2002/96/ce rohs and weee directivesmodel

code description

adps300 a-pool system ph-clj pvdf-ptfe-vt 05-05/05-05 230v

adps301 a-pool system ph-clj pvdf-ptfe-vt 10-04/10-04 230v

Complete Panel with proportional control of pH and Redox for swimming pool up to 500 m comprises:
1 AQUAPOOL pump pH-Rx PVDF-PTFE-VT.
Modular probe holder with pre-filter, water check valve and flow sensor.
PH and Redox electrodes and buffer solutions.
2 low level switches.Standards.

No. 2004/108/CE EMC directive
No. 2006/95/CE DBT low voltage directive
No. 2011/65/UE , 2002/96/CE RoHS and WEEE directives Model

CODE DESCRIPTION

ADPS100 A-POOL SYSTEM PH-RX PVDF-PTFE-VT 05-05/05-05 230V

ADPS101 A-POOL SYSTEM PH-RX PVDF-PTFE-VT 10-04/10-04 230V

Solenoid metering pump with constant flow rate, with pulses frequency regulation

Dosing adjustment by knob;Double regulation range 0-100%, 0-20% by switch;Standard power supply 230Vac 50/60Hz. Other power supplies on request;On-Off switch;Manual priming valve;Green LED to show pump switch-on, red LED to shows pump dosing pulses. Standards:

n 2004/108/CE Direttiva EMC

n 2006/95/CE DBT Low Voltage Directive

n 2011/65/UE , 2012/19/UE direttive RoHs e WEEE

no. 2004/108/CE EMC directive

no. 2006/95/CE DBT Low Voltage Directive

no. 2011/65/UE, 2012/19/UE RoHs and WEEE directives

Model

CODE DESCRIPTION

AD10001080000000 HC100 01.08 230V PP-GL-VT

AD10002070000000 HC100 02.07 230V PP-GL-VT

AD10002120000000 HC100 02.12 230V PP-GL-VT

AD10004050000000 HC100 04.05 230V PP-GL-VT

AD10005080000000 HC100 05.08 230V PP-GL-VT

INSTALLATION KIT

ADSP6000078 PE TUBE D. 46 2MT

ADSP6000546 PVC CRYSTAL TUBE D. 46 2MT

ADSP6000001 FOOT VALVE PP-VL-VT 46

ADSP6200007 INJECTION VALVE M1/2 PP-VL-VT 46

ADSP6020221 WALL BRACKET HC150-897-997-999-100

ADSP6000041 ANCHORS AND SCREWS

ACCESSORIES AND SPARE PARTS

ADTANK010 A-TANK 1 100 LITRES

ADTANK020 A-TANK 2 200 LITRES

ADTANK030 A-TANK 3 300 LITRES

ADSP60000S8A HC1/HC2/HC3/HC4 PUMP HEAD 2-15 PP-GL-VT

ADSP60000S8P HC1/HC2/HC3/HC4 PUMP HEAD 2-15 PVDF-PTFE-VT

ADSP6000136 AUTOMATIC BLEED VALVE ON HC1/HC2/HC3/HC4 PUMP HEAD 2-15 PVC-CE-VT

Context of use:For private pools, to dose the acid/alkaline corrector with the built-in pH reading tool.

Description:Electromagnetic pump with built-in pH tool for a proportional dosing of acid/alkaline products, with installation kit and equipment.Dosing mode selectable in constant or proportional mode.Renforced PP housing, suitable for aggressive working enviroments;Input: level probe, inhibit, standby, flow sensor, injection;Output: alarm or dosing relay;Statistics;Password;Language and Unit measure selectable;Calibration flow-rate;Simplified setting by user menu;Alphanumeric display, 2 lines 16 characters, to simplify pump managing, during the working mode and during the programmation;Power supply 230 Vac. Upon request: 110V;IP65 protection degree;Wall mounting bracket supplied in installation kit;Manual bleed valve (priming);Upon request PI-mA version available.

Working mode:Constant flow-rate On/Off mode (flow rate in %);Self-calibration of measure probe;Proportional dosing to the selected setpoint value;Selectable Alarms: Level (with reserve, early warning), Flow (flow sensor input), Strokes (max number of strokes), OFA (Over Feed Alarm), RANGE.The kit contains:Suction/injection pipe;2 pH buffer solutions to calibrate the electrode;Wall fixing bracket and dowels;Probe holder G;pH electrode;Foot filter and injection valve.

Standards:

No. 2004/108/CE EMC directiveNo. 2006/95/CE DBT low voltage directiveNo. 2011/65/UE , 2002/96/CE RoHS and WEEE directives Model

CODE DESCRIPTION

AD96200004000 PDE HC151-1 PH-RX 02-08/05-05/07-02 230V PP-GL-VT KIT PH 5M INCLUDED

AD96203004000 PDE HC151-4 PH-RX 10-04/12-02/14-00 230V PP-GL-VT KIT PH 5M INCLUDED

AD96209004000 PDE HC151-7 PH-RX 20-03/25-02/35-00 230V PP-GL-VT KIT PH 5M INCLUDED

Context of use:Constant flow rate dosing pump with pulse frequency regulation. Easy to set, with a single adjustment potentiometer and a LED. Level probe compatible

Description:Analogue electromagnetic constant flow rate dosing pumpHigh-strength PBT container, suitable for high temperatures (both places and liquids)Level probe inputDouble pulse regulation scale 0-100% or 0-20%Power supply: 220VAC 50/60HzOn-Off switchIP65 protectionAnalogue interface with one knob and a LEDManual priming valveWall or foot mounting (brackets included in the kit)

Technical features:DOUBLE REGULATION SCALE 0-100% O 0-20% precise dosing even at low flow ratesPVDF BODY PUMP high chemical compatibilityFIXING BRACKET to simplify the installationPBT CASE high mechanical resistance eco-friendly ergonomic low flammabilityBUILT-IN PIPE HOLDER safe and clean installationREMOVABLE CONNECTIONS easy maintenance of the pump

Standards:No. 2004/108/CE EMC directiveNo. 2006/95/CE DBT low voltage directiveNo. 2011/65/UE , 2002/96/CE RoHS and WEEE directives

Model

CODE DESCRIPTION

AD89000010000 HC897-1 02-08/05-05/07-02 230V PVDF-PTFE-VT

AD89001010000 HC897-2 07-04/08-02/10-00 230V PVDF-PTFE-VT

AD89002010000 HC897-3 03-12/04-10/05-08 230V PVDF-PTFE-VT

AD89003010000 HC897-4 10-04/12-02/14-00 230V PVDF-PTFE-VT

AD89007010000 HC897-5 02-20/2, 5-18/03-15 230V PVDF-PTFE-VT

Model

CODE DESCRIPTION

ADSP6020221 WALL BRACKET HC150-897-997-999-100

ADSP6020156 WALL FIXING BRACKET

ADBAS100 FOOT BRACKET HC150-797-897-997-999-100

ADSTF200 A-STF2

ADSP6000078 PE TUBE D. 46 2MT

ADSP6000370 PE TUBE D. 68

ADSP6000016 POLYETHYLENE HOSE 10X14 (50 m rolls)

ADSP6000546 PVC CRYSTAL TUBE D. 46 2MT

ADSP6000440 PVC CLEAR HOSE 10X14 (100 m rolls)

ADSP6000028 FOOT VALVE PVDF-PTFE-VT 46

ADSP6200031 BALL INJECTION VALVE 1/2 PVDF-PTFE-VT 4X6

ADSP6200040 BALL INJECTION VALVE 1/2 GAS HC999 MOD.3 PVDF-PTFE-DT

ADSP6000001 FOOT VALVE PP-VL-VT 46

ADSP6000774 FOOT VALVE PVC-GL-VT 1014

ADSP6200007 INJECTION VALVE M1/2 PP-VL-VT 46

ADSP6200018 INJECTION VALVE 1/2 68 PP-GL-VT

ADSP6000051 INJECTION VALVE 1/2 PVC-GL-VT 30-50 L

ADCAN3 A-CAN PVC GF1/2 WITH DOUBLE THREAD GM3/8-GM1/2

ADSP6000041 ANCHORS AND SCREWS

ADSLG1 LEVEL PROBE SWITCH w/2 m cable + BRACKET A-SL without CONNECTOR

ADSLG LEVEL PROBE SWITCH w/2 m cable + BRACKET A-SL

ADSLG4 LEVEL PROBE SWITCH w/2 m cable + BRACKET A-SL

AG-MAN

Manual mixer with PVC shaft.

A-SUPP

PVC support to install dosing pumps and mixers.

ADBASFoot fixing bracket.

AG-F

Fast water mixers.Fast speed three-phase AG3-PVC/AG3-AISI 1400 rpm Motor 230/380 V 50 Htz 0.12HP;Fast speed three-phase AG3-PVC/AG3-AISI 1400 rpm Motor 230/380 V 50 Htz 0.12HP.

AG-S

Slow water mixers.Slow single-phase AG1-PVC /AG1-AISI 70 rpm Motor 230V 50Hz 0.12HPSlow speed three-phase AG3-PVC/AG3-AISI 70 rpm Motor 230/380v -50 Htz 0.12HP.

Model

CODE DESCRIPTION

ADAGMP06 AG-MAN-PVC60

ADAGMP07 AG-MAN-PVC70

ADAGMP09 AG-MAN-PVC90

ADSUPP010 A-SUPP A-TANK 1

ADSUPP020 A-SUPP A-TANK 2

ADSUPP030 A-SUPP A-TANK 3

ADSUPP050 A-SUPP A-TANK 5

ADSUPP100 A-SUPP A-TANK 10

ADBAS100 FOOT BRACKET HC150-797-897-997-999-100

ADAG1P06F AG1-PVC60/F

ADAG1P07F AG1-PVC70/F

ADAG1P08F AG1-PVC80/F

ADAG1P09F AG1-PVC90/F

ADAG1A06F AG1-AISI60/F

ADAG1A07F AG1-AISI70/F

ADAG1A08F AG1-AISI80/F

ADAG1A09F AG1-AISI90/F

ADAG3P06F AG3-PVC60/F

ADAG3P07F AG3-PVC70/F

ADAG3P08F AG3-PVC80/F

ADAG3P09F AG3-PVC90/F

ADAG3A06F AG3-AISI60/F

ADAG3A07F AG3-AISI70/F

ADAG3A08F AG3-AISI80/F

ADAG3A09F AG3-AISI90/F

ADAG1P06S AG1-PVC60/S

ADAG1P07S AG1-PVC70/S

ADAG1P08S AG1-PVC80/S

ADAG1P09S AG1-PVC90/S

ADAG1A06S AG1-AISI60/S

ADAG1A07S AG1-AISI70/S

ADAG1A08S AG1-AISI80/S

ADAG1A09S AG1-AISI90/S

ADAG3P06S AG3-PVC60/S

ADAG3P07S AG3-PVC70/S

ADAG3P08S AG3-PVC80/S

ADAG3P09S AG3-PVC90/S

ADAG3A06S AG3-AISI60/S

ADAG3A07S AG3-AISI70/S

ADAG3A08S AG3-AISI80/S

ADAG3A09S AG3-AISI90/S

Pre-assembled skid, composed by chemical tank, dosing pump, support, suction lance, mixer (automatic or manual). To be specified during order

Model

CODE DESCRIPTION

ADSTS100 PT100 PROBE PVC BODY AISI ELECTRODE MG 1/2ADSTS100NC PT100 PROBE PVC BODY DN 12 probe holderADSP4000622 ADAPTATOR M3/4-F1/2ADSP5007205 O-RING FOR ADAPTATORADSP3600004 MODULAR PROBE HOLDER FILTER-FLOW SENSOR CAPADSP3600005 MODULAR PROBE HOLDER ELECTRODE D12(3)ADSP3600010 MODULAR PROBE HOLDER A-JADSP3600009 MODULAR PROBE HOLDER ELECTRODE PG13, 5A803R050 430 MICRON REPLACEMENT FILTER CARTRIDGEADPSM097 MODULAR PROBE HOLDER 10X14 1MOD FILTER(0)-ELECTRODEd12(9)-GF1/2(7)ADPSM01233 MODULAR PROBE HOLDER 10X14 3MOD FILTER(0)-FLOW(1)-PLUG(2)-2XELECTRODEd12(9)ADPSM0126 MODULAR PROBE HOLDER 10X14 2MOD FILTER(0)-FLOW(1)-PLUG(2)-1xA-JADPSTC DN50-60 COLLAR PROBE HOLDER WITH INJECTION 4X6 CONNECTION

model

code description

adeltph01 a-ph 1adeltph05 a-ph 5adeltph10 a- ph 10adeltrx01 a-rx 1adeltrx05 a-rx 5adeltrx10 a-rx 10adeltrx05g a-rx 5 goldadelvph a-vphadelvrx a-vrxadelpph a-pphadelprx a-prxadcv01 a-cv 1adcv02 a-cv 2, 5adcv05 a-cv 5adcv10 a-cv 10adcv15 a-cv 15adcv20 a-cv 20adcg2 chlorine cella a-cg2 0-5 ppmadcg5f chlorine cella a-cg5 0-5 ppm prox. switch filteradcg6f chlorine cella a-cg6 0-5 ppm prox. switch filter-probe holderadsp4000620 replacement kit for pt-cu electrodeadsp6500009 balls replacement kitadelclj05 a-j electrode free chlorine inorganics fluid o-5 ppmadelclj22 a-j electrode free chlorine inorganics fluid 0-2 ppmadelclj25 a-j electrode free chlorine organics fluid 0-5 ppm reading inf. phadelclj25s a-j electrode free chlorine organics fluid 0-5 ppm reading inf. ph salt wateradelclj35 a-j electrode total chlorine 0-5 ppm reading inf. phadeldcj10 a-j electrode chlorine dioxide 0-5 ppm readingadelozj10 a-j electrode ozone 0-5 ppm readingadelpxj02 a-j electrode hydrogen peroxide 0-200 ppm readingadelpaj02 a-j electrode per-acetic acid 0-200 ppm readingadsp6020051 a-j connection cableadelcljcc1 electrolytic solution ecc1 a-j probe adelclj25/220 probeadelcljcc1s electrolytic solution ecc1s a-j probe salt water adelclj25sadelcljm482 ion-selective membrane m.48, 2 a-j probe adelclj25/220/25s probeadsph4 a-sph4adsph7 a-sph7adsph9 a-sph9adsrx a-srx 475 mvadsts100 pt100 probe pvc body aisi electrode mg 1/2adsts100nc pt100 probe pvc body dn 12 probe holderadsp4000622 adaptator m3/4-f1/2adsp5007205 o-ring for adaptator

abs mini dichro underwater light

u/w lights for polyester/liner pool or spa, made of uv resistant white abs.easily disassembled, using the outer side of the frame as a key when the lamp needs replacement.ip 68 protection rate.

model

code description

e-112 u/w halogen light with niche & cable 50w 12v ac lumen 600

e-112-l uwl helogen light with niche & cable for liner50w 12v ac lumen 600

ssrim02 stainless steel aisi 316 l v4a rim lumen 600

e-113 u/w halogen light threaded type with cable 50w 12v ac lumen 600

e-113-l u/w halogen light threaded type with cable for liner 50w 12v ac

ssrim01 stainless steel aisi 316l v4a rim

abs led flat light

made of super bright led with high quality
acid-proof, alkali-proof and uv resistant
the lamp is filled with epoxy inside which makes it 100% waterproof
unique technique of resin lling, with waterproof level p68
constant color and brightness with protection of over electricity and electric surge
low power consumption, high stability
long working life up to 60, 000hours
easy to install, suitable for concrete or liner structure (installation kit not included)

model

code description

e-107-252-w resined water proof abs under waterflat light 12 v ac lumen 2100, color white, 21watt

e-107-252-ww resined water proof abs under waterflat light 12 v ac lumen 2100, color warmwhite, 21watt

e-107-252-rgb resined water proof abs under waterflat light 12 v ac lumen 2100, color rgb, 21watt

rc-01 controller and remote controller (12v ac input output 30a 360watt)

rc-03b controller and remote controller (220-240v ac input output 220-240v ac)

e-107kit kit for liner pools

ABS UNDER WATER LIGHT

Made of top quality ABS materials with UV resistant additives.The fixing of the front part is with stainless steel claws for a stronger grip and longer life.Niche with back thread of 3/4, with an optional marked hole for rear connection.Supplied with a very soft & water tight cable of 2.5 meters of length.Supplied with a water tight gland and a corrugated tube of 1 meter.Available with color options.With brass inserts or self-threading.Sandwich seals for panel pools.CE certified.IP68 protection.

Model

CODE DESCRIPTION

E-101 ABS UNDERWATER LIGHT ROUND CONCRETE 300W 12V WEIGHT 2.70

E-105 ABS UNDERWATER LIGHT ROUND LINER 300W 12V WEIGHT 2.70

SSRIM03 STAINLESS STEEL AISI 316 V4ARIM WEIGHT0.60

aqua abs luxe underwater lights

abs light par56 suitable for both liner and concrete poolssupplied with 12v ac lamp (standard 300w and led are available).kit also contains: light body, light box with connector, power derivation box cei approved with connector, flexible hose protector.2.5mt panel installation without sandwich gasket.installation kit for the desired kind of structure (liner, concrete).ip 68 protection rate.model

code description

200300002 aqua abs underwater lights par56 under water halogen light 300w-12v complete with abs connection box lux and flexible connection cablet concrete

200300001 aqua abs underwater lights par56 under water halogen light 300w-12v complete with abs connection box lux and flexible connection cable liner

ssrim04 stainless steel aisi 316l v4a rim for aqua abs underwater lights

IP64 Complete waterproof transformer with cables for fast wiring.Its high quality guarantees its very long life under heavy duty conditions.Input 230v-240v, Output 12, 14 and 16v. 50/60 HZ.Specially recommended for humid areas and where water is close.Manufactured under European norms, CE certified.

Model

CODE DESCRIPTION

E-245 150W CASCADE TRANSFORMERS IP64 12, 14 AND 16V 50/60 HZ

E-246 300W CASCADE TRANSFORMERS IP64 12, 14 AND 16V 50/60 HZ

E-247 400W CASCADE TRANSFORMERS IP64 12, 14 AND 16V 50/60 HZ

E-248 600W CASCADE TRANSFORMERS IP64 12, 14 AND 16V 50/60 HZ

underwater led bulbs & remote par 56 dc

completey in water proof 316 stainless steel lamp body shell.with stainless steel 316 heat diffusing ring

model

code description

e-120-252-w ss case par56 bulb under water light white color lumen 1400 18w voltage 12 v dc

e-124-252-ww ss case par56 bulb under water light warmwhite color lumen 1400 18w voltage 12 v dc

e-124-252-rgb ss case par56 bulb under water light rgb color lumen600 18w voltage 12 v dc

e-124-333-w ss case par56 bulb under water light white color lumen 1800 24w voltage 12 v dc

e-124-333-ww ss case par56 bulb under water light warm white color lumen 1800 24w voltage 12 v dc

e-124-333-rgb ss case par56 bulb under water light rgb color lumen 820 24w voltage 12 v dc

e-126-441-w ss case par56 bulb under water light white color lumen 2200 35w voltage 12 v dc

e-126-441-ww ss case par56 bulb under water light warm white color lumen 2200 35w voltage 12 v dc

e-126-441-rgb ss case par56 bulb under water light rgb color lumen 1022 35w voltage 12 v dc

rc-03 controller and remote controller (220v dc input-output 11.66a 140 watt)

rc-04 amplifier 140 watt

abs floor nozzle with radial emission nozzle made in abs with fitting 63 and 50.complete with gasket, fixing flange at 5 screw in inox 316 and cover flange.flow rate: 13.49m/h at speed 4m/sec.in accordance with legislation uni 13451.

model

code description

200200028f abs radial floor inlet 2m thread for concrete pools flow rate 13.49m3/hr

200200027f abs radial floor inlet 2m thread for liner pools flow rate 13.49m3/hr

High quality vacuum point made in ABSResistance in corrosion and ultra-violetANSP / APSP -1602011 standard

Model

CODE DESCRIPTION

F-203 ABS VACUUM POINT THREADED FOR CONCRETE POOLS FLOW RATE 9 M3/HR

F-204 ABS VACUUM POINT THREADED FOR LINER POOLS FLOW RATE 13.02 M3/HR

ABS wall conduit with site for collection nozzle.

Model

CODE DESCRIPTION

200200686 ABS WALL CONDUIT L250MM 21/2F 11/2F

200200685 ABS WALL CONDUIT L300MM 21/2F 11/2F

F-250 ABS WALL CONDUIT L300MM

High quality main drain made in ABS with anti-vortex gridResistance in corrosion and ultra-violetANSP / APSP -1602011 standard

Model

CODE DESCRIPTION

F-198 ABS WALL RETURN GUTTER DRAIN FOR CONCRETE POOLS FLOW RATE 9M3/HR

injection nozzle designed for high flow rate.the innovative design, an inward embrasure form with directional fins improve the distribution of flow and adjustable fins improve the flow distribution.the outer-clamping ring nut also has a embrasure and conical form, that allows to distribute extending the flow distribution effect creating a twirled conical effect of the flow right form the very beginning of the waters emissions 5 socket insert.screw in inox 316 for mod. liner, in additional elegant flange cover.flow rate: 13.49m/h at speed 4m/secin accordance with legislation uni 13451.

overflow channel drain and vacuum point

model

code description

200200017f abs directional wall inlet 2 m thread for concrete pools flow rate 13.49m3/hr

200200048f abs directional wall inlet 2 m thread for liner pools flow rate 13.49m3/hr

or all kind of main drains the following points need to be taken under consideration:water flow velocity 0.5m/sec.maximum suction velocity 1.5m/sec.minimum distance between drains is more than 2 meters.recommended to use a special device to deduct the vacuum and automatically switch off the pump.main drain in

aqua round main drain

main drain made in abs and anti-vortex grid.in accordance with legislation uni for public use and uni 13451.lateral fitting d.63f or lower d.50.large diameter (195mm) for accomodate a submersible pump and reduced height (140mm) for floor slot.sucket insert and screw s.s 316 for mod. liner.square frame with adjustable loops for concrete.

model

code description

200200037 abs heavy duty main drain round for liner flow rate 29.72m3/hr

High quality main drain made in ABS with anti-vortex gridResistance in corrosion and ultra-violetANSP/APSP -1602011 standard

Model

CODE DESCRIPTION

F-137 ABS ROUND MAIN DRAIN COVER CONCRETE FLOW RATE -33.48 M/H

For all kind of main drains the following points need to be taken under consideration:Water flow velocity 0.5m/sec.Maximum suction velocity 1.5m/sec.Minimum distance between drains is more than 2 meters.Recommended to use a special device to deduct the vacuum and automatically switch off the pump.

AQUA SQUARE MAIN DRAIN

Main drain made in ABS and anti-vortex grid.In accordance with legislation UNI for public use and UNI 13451.Lateral fitting D.63F or lower D.50.Large diameter (195mm) for accomodate a submersible pump and reduced height(140mm) for floor slot.Sucket insert and screw S.S 316 for mod. Liner.Square frame with adjustable loops for the mod. concrete.

