Min. Order (MOQ)
1 Set(s)
-
Accuracy class 0.05%, 0.1%
Power supply AC 220V ± 10% or AC 110V ± 10%, 50/60Hz
-
U1, U2, U3 Range 10V, 20V, 50V, 100V, 200V, 400V, 800V
Output range (0-120%)% RG
-
Adjustment resolution 0.01% RG
Output stability 0.01%/min
-
Measurement accuracy 0.05% RG
Output load capability 50VA
-
Measurement resolution ≤5×10-5 RG
I1, I2, I3 Range 0.1A, 0.25A, 0.5A, 1A, 2.5A, 5A, 10A, 25A, 50A, 100A
-
Output range (0-120)% RG
Adjustment resolution 0.01% RG
INTRODUCTION:The device is composed of Program-Controlled Three-Phase standard power resource, DC standard power source, Three Phase Multifunction Reference standard meter, computer and management software. The technical index of the device is compliance with national industry related standards and verification regulation. It can be used at power Grid Company, power Supply Company and power plants for measuring and testing power institutions, also it can be applied at railway, petroleum, chemical industry and mining enterprises, etc. FEATURES1.Normal indicating instrument2.Power frequency and dc digital instrument3.Transducer4.Electric energy meter5.Error of the ac sample6.The meters it can the verify: ACDC voltmeter, ammeter, singlethree-phase active, reactive power meter, phase 7.meter, for access to power, frequency meter, synchronous meter, etc.8.The transducers types it can verify, ACDC voltage transducer, current transducer, singlethree-phase active, 9.reactive power transducer, phase transducer, a power factor transducer, frequency transducers.10.The watt-hour meters types it can verify: electronic type and inductive single-phase and three-phase meritorious electric energy meter and reactive watt-hour meter.11.Can be set and measuring 2-31 times harmonic.12.Wide measuring range, high stability, high resolution, low distortion degree.13.Automatic data rounding, various forms of certificate format, inquires and print convenient14.Under the computer control, it can realize the automatic verification for watt-hour meters and transducers, semi-automatic verification for all kinds of instruction machine15.Its block structure, convenient for inspection and it can be used independently16.Automatic failure detection can avoid the damage of equipment which caused by wrong operation
Additional Information:
Payment Terms :
T/T, Western Union,
Delivery Time : 7 Days
