We offer the best product range of Elevator Traction Machine.
One of the best manufacturers of Elevator Traction Machines is “J.D. Engineering Works” since 1975 they are in the Engineering Profession. The technical team is always enthusiastic towards their work. They always try to manufacture products that are eco-friendly or consume less input or give more output. J.D. Engineering Works always serve better to their customers.
Gearless Elevator Traction Machine
A gearless elevator machine is a head on direct-drive system, there is no gear between the motor and direct sheave (pulley). Manual breaking system is also present in the machine.
Because of Low rpm the life of the bearing is drastically high. JD Engineering Works choose best and quality approved raw material to make their products.
J.d. Engineering Works are manufacturing series of elevator machine:-
1. JDE 24P 6 Series: This is basically a 6 passenger elevator2. JDE 24P 8 Series: This is basically an 8 passenger elevator motor.2. JDE 24P 10 Series: This is basically an 10 passenger elevator motor.2. JDE 24P 13 Series: This is basically an 13 passenger elevator motor.2. JDE 24P 15 Series: This is basically an 15 passenger elevator motor.
Speciality of JD Engineering Works Elevator Motor:-
Gearless Technology: Gearless Technology has been used in this Motor, which helps to boost the speed and makes the ride experience better.
Additional Information:
Payment Terms :
Packaging Details : PACKING LIST :-
Gearless Machine
Break Releaser
Break Releaser Wire
Encoder Wire
4mm Three-phase Wire
Specifications
| Material | Cast Iron |
|---|---|
| Voltage | 380VAC Three Phase |
| Capacity | 6 Passengers |
| Usage/ Application | Uses in Lifts/Elevators |
| Power | 2.8 KW |
| Number Of Ropes | 4 |
| Current | 8 amp |
| Weight | Approx. 160 kgs |
| Frequency | 24 HZ |
| Warranty | 4 Years |
| Torque | 220 NM |
| Usage/Application | Use in Lifts or Elevators |
| Max Static Load | 2500 Kgs |
| Brake Voltage | 110V DC |
| I Deal In | New Only |
| Brand | J. D. Engineering Works |
| Country of Origin | Made in India |
| IP Protection | IP 41 |
| sheave diameter | 320 mm |