Model

CODE DESCRIPTION

200200038 AQUA ABS SQUARE HEAVY DUTY MAIN DRAIN FOR CONCRETE FLOW RATE 28.11M3/HR

high quality main drain made in abs with anti-vortex gridresistance in corrosion and ultra-violetexternal dimension 303 x 303 h 32mm, abs gri 276 x 276 mmansp/apsp -1602011 standard

model

code description

f-152 abs square main drain cover- flow rate 51 m/h

abs skimmer with flared mouth moulded in one-piece without welds.overflow line of clamp more advanced compared to traditional skimmer to increase the rapid and efficient suction.supplied complete with square frame special lid with anti-removal system.fittings d.50 63 -75 with shutter flap overflow system d.50.pp basket, anti-noise clamp thread for pressure test, socket insert, screw in s.s. 316 for mod. liner, in additional elegant flange cover.can be installed in a prefabricated pools without sandwich gasket.liter capacity 22.flow rate: 9.82m/h d.50 15.61m/h d.63 22.08m/h d.75in according with legislation uni 13451.

model

code description

2002c0004 abs aqua classic skimmers concrete flow rate 9.82m3/hr d.50 15.61m3/hr d.63 22.08m3/hr d.75

2002c0003 abs aqua classic skimmers liner flow rate 9.82m3/hr d.50 15.61m3/hr d.63 22.08m3/hr d.75

exclusive version of the overflow skimmer for installation in the pool corner with theextension of the wall, a natural funnel that captures all the impurities quickly andinsuperable for a total cleaning of the water mirror.supplied complete with square frame special lid with anti-removal system.fittings d.50 63 with shutter flap overflow system d.32x25mf.pp basket, floating weir system thread for pressure test, socket insert, screw ins.s. 316 for mod. liner, in additional elegant flange cover.ccan be installed in prefrabricated pools without sandwich gasket.flow rate: 9.82m/h d.50 15.61m/h d.63in according with legislation uni 13451.

model

code description

200200002 abs aqua overflow corner skimmer concrete (right handed) flow rate 9.82m3/hr d.50 15.61m3/hr d.63

202000045 abs aqua overflow corner skimmer concrete (left handed) flow rate 9.82m3/hr d.50 15.61m3/hr d.63

200200001 abs aqua overflow corner skimmer liner (right handed) flow rate 9.82m3/hr d.50 15.61m3/hr d.63

200200044 abs aqua overflow corner skimmer liner (left handed) flow rate 9.82m3/hr d.50 15.61m3/hr d.63

abs skimmer with exclusive flared flat mouth for to flow acceleration.injected in one-block.designed and built to increase the waters level up to few centimeters away from the top of the edge.supplied completely with square frame special lid with anti-removal system.fittings d.50 63 with shutter flap overflow system d.32x25mf.pp basket, floating weir system thread for pressure test, socket insert, screw in s.s 316 for mod. liner, in additional elegant flange cover.flow rate: 9.82m/h d.50 15.61m/h d.63.in according with legislation uni 13451.

model

code description

200200004 abs aqua overflow straight skimmer concrete flow rate 9.82m3/hr d.50 15.61m3/hr d.63

200200003 abs aqua overflow straight skimmer liner flow rate 9.82m3/hr d.50 15.61m3/hr d.63

ABS bodyCover adaptorABS Skimmer coverABS Skimmer frame coverLevel sensorSupport for level sensor adjustmentOverflow system stub pipeAnti-intrusion system for Skimmer coverNozzle connection 50FOverflow system connection 50M (to be drilled during installation)Standards:Inlet systems UNI EN 10637:2006 Par.5.2.3.3UNI EN 13451-1:2002 points 4.41 4.5 4.64.11 4.12 6.1 6.2 6.3 6.1 6.2UNI EN 13451-3:2002 points 4.27 A.2.2

ABS WATER LEVEL REGULATOR

Manufactured of high-quality ABS Plastic by injection moulding under rigorous production control to guarantee resistance and durability.Maximum working pressure is 2.5 bar.

Model

CODE DESCRIPTION

200200759 ABS AQUA MECHANICAL LEVEL REGULATOR

200200730 ABS AQUA ELECTRICAL LEVEL REGULATOR

F-120 ABS AQUA E WATER LEVEL REGULATOR

New deluxe vacuum brush made of plastic clip.

To be connected to 38 mm vacuum hose.

Curved wall brush made of plastic 45cm clip.

For 38 hose.

Straight wall brush made of plastic 26cm clip.

Stainless steel curved algae brush reinforced 45cm clip.

Stainless steel straight wall brush 25 cm- clip.

Model

CODE DESCRIPTION

BRUSHES

C-120 CURVED WALL BRUSH MADE OF PLASTIC 45CM- CLIP

C-121 STRAIGHTWALL BRUSH MADE OF PLASTIC 26CM- CLIP

C-122 STAINLESS STEEL CURVED ALGAE REINFORCED 45CM CLIP

C-123 STAINLESS STEEL STRAIGHT WALL BRUSH 25CM CLIP

Model

CODE DESCRIPTION

LEAF SKIMMERS

C-142 STANDARD SURFACE LEAF SKIMMER CLIP

C-143 HEAVY DUTY SURFACE LEAF SKIMMER CLIP

C-144 STANDARD DEEP LEAF RAKE CLIP

C-145 HEAVY DUTY DEEP LEAF RAKE CLIP

Model

CODE DESCRIPTION

C-151 MAINTENANCE KIT 5PCS (FLEXIBLE POOL CLEANER, SURFACE LEAF SKIMMER, CURVED BRUSH, TEST KIT & THERMOMETER)

METAL POOL CLEANER

Heavy aluminum bottom cleaner.Very robust.Supplied with wheels, brushes and internal ballast.For 38 hose.

ALUMINIUM POOLCLEANER

Vacuum brush with swivel and EZ-ClipFor 38 hose.

FLEXIBLE POOLCLEANER

Made of flexible plastic to adapt to the differentshapes and angles of swimming pools.Supplied with 8 wheels.For 38 hose.Fixing: Clip.

Model

CODE DESCRIPTION

METAL POOL CLEANER

C-102 METAL POOL CLEANERS, 33CM, 38 CLIP

C-103 METAL POOL CLEANERS, 45CM, 38 CLIP

ALUMINIUM POOLCLEANER

C-107 ALUMINIUM POOL CLEANER , 14CM, 38 CLIP

C-108 ALUMINIUM POOL CLEANER , 18CM, 38 CLIP

FLEXIBLE POOLCLEANER

C-111 FLEXIBLE POOLCLEANER, WITH , 38 CLIP

C-112 FLEXIBLE POOLCLEANER, WITHOUT, 38 CLIP

selffloating hose

made of eva, uv-resistant.eases manual and automatic pool cleaners handling because of its flexibility.its design enables the hose to keep floating even when full of water and allows thepool cleaner to work freely on the pool floor.end fittings included.

model

code description

selffloating hose

c-130 self floating hose 38 , length 10m

c-131 self floating hose 38 , length 12m

c-132 self floating hose 38 , length 15m

c-133 self floating hose 38 , length 30m

c-135 hose cuffs 38

Model

CODE DESCRIPTION

C-141 TELESCOPIC HANDLE LENGTH 1.50MTR (3 X 0.50MTR) CLIP

C-137 TELESCOPIC HANDLES LENGTH 4.80 (2 x 2.40)m, CLIP

C-138 TELESCOPIC HANDLES LENGTH 9.00 (3 x 3.00)m, CLIP

model

code description

l-305 inclined ladder stainless steel aisi 304 luxe treads 2

l-306 inclined ladder stainless steel aisi 304 luxe treads 3

l-307 inclined ladder stainless steel aisi 304 luxe treads 4

l-308 inclined ladder stainless steel aisi 304 luxe treads 5

l-305-316 inclined ladder stainless steel aisi 304 luxe treads 2

l-306-316 inclined ladder stainless steel aisi 304 luxe treads 3

l-307-316 inclined ladder stainless steel aisi 304 luxe treads 4

l-308-316 inclined ladder stainless steel aisi 304 luxe treads 5

model

code description

l-205 muro ladder stainless steel aisi 304 luxe treads 2

l-206 muro ladder stainless steel aisi 304 luxe treads 3

l-207 muro ladder stainless steel aisi 304 luxe treads 4

l-208 muro ladder stainless steel aisi 304 luxe treads 5

l-205-316 muro ladder stainless steel aisi 316 luxe treads 2

l-206-316 muro ladder stainless steel aisi 316 luxe treads 3

l-207-316 muro ladder stainless steel aisi 316 luxe treads 4

l-208-316 muro ladder stainless steel aisi 316 luxe treads

TRANSGRATE

Designed for Olympic pools.Molded from engineering plastics.Designed for ease of installation and maximum flexibility.A vailable in a standard width of 250, 300, 350mm. can be cut to custom sizes at request.

LOGIGRATE

Designed for Olympic pools.Molded from engineering plastics.Features elements which run parallel to the pool edge.Designed for ease of installation, safety, and maximum exibility.A vailable in a 3 size width of 250, 300 or 350mm.

GRATING SUPPORT

Made in plastic.Suitable for 22, 24 and 35 mm high grating.Supplied in 2 m length.Inside measurement 24 x 37 mm.

Model

CODE DESCRIPTION

GR-101 ABS OVERFLOW GRATING H = 22MM AND W = 195MM

GR-102 ABS OVERFLOW GRATING H = 35MM AND W = 195MM

GR-103 ABS OVERFLOW GRATING H = 22MM AND W = 245MM

GR-104 ABS OVERFLOW GRATING H = 35MM AND W = 245MM

GR-90 -01 ABS OVERFLOW GRATING ANGLE 90 245 X 35MM

GR-90 -02 ABS OVERFLOW GRATING ANGLE 90 245 X 22MM

GR-90 -03 ABS OVERFLOW GRATING ANGLE 90 195 X 35MM

GR-90 -04 ABS OVERFLOW GRATING ANGLE 90 195 X 22MM

GR-45 -01 ABS OVERFLOW GRATING ANGLE 45 245 X 35MM

GR-45 -02 ABS OVERFLOW GRATING ANGLE 45 245 X 22MM

GR-45 -03 ABS OVERFLOW GRATING ANGLE 45 195 X 35MM

GR-45 -04 ABS OVERFLOW GRATING ANGLE 45 195 X 22MM

GR-112 ABS OVERFLOW GRATING TRANSGRATE 250 X 25MM

GR-113 ABS OVERFLOW GRATING TRANSGRATE 300 X 25MM

GR-114 ABS OVERFLOW GRATING TRANSGRATE 350 X 25MM

AWE026C ABS OVERFLOW GRATING ABS LONG GRATE GLASS FILLED 250 X 35MM

AWE027C ABS OVERFLOW GRATING ABS LONG GRATE GLASS FILLED 300 X 35MM

AWE028C ABS OVERFLOW GRATING ABS LONG GRATE GLASS FILLED 350 X 35MM

GR-119 ABS GRATING SUPPORT FOR 22, 24 and 35MM GRATING 2M LENGTH (PRICE PER 1 MTR)

Model

CODE DESCRIPTION

L-405 OVERFLOW LADDER STAINLESS STEEL AISI 304 LUXE TREADS 2

L-406 OVERFLOW LADDER STAINLESS STEEL AISI 304 LUXE TREADS 3

L-407 OVERFLOW LADDER STAINLESS STEEL AISI 304 LUXE TREADS 4

L-408 OVERFLOW LADDER STAINLESS STEEL AISI 304 LUXE TREADS 5

L-405 OVERFLOW LADDER STAINLESS STEEL AISI 316 LUXE TREADS 2

L-406 OVERFLOW LADDER STAINLESS STEEL AISI 316 LUXE TREADS 3

L-407 OVERFLOW LADDER STAINLESS STEEL AISI 316 LUXE TREADS 4

L-408 OVERFLOW LADDER STAINLESS STEEL AISI 316 LUXE TREADS 5

Made of 42 polished stainless steel AISI-316 or AISI-304Steps are made of stainless steel and anti slipperyComplete with anchor fixtures for deck

Model

CODE DESCRIPTION

L-105 STANDARD LADDER STAINLESS STEEL AISI 304 LUXE TREADS 2

L-106 STANDARD LADDER STAINLESS STEEL AISI 304 LUXE TREADS 3

L-107 STANDARD LADDER STAINLESS STEEL AISI 304 LUXE TREADS 4

L-108 STANDARD LADDER STAINLESS STEEL AISI 304 LUXE TREADS 5

Digital Controller DIN rail mounting.Backlighted LCD display, 2 lines x 16 characters and 4 keys keypad, for an easy user interface;2 set-points with independent adjustment and free relay outputs, selectables in On-Off mode, Proportional or Time-Pause Mode;0/4-20 mA Proportional Output with selectable range;PT100 temperature probe, Level and Flow sensor inputs;Setting menu protected by password;Fast setting by user menu selection, manual control of both relays (pumps priming), runtime monitoring of all outputs and control of the last probe calibration;Realy n.2 selectable as setpoint or on each alarm signal.Statistics of the alarms, of the number of setpoint activations and of the operating time of each relay;Self-calibration of measure probes.

ADIN20S pH-Rx

Controller for measurement and control of pH measure range 0.00-14.00 pH, with 0.01 pH accuracy, Redox potential, measure range -15001500 mV, with 1 mV accuracy;Changing of the monitored parameter by Advanced Settings Menu, protected by password.

ADIN20S CHLORINE

Controller for measurement and regulation of free chlorine available for amperometric Pt- Cu probes;Measure Range:0.00-10.00 ppm.

ADIN20S CD

Controller for measurement and control of conductivity, available for conductivity probes with K=1, K=5 and K=10.

ADIN20S CL-J

Controller for measurement and regulation of free chlorine and each other measure available for amperometric selective membrane 4-20mA probes;Measure Range selectable: 0.00-2.00 ppm/0.00-5.00ppm/0.00-10.00ppm/0.00-20.00ppm/0-200ppm.

Model

CODE DESCRIPTION

ADINS20PHRX AQUA DIN 20 START PH-RX CONTROLLER

ADINS20CL AQUA DIN 20 START CHLORINE (PT-CU) CONTROLLER

ADINS20CD AQUA DIN 20 START CONDUCTIVITY CONTROLLER

ADINS20CLJ AQUA DIN 20 START PPM A-J PROBES

Digital Controller for wall mounting .Backlighted LCD display, 2 lines x 16 characters and 4 keys keypad, for an easy user interface;2 set-points with independent adjustment and free relay outputs, selectables in On-Off mode, Proportional or Time-Pause Mode;0/4-20 mA Proportional Output with selectable range;PT100 temperature probe, Level and Flow sensor inputs;Programmation protected by password;Fast setting by user menu selection, manual control of both relays (pumps priming), runtime monitoring of all outputs and control of the last probe calibration;Realy n.2 selectable as setpoint or on each alarm signal.Statistics of the alarms, of the number of setpoint activations and of the operating time of each relay;Self-calibration of measure probes.

AE S pH-Redox

Controller for measurement and control of pH measure range 0.00-14.00 pH, with 0.01 pH accuracy, Redox potential, measure range -15001500 mV, with 1 mV accuracy;Changing of the monitored parameter by Advanced Settings Menu, protected by password.

AE S Chlorine

Controller for measurement and regulation of free chlorine available for amperometric Pt- Cu probes;Measure Range:0.00-10.00 ppm.

AE S CD

Controller for measurement and control of conductivity, available for conductivity probes with K=1, K=5 and K=10.

AE S CL-J

Controller for measurement and regulation of free chlorine and each other measure available for amperometric selective membrane 4-20mA probes;Measure Range selectable: 0.00-2.00 ppm/0.00-5.00ppm/ 0.00-10.00ppm/0.00-20.00ppm/0-200ppm.

Model

CODE DESCRIPTION

ADESPHRX AQUA AE START PH-RX CONTROLLER

ADESCL AQUA AE START CHLORINE (PT-CU) CONTROLLER

ADESCD AQUA AE START CONDUCTIVITY CONTROLLER

ADESCLJ AQUA AE START PPM A-J PROBES

Digital Controller for panel mounting 4896.Backlighted LCD display, 2 lines x 16 characters and 4 keys keypad, for an easy user interface;2 set-points with independent adjustment and free relay outputs, selectables in On-Off mode, Proportional or Time-Pause Mode;0/4-20 mA Proportional Output with selectable range;PT100 temperature probe, Level and Flow sensor inputs;Setting menu protected by password;Fast setting by user menu selection, manual control of both relays (pumps priming), runtime monitoring of all outputs and control of the last probe calibration;Realy n.2 selectable as setpoint or on each alarm signal.Statistics of the alarms, of the number of setpoint activations and of the operating time of each relay;Self-calibration of measure probes

AR 10 S pH-Redox

Controller for measurement and control of pH measure range 0.00-14.00 pH, with 0.01 pH accuracy, Redox potential, measure range -15001500 mV, with 1 mV accuracy;Changing of the monitored parameter by Advanced Settings Menu, protected by password.

AR 10 S Chlorine

Controller for measurement and regulation of free chlorine available for amperometric Pt- Cu probes;Measure Range:0.00-10.00 ppm.

AR 10 S CD

Controller for measurement and control of conductivity, available for conductivity probes with K=1, K=5 and K=10.

AR 10 S CL-J

Controller for measurement and regulation of free chlorine and each other measure available for amperometric selective membrane 4-20mA probes;Measure Range selectable: 0.00-2.00ppm/0.00-5.00ppm /0.00-10.00ppm/0.00-20.00ppm/0-200ppm.

Model

CODE DESCRIPTION

ADRS10PHRX AQUA AR 10 START PH-RX CONTROLLER

ADRS10CL AQUA AR 10 START CHLORINE (PT-CU) CONTROLLER

ADRS10CD AQUA AR 10 START CONDUCTIVITY CONTROLLER

ADRS10CLJ AQUA AR 10 START PPM A-J PROBES

Controller for measurement and proportional control of pH, Redox, Chlorine and conductivity.

AW 96 pH

Controller for measurement and proportional control of pH, measure 0.00-14.00 pH;Microprocessor technology with digital control and LCD display;n.3 indipendent set-points, free contact relay output On-Off;1 output relay selectable in proportional time-pause mode;Hysteresi and activation delay selectables;4-20 mA output for recorder with galvanic isolation;4-20 mA proportional output, selectable on set-point2, with galvanic insulation;Wall mounting box, IP65 protection degree;pH electrode not included;Standard power supply 230Vac.

AW 96 Rx

Controller for measurement and proportional control of Redox potential over range 0-2000 mV;Microprocessor technology with digital control and LCD display;3 set-points independently adjustable with On/Off volt free relay outputs;1 pulse proportional volt free relay output;Hysteresis adjustment and programmable delay;4-20 mA output for chart recording with galvanic isolation;4-20 mAproportional output;Vertical mounting version IP65 enclosure;Redox electrode not included;Power supply as standard 230VAC.

AW 96 S Chlorine

Controller for measurement and proportional control of free chlorine over range 0.00-10.00 ppm;Microprocessor technology with digital control and LCD display;3 set-points independently adjustable with On/Off volt free relay outputs;1 pulse proportional volt free relay output;Hysteresis adjustment and programmable delay;4-20 mA output for chart recording with galvanic isolation;4-20 mA proportional output;Vertical mounting version IP65 enclosure;Chlorine electrode not included (A-CG);Power supply as standard 230VAC.

AW 96 S CD

Controller for measurement and proportional control of conductivity over range 0-20000S;Other ranges on request are 0-2000S or 0-200S;Microprocessor technology with digital control and LCD display. 3 indipendent set-points, free contact relay output On-Off;1 pulse proportional volt free relay output and 1 timed pulse proportional volt free relay output;Hysteresi and activation delay selectable;Manual and automatic temperature compensation 0-100C;Temperature probe not included (compatible with A-ST1 probe);4-20 mA output for recorder with galvanic isolation;4-20 mA proportional output, selectable on set-point2, with galvanic insulation;Wall mounting box, IP65 protection degree;Conductivity electrode not included (compatible with A-CD probe with exclusion the termocompensate)Standard power supply 230VAC.

Model

CODE DESCRIPTION

ADW96PH AW-96 PH 230V

ADW96PHF AW-96 PHF 230V

ADW96RX AW-96 RX 230V

ADW96CL AW-96 CL 230V

ADW96CD AW-96 CD 0-20000 uS 230V

ADW96CD1 AW-96 CD 0-2000 uS 230V

ADW96CD2 AW-96 CD 0-200 uS 230V

INSTALLATION KIT

ADSP6020156 WALL FIXING BRACKET

ADSP6020224 WALL ADAPTERFIXING BRACKET 4 SCREW

Cylindrical vertical container with self-supporting structure and flat bottom, suitable for the safety containing of the A-TANK tanks. It is made in non-toxic UV-stabilised polyethylene to provide a higher protection from atmospheric agents, with a neutral, translucent colour. It is monolithic, i.e. moulded in a single piece, with no joints. It can be placed on flat surfaces without particular precautions.

Model

CODE DESCRIPTION

ADELTPH01 A-pH

ADELTPH05 A-pH 5

ADELTPH10 A- pH 10

ADELTRX01 A-Rx 1

ADELTRX05 A-Rx 5

ADELTRX10 A-Rx 10

ADELTRX05G A-Rx 5 GOLD

ADELVPH A-VpH

ADELVRX A-VRx

ADELPPH A-PpH

ADELPRX A-PRx

ADCV01 A-CV 1

ADCV02 A-CV 2, 5

ADCV05 A-CV 5

ADCV10 A-CV 10

ADCV15 A-CV 15

ADCV20 A-CV 20

ADSPH4 A-SPH4

ADSPH7 A-SPH7

ADSPH9 A-SPH9

ADSRX A-SRX 475 mV

ADCG2 CHLORINE CELLA A-CG2 0-5 PPM

ADCG5F CHLORINE CELLA A-CG5 0-5 PPM PROX. SWITCH FILTER

ADCG6F CHLORINE CELLA A-CG6 0-5 PPM PROX. SWITCH FILTER-PROBE HOLDER

ADSP4000620 REPLACEMENT KIT FOR Pt-Cu ELECTRODE

ADSP6500009 BALLS REPLACEMENT KIT

ADELCLJ05 A-J ELECTRODE FREE CHLORINE INORGANICS FLUID O-5 PPM

ADELCLJ22 A-J ELECTRODE FREE CHLORINE INORGANICS FLUID 0-2 PPM

ADELCLJ25 A-J ELECTRODE FREE CHLORINE ORGANICS FLUID 0-5 PPM READING INF. PH

ADELCLJ35 A-J ELECTRODE TOTAL CHLORINE 0-5 PPM READING INF. PH

ADELDCJ10 A-J ELECTRODE CHLORINE DIOXIDE 0-5 PPM READING

ADELOZJ10 A-J ELECTRODE OZONE 0-5 PPM READING

ADELPXJ02 A-J ELECTRODE HYDROGEN PEROXIDE 0-200 PPM READING

ADELPAJ02 A-J ELECTRODE PER-ACETIC ACID 0-200 PPM READING

ADSP6020051 A-J CONNECTION CABLE 4

ADELCLJ25S A-J ELECTRODE FREE CHLORINE ORGANICS FLUID 0-5 PPM READING INF. PH SALT WATER

ADPACDK1A PACD K1

ADPACDK5A PACD K5

ADPACCDK1A PACCD K1

ADPACCDK5A PACCD K5

ADTACCDK1 TACCD K1

ADTACCDK5 TACCD K5

ADTACDK1 TACD K1

Multifunction solenoid digital dosing pumps. Dosing mode selectable in constant or proportional mode.

Renforced PP housing, suitable for aggressive working enviroments;Input: level probe, inhibit, standby, flow sensor, injection;Output: alarm or dosing relay;Statistics;Password;Language and Unit measure selectable;Calibration flow-rate;Simplified setting by user menu;Alphanumeric display, 2 lines 16 characters, to simplify pump managing, during the working mode and during the programmation;Power supply 230 Vac. Upon request: 110V;IP65 protection degree;Wall mounting bracket supplied in installation kit;Manual bleed valve (priming).

WORKING MODE

Constant flow-rate On/Off mode (flow rate in %);Self-calibration of measure probe;PH or Redox (ORP) measure selectable from the Programmation menu;Proportional dosing to the selected setpoint value;Selectable Alarms: Level (with reserve, early warning), Flow (flow sensor input), Strokes (max number of strokes), OFA (Over Feed Alarm), RANGE.

Standards:

n 2004/108/CE Direttiva EMC

n 2006/95/CE DBT Low Voltage Directive

n 2011/65/UE , 2012/19/UE direttive RoHs e WEEE

no. 2004/108/CE EMC directive

no. 2006/95/CE DBT Low Voltage Directive

no. 2011/65/UE, 2012/19/UE RoHs and WEEE directives

CODE DESCRIPTION

AD96200000000 PDE HC151-1 PH-RX 02-08/05-05/07-02 230V PP-GL-VT

AD96201000000 PDE HC151-2 PH-RX 07-04/08-02/10-00 230V PP-GL-VT

AD96202000000 PDE HC151-3 PH-RX 03-12/04-10/05-08 230V PP-GL-VT

AD96203000000 PDE HC151-4 PH-RX 10-04/12-02/14-00 230V PP-GL-VT

AD96207000000 PDE HC151-5 PH-RX 02-20/2, 5-18/03-15 230V PP-GL-VT

AD96208000000 PDE HC151-6 PH-RX 10-10/12-08/14-05 230V PP-GL-VT

AD96209000000 PDE HC151-7 PH-RX 20-03/25-02/35-00 230V PP-GL-VT

AD96210000000 PDE HC151-8 PH-RX 04-20/4, 5-18/05-15 230V PP-GL-VT

INSTALLATION KIT

ADSP6000078 PE TUBE D. 46 2MT

ADSP6000546 PVC CRYSTAL TUBE D. 46 2MT

ADSP6000001 FOOT VALVE PP-VL-VT 46

ADSP6200007 INJECTION VALVE M1/2 PP-VL-VT 46

ADSP6020221 WALL BRACKET HC150-897-997-999-100

ADSP6000041 ANCHORS AND SCREWS

ACCESSORIES AND SPARE PARTS

ADSLG4 LEVEL PROBE SWITCH w/2 m cable + BRACKET A-SL

ADBAS100 FOOT BRACKET HC150-797-897-997-999-100

ADLASM10B0 COMPLETE SUCTION LANCE WITH C-PROBE LEV.-S/BNC T-A (60/100L-H700) GLVT 4X6

ADLASM30B0 COMPLETE SUCTION LANCE WITH C-PROBE LEV.-S/BNC T-A (2/300L-H940) GLVT 4X6

ADTANK010 A-TANK 1 100 LITRES

ADTANK020 A-TANK 2 200 LITRES

ADTANK030 A-TANK 3 300 LITRES

ADELTPH01 A-pH 1

ADELTPH05 A-pH 5

ADELTPH10 A- pH 10

ADELTRX01 A-Rx 1

ADELTRX05 A-Rx 5

ADELTRX10 A-Rx 10

ADSPH4 A-SPH4

ADSPH7 A-SPH7

ADSPH9 A-SPH9

ADSRX A-SRX 475 mV

ADSPH4 A-SPH4

ADSPH7 A-SPH7

ADSPH9 A-SPH9

ADSRX A-SRX 475 mVADSP9000100 HC150/797/897/997 PUMP HEAD 2-14 PP-GL-VT

ADSP900P000 HC150/797/897/997 PUMP HEAD 2-14 PVDF-PTFE-VT

ADSP900S001 PUMP HEAD 1-14 PVC-CE-VT AUTOMATIC DISCHARGE

Multifunction solenoid digital dosing pumps. Dosing mode selectable in constant or proportional mode.

