We offer a complete product range of Safety Relays Mats
We are leading manufacturer and supplier of Safety Relays Mats pressure-sensitive safety mat is a presence-sensing device (PSSD). When someone steps onto it, embedded contacts change state—triggering a controller or relay to stop hazardous machinery immediately
However, mats alone cannot monitor for open circuits or faults—they need a safety relay or dedicated mat controller to meet standards like ISO 13849 or SIL 3
Safety Mat
Typically 9–15mm thick with rugged, non-slip rubber or PVC surfaces.
Operate at 24VDC and detect 20–30kg pressure to trigger
Durable: millions of cycles, IP65 protection, wide temp range
Mat Controller / Safety Relay
Accepts 4-wire input (two redundant channels) from the mat.
Monitors for open/short circuits, includes auto/manual reset, and activates safety outputs
Brands like Rockwell MatGuard, Banner Engineering SM Series, Schneider, Dold, HTS, Omron offer reliable units with safety category 3–4/PLd–e or SIL 3
Applications
Ideal for safeguarding around:
Injection moulding & stamping machines
Robot cells & welding zones
Material handling and conveyor areas
Presses, lifters, automatic doors
Benefits include cost-effective coverage vs. light curtains, ideal in muddy or crowded environments .
Safety Relay for Safety Mat (24VDC): Tailored for mat use, complies with CE, pairs with ATO mats
Phoenix Contact Safety Relay: Trusted industrial-grade relay , ensures dual-channel monitoring.
Schneider Electric XPSBAC34AP Safety Relay: DIN-rail mount modular relay with redundant safety inputs.
Basic pressure mat Sizes 0.5–1m²; 24V, 4-wire, 12–15mm thick
Rugged IP65 mat Custom sizes, NO/NC options, CE-certified
Safety relay/controller 4-wire input, dual-channel, auto/manual reset, PLe or SIL3 ready
Installing a Reliable Safety Mat System
Select suitable mat: Choose size, thickness, pressure threshold, weather or chemical resistance.
Use proper relay/controller: Ensure it's designed for 4-wire mat inputs with fault monitoring.
Wire redundancy correctly: Mat’s two internal circuits to S11–S12 and S21–S22; jumper feedback Y1–Y2; reset switch S33–S34
Test & certify: Validate fault detection and machine stops according to ISO 13849 or IEC 62061.
Maintain spares and schedule replacements: Relays typically need 5–7year replacements
Pressure-sensitive mat (9–15mm, IP-rated, 20kg activation)
Safety relay/controller (4-wire input, dual-channel, auto/manual reset)
Proper wiring and redundancy to meet functional safety standards
This setup offers reliable, cost-effective protection for hazardous zones. Let me know if you'd like quotes, datasheets, or spec comparisons for specific models or configurations!
