Our Product / Services
Our offered Product range includes Double Unit Organ Bath, Demostrationde Mountable Transformers, Linear Air Track, Viscometer Bath and SEED GERMINATOR DUAL CHAMBER.
Milky white and black screen fitted on a base board with diffused light arrangement overall dimensions are 23"x15"x18" high. A stainless upright with adjustable slide arm with clamp magnifier, main cord and plug.
A Perspex organ bath with fine thermostatic temperature control; electric stirrer; and complete set of accessories, making it a versatile unit for all research work. Bath 12"x9"x8", with leak proof dovetailed joints, resting in sturdy metal frame; top of the bath carries a 1"x3/8" thick band, for fixing accessories, Inside the bath is a metal sheathed heating element (easily replaceable), controlled by means of a fine adjustable thermostat with sensitivity 1C.
The stirrer unit is completely independent and dips in the bath in one corner, fixing on its special stainless steel upright. A MS junction box is fitted to the bath frame, and carries all the electrical leads and connections, Two pilot lamps indicate functioning of the thermostat and stirrer.
Standard components are :-
a) Double set of glass inner vessels.
b) Oxygen tubes
c) Warming coils
d) Two stainless steel capillary levers.
e) Four stainless steel uprights with boss heads,
f) X blocks.
Round glass or S.S. jar of 30 cms. dia. 30 cms. depth motor fitted with a stirrer having water circulation to maintain gradient of temp. Suitable to hold 6 viscometers. Digital Electronic Temp. Controller and Indicating lamps. Temp. Range 5C above embient to 95C. Accuracy 0.1C.
Square section aluminium alloy track, length 1.5 m, with staggered holes, supported on two light alloy castings. One support has a two point contact and other a one point contact for lateral and horizontal adjustments by means of a knurled screw. Identical end caps enable air to be introduced from either end of the track keeping the other end closed.
Comprising a wooden resonance box of 114 cm length, 12.5 cm width and 10 cm height, with two rules 1 meter long sub-divided into millimeters. One each brass and steel wire of different diameter attached to fixed bridge and tensioned by fine adjustment pegs, two moveable bridges, pulley and fixed screw to enable a third wire to be fixed for tensioning by masses. One each additional wire of steel and brass, each 1.5 m lenght and of 22 SWG.
|
Made of Polypropylene, these cone shaped flasks are rigid, translucent & autoclavable. The screw cap keeps the contents of the flask contamination free and makes the flask leakproof. Threads should be disengaged before autoclaving.
Most suitable for conducting various experiments on a variety of seeds under different conditions of temperatures and humidity. Atmospheric conditions are created with the chamber to perform different experiments without going onto the field. The walled unit has inner chamber made up of anodized aluminum or stainless steel and outer outer chamber of M.S sheet duly painted. Full view inner glass door permits inspection of specimens. Both compartments are provided with independent controls. Each chamber can accommodates 14 perforated trays of size 430*480m.m. each. Humidity (NOT ADJUSTABLE) IS created in a S.S. water reservoir filled at bottom in both chambers to create 90% to 95% -+ 3% RH humidity.
INSIDE CHAMBER SIZE (WXHXD) (a)One chamber can control temperature from ambient to 50%c -+ 1 degree c. and the other chamber is fitted with ISI marked SHRIRAM compressor so as to maintain temperature from 5 degree to 50 degree c. -+1 degree c. (b)-do- same as above but fitted with heating and cooling system in both chambers, so as to control temperature from 5 degree c. to 50 degree c. -+ 1 degree in both chambers.
OPTIONAL ACCESSORIES (a)Interior illumination with 3 nos. fluorescent tubes (for each chamber) (b)Exterior illumination with 3 nos. fluorescent tubes (for each chamber) (c)Automatic 0-24 hour timer to regulate cyclic illumination conditions(for each chamber) (d)Humidity control arrangement from 55% to 95% -+3% RH, controlled by humidistat. (e)Electronic digital temperature indicator-cum-controller (for each chamber) (f)Dual setting digital temperature controller for setting two different temperatures for day night (g)Automatic voltage stabilizer 3 KVA (for each chamber)
Comprises U & I cores of low loss magnetic material, to form a closed core of cross section 25 mm in plane of laminations, 32 mm perpendicular to them is an I - core of length 102 mm. U core external height 102mm. Internal height to take bobbin length 77 mm. Pair of pole pieces, each 65x30x25 mm with on end shaped to part of a cone for maximum flux density. Hole drilled through total length along cone axis to take a light beam. Pole pieces will accept supertrods & shading ring (provided with accessories) & may be clamped on any separation on U core, or in contact as a non laminated I - core. Cast aluminium alloy stand consisting of a heavy base on four rubber feet with removable clamping arms. Maximum dimensions of base 190x200x115 mm. Channel 35 mm wide & 3 mm deep to take transformer core, extends across full width. Integral support for arms, to rear, is below the level of the pole pieces. Arms pivot on steel spindle with adjustment of knobs to rear bringing hard rubber pads at front end of arms to bear on transformer core. Synthetic hammer finish except of clean metal in channel & 4 mm hole to take on earthing plug lead. Complete with all the accessories.