Renforced PP housing, suitable for aggressive working enviroments;Input: level probe, inhibit, standby, flow sensor, injection;Output: alarm or dosing relay;Statistics;Password;Language and Unit measure selectable;Calibration flow-rate;Simplified setting by user menu;Alphanumeric display, 2 lines 16 characters, to simplify pump managing, during the working mode and during the Programmation;Power supply 230 Vac. Upon request: 110V;IP65 protection degree;Wall mounting bracket supplied in installation kit;Manual bleed valve (priming).

WORKING MODE

Constant flow rate On/Off mode or Cycle mode (time/pause dosing, Ton-Toff);Proportional to an analogical signal 4-20 mA. Dosing range completely selectable by the user;Proportional to a digital signal (water-meter pulse-sender).MODE: ppm, 1xN (multiplication of received pulses), 1:N (division of received pulses), 1xN(T) (proportional dosing between two pulses), 1xN(M) (with frequency self-regulation for excessive input pulses);Batch Mode (selecting number of strokes or quantity or frequency, all in time): external mode (start by external signal) and manual mode (start by arrow keys UP, DOWN);Selectable Alarms: Level (with reserve, early warning), Flow (flow sensor input), Strokes (max number of strokes).

Standards:

n 2004/108/CE Direttiva EMC

n 2006/95/CE DBT Low Voltage Directive

n 2011/65/UE , 2012/19/UE direttive RoHs e WEEE

no. 2004/108/CE EMC directive

no. 2006/95/CE DBT Low Voltage Directive

no. 2011/65/UE, 2012/19/UE RoHs and WEEE directives

Model

CODE DESCRIPTION

AD96100000000 PDE HC151-1 PI-MA 02-08/05-05/07-02 230V PP-GL-VT

AD96101000000 PDE HC151-2 PI-MA 07-04/08-02/10-00 230V PP-GL-VT

AD96102000000 PDE HC151-3 PI-MA 03-12/04-10/05-08 230V PP-GL-VT

AD96103000000 PDE HC151-4 PI-MA 10-04/12-02/14-00 230V PP-GL-VT

AD96107000000 PDE HC151-5 PI-MA 02-20/2, 5-18/03-15 230V PP-GL-VT

AD96108000000 PDE HC151-6 PI-MA 10-10/12-08/14-05 230V PP-GL-VT

AD96109000000 PDE HC151-7 PI-MA 20-03/25-02/35-00 230V PP-GL-VT

AD96110000000 PDE HC151-8 PI-MA 04-20/4, 5-18/05-15 230V PP-GL-VT

INSTALLATION KIT

ADSP6000078 PE TUBE D. 46 2MT

ADSP6000546 PVC CRYSTAL TUBE D. 46 2MT

ADSP6000001 FOOT VALVE PP-VL-VT 46

ADSP6200007 INJECTION VALVE M1/2 PP-VL-VT 46

ADSP6020221 WALL BRACKET HC150-897-997-999-100

ADSP6000041 ANCHORS AND SCREWS

ACCESSORIES AND SPARE PARTS

ADSLG4 LEVEL PROBE SWITCH w/2 m cable + BRACKET A-SL

ADBAS100 FOOT BRACKET HC150-797-897-997-999-100

ADLASM10B0 COMPLETE SUCTION LANCE WITH C-PROBE LEV.-S/BNC T-A (60/100L-H700) GLVT 4X6

ADLASM30B0 COMPLETE SUCTION LANCE WITH C-PROBE LEV.-S/BNC T-A (2/300L-H940) GLVT 4X6

ADTANK010 A-TANK 1 100 LITRES

ADTANK020 A-TANK 2 200 LITRES

ADTANK030 A-TANK 3 300 LITRES

ADSP9000100 HC150/797/897/997 PUMP HEAD 2-14 PP-GL-VT

ADSP900P000 HC150/797/897/997 PUMP HEAD 2-14 PVDF-PTFE-VT

ADSP900S001 PUMP HEAD 1-14 PVC-CE-VT AUTOMATIC DISCHARGE

Analogical metering dosing pump with constant flow rate;Level probe input;Power supply: 220VAC 50/60Hz. Upon request 110V;On-Off switch;IP65 protection degree;Analogical interface by knob and a LED bicoloured;Manual priming valve;Wall or foot mounting (brackets included in the kit);PVDF BODY PUMP high chemical compatibility;FIXING BRACKET to simplify the installation;PBT CASE high mechanical resistance-eco-friendly-ergonomic low flammability;BUILT-IN PIPE HOLDER safe and clean installation;REMOVABLE CONNECTIONS easy maintenance of the pump.

Standards:

n 2004/108/CE Direttiva EMC

n 2006/95/CE DBT Low Voltage Directive

n 2011/65/UE , 2012/19/UE direttive RoHs e WEEE

no. 2004/108/CE EMC directive

no. 2006/95/CE DBT Low Voltage Directive

no. 2011/65/UE, 2012/19/UE RoHs and WEEE directives

Model

CODE DESCRIPTION

AD89000010000 HC897-1 02-08/05-05/07-02 230V PVDF-PTFE-VT

AD89001010000 HC897-2 07-04/08-02/10-00 230V PVDF-PTFE-VT

AD89002010000 HC897-3 03-12/04-10/05-08 230V PVDF-PTFE-VT

AD89003010000 HC897-4 10-04/12-02/14-00 230V PVDF-PTFE-VT

AD89007010000 HC897-5 02-20/2, 5-18/03-15 230V PVDF-PTFE-VT

INSTALLATION KIT

ADSP6000078 PE TUBE D. 46 2MT

ADSP6000546 PVC CRYSTAL TUBE D. 46 2MT

ADSP6000028 FOOT VALVE PVDF-PTFE-VT 46

ADSP6200031 INJECTION VALVE M1/2 PVDF-PTFE-VT 46

ADSP6020221 WALL BRACKET HC150-897-997-999-100

ADBAS100 FOOT BRACKET HC150-797-897-997-999-100

ADSP6000041 ANCHORS AND SCREWS

ACCESSORIES AND SPARE PARTS

ADSLG1 LEVEL PROBE SWITCH w/2 m cable + BRACKET A-SL without CONNECTOR

ADLASM1000 COMPLETE SUCTION LANCE WITH LEVEL SWITCH PROBE WITHOUT CONNECTOR T-A (60/100L-H600) GL-VT 4X6

ADLASM3000 COMPLETE SUCTION LANCE WITH LEVEL SWITCH PROBE WITHOUT CONNECTOR T-A (2/300L-H940) GL-VT 4X6

ADTANK010 A-TANK 1 100 LITRES

ADTANK020 A-TANK 2 200 LITRES

ADTANK030 A-TANK 3 300 LITRES

ADSP900P000 HC150/797/897/997 PUMP HEAD 2-14 PVDF-PTFE-VT

ADSP900S000 HC897 PUMP HEAD AUTOMATIC BLEED PVC-PVDF-VT

Constant flow rate dosing pump with pulse frequency regulation. Easy to set, by a single potentiometer and a LED. Level probe input connection.

High resistance PBT box, suitable for environments and chemicals with high temperatures;Level probe input;Double frequency regulation scale, 0-100% or 0-20%;Power supply: 220VAC 50/60Hz. Upon request 110V;On-Off switch;IP65 protection degree;Analogical user interface by one knob and a LED;Manual air bleed valve for quick priming;Ready for wall or foot mounting (brackets included). Standards:

n 2004/108/CE Direttiva EMC

n 2006/95/CE DBT Low Voltage Directive

n 2011/65/UE , 2012/19/UE direttive RoHs e WEEE

no. 2004/108/CE EMC directive

no. 2006/95/CE DBT Low Voltage Directive

no. 2011/65/UE, 2012/19/UE RoHs and WEEE directives

Model

CODE DESCRIPTION

AD98001000000 HC899-1 10-10/12-08/14-05 230V PP-GL-VT

AD98002000000 HC899-2 04-20/4, 5-18/05-15 230V PP-GL-VT

AD98003000000 HC899-3 20-05/25-03/35-01 230V PP-GL-VT

AD980040Y0000 HC899-4 35-02/45-01/50-0, 5 PVC-GL-VT

INSTALLATION KIT

ADSP6000078 PE TUBE D. 46 2MT

ADSP6000546 PVC CRYSTAL TUBE D. 46 2MT

ADSP6000370 PE TUBE D. 68

ADSP6000016 POLYETHYLENE HOSE 10X14 (50 m rolls)

ADSP6000440 PVC CLEAR HOSE 10X14 (100 m rolls)

ADSP6000001 FOOT VALVE PP-VL-VT 46

ADSP6000774 FOOT VALVE PP-VL-VT 1014

ADSP6200007 INJECTION VALVE M1/2 PP-VL-VT 46

ADSP6200018 INJECTION VALVE 1/2 68 VITON

ADSP6000051 INJECTION VALVE 1/2 1014 VITON

ADSP6020221 WALL BRACKET HC150-897-997-999-100

ADSP6000041 ANCHORS AND SCREWS

ADBAS100 FOOT BRACKET HC150-797-897-997-999-100

ACCESSORIES AND SPARE PARTS

ADSLG LEVEL PROBE SWITCH w/2 m cable + BRACKET A-SL

ADLASM10C0 COMPLETE SUCTION LANCE WITH LEVEL SWITCH PROBE AND CONNECTOR T-A (60/100L-H600) GL-VT 4X6

ADLASM30C0 COMPLETE SUCTION LANCE WITH LEVEL SWITCH PROBE AND CONNECTOR T-A (2/300L-H940) GL-VT 4X6

ADTANK010 A-TANK 1 100 LITRES

ADTANK020 A-TANK 2 200 LITRES

ADTANK030 A-TANK 3 300 LITRES

ADTANK050 A-TANK 5 500 LITRES

ADTANK100 A-TANK 10 1000 LITRES

SPARE PARTS

ADSP6000C16 PUMP HEAD 4-20/10-10 PP-GL-VT MOD. 1-2

ADSP6000C17 PUMP HEAD 4 20/05 PP-GL-VT MOD. 3

ADSP6000C11 PUMP HEAD 30-02/50-05 PVC-GL-VT MOD. 4

ADSP6000C09 PUMP HEAD 4-20/10-10 PVDF-PTFE-VT MOD. 1-2

ADSP6000C10 PUMP HEAD 4 20/05 PVDF-PTFE-VT MOD. 3

Solenoid metering pump with constant flow rate, with pulses frequency regulation

• Dosing adjustment by knob
• Double regulation range 0-100%, 0-20% by switch;
• Standard power supply 230 Vac 50/60 HZ. Other power supplies on request.
• On-Off switch
• Manual Priming Value
• Green LED to show pump switch-on, red LED to shows pump dosing pulses.

Solenoid metering pump with constant flow rate, with pulses frequency regulation

Dosing adjustment by knob;Double regulation range 0-100%, 0-20% by switch;Standard power supply 230Vac 50/60Hz. Other power supplies on request;On-Off switch;Manual priming valve;Green LED to show pump switch-on, red LED to shows pump dosing pulses.

Standards:

n 2004/108/CE Direttiva EMC

n 2006/95/CE DBT Low Voltage Directive

n 2011/65/UE , 2012/19/UE direttive RoHs e WEEE

no. 2004/108/CE EMC directive

no. 2006/95/CE DBT Low Voltage Directive

no. 2011/65/UE, 2012/19/UE RoHs and WEEE directives

Model

CODE DESCRIPTION

AD10001080000000 HC100 01.08 230V PP-GL-VT

AD10002070000000 HC100 02.07 230V PP-GL-VT

AD10002120000000 HC100 02.12 230V PP-GL-VT

AD10004050000000 HC100 04.05 230V PP-GL-VT

AD10005080000000 HC100 05.08 230V PP-GL-VT

INSTALLATION KIT

ADSP6000078 PE TUBE D. 46 2MT

ADSP6000546 PVC CRYSTAL TUBE D. 46 2MT

ADSP6000001 FOOT VALVE PP-VL-VT 46

ADSP6200007 INJECTION VALVE M1/2 PP-VL-VT 46

ADSP6020221 WALL BRACKET HC150-897-997-999-100

ADSP6000041 ANCHORS AND SCREWS

ACCESSORIES AND SPARE PARTS

ADTANK010 A-TANK 1 100 LITRES

ADTANK020 A-TANK 2 200 LITRES

ADTANK030 A-TANK 3 300 LITRES

ADSP60000S8A HC1/HC2/HC3/HC4 PUMP HEAD 2-15 PP-GL-VT

ADSP60000S8P HC1/HC2/HC3/HC4 PUMP HEAD 2-15 PVDF-PTFE-VT

ADSP6000136 AUTOMATIC BLEED VALVE ON HC1/HC2/HC3/HC4 PUMP HEAD 2-15 PVC-CE-VT

The HC150 series solenoid driven dosing pumps is the ideal solution for small dosing of chemical products. The pumps are regulated through analogical controls, including a two-colour LED and a regulating knob. Predisposition for the level probe.

Available in 3 models:

1) HC150 Constant

(with or without level probe facility) with regulating of flow-rate 0-100% or 0-20% of the nominal flow;

2) HC150 PI:

Constant working mode:with regulating of flow-rate 0-100% or 0-20% of the nominal flow.Proportional working mode:1xN with the possibility of regulating N between 110;1:N with the possibility of regulating N between 11000.

3) HC150 mA:

Constant working mode:with regulating of flow-rate 0-100% or 0-20% of the nominal flow;Proportional working mode:mA signal proportional dosing mode;mA: the number of pulses is proportional to the current signal (4-20mA).

Standards:

n 2004/108/CE Direttiva EMC

n 2006/95/CE DBT Low Voltage Directive

n 2011/65/UE , 2012/19/UE direttive RoHs e WEEE

no. 2004/108/CE EMC directive

no. 2006/95/CE DBT Low Voltage Directive

no. 2011/65/UE, 2012/19/UE RoHs and WEEE directives

Model

CODE DESCRIPTION

AD95000200000 PDE HC150 CST S/Liv.-0 1.5-05/02-03/03-01 230V PP-GL-VT

AD95001200000 PDE HC150 CST S/Liv.-1 02-08/03-07/05-05/07-02 230V PP-GL-VT

AD95011200000 PDE HC150 CST S/Liv.-2 07-04/08-02/10-00 230V PP-GL-VT

AD95002200000 PDE HC150 CST S/Liv.-3 03-12/04-10/05-08 230V PP-GL-VT

AD95013200000 PDE HC150 CST S/Liv.-4 10-04/12-02/14-00 230V PP-GL-VT

AD95014200000 PDE HC150 CST S/Liv.-5 02-20/2, 5-18/03-15 230V PP-GL-VT

AD95000000000 PDE HC150 CST+Liv.-0 1.5-05/02-03/03-01 230V PP-GL-VT

AD95001000000 PDE HC150 CST+Liv.-1 02-08/03-07/05-05/07-02 230V PP-GL-VT

AD95011000000 PDE HC150 CST+Liv.-2 07-04/08-02/10-00 230V PP-GL-VT

AD95002000000 PDE HC150 CST+Liv.-3 03-12/04-10/05-08 230V PP-GL-VT

AD95013000000 PDE HC150 CST+Liv.-4 10-04/12-02/14-00 230V PP-GL-VT

AD95014000000 PDE HC150 CST+Liv.-5 02-20/2, 5-18/03-15 230V PP-GL-VT

AD95700000000 PDE HC150 PI (1XN-1/N9)+Liv.-0 1.5-05/02-03/03-01 230V PP-GL-VT

AD95701000000 PDE HC150 PI (1XN-1/N)+Liv.-1 02-08/03-07/05-05/07-02 230V PP-GL-VT

AD95711000000 PDE HC150 PI (1XN-1/N)+Liv.-2 07-04/08-02/10-00 230V PP-GL-VT

AD95702000000 PDE HC150 PI (1XN-1/N)+Liv.-3 03-12/04-10/05-08 230V PP-GL-VT

AD95713000000 PDE HC150 PI (1XN-1/N)+Liv.-4 10-04/12-02/14-00 230V PP-GL-VT

AD95714000000 PDE HC150 PI (1XN-1/N)+Liv.-5 02-20/2, 5-18/03-15 230V PP-GL-VT

AD95500000000 PDE HC150 mA+Liv.-0 1.5-05/02-03/03-01 230V PP-GL-VT

AD95501000000 PDE HC150 mA+Liv.-1 02-08/03-07/05-05/07-02 230V PP-GL-VT

AD95511000000 PDE HC150 mA+Liv.-2 07-04/08-02/10-00 230V PP-GL-VT

AD95502000000 PDE HC150 mA+Liv.-3 03-12/04-10/05-08 230V PP-GL-VT

AD95513000000 PDE HC150 mA+Liv.-4 10-04/12-02/14-00 230V PP-GL-VT

AD95514000000 PDE HC150 mA+Liv.-5 02-20/2, 5-18/03-15 230V PP-GL-VT

INSTALLATION KIT

ADSP6000078 PE TUBE D. 46 2MT

ADSP6000546 PVC CRYSTAL TUBE D. 46 2MT

ADSP6000001 FOOT VALVE PP-VL-VT 46

ADSP6200007 INJECTION VALVE M1/2 PP-VL-VT 46

ADSP6020221 WALL BRACKET HC150-897-997-999-100

ADSP6000041 ANCHORS AND SCREWS

ACCESSORIES AND SPARE PARTS

ADSLG4 LEVEL PROBE SWITCH w/2 m cable + BRACKET A-SL

ADBAS100 FOOT BRACKET HC150-797-897-997-999-100

ADLASM10B0 COMPLETE SUCTION LANCE WITH C-PROBE LEV.-S/BNC T-A (60/100L-H700) GLVT 4X6

ADLASM30B0 COMPLETE SUCTION LANCE WITH C-PROBE LEV.-S/BNC T-A (2/300L-H940) GLVT 4X6

ADTANK010 A-TANK 1 100 LITRES

ADTANK020 A-TANK 2 200 LITRES

ADTANK030 A-TANK 3 300 LITRES

ADSP9000100 HC150/797/897/997 PUMP HEAD 2-14 PP-GL-VT

ADSP900P000 HC150/797/897/997 PUMP HEAD 2-14 PVDF-PTFE-VT

ADSP900S001 PUMP HEAD 1-14 PVC-CE-VT AUTOMATIC DISCHARGE

These Cartridges act by means of a physicochemical property of the active carbon (adsorption) and in some cases associated with the filtration action of various filtering materials. AQUA uses various active granulated carbon, suggesting the most appropriate types according to the conditions and diverse needs of filtering required. Our active granulated carbon extracted from vegetable coco fruit has characteristics that are very suitable for treating water in general.

These active carbon cartridges have the following specifications :GRAIN HARDNESSInsignificant presence of Carbon Powder Residuals. VERY HIGH SURFACE FILTRATION AREA (up to 1500m2/g)High Adsorption;Longer life. VERY HIGH RETENTION CAPACITYInsignificant presence of ash, less impurity. The general characteristics in understanding what makes a very efficient carbon cartridge are the following:

Pre-FiltrationTreatment of water beforehand, through a pre-filtration action which permits a first treatment of the water itself allowing a longer life to the cartridge;

Absorption performance of the carbon It is determined by the quality and quantity of carbon used. Also the contact time has a very important impact on the final result. In fact the longer the water remains in contact with the carbon (flow rate) the stronger the carbon adsorption effect will be, thus purifying the water;

Post-FiltrationTreatment of water after hand, through a post-filtration action which permits a further treatment of the water itself and eliminating any suspended carbon residuals. Having all three the above elements will no doubt reduce the flow rate. This means a better performance of the process because it optimises the active carbon action. Active carbon will in the end saturate and the life time depends on how the cartridge is being used. We highly recommend following the instructions on our data sheet relevant to each type of carbon cartridge. Thanks to the exceptional quality of our Melt Blown Pre & Post filtration, our GAC active carbon cartridges guarantee a perfect and superior quality cartridge. These pre & post filters not only will withhold all suspended particles and carbon fines but also will regulate the water flow thus assuring a perfect removal of chlorine. Laboratory tests confirm the excellent quality of our GAC Cartridge.

Applications:

Water treatment;Food/Beverage.

Model

CODE DESCRIPTION

A4120010 CARTRIDGE CARBON 5 CA P20

A4120020 CARTRIDGE CARBON 7 CA P20

A4120030 CARTRIDGE CARBON 93/4 CA P20

A4120040 CARTRIDGE CARBON 20 CA P20

A4120050 CARTRIDGE CARBON 5 CA BLUE P20

A4120060 CARTRIDGE CARBON 7 CA BLUE P20

A4120070 CARTRIDGE CARBON 93/4 CA BLUE P20

A4120080 CARTRIDGE CARBON 20 CA BLUE P20

A4120700 CARTRIDGE CA-KID 93/4 TRANSPARENT

A4120560 CARTRIDGE CARB.93/4 GAC PP40 (GAC-CC-40M)

A4120570 CARTRIDGE CARB.20 GAC PP40 (GAC-CC-40M)

A4120710 CARTRIDGE CA-KID 93/4 WHITE

A4120620 CARTRIDGE CARB.93/4 GAC PP40 (GAC-CC-40M) AQUA BIG

A4120630 CARTRIDGE CARB.20 GAC PP40 (GAC-CC-40M) AQUA BIG

A4120660 CARTRIDGE CARB.30 GAC PP40 (GAC-CC-40M) AQUA BIG

A4220050 CARTRIDGE CARBON BLOCK 93/4 MOD. CTO-E

A4220070 CARTRIDGE CARBON BLOCK 20 MOD. CTO-E-MM508

A4220110 CARTRIDGE CARBON BLOCK MODEL CTO-E AQUA BIG 93/4 10MIC

A4220120 CARTUCCIA CARBON BLOCK MODEL CTO-E AQUA BIG 20 10MIC

A4090010 CARTRIDGE 5 RLA-CA 80MIC

A4090020 CARTRIDGE 7 RLA-CA 80MIC

A4090030 CARTRIDGE 93/4 RLA-CA 80MIC

A4210020 CARTRIDGE CARB/PP 5 FA-CA

A4210030 CARTRIDGE CARB/PP 7 FA-CA

A4210040 CARTRIDGE CARB/PP 93/4 FA-CA

A4210050 CARTRIDGE CARB/PP 10 FA-CA

A4210060 CARTRIDGE CARB/PP 20 FA-CA

A4210530 CARTRIDGE CARB/MELT BLOWN 5 FRN-CA 5M

A4210540 CARTRIDGE CARB/MELT BLOWN 93/4 FRN-CA 5M

A4210550 CARTRIDGE CARB/MELT BLOWN 20 FRN-CA 5M

A4210510 CARTRIDGE CARB/MELT BLOWN 5 FRN-CA 20M

A4210500 CARTUCCIA CARB/MELT BLOWN 93/4 FRN-CA 20M

A4210520 CARTRIDGE CARB/MELT BLOWN 20 FRN-CA 20M

A4210600 CARTRIDGE FR-N CA PLUS 93/4 5MIC+CARBON

The cartridges of the STERYL series are made out of PP and mechanically (not organically) filter via the absolute filtering specific properties present in PP (degree of absolute filtration of 0.5 micron).

The filtering surface of these cartridges is extremely porous, consisting of tiny holes that are able to catch the finest solid particles, including various types of relatively big bacteria (when compared, for instance, to many molecules).

Therefore, it is important to note that this antibacterial action is possible due to these tiny (0.5 micron) pores that act as barriers! How often the cartridges must be changed depends on the usage, however it is advisable not to use the cartridge for more than 12 months.

Three versions of the antibacterial cartridges are available:

FRA-STERYLabsolute filtration of 99% 0, 5 micron

FRA-CA STERYLabsolute filtration of 99% 0, 5 micron + granular post activated carbon

FRA-UF STERYLabsolute filtration of 99% 0, 5 micron + hollow fibre ultrafiltration 0.2 micron

Applications:

Domestic drinking water;Pharmaceutical industry;Food and Beverage industry.

Model

CODE DESCRIPTION

A4250300 CARTRIDGE PP MELT BLOWN 93/4 FR0, 5A

A4350460 CARTRIDGE PP MELT BLOWN 20 FR0, 5A

A4190030 CARTRIDGE STERIL 93/4 FR-A + CA (CARTRIDGE PP 0, 5 MICRON+CARBON)

A9030220 CARTRIDGE STERIL 93/4 FR-A + UF (CARTRIDGE PP 0, 2 MICRON)

Big Line is a line of two-piece containers for medium-sized cartridges. It is suitable for situations where a certain quantity of water is consumed. The line comes in the AQUA BIG series, measuring 9 3/4 20 30, with an opaque (White PP) or transparent (Blue SAN) sump. The heads are made with a female threading without brass inserts and with a plastic blow-off valve, in black PP. The containers are designed for wall mounting, and all hold filter cartridges with a 4.5-inch diameter measuring from 9 3/4 20 30. All containers come without cartridges, and have black heads and transparent or blue sumps. Other colors are available upon request for bulk orders.

Technical Features:

Head: PP without brass inserts

Sump: Transparent SAN-PP blue

O-Ring: Silicone

Max working pressure: 8 BAR Max

Burst pressure: 35 BAR Max

Max working temperature: 5C + 50C min./max

Minimum working temperature: 5C

Capacity (empty) at 2 BAR: 1 106, 98 Lt./min. 1 1/2 194, 48 Lt./min.

Model

CODE DESCRIPTION

A1050120 AQUA BIG 1 F V/T 93/4

A1050130 AQUA BIG 11/2 F V/T 93/4

A1050140 AQUA BIG 1 F V/T 20

A1050150 AQUA BIG 11/2 F V/T 20

A1050340 AQUA BIG 11/2 F V/T 30

A1050180 AQUA BIG 1 F V/O 93/4 BLUE BOWL

A1050240 AQUA BIG 11/2 F V/O 93/4 BLUE BOWL

A1050170 AQUA BIG 1 F V/O 20 BLUE BOWL

A1050160 AQUA BIG 11/2 F V/O 20 BLUE BOWL

A1050290 AQUA BIG 11/2 F V/O 30 BLUE BOWL

BIG LINE ACCESSORIES

A6010090 PLASTIC KEY AQUA BIG

DIFFUSER TUBE

A6012080 DIFFUSER TUBE 9 3/4 FOR AQUA BIG

A6012090 DIFFUSER TUBE 20 FOR AQUA BIG

MG010480 O-RING FOR AQUA BIG HOUSING DIFFUSER TUBE

A6012100 DIFFUSER DISC FOR AQUA BIG BLUE

A6012170 DIFFUSER DISC FOR AQUA BIG V/T

DIFFUSER KIT

A6012430 DIFFUSER KIT FOR AQUA BIG OPAQUE 93/4

A6012440 DIFFUSER KIT FOR AQUA BIG OPAQUE 20

A6013050 DIFFUSER KIT FOR AQUA BIG OPAQUE 30

A6012450 DIFFUSER KIT FOR AQUA BIG TRASPARENT 9 3/4

A6012460 DIFFUSER KIT FOR AQUA BIG TRASPARENT 20

A6013080 DIFFUSER KIT FOR AQUA BIG TRASPARENT 30

BRACKETS & SUPPORT

PN020100 SINGLE METAL BRACKET AQUA BIG HOUSING

PN020040 DOUBLE METAL BRACKET AQUA BIG HOUSING

OTHER ACCESSORIES

MG011220 O-RING REF. VMQ70 -140X5 RED SILICONE

Aqua proposes the line of empty CV containers in various heights, completely made of crystal polystyrene, in versions transparent and opaque. Within which to place the various types of filtration products (active carbon, exchange ion resins, polyphosphates) for a physical treatment of water. Reusable. Household etc.

Applications:

Water treatment;Food/Beverage.

Model

CODE DESCRIPTION

A4110070 EMPTY CARTRIDGE 5 CV BLUE

A4110110 EMPTY CARTRIDGE 7 CV BLUE

A4110060 EMPTY CARTRIDGE 93/4 CV BLUE

A4110120 EMPTY CARTRIDGE 20 CV BLUE

A4110010 EMPTY CARTRIDGE 5 CV TRANSPARENT

A4110020 EMPTY CARTRIDGE 7 CV TRASPARENT

A4110030 EMPTY CARTRIDGE 93/4 CV TRANSPARENT

A4110040 EMPTY CARTRIDGE 20 CV TRANSPARENT

A4110090 EMPTY CARTRIDGE 93/4 CV-KID TRANSPARENT

Our Polypropylene wound cartridges are part of the depth and deforming cartridge series. They are manufactured using only 100% pure non-toxic polypropylene yarn. This series offers an excellent ratio between cost/quality, even though usually referred to as economic-type they are manufactured so as to guarantee a high nominal filtration level.WOUND CARTRIDGE OPEN-END WASH OIL RESIDUAL 0, 2% This yarn is manufactured using machinery that allows a shorter production period and therefore a more economically priced product. The raw material used for this product is exactly the same as the Wash Carded type. The only difference is that it is not carded after the process of extrusion & twist but simple manufactured around a BCF (by extrusion spun yarn) making it compact and uniform. Although less compact than the carded one, it still yields a satisfying filtration performance at lower costs. Amongst the inconveniences of this cartridge is that at the beginning of use it creates a small amount of foam that after a short period will disappear. Even if the foam is non-toxic, in certain applications it could cause minor problems to the post-filtration unit. Therefore it is important to know where such cartridge will be applied to avoid any inconvenience. The inside core of the filter is rigid and in Polypropylene which guarantees stability. The lengths range from 4 to 40 and the micron range from 1 to 100.

Applications:

Water treatment, Electronic/Nuclear, Biotechnology/Fine chemicals, Food/Beverage, Coatings/Resins, General Industrial, Bulk chemicals/Petrochemicals, Galvanic.

Technical Features:

The FA cartridges can be used as end-line filtration or as prefiltration, to remove sand, lime and rust.

Model

CODE DESCRIPTION

A4010090 CARTRIDGE 5 FA 1MIC

A4010110 CARTRIDGE 5 FA 5MIC

A4010120 CARTRIDGE 5 FA 10MIC

A4010130 CARTRIDGE 5 FA 20MIC

A4010140 CARTRIDGE 5 FA 30MIC

A4010150 CARTRIDGE 5 FA 50MIC

A4010160 CARTRIDGE 5 FA 100MIC

A4010170 CARTRIDGE 7 FA 1MIC

A4010190 CARTRIDGE 7 FA 5MIC

A4010200 CARTRIDGE 7 FA 10MIC

A4010210 CARTRIDGE 7 FA 20MIC

A4010220 CARTRIDGE 7 FA 30MIC

A4010230 CARTRIDGE 7 FA 50MIC

A4010240 CARTRIDGE 7 FA 100MIC

A4010250 CARTRIDGE 93/4 FA 1MIC

A4010270 CARTRIDGE 93/4 FA 5MIC

A4010280 CARTRIDGE 93/4 FA 10MIC

A4010290 CARTRIDGE 93/4 FA 20MIC

A4010300 CARTRIDGE 93/4 FA 30MIC

A4010310 CARTRIDGE 93/4 FA 50MIC

A4010320 CARTRIDGE 93/4 FA 100MIC

A4010330 CARTRIDGE 10 FA 1MIC

A4010350 CARTRIDGE 10 FA 5MIC

A4010360 CARTRIDGE 10 FA 10MIC

A4010370 CARTRIDGE 10 FA 20MIC

A4010380 CARTRIDGE 10 FA 30MIC

A4010390 CARTRIDGE 10 FA 50MIC

A4010400 CARTRIDGE 10 FA 100MIC

A4010410 CARTRIDGE 20 FA 1MIC

A4010430 CARTRIDGE 20 FA 5MIC

A4010440 CARTRIDGE 20 FA 10MIC

A4010450 CARTRIDGE 20 FA 20MIC

A4010460 CARTRIDGE 20 FA 30MIC

A4010470 CARTRIDGE 20 FA 50MIC

A4010480 CARTRIDGE 20 FA 100MIC

A4010490 CARTRIDGE 30 FA 1MIC

A4010510 CARTRIDGE 30 FA 5MIC

A4010520 CARTRIDGE 30 FA 10MIC

A4010530 CARTRIDGE 30 FA 20MIC

A4010540 CARTRIDGE 30 FA 30MIC

A4010550 &

Our FR-E series, is a break through in technology granting an interesting option to our consolidated and outstanding FR-N series. Because of our melt-blown fabrication and procedure, these FR-E series grant a true compromise for those applications that require a just Price/Quality performance ratio. During the manufacturing phase, and without the essence of the internal core, these cartridges grant a perfect and compact resistance of filtration. Thanks to the method of fabrication and experience gained with our exceptional FRN series, these series offer a mere absence of particle media loss. Vast chemical compatibility because made only with 100% pure polypropylene, insuring nearly infinite applications Laboratory tests show that these series are guaranteed to give at least 80% efficiency of stated particle size confirming its perfect price/quality ratio.

Applications:

The FR-E cartridges can be used as end-line filtration or as prefiltration.

Water treatment Electronic/Nuclear Biotechnology/Fine chemicalsFood/Beverage Coatings/Resins GeneralIndustrial Pharmaceutical/Cosmetics Bulk chemicals/Petrochemicals Galvanic. Model

CODE DESCRIPTION

A4260270P CART.PP MELT-BLOWN SEC 93/4 FR5nE D62 WITH LABEL

A4260290P CART.PP MELT-BLOWN SEC 93/4 FR20nE D62 WITH LABEL

A4260430P CART.PP MELT-BLOWN SEC 20 FR5nE D62 WITH LABEL

A4260450P CART.PP MELT-BLOWN SEC 20 FR20nE D62 WITH LABEL

A426051P CART.PP MELT-BLOWN SEC 30 FR5nE D62 WITH LABEL

A4260530P CART.PP MELT-BLOWN SEC 30 FR20nE D62 WITH LABEL

A4260590P CART.PP MELT-BLOWN SEC 40 FR5nE D62 WITH LABEL

A4260610P CART.PP MELT-BLOWN SEC 40 FR20nE D62 WITH LABEL

A4350120 CART. 9 3/4 FRE AB 5mic

A4350140 CART. 9 3/4 FRE AB 20mic

A4350200 CART. 20 FRE AB 5mic

A4350220 CART. 20 FRE AB 20mic

our depth cartridges fr-n series are designed to obtain a high efficiency and filtration of various liquids having impurity. using only 100% pure polypropylene they are manufactured through state of the art technology. they are generally used in applications that require extremely high quality filtration. during the manufacturing process, the polypropylene is mixed with compressed hot air. then it is stratified on a rigid polypropylene core through a continues and constant rotating movement. this process infuses and intersects the polypropylene fibres amongst themselves. this creates the so called depth cartridge guaranteeing a uniform filtration along all the surface of the cartridge. the polypropylene fibres used are always and only of first choice which processed at high temperatures welds them together eliminating any possibility of losing particles or residuals. the range vary from 1 to 90 micron and standard lengths are 93/4 to 40. the cartridges are made up as one whole piece no matter what length. the fr-n cartridges are fully tested to achieve at least 95% filtration efficiency. this means that a 10 micron fr-n cartridge will filter 95% of particles having a diameter of 10 micron or more. the extraordinary filtration capability of the fr-n cartridges is obtained thanks to its wide filtering surface and compactness which is distributed along all the surface of the cartridge itself. the cartridges need the be changed when a loss in pressure drop is detected or in any case when the specific filtering application requires it.

applications:

the fr-n cartridges can be used as end-line filtration or as prefiltration.

water treatment electronic/nuclear biotechnology/fine chemicals food/beverage coatings/resins general industrial -pharmaceutical/ cosmetics bulk chemicals/petrochemicals galvanic.

model

code description

a4240090 cart.pp melt-blown 5 fr1n

a4240100 cart.pp melt-blown 5 fr3n

a4240110 cart.pp melt-blown 5 fr5n

a4240120 cart.pp melt-blown 5 fr10n

a4240130 cart.pp melt-blown 5 fr20n

a4240140 cart.pp melt-blown 5 fr30n

a4240150 cart.pp melt-blown 5 fr50n

a4240160 cart.pp melt-blown 5 fr90n

a4240250 cart.pp melt-blown 93/4 fr1n

a4240260 cart.pp melt-blown 93/4 fr3n

a4240270 cart.pp melt-blown 93/4 fr5n

a4240280 cart.pp melt-blown 93/4 fr10n

a4240290 cart.pp melt-blown 93/4 fr20n

a4240300 cart.pp melt-blown 93/4 fr30n

a4240310 cart.pp melt-blown 93/4 fr50na4240320 cart.pp melt-blown 93/4 fr90n

a4240330 cart.pp melt-blown 10 fr1n

a4240340 cart.pp melt-blown 10 fr3n

a4240350 cart.pp melt-blown 10 fr5n

a4240360 cart.pp melt-blown 10 fr10n

a4240370 cart.pp melt-blown 10 fr20n

a4240380 cart.pp melt-blown 10 fr30n

a4240390 cart.pp melt-blown 10 fr50n

a4240400 cart.pp melt-blown 10 fr90n

a4240410 cart.pp melt-blown 20 fr1n

a4240420 cart.pp melt-blown 20 fr3n

a4240430 cart.pp melt-blown 20 fr5n

a4240440 cart.pp melt-blown 20 fr10n

a4240450 cart.pp melt-blown 20 fr20n

a4240460 cart.pp melt-blown 20 fr30n

a4240470 cart.pp melt-blown 20 fr50n

a4240480 cart.pp melt-blown 20 fr90n

a4240490 cart.pp melt-blown 30 fr1n

a4240500 cart.pp melt-blown 30 fr3n

a4240510 cart.pp melt-blown 30 fr5n

a4240520 cart.pp melt-blown 30 fr10n

a4240530 cart.pp melt-blown 30 fr20n

a4240540 cart.pp melt-blown 30 fr30n

a4240550 cart.pp melt-blown 3

FP2 Duplex filter cartridge housings with brass inserts and transparent SAN sump or opaque white sump.

Technical Features:

Head: PP with brass inserts

Sump: Transparent SAN-PP white

O-Ring: NBR 70 Sh A

Max working pressure: 8 BAR Max

Burst pressure: 35 BAR Max

Max working temperature: 5C + 50C min./max

Minimum working temperature: 5C

Capacity (empty) at 2 BAR: 3/4F 108, 50 Lt./min. 1F 106, 60 Lt./min.

Life test: 200, 000 cicles from 0-10 BAR

Model

CODE DESCRIPTION

A1120010 DUPLEX FP2 V/T 9 3/4 FI 3/4

A1120020 DUPLEX FP2 V/T 9 3/4 FI 1

A1120110 DUPLEX FP2 V/O 9 3/4 FI 3/4

A1120310 DUPLEX FP2 V/O 20 FI 3/4

A1120120 DUPLEX FP2 V/O 9 3/4 FI 1A1120320 DUPLEX FP2 V/O 20 FI 1

The heads are made with female-threaded ports with brass inserts and brass blow-off valves. The heads are designed for wall mounting. All containers allow handling medium capacities and are particularly suitable for domestic and residential use. The housings are supplied empty (without cartridge) with black head and transparent (blue SAN) sump. Other colors are available upon request for bulk orders. The package is neutral but may be personalized upon request for bulk orders.
Height: 9 3/4;
Inlet-Outlet high resistance brass ports, 3/4 1 BSP threaded;
Suitable for all range of AQUA cartridges model DOE;
Up to 50 C (122 F) and 8 BAR (116 PSI) working condition.

Model

CODE DESCRIPTION

A1122010 DUPLEX GIBO FP2 V/T 9 3/4 FI 3/4

A1122020 DUPLEX GIBO FP2 V/T 9 3/4 FI 1

The heads are made with female-threaded ports with brass inserts and brass blow-off valves. The heads are designed for wall mounting. All containers allow handling medium capacities and are particularly suitable for domestic and residential use. The housings are supplied empty (without cartridge) with black head and transparent (blue SAN) sump. Other colors are available upon request for bulk orders. The package is neutral but may be personalized upon request for bulk orders.
Height: 9 3/4;
Inlet-Outlet high resistance brass ports, 3/4 1 BSP threaded;
Suitable for all range of AQUA cartridges model DOE;
Up to 50 C (122 F) and 8 BAR (116 PSI) working condition.

Model

CODE DESCRIPTION

A1132010 TRIPLEX GIBO FP2 V/T 9 3/4 FI 3/4

A1132020 TRIPLEX GIBO FP2 V/T 9 3/4 FI 1

FP3 Duplex filter cartridge housings with brass inserts and transparent SAN sump or opaque white sump.

Model

CODE DESCRIPTION

A1120320 DUPLEX FP2 V/O 20 FI 1

A1121010 DUPLEX FP3 V/T 9 3/4 FI 3/4

A1121210 DUPLEX FP3 V/T 20 FI 3/4

A1121020 DUPLEX FP3 V/T 9 3/4 FI 1

A1121220 DUPLEX FP3 V/T 20 FI 1

A1121110 DUPLEX FP3 V/O 9 3/4 FI 3/4

A1121310 DUPLEX FP3 V/O 20 FI 3/4

A1121120 DUPLEX FP3 V/O 9 3/4 FI 1

1121320 DUPLEX FP3 V/O 20 FI 1

FP3 Triplex filter cartridge housings with brass inserts and transparent SAN sump or opaque white sump.

Model

CODE DESCRIPTION

A1131010 TRIPLEX FP3 V/T 9 3/4 FI 3/4

A1131210 TRIPLEX FP3 V/T 20 FI 3/4

A1131020 TRIPLEX FP3 V/T 9 3/4 FI 1

A1131220 TRIPLEX FP3 V/T 20 FI 1

A1131110 TRIPLEX FP3 V/O 9 3/4 FI 3/4

A1131310 TRIPLEX FP3 V/O 20 FI 3/4

A1131120 TRIPLEX FP3 V/O 9 3/4 FI 1

A1131320 TRIPLEX FP3 V/O 20 FI 1

Professional housing completely made in natural PP, with VITON
gaskets.
As completely produced with first rate thermoplastic polymers, FP2 ALL-PP filters are suitable for both industrial and food and beverage applications, where high standards of clean quality and performance are needed. These housing can function with a temperature up to 40C and
pressure up to 6 bar.
VITON gaskets guarantee a perfect watertight and chemical compatibility.
Available in 9 3/4 and 20 size;
High endurance Inlet-Outlet connections with female threads BSP 1/2- 3/4-1;
Compatible with all AQUAs range cartridges;
Working condition up to 40C (100F) and 6 BARS (87 PSI).

Model

CODE DESCRIPTION

A1090010 FP2 ALL PP 1/2 F SVS 9 3/4 AQUA

A1090020 FP2 ALL PP 3/4 F SVS 9 3/4 AQUA

A1090030 FP2 ALL PP 1 F SVS 9 3/4 AQUA

A1090040 FP2 ALL PP 1/2 F SVS 20 AQUA

A1090050 FP2 ALL PP 3/4 F SVS 20 AQUA

A1090060 FP2 ALL PP 1 F SVS 20 AQUA

HIGH COMPATIBILITY ACCESSORIES

A6010010 PLASTIC KEY FP2-FP3

A6010930 SINGLE PLASTIC BRACKET FP2-FP3 HOUSING

MG010340 O-RING REF. 6362 VITON

The brass head container, comes with a transparent SAN or TROGAMID sump. All containers are designed to hold standard filter cartridges measuring 5-7-93/4-20 inches, with heads designed for wall mounting, and allow handling medium capacities. The line is suitable for products used in the semi-professional and the professional sector, where excellent performance is required due to the presence of chemicals and high working pressures and temperatures.

Model

CODE DESCRIPTION

A3010010 F03 3/4 F V/T 5

A3010020 F03 3/4 F V/T 7

A3010030 F03 3/4 F V/T 93/4

A3010040 F03 3/4 F V/T 20

A3010050 F03 1 F V/T 5

A3010060 F03 1 F V/T 7

A3010070 F03 1 F V/T 93/4

A3010080 F03 1 F V/T 20

A3010090 F03 11/4 F V/T 7

A3010100 F03 11/4 F V/T 93/4

A3010110 F03 11/4 F V/T 20

A3010120 F03 1 1/2 F V/T 93/4

A3010130 F03 11/2 F V/T 20

A3010140 F03 2 F V/T 93/4

A3010150 F03 2 F V/T 20

A3020010 F03 3/4 F V/T 5 TROGAMID

A3020020 F03 3/4 F V/T 7 TROGAMID

A3020030 F03 3/4 F V/T 93/4 TROGAMID

A3020050 F03 1 F V/T 5 TROGAMID

A3020060 F03 1 F V/T 7 TROGAMID

A3020070 F03 1 F V/T 93/4 TROGAMID

A3020090 F03 11/4 F V/T 7 TROGAMID

A3020100 F03 11/4 F V/T 93/4 TROGAMID

A3020120 F03 1 1/2 F V/T 93/4 TROGAMID

A3020140 F03 2 F V/T 93/4 TROGAMID

A3040010 F03 3/4 F V/O 9 3/4 WHITE

A3040030 F03 1 F V/O 9 3/4 WHITE

A3040050 F03 1 1/4 F V/O 9 3/4 WHITE

A3040070 F03 1 1/2 F V/O 9 3/4 WHITE

A3040090 F03 2 F V/O 9 3/4 WHITE

A3030070 F03 3/4 F V/AISI 304 9 3/4 W/ DRAIN FAUCET

A3030080 F03 1 F V/AISI 304 9 3/4 W/ DRAIN FAUCET

A3030090 F03 1 1/4 F V/AISI 304 9 3/4 W/ DRAIN FAUCET

A3030100 F03 11/2 F V/AISI 304 9 3/4 W/ DRAIN FAUCET

A3030110 F03 2 F V/AISI 304 9 3/4 W/ DRAIN FAUCET

Professional Housing for extreme working condition. Made of glass-reinforced high quality thermoplastic polymer, FP2 HT filter housings are a technical alternative to Brass and Stainless housings.
These housings can withstand temperatures up to a maximum of 90C and pressure up to 8 bar. Excellent chemical compatibility makes FP2 HT housings an ideal choice for a wide variety of industrial applications.
High quality VITON o-ring for a perfect sealing.
Available in 93/4 and 20 length;
With In-Out high resistance thread BSP 1/2-3/4-1 female;
Excellent alternative to brass and stainless housings;
Suitable for All Range of AQUA cartridges;
Up to 90C (194F) and 8 bar (116 PSI) working condition.

Model

CODE DESCRIPTION

A1110010 FP2 HT PP 1/2 F SVS 9 3/4 AQUA

A1110020 FP2 HT PP 3/4 F SVS 9 3/4 AQUA

A1110030 FP2 HT PP 1 F SVS 9 3/4 AQUA

A1110040 FP2 HT PP 1/2 F SVS 20 AQUA

A1110050 FP2 HT PP 3/4 F SVS 20 AQUA

A1110060 FP2 HT PP 1 F SVS 20 AQUA

HIGH TEMPERATURE ACCESSORIES

A6010010 PLASTIC KEY FP2-FP3

PN020010 SINGLE METAL BRACKET FP2-FP3 HOUSING

PN020030 DOUBLE METAL BRACKET FP2-FP3 HOUSING

MG010340 O-RING REF. 6362 VITON

Cartridges series In-Line are designed to meet the needs of small footprint. Thanks to the technology of realization do not need a dedicated container but can be assembled directly in the line of flow of the water to be treated.

The In-Out female couplings 1/4 NPT easily adapt to rapid connections with flexible hoses (available on request).

The cartridges are made of non-toxic material (PP) and are available with the following filter media:

PP for sediment filtration, CA for reducing chlorine and odors, UF for reducing bacterial load.

Model

CODE DESCRIPTION

P9020340 CARTRIDGE SEDIMENT IN-LINE 10 1/4 FNPT WHITE

A9020060 CARTRIDGE CARBON 1/4 X 1/4

P9020270 CARTRIDGE ULTRAFILTRACION 10 IN-LINE 1/4 FNPT WHITE

AQUA offers various polyphosphate cartridges that defer in sizes and with defined characteristics.

Polyphosphate salts are anti-scaling chemical agents. Therefore ideal for use with hard calcareous water, and where eliminating of scale and corrosion is required.

A polyphosphate cartridge consists of a plastic canister filled with crystal salts of different mesh. The canisters can vary in size. Once the polyphosphate salt has dissolved a chemical reaction takes place withholding the suspended particles. This prevents scaling and depositing of the particles along pipelines or inside mechanical components, avoiding inefficiency.

To be efficient, all polyphosphate cartridge require a determined time of water contact. However, thanks to its fast dissolving effect this period is relatively short.

Polyphosphate cartridges have a low pressure drop. Usually they are used in industrial applications. Standard regulations require that only minimal dosage is allowed when applied to drinking water. Therefore, in these cases, it is necessary to have an accurate and controlled dosage guaranteed by a dosing pump (see our Dosing Systems Product Guide).

It is important to fully understand the use of such cartridges so as to determine the correct application. For applications and maintenance, please refer to the data sheet indicated for each model.

Cartridges with ionic exchange resin are used for eliminating ionic substance which are present in water.

According to the type of filter media used, they can by applied for treating water with calcium and magnesium, reducing the presence of iron and obtain de-mineralized water.

All cartridges are assembled with a pre and post filtration. This optimizes the efficiency of the resin for water inbound and improves the quality of the treated water outbound. Similar to the GAC cartridges, the Pre & post filters are made of melt blown which is of the same technology used for our FR-N cartridges.

This technology guarantees a very efficient filtering action.

Model

CODE DESCRIPTION

A4150010 CARTRIDGE 93/4 RC PP5M

A4150040 CARTRIDGE 20 RC PP5M

A4150050 CARTRIDGE 93/4 RC PP5M AQUA BIG

A4150060 CARTRIDGE 20 RC PP5M AQUA BIG

A4150070 CARTRIDGE 93/4 RCA (DEMI) PP5M

A4150080 CARTRIDGE 20 RCA (DEMI) PP5M

A4150090 CARTRIDGE 93/4 RCA (DEMI) PP5M AQUA BIG

A4150100 CARTRIDGE 20 RCA (DEMI) PP5M AQUA BIG

A4150110 CARTRIDGE 20 FE (MAZ) PP40M AQUA BIG

AQUA KID handles medium capacity while featuring reduced dimensions. The head of Aqua Kid has three-way coupling to allow straight line or square assembly, depending on the size of the installation area.

AQUA KID ECO is the alternative to the classical Aqua Kid container. While featuring the same technical characteristics, the head on AQUA KID ECO has a different look, and the container comes in an economical package.

Model

CODE DESCRIPTION

A1010140 AQUA KID 2P 1/2 FI V/T 5

A1010470 AQUA KID ECO 2P 1/2 FI V/T 5

A1010670 AQUA KID 2P 3/4 FI V/T 5

AQUA KID handles medium capacity while featuring reduced dimensions. The head of Aqua Kid has three-way coupling to allow straight line or square assembly, depending on the size of the installation area.

AQUA KID ECO is the alternative to the classical Aqua Kid container. While featuring the same technical characteristics, the head on AQUA KID ECO has a different look, and the container comes in an economical package.

Model

CODE DESCRIPTION

A2011150 AQUA KID 3P 1/2 FI V/TA2011180 AQUA KID 3P 3/4 FI V/T 5

A2011190 AQUA KID 3P 1/2 FI V/T 93/4

A2011200 AQUA KID 3P 3/4 FI V/T 93/4

A2011210 AQUA KID ECO 3P 1/2 FI V/T 5

A2011220 AQUA KID ECO 3P 1/2 FI V/T 93/4

SHORT LINE ACCESSORIES

A6011800 PLASTIC PLUG 1/2 + O-RING

A6012380 PLASTIC PLUG 3/4 + O-RING

A6010220 PLASTIC KEY AQUA KID

A6012370 SINGLE PLASTIC BRACKETFOR AQUA KID (NO ECO)

A6010100 DIFFUSER TUBE 5 FOR FP2-FP3

A6011370 DIFFUSER DISC FOR AQUA KID

PG010060 O-RING FOR STANDARD HOUSING DIFFUSER TUBE

MG010200 OR FOR AQUAKID SUMP 68, 26 X 3, 53 REF.171

A6010120 DIFFUSER TUBE 9 3/4 FOR FP2-FP3

This is a line of containers for small and extremely small cartridges. The line has been specially designed for applications where there is reduced installation space and minimum capacity. The Short Line includes the Micro Aqua, Mini Aqua, Aqua Net, Aqua Kid and Aqua Kid Eco filters. All the containers in the line come without cartridges, and have white heads and transparent (Blue SAN) or white (Opaque PP) sump. Other colors are available upon request for bulk orders. MICRO and MINI AQUA are the smallest containers in the series. The unique shape of the head on these containers allows direct installation on the wall. These containers are particularly suitable for pre-filtering treatment on small electrical appliances and in any situation where a minimum amount of water is required.

Model

CODE DESCRIPTION

A8030330 AQUA-MICRO 1/4 F TRANSPARENT BOWL

A8030340 AQUA-MICRO 3/8 F TRANSPARENT BOWL

A8030230 AQUA-MINI 1/4 F TRANSPARENT BOWL

A8030240 AQUA-MINI 3/8 F TRANSPARENT BOWL

AQUA NET has been specially designed for vertical installation with in-take at the bottom and out-put at the top.

Aqua Net is ideal for small-capacity devices and small areas, and can be applied to pipe fittings, hydro-cleaning machines, and beverage distributors

Model

CODE DESCRIPTION

A8030110 AQUA-NET 3/4 F TRANSPARENT BOWL

The heads are made with female-threaded ports with brass inserts and brass blow-off valves. The heads are designed for wall mounting. All containers allow handling medium capacities and are particularly suitable for domestic and residential use. The housings are supplied empty (without cartridge) with black head and transparent (blue SAN) sump. Other colors are available upon request for bulk orders. The package is neutral but may be personalized upon request for bulk orders.
Height: 9 3/4;
Inlet-Outlet high resistance brass ports, 3/4 1 BSP threaded;
Suitable for all range of AQUA cartridges model DOE;
Up to 50 C (122 F) and 8 BAR (116 PSI) working condition.

Model

CODE DESCRIPTION

A1010810 FP2 GIBO 3/4 FI V/T 93/4

A1010820 FP2 GIBO 1 FI V/T 93/4

FP2/1 Aquafin filter cartridge housings with brass inserts and transparent SAN sump or opaque white sump.

Model

CODE DESCRIPTION

A1010500 FP2/1 1/2 FI V/T 5

A1010510 FP2/1 1/2 FI V/T 7

A1010520 FP2/1 1/2 FI V/T 93/4

A1010530 FP2/1 3/4 FI V/T 5

A1010540 FP2/1 3/4 FI V/T 7

A1010430 FP2/1 3/4 FI V/T 93/4

A1010550 FP2/1 1 FI V/T 5

A1010560 FP2/1 1 FI V/T 7

A1010440 FP2/1 1 FI V/T 93/4

A1040500 FP2/1 1/2 FI V/O 5 WHITE BOWL

A1040510 FP2/1 1/2 FI V/O 7 WHITE BOWL

A1040520 FP2/1 1/2 FI V/O 93/4 WHITE BOWL

A1040530 FP2/1 1/2 FI V/O 20 WHITE BOWL

A1040540 FP2/1 3/4 FI V/O 5 WHITE BOWL

A1040550 FP2/1 3/4 FI V/O 7 WHITE BOWL

A1040560 FP2/1 3/4 FI V/O 93/4 WHITE BOWL

A1040570 FP2/1 3/4 FI V/O 20 WHITE BOWL

A1040580 FP2/1 1 FI V/O 5 WHITE BOWL

A1040590 FP2/1 1 FI V/O 7 WHITE BOWL

A1040600 FP2/1 1 FI V/O 93/4 WHITE BOWL

A1040610 FP2/1 1 FI V/O 20 WHITE BOWL

FP2/2 Hydro filter cartridge housings with brass inserts and transparent SAN sump or opaque white sump.

Model

CODE DESCRIPTION

A1010160 FP2/2 1/2 FI V/T 5

A1010170 FP2/2 1/2 FI V/T 7

A1010180 FP2/2 1/2 FI VT 93/4

A1010270 FP2/2 3/4 FI V/T 5

A1010280 FP2/2 3/4 FI V/T 7

A1010290 FP2/2 3/4 FI V/T 93/4

A1010250 FP2/2 1 FI V/T 5

A1010190 FP2/2 1 FI V/T 7

A1010200 FP2/2 1 FI V/T 93/4

A1040210 FP2/2 1/2 FI V/O 5 WHITE BOWL

A1040220 FP2/2 1/2 FI V/O 7 WHITE BOWL

A1040230 FP2/2 1/2 FI V/O 93/4 WHITE BOWL

A1040240 FP2/2 1/2 FI V/O 20 WHITE BOWL

A1040250 FP2/2 3/4 FI V/O 5 WHITE BOWL

A1040260 FP2/2 3/4 FI V/O 7 WHITE BOWL

A1040270 FP2/2 3/4 FI V/O 93/4 WHITE BOWL

A1040280 FP2/2 3/4 FI V/O 20 WHITE BOWL

A1040290 FP2/2 1 FI V/O 5 WHITE BOWL

A1040300 FP2/2 1 FI V/O 7 WHITE BOWL

A1040310 FP2/2 1 FI V/O 93/4 WHITE BOWL

A1040320 FP2/2 1 FI V/O 20 WHITE BOWL

FP2/3 Aqualux filter cartridge housings with brass inserts and transparent SAN sump or opaque white sump.

FP2/4 Sirio filter cartridge housings without brass inserts and transparent SAN sump or opaque white sump.

Model

CODE DESCRIPTION

A1070010 FP2/4 1/4 F V/T 5 SIRIO

A1070020 FP2/4 1/4 F V/T 93/4 SIRIO

A1070030 FP2/4 1/4 F V/T 20 SIRIO

A1070040 FP2/4 3/8 F V/T 5 SIRIO

A1070050 FP2/4 3/8 F V/T 93/4 SIRIO

A1070060 FP2/4 3/8 F V/T 20 SIRIO

A1070070 FP2/4 1/2 F V/T 5 SIRIO

A1070080 FP2/4 1/2 F V/T 93/4 SIRIO

A1070090 FP2/4 1/2 F V/T 20 SIRIO

A1070100 FP2/4 3/4 F V/T 5 SIRIO

A1070110 FP2/4 3/4 F V/T 93/4 SIRIO

A1070120 FP2/4 3/4 F V/T 20 SIRIO

A1080010 FP2/4 1/4 F V/O 5 WHITE BOWL SIRIO

A1080020 FP2/4 1/4 F V/O 93/4 WHITE BOWL SIRIO

A1080030 FP2/4 1/4 F V/O 20 WHITE BOWL SIRIO

A1080040 FP2/4 3/8 F V/O 5 WHITE BOWL SIRIO

A1080050 FP2/4 3/8 F V/O 93/4 WHITE BOWL SIRIO

A1080060 FP2/4 3/8 F V/O 20 WHITE BOWL SIRIO

A1080070 FP2/4 1/2 F V/O 5 WHITE BOWL SIRIO

A1080080 FP2/4 1/2 F V/O 93/4 WHITE BOWL SIRIO

A1080090 FP2/4 1/2 F V/O 20 WHITE BOWL SIRIO

A1080100 FP2/4 3/4 F V/O 5 WHITE BOWL SIRIO

A1080110 FP2/4 3/4 F V/O 93/4 WHITE BOWL SIRIO

A1080120 FP2/4 3/4 F V/O 20 WHITE BOWL SIRIO

FP3/1 Aquafin filter cartridge housings with brass inserts and transparent SAN sump or opaque white sump.

Model

CODE DESCRIPTION

A2010730 FP3/1 1/2 FI V/T 5

A2010910 FP3/1 1/2 FI V/T 7

A2010470 FP3/1 1/2 FI V/T 93/4

A2010920 FP3/1 1/2 FI V/T 20

A2010930 FP3/1 3/4 FI V/T 5

A2010940 FP3/1 3/4 FI V/T 7

A2010320 FP3/1 3/4 FI V/T 93/4

A2010660 FP3/1 3/4 FI V/T 20

A2010950 FP3/1 1 FI V/T 5

A2010790 FP3/1 1 FI V/T 7

A2010310 FP3/1 1 FI V/T 93/4

A2010780 FP3/1 1 FI V/T 20

A2040720 FP3/1 1/2 FI V/O 5 WHITE BOWL

A2040730 FP3/1 1/2 FI V/O 7 WHITE BOWL

A2040740 FP3/1 1/2 FI V/O 93/4 WHITE BOWL

A2040750 FP3/1 1/2 FI V/O 20 WHITE BOWL

A2040760 FP3/1 3/4 FI V/O 5 WHITE BOWL

A2040770 FP3/1 3/4 FI V/O 7 WHITE BOWL

A2040520 FP3/1 3/4 FI V/O 93/4 WHITE BOWL

A2040780 FP3/1 3/4 FI V/O 20 WHITE BOWL

A2040790 FP3/1 1 FI V/O 5 WHITE BOWL

A2040800 FP3/1 1 FI V/O 7 WHITE BOWL

A2040580 FP3/1 1 FI V/O 93/4 WHITE BOWL

A2040630 FP3/1 1 FI V/O 20 WHITE BOWL

FP3/2 Hydro filter cartridge housings without brass inserts and transparent SAN sump or opaque white sump.

Model

CODE DESCRIPTION

A2010510 FP3/2 1/2 FI V/T 5

A2010270 FP3/2 1/2 FI V/T 7

A2010280 FP3/2 1/2 FI V/T 9 3/4

A2010670 FP3/2 1/2 FI V/T 20

A2010520 FP3/2 3/4 FI V/T 5

A2010530 FP3/2 3/4 FI V/T 7

A2010540 FP3/2 3/4 FI V/T 93/4

A2010680 FP3/2 3/4 FI V/T 20

A2010550 FP3/2 1 FI V/T 5

A2010560 FP3/2 1 FI V/T 7

A2010570 FP3/2 1 FI V/T 93/4

A2010690 FP3/2 1 FI V/T 20

A2040260 FP3/2 1/2 FI V/O 5 WHITE BOWL

A2040270 FP3/2 1/2 FI V/O 7 WHITE BOWL

A2040280 FP3/2 1/2 FI V/O 93/4 WHITE BOWL

A2040450 FP3/2 1/2 FI V/O 20 WHITE BOWL

A2040290 FP3/2 3/4 FI V/O 5 WHITE BOWL

A2040300 FP3/2 3/4 FI V/O 7 WHITE BOWL

A2040310 FP3/2 3/4 FI V/O 93/4 WHITE BOWL

A2040460 FP3/2 3/4 FI V/O 20 WHITE BOWL

A2040330 FP3/2 1 FI V/O 7 WHITE BOWL

A2040340 FP3/2 1 FI V/O 93/4 WHITE BOWL

A2040470 FP3/2 1 FI V/O 20 WHITE BOWL

FP3/3 Aqualux filter cartridge housings without brass inserts and transparent SAN sump or opaque white sump.

Model

CODE DESCRIPTION

A2010580 FP3/3 1/2 FI V/T 5

A2010590 FP3/3 1/2 FI V/T 7

A2010500 FP3/3 1/2 FI V/T 93/4

A2010700 FP3/3 1/2 FI V/T 20

A2010600 FP3/3 3/4 FI V/T 5

A2010610 FP3/3 3/4 FI V/T 7

A2010620 FP3/3 3/4 FI V/T 93/4

A2010710 FP3/3 3/4 FI V/T 20

A2010630 FP3/3 1 FI V/T 5

A2010640 FP3/3 1 FI V/T 7

A2010650 FP3/3 1 FI V/T 93/4

A2010720 FP3/3 1 FI V/T 20

A2040350 FP3/3 1/2 FI V/O 5 WHITE BOWL

A2040360 FP3/3 1/2 FI V/O 7 WHITE BOWL

A2040370 FP3/3 1/2 FI V/O 93/4 WHITE BOWL

A2040480 FP3/3 1/2 FI V/O 20 WHITE BOWL

A2040380 FP3/3 3/4 FI V/O 5 WHITE BOWL

A2040390 FP3/3 3/4 FI V/O 7 WHITE BOWL

A2040400 FP3/3 3/4 FI V/O 93/4 WHITE BOWL

A2040490 FP3/3 3/4 FI V/O 20 WHITE BOWL

A2040410 FP3/3 1 FI V/O 5 WHITE BOWL

A2040420 FP3/3 1 FI V/O 7 WHITE BOWL

A2040430 FP3/3 1 FI V/O 93/4 WHITE BOWL

A2040500 FP3/3 1 FI V/O 20 WHITE BOWL

Sirio Fast filter cartridge housings, PP white housing and sump and with or without brass inserts.

Model

CODE DESCRIPTION

A1081000 FP2 SIRIO FAST 5 3/8 J.G. AQUA

A1081010 FP2 SIRIO FAST 9 3/4 3/8 J.G. AQUA

A1081030 FP2 SIRIO FAST 5 3/8 AQUA

A1081040 FP2 SIRIO FAST 9 3/4 3/8 AQUA

A1081060 FP2 SIRIO FAST 5 FI 1/2 AQUA

A1081070 FP2 SIRIO FAST 9 3/4 FI 1/2 AQUA

A1081080 FP2 SIRIO FAST 20 FI 1/2 AQUA

A1081090 FP2 SIRIO FAST 5 FI 3/4 AQUA

A1081100 FP2 SIRIO FAST 9 3/4 FI 3/4 AQUA

A1081110 FP2 SIRIO FAST 20 FI 3/4 AQUA

A1081120 FP2 SIRIO FAST 5 FI 1 AQUA

A1081130 FP2 SIRIO FAST 9 3/4 FI 1 AQUA

A1081140 FP2 SIRIO FAST 20 FI 1 AQUA

FP2 filter cartridge housings with brass inserts and transparent SAN sump or opaque white sump.

Model

CODE DESCRIPTION

A1010010 FP2 1/2 FI V/T 5

A1010020 FP2 1/2 FI V/T 7

A1010030 FP2 1/2 FI V/T 93/4

A1010040 FP2 3/4 FI V/T 5

A1010050 FP2 3/4 FI V/T 7

A1010060 FP2 3/4 FI V/T 93/4

A1010070 FP2 1 FI V/T 5

A1010080 FP2 1 FI V/T 7

A1010090 FP2 1 FI V/T 93/4

A1010100 FP2 11/4 FI V/T 5

A1010110 FP2 11/4 FI V/T 7

A1010120 FP2 11/4 FI V/T 93/4

A1010130 FP2 11/2 FI V/T 93/4

A1040010 FP2 1/2 FI V/O 5 WHITE BOWL

A1040020 FP2 1/2 FI V/O 7 WHITE BOWL

A1040030 FP2 1/2 FI V/O 93/4 WHITE BOWL

A1040040 FP2 1/2 FI V/O 20 WHITE BOWL

A1040050 FP2 3/4 FI V/O 5 WHITE BOWL

A1040060 FP2 3/4 FI V/O 7 WHITE BOWL

A1040070 FP2 3/4 FI V/O 93/4 WHITE BOWL

A1040080 FP2 3/4 FI V/O 20 WHITE BOWL

A1040090 FP2 1 FI V/O 5 WHITE BOWL

A1040100 FP2 1 FI V/O 7 WHITE BOWL

A1040110 FP2 1 FI V/O 93/4 WHITE BOWL

A1040120 FP2 1 FI V/O 20 WHITE BOWL

A1040130 FP2 11/4 FI V/O 5 WHITE BOWL

A1040140 FP2 11/4 FI V/O 7 WHITE BOWL

A1040150 FP2 11/4 FI V/O 93/4 WHITE BOWL

A1040160 FP2 11/4 FI V/O 20 WHITE BOWL

A1040170 FP2 11/2 FI V/O 93/4 WHITE BOWL

A1040180 FP2 11/2 FI V/O 20 WHITE BOWL

FP2 filter cartridge housings without brass inserts and transparent SAN sump or opaque white sump.

Model

CODE DESCRIPTION

A1020010 FP2 1/4 F V/T 5

A1020020 FP2 1/4 F V/T 7

A1020030 FP2 1/4 F V/T 93/4

A1020040 FP2 3/8 F V/T 5

A1020050 FP2 3/8 F V/T 7

A1020060 FP2 3/8 F V/T 93/4

A1020070 FP2 1/2 F V/T 5

A1020080 FP2 1/2 F V/T 7

A1020090 FP2 1/2 F V/T 93/4

A1020100 FP2 3/4 F V/T 5

A1020110 FP2 3/4 F V/T 7

A1020120 FP2 3/4 F V/T 93/4

A1020130 FP2 1 F V/T 5

A1020140 FP2 1 F V/T 7

A1020150 FP2 1 F V/T 93/4

A1030010 FP2 1/4 F V/O 5 WHITE BOWL

A1030020 FP2 1/4 F V/O 7 WHITE BOWL

A1030030 FP2 1/4 F V/O 93/4 WHITE BOWL

A1030040 FP2 1/4 F V/O 20 WHITE BOWL

A1030050 FP2 3/8 F V/O 5 WHITE BOWL

A1030060 FP2 3/8 F V/O 7 WHITE BOWL

A1030070 FP2 3/8 F V/O 93/4 WHITE BOWL

A1030080 FP2 3/8 F V/O 20 WHITE BOWL

A1030090 FP2 1/2 F V/O 5 WHITE BOWL

A1030100 FP2 1/2 F V/O 7 WHITE BOWL

A1030110 FP2 1/2 F V/O 93/4 WHITE BOWL

A1030120 FP2 1/2 F V/O 20 WHITE BOWL

A1030130 FP2 3/4 F V/O 5 WHITE BOWL

A1030140 FP2 3/4 F V/O 7 WHITE BOWL

A1030150 FP2 3/4 F V/O 93/4 WHITE BOWL

A1030160 FP2 3/4 F V/O 20 WHITE BOWL

A1030170 FP2 1 F V/O 5 WHITE BOWL

A1030180 FP2 1 F V/O 7 WHITE BOWL

A1030190 FP2 1 F V/O 93/4 WHITE BOWL

A1030200 FP2 1 F V/O 20 WHITE BOWL

FP3 filter cartridge housings without brass inserts and transparent SAN sump or opaque white sump.

Model

CODE DESCRIPTION

A2020010 FP3 1/4 F V/T 5

A2020020 FP3 1/4 F V/T 7

A2020030 FP3 1/4 F V/T 93/4

A2020040 FP3 1/4 F V/T 20

A2020050 FP3 3/8 F V/T 5

A2020060 FP3 3/8 F V/T 7

A2020070 FP3 3/8 F V/T 93/4

A2020080 FP3 3/8 F V/T 20

A2020090 FP3 1/2 F V/T 5

A2020100 FP3 1/2 F V/T 7

A2020110 FP3 1/2 F V/T 93/4

A2020120 FP3 1/2 F V/T 20

A2020130 FP3 3/4 F V/T 5

A2020140 FP3 3/4 F V/T 7

A2020150 FP3 3/4 F V/T 93/4

A2020160 FP3 3/4 F V/T 20

A2020170 FP3 1 F V/T 5

A2020180 FP3 1 F V/T 7

A2020190 FP3 1 F V/T 93/4

A2020200 FP3 1 F V/T 20

A2030010 FP3 1/4 F V/O 5 WHITE BOWL

A2030020 FP3 1/4 F V/O 7 WHITE BOWL

A2030030 FP3 1/4 F V/O 93/4 WHITE BOWL

A2030040 FP3 1/4 F V/O 20 WHITE BOWL

A2030050 FP3 3/8 F V/O 5 WHITE BOWL

A2030060 FP3 3/8 F V/O 7 WHITE BOWL

A2030070 FP3 3/8 F V/O 93/4 WHITE BOWL

A2030080 FP3 3/8 F V/O 20 WHITE BOWL

A2030090 FP3 1/2 F V/O 5 WHITE BOWL

A2030100 FP3 1/2 F V/O 7 WHITE BOWL

A2030110 FP3 1/2 F V/O 93/4 WHITE BOWL

A2030120 FP3 1/2 F V/O 20 WHITE BOWL

A2030130 FP3 3/4 F V/O 5 WHITE BOWL

A2030140 FP3 3/4 F V/O 7 WHITE BOWL

A2030150 FP3 3/4 F V/O 93/4 WHITE BOWL

A2030160 FP3 3/4F V/O 20 WHITE BOWL

A2030170 FP3 1 F V/O 5 WHITE BOWL

A2030180 FP3 1 F V/O 7 WHITE BOWL

A2030190 FP3 1 F V/O 93/4 WHITE BOWL

A2030200 FP3 1 F V/O 20 WHITE BOWL

FP3 filter cartridge housings with brass inserts and transparent SAN sump or opaque white sump.

Model

CODE DESCRIPTION

A2010010 FP3 1/2 FI V/T 5

A2010020 FP3 1/2 FI V/T 7

A2010030 FP3 1/2 FI V/T 93/4

A2010040 FP3 1/2 FI V/T 20

A2010050 FP3 3/4 FI V/T 5

A2010060 FP3 3/4 FI V/T 7

A2010070 FP3 3/4 FI V/T 93/4

A2010080 FP3 3/4 FI V/T 20

A2010090 FP3 1 FI V/T 5

A2010100 FP3 1 FI V/T 7

A2010110 FP3 1 FI V/T 93/4

A2010120 FP3 1 FI V/T 20

A2010130 FP3 11/4 FI V/T 5

A2010140 FP3 11/4 FI V/T 7

A2010150 FP3 11/4 FI V/T 93/4

A2010160 FP3 11/4 FI V/T 20

A2010170 FP3 11/2 FI V/T 93/4

A2010180 FP3 11/2 FI V/T 20

A2040010 FP3 1/2 FI V/O 5 WHITE BOWL

A2040020 FP3 1/2 FI V/O 7 WHITE BOWL

A2040030 FP3 1/2 FI V/O 93/4 WHITE BOWL

A2040040 FP3 1/2 FI V/O 20 WHITE BOWL

A2040050 FP3 3/4 FI V/O 5 WHITE BOWL

A2040060 FP3 3/4 FI V/O 7 WHITE BOWL

A2040070 FP3 3/4 FI V/O 93/4 WHITE BOWL

A2040080 FP3 3/4 FI V/O 20 WHITE BOWL

A2040090 FP3 1 FI V/O 5 WHITE BOWL

A2040100 FP3 1 FI V/O 7 WHITE BOWL

A2040110 FP3 1 FI V/O 93/4 WHITE BOWL

A2040120 FP3 1 FI V/O 20 WHITE BOWL

A2040130 FP3 11/4 FI V/O 5 WHITE BOWL

A2040140 FP3 11/4 FI V/O 7 WHITE BOWL

A2040150 FP3 11/4 FI V/O 93/4 WHITE BOWL

A2040160 FP3 11/4 FI V/O 20 WHITE BOWL

A2040170 FP3 11/2 FI V/O 93/4 WHITE BOWL

A2040180 FP3 11/2 FI V/O 20 WHITE BOWL

Stainless steel net cartridges are so-called surface cartridges with non deforming structure.They are well indicated for difficult applications such as filtering of corrosive liquids or where high temperatures apply.

They are available in the following versions:Series AC; non-pleated stainless steel with end caps in polypropyleneSeries AC-HT; non-pleated stainless steel with end caps in stainless steel.

Because of its structure, stainless steel has no particle migration therefore especially suitable for those applications where drinkable water is being processed. The Stainless steel net has a special structure called REPS that thanks to its characteristics makes it very strong and of high filtering efficiency. All end caps are electrically welded and no resin or glues are used.

All stainless steel cartridges are washable and therefore can be used time and time again. It can be done by backwashing them or washed with special chemicals.

Model

CODE DESCRIPTION

A4050110 CARTRIDGE 5 AC 80MIC 3/4-1

A4050130 CARTRIDGE 93/4 AC 80MIC 3/4-1

A4050140 CARTRIDGE 20 AC 80MIC 3/4-1

A4050030 CARTRIDGE 93/4 AC-HT 80MIC 3/4-1

A4050040 CARTRIDGE 20 AC-HT 80MIC 3/4-1

A4050080 CARTRIDGE 93/4 AC-HT 80M 11/4-11/2-2

A4050090 CARTRIDGE 20 AC-HT 80MIC 11/4-11/2-2

Pleated cartridges represent a valid filtering solution for diverse applications. Certified raw materials are used and have particular technical

characteristics that give the cartridge reliability and resistance. An important factor of quality is the mechanical resistance. In both cases of Polyester cartridges, the resistance is given by using 100% pure endless fibres. After pleating, which takes into account fixed parameters (pleats dimensions and quantity) that guarantee maximum efficiency, the element is mounted around a polypropylene rigid core thus assuring stability. It is then all placed inside a polypropylene cage which both ends are closed by end caps. The pleated cartridge allows a vast filtering surface while the PP cage has symmetric slots along all the surface of the cage itself therefore allowing the water to flow equally along all the sides of the cartridge and avoiding the water penetrating just one specific area.

This results in a longer life and major efficiency. The Polyester cartridges can be reused over and over again without loss of efficiency. It is obvious though that the life of these cartridges depend on the working conditions. Even though the maintenance is frequent, It is recommended not to use such cartridges under extreme conditions. Due to the fact that bacteria will undoubtedly grow and nest within the fibre, simply washing a cartridge does not mean it will last forever. Therefore as all washable cartridges, it is recommended to frequently change them in order to guarantee a safe filtration.

Thanks to its compatibility with a vast numbers of chemicals, polyester can be used also in specific applications where othermaterials are not compatible with reagents and/or chemical solvents.Regarding the applications of Polyester cartridges, these are particularly adequate for use in potable water because the raw materials used are compatible.

Model

CODE DESCRIPTION

A4080230 CARTRIDGE AQUA PRO 93/4 PL3MIC

A4080140 CARTRIDGE AQUA PRO 93/4 PL20MIC

A4080150 CARTRIDGE AQUA PRO 93/4 PL50MIC

A4080240 CARTRIDGE AQUA PRO 20 PL3MIC

A4080160 CARTRIDGE AQUA PRO 20 PL20MIC

A4080170 CARTRIDGE AQUA PRO 20 PL50MIC

A4080180 CARTRIDGE AQUA PRO 93/4 PL20M AQUA BIG

A4080190 CARTRIDGE AQUA PRO 93/4 PL50M AQUA BIG

A4080200 CARTRIDGE AQUA PRO 20 PL20M AQUA BIG

A4080210 CARTRIDGE AQUA PRO 20 PL50M AQUA BIG

A4080570 CARTRIDGE AQUA PRO 30 PL20M D.38 AQUA BIG

A4080580 CARTRIDGE AQUA PRO 30 PL50M D.38 AQUA BIG

The washable Net Cartridges are called surface cartridges and have a non-deforming structure. The inside core is manufactured using Talc Filled Polypropylene and a nylon net is welded. The homogenous Net has physical and mechanical characteristics. The square mesh allows a uniform flow along all the surface of the cartridge itself thus minimizes the possibility of clogging. Manufactured using monofilament fibres that enable uniform openings It also allows an accurate capacity of filtration while avoiding pressure drop.

Also thanks to Its smooth surface it is very easy to wash and non shedding. The washable net cartridges give a nominal filtration with efficiency of 80%. When properly utilized, they can be used over and over again maintaining a constant efficiency. The available lengths range from 5 to 20 and the microns range from a minimum of 80 micron upwards. All in compliance to EC regulations. Model

CODE DESCRIPTION

A4030100 CARTRIDGE 5 RLA 80MIC 3/4

A4030010 CARTRIDGE 5 RLA 250MIC 3/4

A4030020 CARTRIDGE 7 RLA 80MIC 3/4

A4030110 CARTRIDGE 7 RLA 250MIC 3/4

A4030030 CARTRIDGE 93/4 RLA 80MIC 3/4

A4030120 CARTRIDGE 93/4 RLA 250MIC 3/4

A4030040 CARTRIDGE 20 RLA 80MIC 3/4

A4030130 CARTRIDGE 20 RLA 250MIC 3/4

A4030050 CARTRIDGE 5 RLA 250MIC 1 1/4-11/2

A4030140 CARTRIDGE 5 RLA 430MIC 1 1/4-11/2

A4030060 CARTRIDGE 7 RLA 80MIC 1 1/4-11/2

A4030150 CARTRIDGE 7 RLA 250MIC 1 1/4-11/2

A4030160 CARTRIDGE 7 RLA 430MIC 1 1/4-11/2

A4030070 CARTRIDGE 93/4 RLA 80MIC 1 1/4-11/2

A4030170 CARTRIDGE 93/4 RLA 250MIC 1 1/4-1 1/2

A4030180 CARTRIDGE 93/4 RLA 430MIC 1 1/4-1 1/2

A4030080 CARTRIDGE 20 RLA 80MIC 1 1/4-11/2

A4030190 CARTRIDGE 20 RLA 250MIC 1 1/4-11/2

A4030200 CARTRIDGE 20 RLA 430MIC 1 1/4-11/2

A4040010 CARTRIDGE 93/4 RL 80MIC

A803R030 CARTRIDGE RLA AQUA-MINI

A803R040 CARTRIDGE RLA AQUA-MICRO

A803R020 CARTRIDGE RLA AQUA-NET

A4030090 CARTRIDGE KID 5 RLA 80MIC

A4030230 CARTRIDGE KID 93/4 RLA 80MIC

A4030240 CARTRIDGE KID 93/4 RLA 250MIC

A4030510 CARTRIDGE BIG 93/4 RLA 80MIC

A4030520 CARTRIDGE BIG 93/4 RLA 250MIC

A4030530 CARTRIDGE BIG 20 RLA 80MIC

A4030540 CARTRIDGE BIG 20 RLA 250MIC

A4030550 CARTRIDGE BIG 30 RLA 80MIC

A4030560 CARTRIDGE BIG 30 RLA 250MIC

The NEW Aqua Series of Motor Driver Dosing Pumps provide high performance, with a very precise adjustable and accurate chemical dosing. These new series have been totally developed, designed and manufactured using only the highest quality materials MADE IN ITALY and state-of-the-art CAD design. The 0-100% flow rate adjustment is provided by a manual stroke adjustment knob that controls the stroke length. The suction stroke is powered by a coil spring. The gearbox reducer is an endless worm and wheel type, operating in an oil bath. The drive shaft and eccentric are supported by heavy duty ball bearings.

Model

CODE DESCRIPTION

AD1010506M300000 FLOW-RATE 115/110/105 LT/H PRESSURE BAR 0/3/6 AMPI PVC

AD1019006M300000 FLOW-RATE 210/200/190 LT/H PRESSURE BAR 0/3/6 AMPI PVC

AD1019006M300000 FLOW-RATE 245/210/180 LT/H PRESSURE BAR 0/3/6 AMPI PVC

AD1034006M300000 FLOW-RATE 430/375/340 LT/H PRESSURE BAR 0/3/6 AMPI PVC

AD1010506M100000 FLOW-RATE 115/110/105 LT/H PRESSURE BAR 0/3/6 AMPI AISI

AD1019006M100000 FLOW-RATE 210/200/190 LT/H PRESSURE BAR 0/3/6 AMPI AISI

AD1019006M100000 FLOW-RATE 245/210/180 LT/H PRESSURE BAR 0/3/6 AMPI AISI

AD1034006M100000 FLOW-RATE 430/375/340LT/H PRESSURE BAR 0/3/6 AMPI AISI

The NEW Aqua Series of Motor Driver Dosing Pumps provide high performance, with a very precise adjustable and accurate chemical dosing. These new series have been totally developed, designed and manufactured using only the highest quality materials MADE IN ITALY and state-of-the-art CAD design. The 0-100% flow rate adjustment is provided by a manual stroke adjustment knob that controls the stroke length. The suction stroke is powered by a coil spring. The gearbox reducer is an endless worm and wheel type, operating in an oil bath. The drive shaft and eccentric are supported by heavy duty ball bearings.

Model

CODE DESCRIPTION

AD2528909M300000 FLOW-RATE 289 LT/H PRESSURE BAR 9 AMPI PVC

AD2557809M300000 FLOW-RATE 578 LT/H PRESSURE BAR 9 AMPI PVC

AD2555905M300000 FLOW-RATE 559 LT/H PRESSURE BAR 5 AMPI PVC

AD25111855M300000 FLOW-RATE 1118 LT/H PRESSURE BAR 5 AMPI PVC

AD2528909M100000 FLOW-RATE 289 LT/H PRESSURE BAR 9 AMPI AISI

AD2557809M100000 FLOW-RATE 578 LT/H PRESSURE BAR 9 AMPI AISI

AD2555905M100000 FLOW-RATE 559 LT/H PRESSURE BAR 5 AMPI AISI

AD25111855M100000 FLOW-RATE 1118 LT/H PRESSURE BAR 5 AMPI AISI

The NEW Aqua Series of Motor Driver Dosing Pumps provide high performance, with a very precise adjustable and accurate chemical dosing. These new series have been totally developed, designed and manufactured using only the highest quality materials MADE IN ITALY and state-of-the-art CAD design. The 0-100% flow rate adjustment is provided by a manual stroke adjustment knob that controls the stroke length. The suction stroke is powered by a coil spring. The gearbox reducer is an endless worm and wheel type, operating in an oil bath. The drive shaft and eccentric are supported by heavy duty ball bearings.

Model

CODE DESCRIPTION

AD1703630M300000 FLOW-RATE 36 LT/H PRESSURE BAR 30 AMPI PVC

AD1706430M300000 FLOW-RATE 64 LT/H PRESSURE BAR 30 AMPI PVC

AD1708313M300000 FLOW-RATE 83 LT/H PRESSURE BAR 13 AMPI PVC

AD1714813M300000 FLOW-RATE 148 LT/H PRESSURE BAR 13 AMPI PVC

AD1713208M300000 FLOW-RATE 132 LT/H PRESSURE BAR 8 AMPI PVC

AD1723708M300000 FLOW-RATE 237 LT/H PRESSURE BAR 8 AMPI PVC

AD1716806M300000 FLOW-RATE 168 LT/H PRESSURE BAR 6 AMPI PVC

AD1730006M300000 FLOW-RATE 300 LT/H PRESSURE BAR 6 AMPI PVC

AD1723604M300000 FLOW-RATE 236 LT/H PRESSURE BAR 4 AMPI PVC

AD1742204M300000 FLOW-RATE 422 LT/H PRESSURE BAR 4 AMPI PVC

AD1703630M100000 FLOW-RATE 36 LT/H PRESSURE BAR 30 AMPI AISI

AD1706430M100000 FLOW-RATE 64 LT/H PRESSURE BAR 30 AMPI AISI

AD1708313M100000 FLOW-RATE 83 LT/H PRESSURE BAR 13 AMPI AISI

AD1714813M100000 FLOW-RATE 148 LT/H PRESSURE BAR 13 AMPI AISI

AD1713208M100000 FLOW-RATE 132 LT/H PRESSURE BAR 8 AMPI AISI

AD1723708M100000 FLOW-RATE 237 LT/H PRESSURE BAR 8 AMPI AISI

AD1716806M100000 FLOW-RATE 168 LT/H PRESSURE BAR 6 AMPI AISI

AD1730006M100000 FLOW-RATE 300 LT/H PRESSURE BAR 6 AMPI AISI

AD1723604M100000 FLOW-RATE 236 LT/H PRESSURE BAR 4 AMPI AISI

AD1742204M100000 FLOW-RATE 422 LT/H PRESSURE BAR 4 AMPI AISI

Simple and easy protection filter to remove suspended particles, sand and metal particles.

Manufactured with polypropylene head equipped with brass Inlet-Outlet inserts, transparent SAN bowl, brass drain valve. The filter is supplied complete with nylon filtering element. Easy and quick cartridge washing operation. Available in different sizes, its the ideal for point-of-entry domestic installations.

Model

CODE DESCRIPTION

A8000500 FILTER AP EASY 1/2 F

A8000510 FILTER AP EASY 3/4 F

A8000520 FILTER AP EASY 1 F

A8000530 FILTER AP EASY 11/4

A8000540 FILTER AP EASY 11/2

ACCESSORIES AND SPARE PARTS

A4030030 CARTRIDGE 93/4 RLA 80MIC 3/4

A4030070 CARTRIDGE 93/4 RLA 80MIC 11/4-11/2

A6010010 PLASTIC BOWL KEY FOR AP EASY

A6010930 SINGLE PLASTIC BRACKET FP2-FP3 HOUSING

A6010035 KIT N 4 SCREWS + WASHERS FOR BRACKET

A6012900 CARTRIDGE SUPPORT

Professional Double stage filtration system easy to use and to mantain; sand, metal and suspended particles removing. Equipped with dust painted steel braket, polypropylene heads with brass connections, transparent SAN Sump, brass discharge valve. The system is equipped with self cleaning pre-filter in nylon washable net 80 micron rating.

Ideal filter for both domestic and industrial plant protection such as reverse osmosis system, softeners etc. AP-Easy Duplex is studied to fit all AQUA cartridges. Upon request : In-Out manometer to check the clogging of cartridges. Upon request: automatic valve with programmable digital timer for auto-cleaning system.

Model

CODE DESCRIPTION

A8000810 FILTER AP EASY DUPLEX 1/2 FI 93/4

A8000820 FILTER AP EASY DUPLEX 3/4 FI 93/4

A8000830 FILTER AP EASY DUPLEX 1 FI 93/4

A8000840 FILTER AP EASY DUPLEX 1/2 FI 93/4 20

A8000850 FILTER AP EASY DUPLEX 3/4 FI 93/4 20

A8000860 FILTER AP EASY DUPLEX 1 FI 93/4 20

ACCESSORIES AND SPARE PARTS

A4030030 CARTRIDGE 93/4 RLA 80MIC 3/4

A6010010 PLASTIC BOWL KEY FOR AP EASY

PN020030 DOUBLE METAL BRACKET FP2-FP3 HOUSINGMG011370 O-RING REF. 4350 NBR 70 FOR SUMP

AB060080 MANOMETER MG 1/8

Simple and easy protection filter to remove suspended particles, sand and metal particles. Manufactured with brass head, transparent Trogamid
bowl, upon requst a stainless steel bowl version is available. The filter is supplied complete with stainless steel filtering element. Easy and quick cartridge washing operation. Available in different sizes, its the ideal for point-of-entry domestic installations.

Model

CODE DESCRIPTION

A8000600 FILTER AP EASY HT 3/4 F

A8000610 FILTER AP EASY HT 1 F

A8000620 FILTER AP EASY HT 11/4 F

A8000630 FILTER AP EASY HT 11/2 F

A8000640 FILTER AP EASY HT 2 F

A3030070 FILTER AP EASY HT SS F03 3/4 F V/AISI 304 9 3/4 W/ DRAIN FAUCET

A3030080 FILTER AP EASY HT SS F03 1 F V/AISI 304 9 3/4 W/ DRAIN FAUCET

A3030090 FILTER AP EASY HT SS F03 1 1/4 F V/AISI 304 9 3/4 W/ DRAIN FAUCET

A3030100 FILTER AP EASY HT SS F03 11/2 F V/AISI 304 9 3/4 W/ DRAIN FAUCET

A3030110 FILTER AP EASY HT SS F03 2 F V/AISI 304 9 3/4 W/ DRAIN FAUCET

ACCESSORIES AND SPARE PARTS

A4050030 CARTRIDGE 93/4 AC-HT 80MIC 3/4-1

A4050080 CARTRIDGE 7 AC-HT 80MIC 1- 11/4

S3010070 METAL BOWL KEY FOR AP EASY HT

PN020010 SINGLE METAL BRACKET FP2-FP3 HOUSING

A6010035 KIT N 4 SCREWS + WASHERS FOR BRACKET

A6013090 CARTRIDGE SUPPORT 11.02

AB060080 MANOMETER MG 1/8

Professional Double stage filtration system easy to use and to maintenance; sand, metal and suspended particles removing. Equipped with dust painted steel brake, polypropylene heads with brass connections, transparent SAN Sump, brass discharge valve. The system is equipped with self cleaning pre-filter in nylon washable net 80 micron rating.

Ideal filter for both domestic and industrial plant protection such as osmosis system, softeners etc. AP-Easy Triplex is studied to fit all AQUA cartridges. Upon request : In-Out manometer to check the obstruction of cartridges. Upon request: automatic valve with programmable digital timer for auto-cleaning system.

Model

CODE DESCRIPTION

A8000910 FILTER AP EASY TRIPLEX 1/2 FI 93/4

A8000920 FILTER AP EASY TRIPLEX 3/4 FI 93/4

A8000930 FILTER AP EASY TRIPLEX 1 FI 93/4

A8000940 FILTER AP EASY TRIPLEX 1/2 FI 93/4 20 (X2)

A8000950 FILTER AP EASY TRIPLEX 3/4 FI 93/4 20(X2)

A8000960 FILTER AP EASY TRIPLEX 1 FI 93/4 20 (X2)

ACCESSORIES AND SPARE PARTS

A4030030 CARTRIDGE 93/4 RLA 80MIC 3/4 57.67

A6010010 PLASTIC BOWL KEY FOR AP EASY 19.66

PN020070 TRIPLE METAL BRACKET FP2-FP3 HOUSING 212.76

MG011370 O-RING REF. 4350 NBR 70 FOR SUMP 8.86

AB060080 MANOMETER MG 1/8

The filter AP-ECO has been conceived to filter domestic and industrial water. It is ideal to protect pipes and the plants connected to, from corrosion and deterioration due to the suspended particles such as sand and rust, etc. The filter is manufactured with brass head, SAN sump and a cartridge made of Arnite and a filtering polyester washable net. A simple and easy action on the tap connected at the bottom of the sump activates the flushing of the cartridge. HT version is suitable for the filtration of water with high temperature (up to 80 C) it is equipped with a Trogamid sump and a stainless steel cartridge. The AP-ECO head has threaded female connections and a relief valve very useful during the filling and the maintenance phases.

Model

CODE DESCRIPTION

A8000310 FILTER AP ECO 1/2 F

A8000300 FILTER AP ECO 3/4 F

A8000330 FILTER AP ECO HT 1/2 F

A8000320 FILTER AP ECO HT 3/4 F

ACCESSORIES AND SPARE PARTS

A800C030 89 MIC RLA AP STD/ECO CARTRIDGE

A800C040 89 MIC AC AP STD/ECO HT CARTRIDGE

AB060080 MANOMETER MG 1/8

Simple and easy protection filter to remove suspended particles, sand and metal particles. Manufactured with polypropylene head and bowl.
The filter is supplied complete with a washable net nylon cartridge element. IN/OUT connections in brass. Thanks to the washable net cartridge, cleaning and maintenance is quick and easy. Its the ideal for point-of-entry installations. Upon request: automatic valve with programmable digital timer for auto-cleaning system. Model EV is provided with a 24 VDC solenoid valve that allows you to automatically clean the cartridge element.

Model

CODE DESCRIPTION

A8000740 FILTER AP IND 20 11/4

A8000750 FILTER AP IND 20 2

A8000760 FILTER AP IND 20E 11/4

A8000770 FILTER AP IND 20E 2

ACCESSORIES AND SPARE PARTS

A4030530 CARTRIDGE RLA-A.BIG 20 80 MICRON

A4030540 CARTRIDGE RLA-A.BIG 20 250 MICRON

A6010090 PLASTIC KEY

PN020010 SINGLE METAL BRACKET (10PCS./BOX)

A6010020 KIT N4 SCREWS M8X30 DIN571

AB060080 MANOMETER MG 1/8

Simple and easy protection filter to remove suspended particles, sand and metal particles. Manufactured with polypropylene head and bowl. The filter is supplied complete with a washable net nylon cartridge element. IN/OUT connections in brass. Thanks to the washable net cartridge, cleaning and maintenance is quick and easy. Its the ideal for point-of-entry installations. Upon request: automatic valve with programmable digital timer for auto-cleaning system. Model EV is provided with a 24 VDC solenoid valve that allows you to automatically
clean the cartridge element.

Model

CODE DESCRIPTION

A8000700 FILTER AP IND 9 11/4

A8000710 FILTER AP IND 9 2

A8000720 FILTER AP IND 9E 11/4

A8000730 FILTER AP IND 9E 2

ACCESSORIES AND SPARE PARTS

A4030510 CARTRIDGE BIG 93/4 RLA 80MIC

A4030520 CARTRIDGE BIG 93/4 RLA 250MIC

A6010090 PLASTIC BOWL KEY FOR AP IND

PN020010 SINGLE METAL BRACKET FP2-FP3 HOUSING

A6010020 KIT N 4 SCREWS M8X30 DIN571

AB060080 MANOMETER MG 1/8

Innovative protection filter to remove suspended particles, sand and metal particles. Manufactured with Delrin body, 360 rotating brass Inlet-Outlet connection plate, transparent SAN bowl, plastic drain valve. The filter is supplied complete with nylon filtering element. The water enter the filter and flows down to the cartridge from inside to outside.
A simple turning counter-clockwise of the knob activates high speed-wash with water, by the Venturi functioning principle of the interior plastic slot cylinder. Dirty water goes out by the drain valve. To finish cartridge cleaning operation turn clockwise the knob. No interruption of filtered water supply during cartridge- washing operation.

Innovative protection filter to remove suspended particles, sand and metal particles. Manufactured with Delrin body, 360 rotating brass Inlet-
Outlet connection plate, transparent SAN bowl, plastic drain valve. The filter is supplied complete with nylon filtering element. The water enter
the filter and flows down to the cartridge from inside to outside. A simple turning counter-clockwise of the knob activates high speedwash with water, by the Venturi functioning principle of the interior plastic slot cylinder.
Dirty water goes out by the drain valve. To finish cartridge cleaning operation turn clockwise the knob. No interruption of filtered water supply during cartridge-washing operation.

The filter AP-STD has been conceived to filter domestic and industrial water. It is ideal to protect pipes and the plants connected to, from corrosion and deterioration due to the suspended particles such as sand and rust, etc. The filter is manufactured with brass head, SAN sump and a cartridge made of Arnite and a filtering polyester washable net. A simple and easy action on the tap connected at the bottom of the sump activates the flushing of the cartridge. HT version is suitable for the filtration of water with high temperature (up to 80C), it is equipped with a Trogamid sump and a stainless steel cartridge. The APSTD head has threaded male connections complete with rotating couplings so as to make the installation easy. Two connections G1/8 on the top of the filter can be used to make the maintenance easy and also to connect 2 gauges for a pressure control up-stream and down-stream the filtering cartridge.

Model

CODE DESCRIPTION

A8000210 FILTER AP STD 1/2 M

A8000220 FILTER AP STD 3/4 M

A8000200 FILTER AP STD 1 M

A8000240 FILTER AP STD HT 1/2 M

A8000250 FILTER AP STD HT 3/4 M

A8000230 FILTER AP STD HT 1 M

ACCESSORIES AND SPARE PARTS

A800C030 89 MIC RLA AP STD/ECO CARTRIDGE

A800C040 89 MIC AC AP STD/ECO HT CARTRIDGE

AB060080 MANOMETER MG 1/8

Ideal for the automatic cleaning of the filter installed on point-of-entry. Automatic cleaning filter kit with digital timer programmable each day of the week. Self clean kit is simple and easy to use and to maintain. Self clean kit is completed with programmable digital timer and alectro motor with hose connector.

Model

CODE DESCRIPTION

A8000970 SELF CLEAN KIT FOR FILTER AP ECO/STD/EASY/EASYHT/DUPLEX/TRIPLEX

A8000980 SELF CLEAN KIT FOR FILTER AP IND

cleaning station for self-service machines.

cleaning station complete for one or two products.available with hose of 10-15 meters and with gun or lance.all model available with back flow preventer. flow rate 13 lpm @ 3 bar.

model

code description

a9500700 cleaning station aqua mix 1/pvdf selector + tube 10mt + gun prof

a9500710 cleaning station aqua mix 1/pvdf selector + tube 10mt + lance prof

a9500720 cleaning station aqua mix 1/pvdf selector + tube 15 mt + gun prof

a9500730 cleaning station aqua mix 1/pvdf selector + tube 15 mt + lance

a9500780 cleaning station aqua mix 2/pvdf selector + tube 10 mt + gun prof

a9500770 cleaning station aqua mix 2/pvdf selector + tube 10 mt + lance

a9500740 cleaning station aqua mix 2/pvdf selector + tube 15 mt + gun prof

a9500750 cleaning station aqua mix 2/pvdf selector + tube 15 mt + lance

a9501060 cleaning station aqua mix 1/pvdf selector + backfl. prev. + tube

a9501070 cleaning station aqua mix 1/pvdf selector + backfl. prev. + tube

a9501080 cleaning station aqua mix 1/pvdf selector + backfl. prev. + tube

a9501090 cleaning station aqua mix 1/pvdf selector + backfl. prev. + tube

a9500990 cleaning station aqua mix 2/pvdf selector + backfl. prev. + tube

a9501150 cleaning station aqua mix 2/pvdf selector + backfl. prev. + tube

a9500980 cleaning station aqua mix 2/pvdf selector + backfl. prev. + tube

a9501160 cleaning station aqua mix 2/pvdf selector + backfl. prev. + tube

standard kit

a9500600 nozzles kit for venturi pipe

adsp6000075 foot filter for tube 6x9

mb020210 stainless steel foot filter heavy weight

sh020460 tube 1.5 m cristal 6x9 mm

s6060410 rack for single 5lt chemical container

a9501100 kit tube complete 10 m.

a9501110 kit tube complete 15 m.

a9501120 kit tube complete 20 m.

spare parts accessories

a9800110 professional lance with fan nozzle-flow rate untill 30 l/m

a9800100 professional gun with adjustable spray untill 60 l/m

sb050090 backflow preventer

a9500430 backflow preventer kit

sb050080 stainless steel flexible hose 1, 5mt fg3/4 fg3/4

Cleaning station for self-service machines.

Cleaning station complete for one or two products. Available with hose of 15 meters with gun. Flow rate 13 LPM @ 3 bar.

Model

CODE DESCRIPTION

A9501170 CLEANING STATION AQUA MIX LIGHT 1 PROD. + PIPE ECO 15mt + GUN ECO

A9501180 CLEANING STATION AQUA MIX LIGHT 2 PROD. + PIPE ECO 15mt + GUN ECO

STANDARD KIT

A9500600 NOZZLES KIT FOR VENTURI PIPE

ADSP6000075 FOOT FILTER FOR TUBE 6X9

MB020210 STAINLESS STEEL FOOT FILTER HEAVY WEIGHT

SH020460 TUBE 1.5 M CRISTAL 6X9 MM

A9501190 PVC ECO TUBE 15mt AQUA MIX LIGHT

S6060410 RACK FOR SINGLE 5lt CHEMICAL CONTAINER

SPARE PARTS ACCESSORIES

A9800101 ECO GUN FOR AQUA MIX LIGHT

ADSP6002002 PVC TUBE FOR EV INLET 3/4 M-F 1, 5mt

Moulded plastic push button dispenser up to four products.

Flow rates: 14 LPM and 4 LPM.Automatically and accurately dilutes chemical concentrates.Complies European water regulations EN1717

Model

CODE DESCRIPTION

ADHYA110 AQUADIL 1 PRODUCT 4 LPM

ADHYA111 AQUADIL 1 PRODUCT 14 LPM

ADHYA140 AQUADIL 4 PRODUCTS 4 LPM

ADHYA141 AQUADIL 14 PRODUCTS 4 LPM

ADHYA142 AQUADIL 4 PRODUCTS 3X4 LPM 1X14 LPM

ADHYA143 AQUADIL 4 PRODUCTS 2X4 LPM 2X14 LPM

STANDARD KIT

ADHYD10089410 FOOT FILTER

ADHYD509900 CERAMIC WEIGHT

A9500600 NOZZLES KIT FOR VENTURI PIPE

SH020460 TUBE 1.5 M CRISTAL 6X9 MM

AQUADOSE, push pump used to dose chemical concentrates.

Allows to dose 30. 22 or 15 cc each push.Automatically and accurately dilutes chemical concentrates.Complies European water regulations EN1717

Model

CODE DESCRIPTION

ADHYD616 AQUADOSE

Moulded plastic push button dispenser for one product.

Flow rates: 14 LPM and 4 LPM.Automatically and accurately dilutes chemical concentrates.Easily installed and simple to use.

Model

CODE DESCRIPTION

ADHYA010 MINI AQUADIL 1 PRODUCT 4 LPM (minimum order 20 pc)

ADHYA011 MINI AQUADIL 1 PRODUCT 14 LPM (minimum order 20 pc)

STANDARD KIT

ADHYD10089410 FOOT FILTER

ADHYD509900 CERAMIC WEIGHT

A9500600 NOZZLES KIT FOR VENTURI PIPE

SH020460 TUBE 1.5 M CRISTAL 6X9 MM

Economical anti-scale system

This system is a very economical anti-scale for laundry and dishwasher machines. The polyphosphates contained in the unit are effective for about four months on the average. Working pressure (max): 8 bar. Working temperature: 5 40 C. Suggested flow rate: 8 10 LPM.

Model

CODE DESCRIPTION

A8030010 SALVALAVATRICE COMPLETE 3/4

Thanks to Bluetooth technology the AquaDet4 can be connect with a PDA or Smartphone. The Bluetooth make easy the way to program the system, no more uncomfortable situation behind the dishwashing machine. SW application for Bluetooth Aqua Control Det4 can be installed on devices with Microsoft Windows Mobile 6 or later and Microsoft Bluetooth stack, on PCs running Windows XP or 7 operating system and with Microsoft Bluetooth bluetooth driver Enumerator. Keeps in memory all the statistics data regarding chemical consumptions, cycles counter, racks counter and working time. Moreover, if the temperature probe is connected, the DET4 keeps in memory the average daily temperature of the washing tank.
Password The programming and the statistics data are fully protected by a 4-digit password.
O.F.A. (Over Feed Alarm) To avoid detergent over feed in case problems with the reading of the probe.
Level alarms Each chemical has its input for the level probe.
Protection degree IP65 against dust and water sprays.

Model

CODE DESCRIPTION

AD4310N0NE000000 AQUA DET 4 MOD1 10-0, 1/1, 5-03 SANTOPRENE/SILICONE CON. PROBE 100230VAC

AD4350R0RE000000 AQUA DET 4 MOD5 10-0, 1/02-07 SANTOPRENE/PP-GL-VT CON. PROBE

AD4330P0PE000000 AQUA DET 4 MOD3 10-0, 1/1, 5-03/1, 5-03 SANTOPRENE/SILICONE/SILICONE CON. PROBE 100230VAC

AD4370S0SE000000 AQUA DET 4 MOD7 10-0, 1/02-07/1, 5-03 SANTOPRENE/PP-GL-VT/SILICONE CON. PROBE 100230VAC

AD4310N0NE0D0000 AQUA DET 4 MOD 1 10-0, 1/1, 5-03 SANTOPRENE/SILICONE INDUC. PROBE

AD4350R0RE0D0000 AQUA DET 4 MOD5 10-0, 1/02-07 SANTOPRENE/PP-GL-VT INDUC. PROBE

AD4330P0PE0D0000 AQUA DET 4 MOD3 10-0, 1/1, 5-03/1, 5-03 SANTOPRENE/SILICONE/SILICONE INDUC. PROBE 100230VAC

AD4370S0SE0D0000 AQUA DET 4 MOD7 10-0, 1/02-07/1, 5-03 SANTOPRENE/PP-GL-VT/SILICONE INDUC. PROBE 100230VAC

STANDARD KIT

ADSP6020156 MOUNTING BRACKET

ADSP6000068I STAINLESS STEEL INJECTION FITTING FOR DETERGENT

ADSP6000063 HOSE BARB ADAPTER

ADSP6500051 STAINLESS STEEL CHECK VALVE

ADSP6000917 FOOT FILTER

ADSP6000546 ROLL OF PVC CRYSTAL TUBE (2 M)

ADSP6000078 ROLL OF POLYETHYLENE TUBING (2 M)

ADPACDNK1 CONDUCTIVITY PROBE (3M-CABLE)

ADCDIND INDUCTIVE PROBE KIT FOR A MAINTENANCE-FREE CONDUCTIVITY READING.

SPARE PARTS

ADSP8000128 TEC COMPLETE SILICONE TUBING

ADPS8000112 COMPLETE TYGON TUBING

ADPS8000109 TEC SANTOPRENE TUBING

ADSP000023B COMPLETE SILICONE TUBING ROLL HOLDER

ADSP000023A COMPLETE TYGON TUBING ROLL HOLDER

ADSP000009A COMPLETE SANTOPRENE TUBING ROLL HOLDER

Dosing system for solid detergent and rinse aid for all types of dishwashers. The dosage duration of solid detergent is determined by conductivity measured in the dishwasher tank. The conductivity parameters are read from the conductivity probe supplied. The duration of the rinse aid dispenser is programmable. The dosages depend on the different washing phases of the dishwasher.

The system is equipped with digital display and control of washing statistics. The system can be connected to a computer or a smartphone through Bluetooth technology on request.

Model

CODE DESCRIPTION

ADPDET42 AQUA DET 4-2 PANEL WITH EV+SOLVER RINSE-AID PUMP 1, 5-03 SILICONE CON. PROBE 100230VAC

ADPDET421 AQUA DET 4-2 PANEL WITH EV+SOLVER RINSE-AID PUMP 1, 5-03 SILICONE INDUC. PROBE 100230VAC

STANDARD KIT

ADSP6000063 HOSE BARB ADAPTER

ADSP6500051 STAINLESS STEEL CHECK VALVE

ADSP6000917 FOOT FILTER

ADSP6000546 ROLL OF PVC CRYSTAL TUBE (2 M)

ADSP6000078 ROLL OF POLYETHYLENE TUBING (2 M)

ADPACDNK1 STANDARD CONDUCTIVITY PROBE

ADCDIND KIT INDUCTIVE PROBE KIT FOR A MANTEINANCE-FREE CONDUCTIVITY READING

SPARE PARTS

ADSP8000128 COMPLETE SILICONE TUBING

ADSP000023B COMPLETE SILICONE TUBING ROLL HOLDER

OPTIONAL

ADSP6000050 1/8 T-FITTING

ADSP6000550 BLUETOOTH KIT

Three-Operation Mode Digital Peristaltc Pump

2ST model is designed for detergent dosing in warewashing machines in a simple, flexible and accurate way. The pump is feed by charge and rinse solenoid valve, it can be also feed by a single charge/rinse solenoid valve and it is programmable in three modes: time and speed, chemical grams/liter, chemical active/liter.

Model

CODE DESCRIPTION

ADD6004010000000 DGTEC 2ST 04-01 230VAC SANTOPRENE

ADD6006010000000 DGTEC 2ST 06-01 230VAC SANTOPRENE

STANDARD KIT

ADSP6000068N INJECTION CONNECTOR 90 PP 4X6 D. 10 MM

ADSP8000025 WALL MOUNTING BRACKET TEC BLACK PP

ADSP6000917 PP SHORT FOOT FILTER WITH WEIGHT W/O VALVE

ADSP6000546 TUBE 2 M PVC CRISTAL 4X6 MM

SPARE PARTS

ADSP8000109 SANTOPRENE TUBE WITH COUPLINGS FOR TEC

ADSP8000009A COMPLETE ROLLER HOLDER FOR TEC SANTOPRENE

OPTIONAL

ADSP6000068I STAINLESS STEEL 90 INJECTION CONNECTOR 4X6 D. 10 MM

Controlled by conductivity probe digital pump

CD model is designed for detergent dosing controlled by conductivity probe installed in warewashing machine tank for a simple and accurate dosing.

CODE DESCRIPTION

ADD4006010000000 DGTEC CD 06-01 230VAC WITH PROBE SANTOPRENE

ADD4010010000000 DGTEC CD 10-01 230VAC WITH PROBE SANTOPRENE

STANDARD KIT

ADSP6000068N INJECTION CONNECTOR 90 PP 4X6 D. 10 MM

ADSP8000025 WALL MOUNTING BRACKET TEC BLACK PP

ADSP6000917 PP SHORT FOOT FILTER WITH WEIGHT W/O VALVE

ADSP6000546 TUBE 2 M PVC CRISTAL 4X6 MM

ADPACDK1D CONDUCTIVITY PROBE

SPARE PARTS

ADSP8000109 SANTOPRENE TUBE WITH COUPLINGS FOR TEC

ADSP8000009A COMPLETE ROLLER HOLDER FOR TEC SANTOPRENE

OPTIONAL

ADSP6000068I STAINLESS STEEL 90 INJECTION CONNECTOR 4X6 D. 10 MM

Three-Operation Mode Digital Peristaltc Pump

ST model is designed for detergent (rinse) dosing in warewashing machines in a simple, flexible and accurate way. The pump is feed by charge/rinse solenoid valve and it is programmable in three modes: time and speed, chemical grams/liter, chemical active/liter.

Model

CODE DESCRIPTION

ADD5004010000000 DGTEC ST 04-01 230VAC SANTOPRENE

ADD5006010000000 DGTEC ST 06-01 230VAC SANTOPRENE

STANDARD KIT

ADSP6000068N INJECTION CONNECTOR 90 PP 4X6 D. 10 MM

ADSP8000025 WALL MOUNTING BRACKET TEC BLACK PP

ADSP6000917 PP SHORT FOOT FILTER WITH WEIGHT W/O VALVE

ADSP6000546 TUBE 2 M PVC CRISTAL 4X6 MM

SPARE PARTS

ADSP8000109 SANTOPRENE TUBE WITH COUPLINGS FOR TEC

ADSP8000009A COMPLETE ROLLER HOLDER FOR TEC SANTOPRENE

OPTIONAL

ADSP6000068I STAINLESS STEEL 90 INJECTION CONNECTOR 4X6 D. 10 MM

Three-Operation Mode Digital peristaltic Pump

ST model is designed for detergent (rinse) dosing in ware washing machines in a simple, flexible and accurate way. The pump is feed by charge (rinse) solenoid valve and it is programmable in three modes: time and speed, chemical grams/liter, chemical active/liter.

Model

CODE DESCRIPTION

ADD5001030B00000 DGTEC ST-R 01-03 230VAC SILICONE

ADD5001030A00000 DGTEC ST-R 01-03 230VAC TYGON

STANDARD KIT

ADSP6000063 BOILER INJECTION CONNECTOR G 1/8 WITH FITTING FOR HOSE 6-8 MM

ADSP6500051 INJECTION CONNECTOR WITH NON RETURN VALVE G 1/8 4X6

ADSP6000917 PP SHORT FOOT FILTER WITH WEIGHT W/O VALVE

SPARE PARTS

ADSP8000128 SILICONE TUBE WITH COUPLINGS FOR TEC

ADSP8000112 TYGON TUBE WITH COUPLINGS FOR TEC

ADSP8000023B COMPLETE ROLLER HOLDER FOR TEC SILICONE

ADSP8000023A COMPLETE ROLLER HOLDER FOR TEC TYGON

OPTIONAL

ADSP6000050 T CONNECTOR 10-12 MM G 1/8

double system for single tank machines with one solenoid valve.

detergent adjustable by speed 10100% whether in the initial charge that in the top up. Rinse-aid adjustable by speed 10100% and in time from 4 to 24 seconds with steps of 4 seconds by dipswitch. Recognition of the initial charge with the rinse limit of 30 seconds setting by dipswitch.

double system for single tank machines with one or two solenoid valves and small conveyor.

initial charge detergent adjustable by time 0120 seconds. Top up detergent adjustable by speed 10100%. Rinse-aid adjustable by speed 10100%. Rinse limit 30 seconds setting by dipswitch.

model

code description

ad0f00a0a0c00000 aqua det 2 04-01/01-03 24230vac santoprene/tygon

ad0f00a0a0e00000 aqua det 2 04-01/01-03 24230vac santoprene/silicone

standard kit

adsp6000068i stainless steel injection fitting for detergent

adsp6000063 hose barb adapter

adsp6500051 stainless steel check valve

adsp6000917 foot filter

adsp6020156 mounting bracket

adsp6000546 roll of pvc crystal tube (2 m)

adsp6000078 roll of polyethylene tubing (2 m)

spare parts

adsp8000128 tec complete silicone tubing

adps8000112 complete tygon tubing

adps8000109 tec santoprene tubing

adsp000023b complete silicone tubing roll holder

adsp000023a complete tygon tubing roll holder

adsp000009a complete santoprene tubing roll holder

optional

adsp6000050 1/8 t-fitting

double system for single tank machines with one or two solenoid valves and small conveyor.

initial charge detergent adjustable by time 0120 seconds. Top up detergent adjustable by speed 10100%. Rinse-aid adjustable by speed 10100%. Rinse limit 30 seconds setting by dipswitch.

model

code description

ad0f00a0a0c00000 aqua det 2 04-01/01-03 24230vac santoprene/tygon

ad0f00a0a0e00000 aqua det 2 04-01/01-03 24230vac santoprene/silicone

standard kit

adsp6000068i stainless steel injection fitting for detergent

adsp6000063 hose barb adapter

adsp6500051 stainless steel check valve

adsp6000917 foot filter

adsp6020156 mounting bracket

adsp6000546 roll of pvc crystal tube (2 m)

adsp6000078 roll of polyethylene tubing (2 m)

spare parts

adsp8000128 tec complete silicone tubing

adps8000112 complete tygon tubing

adps8000109 tec santoprene tubing

adsp000023b complete silicone tubing roll holder

adsp000023a complete tygon tubing roll holder

adsp000009a complete santoprene tubing roll holder

optional

adsp6000050 1/8 t-fitting

Peristaltic pump for single tank dishwashers with one solenoid valve wich allows to manage both initial charge and top-up dosing independently. Top up dosing controller by time 130 seconds Initial charge dosing controlled by time 1240 seconds. Easily programmable thanks to the flashes of the L.E.D. and the manual procedure to set an accurate dosing time, with 1-second resolution. Available the model with buzzer and level probe.

Model

CODE DESCRIPTION

AD1M004010000000 TEC-1TT 4-1 100240VAC SANTOPRENE

AD1M006010000000 TEC-1TT 6-1 100240VAC SANTOPRENE

AD1M00401E000000 TEC-1TT 4-1 24VAC SANTOPRENE

AD1M00601E000000 TEC-1TT 6-1 24VAC SANTOPRENE

STANDARD KIT

ADSP6000068N INJECTION CONNECTOR 90 PP 4X6 D. 10 MM

ADSP8000025 WALL MOUNTING BRACKET TEC BLACK PP

ADSP6000917 PP SHORT FOOT FILTER WITH WEIGHT W/O VALVE

ADSP6000546 TUBE 2 M PVC CRISTAL 4X6 MM

SPARE PARTS

ADSP8000109 SANTOPRENE TUBE WITH COUPLINGS FOR TEC

ADSP8000009A COMPLETE ROLLER HOLDER FOR TEC SANTOPRENE

OPTIONAL

ADSP6000068I STAINLESS STEEL 90 INJECTION CONNECTOR 4X6 D. 10 MM

Peristaltic pump for single tank dishwashers with one solenoid valve wich allows to manage both initial charge and top-up dosing independently. Top up dosing controlled by speed 10100% Initial charge dosing controlled by time 1240 seconds, with 1-second resolution. Easily programmable thanks to the flashes of the L.E.D. and the manual procedure to set an accurate dosing time. Available the model with buzzer and level probe.

Model

CODE DESCRIPTION

AD1L004010000000 TEC-1TV 4-1 100240VAC SANTOPRENE

AD1L006010000000 TEC-1TV 6-1 100240VAC SANTOPRENE

AD1L00401E000000 TEC-1TV 4-1 24VAC SANTOPRENE

AD1L00601E000000 TEC-1TV 6-1 24VAC SANTOPRENE

STANDARD KIT

ADSP6000068N INJECTION CONNECTOR 90 PP 4X6 D. 10 MM

ADSP8000025 WALL MOUNTING BRACKET TEC BLACK PP

ADSP6000917 PP SHORT FOOT FILTER WITH WEIGHT W/O VALVE

ADSP6000546 TUBE 2 M PVC CRISTAL 4X6 MM

SPARE PARTS

ADSP8000109 SANTOPRENE TUBE WITH COUPLINGS FOR TEC

ADSP8000009A COMPLETE ROLLER HOLDER FOR TEC SANTOPRENE

OPTIONAL

ADSP6000068I STAINLESS STEEL 90 INJECTION CONNECTOR 4X6 D. 10 MM

Peristaltic pump for single tank dishwashers with one solenoid valve wich allows to manage both initial charge and top-up dosing independently. Top-up dosing controlled by speed 10100% Initial charge dosing controlled by speed 10100%. Easy to use thanks to the flashes of the L.E.D. and the manual procedure to set an accurate dosing time. Available the model with buzzer and level probe.

Model

CODE DESCRIPTION

AD1N004010000000 TEC-1VV 4-1 100240VAC SANTOPRENE

AD1N006010000000 TEC-1VV 6-1 100240VAC SANTOPRENE

AD1N00401E000000 TEC-1VV 4-1 24VAC SANTOPRENE

AD1N00601E000000 TEC-1VV 6-1 24VAC SANTOPRENE

STANDARD KIT

ADSP6000068N INJECTION CONNECTOR 90 PP 4X6 D. 10 MM

ADSP8000025 WALL MOUNTING BRACKET TEC BLACK PP

ADSP6000917 PP SHORT FOOT FILTER WITH WEIGHT W/O VALVE

ADSP6000546 TUBE 2 M PVC CRISTAL 4X6 MM

SPARE PARTS

ADSP8000109 SANTOPRENE TUBE WITH COUPLINGS FOR TEC

ADSP8000009A COMPLETE ROLLER HOLDER FOR TEC SANTOPRENE

OPTIONAL

ADSP6000068I STAINLESS STEEL 90 INJECTION CONNECTOR 4X6 D. 10 MM

Peristaltic pump for single tank machines with one or two solenoid valves. Easy to use thanks to the flashes of the L.E.D. Controlled by time. Initial charge time adjustable 1240 seconds. Topup time adjustable 130 seconds.

Peristaltic pump for single tank machines with one or two solenoid valves. Easy to use thanks to flashes of L.E.D. Controlled by time and speed. Initial charge time adjustable 1-240 seconds. Top-up dosing controlled by speed 0-100%.

Model

CODE DESCRIPTION

AD0L00401E000000 TEC-2TV 4-1 MULTI-VOLTAGE SANTOPRENE

AD0L00601E000000 TEC-2TV 6-1 MULTI-VOLTAGE SANTOPRENE

STANDARD KIT

ADSP6000068N INJECTION CONNECTOR 90 PP 4X6 D. 10 MM

ADSP8000025 WALL MOUNTING BRACKET TEC BLACK PP

ADSP6000917 PP SHORT FOOT FILTER WITH WEIGHT W/O VALVE

ADSP6000546 TUBE 2 M PVC CRISTAL 4X6 MM

SPARE PARTS

ADSP8000109 SANTOPRENE TUBE WITH COUPLINGS FOR TEC

ADSP8000009A COMPLETE ROLLER HOLDER FOR TEC SANTOPRENE

OPTIONAL

ADSP6000068I STAINLESS STEEL 90 INJECTION CONNECTOR 4X6 D. 10 MM

Peristaltic pump for single tank machines with one or two solenoid valves. Easy to use thanks to the flashes of the L.E.D. Initial charge speed adjustable 0-100%. Top-up dosing controlled by speed 0-100%.

Peristaltic pump for single tank dishwashers with one solenoid valve. Adjustable by speed 10100%. Priming by switch. Easy to use thanks to flashes of the L.E.D.

Model

CODE DESCRIPTION

AD0A004010000000 TEC-R 4-1 100240VAC SANTOPRENE

AD0A006010000000 TEC-R 6-1 100240VAC SANTOPRENE

AD0A00401E000000 TEC-R 4-1 24VAC SANTOPRENE

AD0A00601E000000 TEC-R 6-1 24VAC SANTOPRENE

STANDARD KIT

ADSP6000068N INJECTION CONNECTOR 90 PP 4X6 D. 10 MM

ADSP8000025 WALL MOUNTING BRACKET TEC BLACK PP

ADSP6000917 PP SHORT FOOT FILTER WITH WEIGHT W/O VALVE

ADSP6000546 TUBE 2 M PVC CRISTAL 4X6 MM

SPARE PARTS

ADSP8000109 SANTOPRENE TUBE WITH COUPLINGS FOR TEC

ADSP8000009A COMPLETE ROLLER HOLDER FOR TEC SANTOPRENE

OPTIONAL

ADSP6000068I STAINLESS STEEL 90 INJECTION CONNECTOR 4X6 D. 10 MM

Fixed flow rate pump

Peristaltic pump for single tank machines with one solenoid valve. Fixed flow rate.

Model

CODE DESCRIPTION

AD0B1V5010000000 TEC-RS 1, 5-1 230VAC SANTOPRENE

AD0B003010000000 TEC-RS 3-1 230VAC SANTOPRENE

STANDARD KIT

ADSP6000068N INJECTION CONNECTOR 90 PP 4X6 D. 10 MM

ADSP8000025 WALL MOUNTING BRACKET TEC BLACK PP

ADSP6000917 PP SHORT FOOT FILTER WITH WEIGHT W/O VALVE

ADSP6000546 TUBE 2 M PVC CRISTAL 4X6 MM

SPARE PARTS

ADSP8000109 SANTOPRENE TUBE WITH COUPLINGS FOR TEC

ADSP000009A COMPLETE ROLLER HOLDER FOR TEC SANTOPRENE

OPTIONAL

ADSP6000068I STAINLESS STEEL 90 INJECTION CONNECTOR 4X6 D. 10 MM

Single adjustment

Peristaltic pump for a single tank dishwashers with one or two solenoid valves. Adjustable by time 1-30 seconds. Priming by switch. Easily programmable thanks to the flashes of the L.E.D. and the manual procedure to set an accurate dosing time. Available the model with buzzer and level probe.

Model

CODE DESCRIPTION

AD0M001030A00000 TEC-1T 1-3 100240VAC TYGON

AD0M001030B00000 TEC-1T 1-3 100240VAC SILICONE

AD0M00103EA00000 TEC-1T 1-3 24VAC TYGON

AD0M00103EB00000 TEC-1T 1-3 24VAC SILICONE

STANDARD KIT

ADSP6000063 BOILER INJECTION CONNECTOR G 1/8 WITH FITTING FOR HOSE 6-8 MM

ADSP6500051 INJECTION CONNECTOR WITH NON RETURN VALVE G 1/8 4X6

ADSP6000917 PP SHORT FOOT FILTER WITH WEIGHT W/O VALVE

ADSP8000025 WALL MOUNTING BRACKET TEC BLACK PP

ADSP6000546 TUBE 2 M PVC CRISTAL 4X6 MM

ADSP6000078 TUBE 2 M PE 4X6 MM

SPARE PARTS

ADSP8000128 SILICONE TUBE WITH COUPLINGS FOR TEC

ADSP8000112 TYGON TUBE WITH COUPLINGS FOR TEC

ADSP8000023B COMPLETE ROLLER HOLDER FOR TEC SILICONE

ADSP8000023A COMPLETE ROLLER HOLDER FOR TEC TYGON

OPTIONAL

ADSP6000050 T CONNECTOR 10-12 MM G 1/8

Single adjustment pump.

Peristaltic pump for single tank dishwashers with one solenoid valve. Adjustable by speed 10100%. Priming by switch. Easy to use tahnks to the flashes of the L.E.D. Available the model with buzzer and level probe.

Model

CODE DESCRIPTION

AD0A001030A00000 TEC-R 1-3 100240VAC TYGON

AD0A001030B00000 TEC-R 1-3 100240VAC SILICONE

AD0A00103EA00000 TEC-R 1-3 24VAC TYGON

AD0A00103EB00000 TEC-R 1-3 24VAC SILICONE

STANDARD KIT

ADSP6000063 BOILER INJECTION CONNECTOR G 1/8 WITH FITTING FOR HOSE 6-8 MM

ADSP6500051 INJECTION CONNECTOR WITH NON RETURN VALVE G 1/8 4X6

ADSP6000917 PP SHORT FOOT FILTER WITH WEIGHT W/O VALVE

SPARE PARTS

ADSP8000128 SILICONE TUBE WITH COUPLINGS FOR TEC

ADSP8000112 TYGON TUBE WITH COUPLINGS FOR TEC

ADSP8000023B COMPLETE ROLLER HOLDER FOR TEC SILICONE

ADSP8000023A COMPLETE ROLLER HOLDER FOR TEC TYGON

OPTIONAL

ADSP6000050 T CONNECTOR 10-12 MM G 1/8

Peristaltic pump for single tank machines with one solenoid valve. Fixed flow rate.

Model

CODE DESCRIPTION

AD0B001030A00000 TEC-RS 1-3 230VAC TYGON

AD0B001030B00000 TEC-RS 1-3 230VAC SILICONE

STANDARD KIT

ADSP6000063 BOILER INJECTION CONNECTOR G 1/8 WITH FITTING FOR HOSE 6-8 MM

ADSP6500051 INJECTION CONNECTOR WITH NON RETURN VALVE G 1/8 4X6

ADSP6000917 PP SHORT FOOT FILTER WITH WEIGHT W/O VALVE

ADSP8000025 WALL MOUNTING BRACKET TEC BLACK PP

ADSP6000546 TUBE 2 M PVC CRISTAL 4X6 MM

SPARE PARTS

ADSP8000128 SILICONE TUBE WITH COUPLINGS FOR TEC

ADSP8000112 TYGON TUBE WITH COUPLINGS FOR TEC

ADSP8000023B COMPLETE ROLLER HOLDER FOR TEC SILICONE

ADSP8000023A COMPLETE ROLLER HOLDER FOR TEC TYGON

OPTIONAL

ADSP6000050 T CONNECTOR 10-12 MM G 1/8

Solenoid driven metering pump HC150

Constant Operation Mode Solenoid pump:adjusting flow rate from 0 to 100% or from 0 to 20%.Available models with level probe.

Model

CODE DESCRIPTION

AD9500223D000 HC150 CST W/O LEVEL 10-01 230V PP-GL-DT DET KIT

AD9500203D000 HC150 CST WHIT LEVEL 10-01 230V PP-GL-DT DET KIT

AD9500120B000 HC150 CST W/O LEVEL 03-07 230V PP-GL-VT RIN KIT

AD9500100B000 HC150 CST WHIT LEVEL 03-07 230V PP-GL-VT RIN KIT

STANDARD KIT

ADSP6020221 ROLL OF PVC CRYSTAL TUBE (2 M)

ADSP6000078 ROLL OF POLYETHYLENE TUBING (2 M)

DETERGENT

ADSP6000053 POLYPROPYLENE INJECTION FITTING WITH EPDM LIP VALVE

ADSP60000917D EPDM FOOT FILTER

RINSE-AID

ADSP6000063 HOSE BARB ADAPTER

ADSP6500051 STAINLESS STEEL CHECK VALVE

ADSP6000917V FPM FOOT FILTER

SPARE PARTS

ADSP9000100 BODY PUMP PP/GL/VT(FPM)

ADSP9000101 BODY PUMP PP/GL/DT(EPDM)

Available for container of 5/10 or 20/25 liters. Available with Dutral or Viton gaskets. With or without cables connector. With or without container adaptor.

Model

CODE DESCRIPTION

ADLASM0A00 SUCTION LANCE (5-10lt h400) GL-DT 46 WITH LEVEL PROBE W/O CONNET.

ADLASM0AC0 SUCTION LANCE (5-10lt h400) GL-DT 46 WITH LEVEL PROBE WITH

ADLASM0AB0 SUCTION LANCE (5-10lt h400) GL-DT 46 WITH LEVEL PROBE WITH BNC

ADLASM2A00 SUCTION LANCE (30lt h490) GL-DT 46 WITH LEVEL PROBE W/O CONNET.

ADLASM2AC0 SUCTION LANCE (30lt h490) GL-DT 46 WITH LEVEL PROBE WITH CONNET.

ADLASM2AB0 SUCTION LANCE (30lt h490) GL-DT 46 WITH LEVEL PROBE WITH BNC

ADLASM1A00 SUCTION LANCE (60-100lt h700) GL-DT 46 WITH LEVEL PROBE W/O

ADLASM1AC0 SUCTION LANCE (60-100lt h700) GL-DT 46 WITH LEVEL PROBE WITH

ADLASM1AB0 SUCTION LANCE (60-100lt h700) GL-DT 46 WITH LEVEL PROBE WITH BNC

ADLASM0A01 SUCTION LANCE (5-10lt h400) GL-DT 812 WITH LEVEL PROBE W/O

ADLASM0AC1 SUCTION LANCE (5-10lt h400) GL-DT 812 WITH LEVEL PROBE WITH

ADLASM0AB1 SUCTION LANCE (5-10lt h400) GL-DT 812 WITH LEVEL PROBE WITH BNC

ADLASM2A01 SUCTION LANCE (30lt h490) GL-DT 812 WITH LEVEL PROBE W/O CONNET.

ADLASM2AC1 SUCTION LANCE (30lt h490) GL-DT 812 WITH LEVEL PROBE WITH CONNET.

ADLASM2AB1 SUCTION LANCE (30lt h490) GL-DT 812 WITH LEVEL PROBE WITH BNC

ADLASM1A01 SUCTION LANCE (60-100lt h700) GL-DT 46 WITH LEVEL PROBE W/O

ADLASM1AC1 SUCTION LANCE (60-100lt h700) GL-DT 812 WITH LEVEL PROBE WITH

ADLASM1AB1 SUCTION LANCE (60-100lt h700) GL-DT 812 WITH LEVEL PROBE WITH BNC

DGTEC TIMER is designed for dosing by daily or weekly timer. For each day is possible to set up to 8 dosing cycles and each cycle can be set for a dosing time from 0 to 60 minutes.

Model

CODE DESCRIPTION

ADD81V4010000000 DGTEC TIMER 1, 4-01 230VAC SANTOPRENE

ADD8003010000000 DGTEC TIMER 03-01 230VAC SANTOPRENE

STANDARD KIT

ADSP6000068N INJECTION CONNECTOR 90 PP 4X6 D. 10 MM

ADSP8000025 WALL MOUNTING BRACKET TEC BLACK PP

ADSP6000917 PP SHORT FOOT FILTER WITH WEIGHT W/O VALVE

ADSP6000546 TUBE 2 M PVC CRISTAL 4X6 MM

SPARE PARTS

ADPACDK1D CONDUCTIVITY PROBE

ADSP8000109 SANTOPRENE TUBE WITH COUPLINGS FOR TEC

ADSP8000009A COMPLETE ROLLER HOLDER FOR TEC SANTOPRENE

OPTIONAL

ADSP6000068I STAINLESS STEEL 90 INJECTION CONNECTOR 4X6 D. 10 MM

tunnel machine system allows washing tunnel management up to a maximum of four washing chambers. pump are dedicated to each washingchamber and each pump has its discharge pipe on the flushing kit of the associated tunnel-machine chamber.

modular distribution panel

the system is modular up to 10 pumps and to each washing chamber is associated with a signal module for the acquisition of solenoid valve signals status. tunnel machine system allows contemporary dosages for all washing chambers.

model

tunnel machine accessories and components

code description

adlfm006 4-way distribution panel ecowash tunnel machine

adlfm005 solenoid valve for ecowash tunnel machine flushing kit

adlfm002 valve module (2x epdm) for ecowash tunnel machine flushing kit

Two-Operation Mode Digital Peristaltic Pump

OPL model is designed for chemical dosing in laundry washing machine in a simple, flexible and accurate way. The pump is designed for dosing in two modes: DOSING CYCLE or RELAY. DOSING CYCLE mode for dosing controlled by set dosing time or chemical grams/ laundry Kg;RELAY mode for dosing by the incoming signal from solenoid valve of laundry machine

Model

CODE DESCRIPTION

ADD7020000P00000 DGTEC OPL 20-00 230VAC PHARMED

ADD7020000B00000 DGTEC OPL 20-00 230VAC SILICONE

ADD7020000000000 DGTEC OPL 20-00 230VAC SANTOPRENE

STANDARD KIT

ADSP8000025 WALL MOUNTING BRACKET TEC BLACK PP

ADSP6000379 PVC CRYSTAL TUBE D. 6X9

SPARE PARTS

ADSP8000124 SILICONE TUBE-6X9 JUNCTION

ADSP800I149 PHARMED TUBE-6X9 JUNCTION

ADSP8000178 SANTOPRENE TUBING-6X9 JUNCTION

ADSP8000023B COMPLETE TUBING ROLL HOLDER

OPTIONAL

ADSP6000075 PP FOOT FILTER WITHOUT WEIGHT

MB 020210 STAINLESS STEEL WEIGHT (6X9 TUBE)

ADSP3400019 SUCTION LANCEWITH FITTING BARB

Multi-machine and tunnel machine chemical dosing modular system

The first dosing system for industrial washing machine completely modular, you can finally assemble the system on the field so as to ensure a wash always perfect.

100% Modular Its easy to build the right system for any need; no more different codes for different configurations.

Installer friendly Programming by a computer with an iconbased software AQUAware for ECOWASH.

VersatileProgrammable working modeEasy to program a washing program combined the trigger signals and the pumps.20 washing programs and with the possibility to set run times or gr/Kg and delay times for each pump.

User friendly The washing machine operator reads on the displayThe washing machine operator reads on the display the names of the washing program (whites, colours, no bleaches, linen etc).

Care of environment Chemicals savings, always the right quantity of chemicals because its possible to select the load of the washing machine (25%, 50%, 75% or 100%). Energy savings thanks the switchingmode power supply with PFC active.

Safe All the modules are connected each other by a serial communication and thanks to the signal module no high voltage signal comes out from the washing machine.

The multi-machine system allows to manage up to four washing machines.Each machine is associated with a Signal module to acquire the status of the relative solenoid valves.The pumps, up to ten, are connected to the product flushing kit. This is connected to the machine flushing kit, which allows to dose the product into the washing machine that required the dosing.The central module manages the flushing solenoid valve at the inlet of the flushing kit and the 4 solenoid valves that control the flow to the washing machines.

Model

CODE DESCRIPTION

EWMC004000000 ECOWASH MULTIMACHINE CENTRAL SYSTEM MODULE

EWMS007020000 ECOWASH SIGNALS MODULE MULTIMACHINE

EWMP020PI0000 ECOWASH 20lt PHARMED TUBE PUMP MODULE

EWMP100PI0000 ECOWASH 100lt PHARMED TUBE PUMP MODULE

EWMR000000000 ECOWASH SINGLE MACHINE RELAY MODULE

ADLF300000 ECOWASH FLUSHING KIT PP WITH EV WITH 3 INLETS

ADLF600000 ECOWASH FLUSHING KIT PP WITH EV WITH 6 INLETS

ADVIL000 LAUNDRY CHECK VALVE 1/4MNPT-8X12 PVC-PTFE-DT-HAST WHITE COL.

ADVIL100 LAUNDRY CHECK VALVE 1/4MNPT-8X12 PVC-PTFE-VT-HAST GREY COL.

ADLFM010 ECOWASH FLUSHING KIT PP ADDING MODULE WITH 3 INLETS

ADLFM003 BASIC MULTI-MACHINE SYSTEM DISTRIBUTION PANEL (2 MACHINES) WITH PVDF SOLENOID VALVES

ADLFM004 ADDITIONAL PVDF SOLENOID VALVE FOR FLUSHING MANIFOLD KIT

STANDARD KIT

ADSP3400019 SUCTION LANCE WITH FITTING BARB

SPARE PARTS

ADSP8000171 COMPLETE PHARMED TUBE (100L/H)

ADSP8000173 COMPLETE SILICONE TUBE (100L/H)

ADSP8000197 COMPLETE SANTOPRENE TUBE (100L/H)

ADSP8000169 COMPLETE PHARMED TUBE (20L/H)

ADSP8000176 COMPLETE SILICONE TUBE (20L/H)

ADSP8000196 COMPLETE SANTOPRENE TUBE (20L/H)

PD8039 COMPLETE ROLL HOLDER FOR 100 L/H PUMPS

ADSP8000023B COMPLETE ROLL HOLDER FOR 20 L/H PUMPS

OPTIONAL

ADSP6000651 PVC CRYSTAL TUBE 8X12

ADLASM0A01 SUCTION LANCE T-A (5/10L-H400) GL-DT(EPDM) 8X12 WITH LEVEL PROBE/ WITHOUT CONNECTOR

ADLASM2A01 SUCTION LANCE T-A (30L-H490) GL-DT(EPDM) 8X12 WITH LEVEL PROBE/ WITHOUT CONNECTOR

ADLASM1A01 SUCTION LANCE T-A (60/100L-H700) GL-DT(EPDM) 8X12 WITH LEVEL PROBE/ WITHOUT CONNECTOR

SINGLE LAUNDRY MACHINE SYSTEMModular systemQuick and easy installationFrom 3 to 8 pumpsFlow rates LF up to 20lt/h HF up to 100lt/hModular flushing manifold includedProgrammable via AQUAware SW for PCIP65 protection degreeStatisticsPriming button for each pump

The Central module is composed of:Three pumps (each pump can have a range of up to 20l/h or 100l/h).One input for level control.One input for flow sensor.Eight intputs for the signals coming from the washing machine (Signal Types: 12 VDC 24 VAC 110 VAC 230 VAC).An output for flushing manifold solenoid valve.A connector for communication with the console (not included).One 24 VDC 0.5 A output for alarm.An output relay for alarm.One DB9 connector for RS-232 communication with PC.

Model

CODE DESCRIPTION

EWL3LS0000 ECOWASH LIGHT 3 PUMPS 20 lt/h SANTOPRENE 230V WITH KIT

EWL3HS0000 ECOWASH LIGHT 3 PUMPS 100 lt/h SANTOPRENE 230V WITH KIT

EWL4LS0000 ECOWASH LIGHT 4 PUMPS 20 lt/h SANTOPRENE 230V WITH KIT

EWL4HS0000 ECOWASH LIGHT 4 PUMPS 100 lt/h SANTOPRENE 230V WITH KIT

EWL5LS0000 ECOWASH LIGHT 5 PUMPS 20 lt/h SANTOPRENE 230V WITH KIT

EWL5HS0000 ECOWASH LIGHT 5 PUMPS 100 lt/h SANTOPRENE 230V WITH KIT

EWL6LS0000 ECOWASH LIGHT 6 PUMPS 20 lt/h SANTOPRENE 230V WITH KIT

EWL6HS0000 ECOWASH LIGHT 6 PUMPS 100 lt/h SANTOPRENE 230V WITH KIT

ACCESSORIES

ADLASM0A01 SUCTION LANCE (5/10L-H400) GL-DT (EPDM) 8X12 WITH LEVEL PROBE/ WITHOUT CONNECTOR

ADLASM2A01 SUCTION LANCE (30L-H490) GL-DT (EPDM) 8X12 WITH LEVEL PROBE/ WITHOUT CONNECTOR

ADLASM1A01 SUCTION LANCE (60/100L-H700) GL-DT (EPDM) 8X12 WITH LEVEL PROBE/ WITHOUT CONNECTOR

SPARE PARTS

ADSP8000169 COMPLETE PHARMED TUBE (20L/H)

ADSP8000176 COMPLETE SILICONE TUBE (20L/H)

ADSP8000196 COMPLETE SANTOPRENE TUBE (20L/H)

ADSP8000171 COMPLETE PHARMED TUBE (100L/H)

ADSP8000173 COMPLETE SILICONE TUBE (100L/H)

ADSP8000197 COMPLETE SANTOPRENE TUBE (100L/H)

PD8039 COMPLETE ROLL HOLDER FOR 100 L/H PUMPS

ADSP8000023B COMPLETE ROLL HOLDER FOR 20 L/H PUMPS

ADSP6000671 SOLENOID VALVE 3/4 M/M 24VDC

PD3314 SEAL WITH FITTING FILTER

EWLAP1L0000 PUMP MODULE 20 L/H WITHOUT TUBE

EWLAP1H0000 PUMP MODULE 100 L/H WITHOUT TUBE

riple system for any model of dishwashing machine

The NEW system AQUA OPL has been designed to dose up to three chemicals into a small laundry machines. Thanks to microprocessor digital technology and a LCD display, the AQUA OPL is easy to program and able to make the most economical use of each chemical. Thanks to Bluetooth technology the AQUA OPL can be connect with a PDA or Smartphone. The Bluetooth make easy the way to program the system, nomore uncomfortable situation behind the laundry machine. SW application for Bluetooth Aqua Control OPL can be installed on devices with Microsoft Windows Mobile 6 or later and Microsoft Bluetooth stack, on PCs running Windows XP or 7 operating system and with Microsoft Bluetooth bluetooth driver Enumerator.

Keeps in memory all the statistics data regarding chemical consumptions, working time and trigger signals counter total and per day.Password: The programming and the statistics data are fully protected by a 4-digit password.Level alarms: Each chemical has its input for the level probe.Protection degree: IP65 against dust and water sprays.Pharmed tubeOutlasts silicone tubing in peristaltic pumps by up to 30 times.Very good general chemical resistance.Temperature resistant from -51 C (-60 F) to 135 C (275 F).Meets USP Class VI, FDA and NSF criteria.
