Packaging Details : Solar Battery Charger is an electronic device that uses solar photovoltaic (PV) energy to charge batteries safely and efficiently. It regulates the voltage and current coming from solar panels and ensures batteries are charged without overcharging, overheating, or discharging.

Solar home lighting systems

Telecom towers

Street lighting systems

Solar UPS/inverters

Remote industrial equipment

EV and surveillance systems
Working Principle
Solar panels generate DC electricity from sunlight.

Charge controller manages the flow of electricity to the battery, avoiding overcharge.

Battery stores energy for later use (typically during night or cloudy conditions).

Optional: DC loads (lights, sensors, etc.) or inverter for AC output.

Types of Solar Battery Chargers

PWM (Pulse Width Modulation) Basic controller, slows current as battery nears full charge
MPPT (Maximum Power Point Tracking) Advanced type, maximizes power from panel even in variable light
Smart Solar Charger IoT-enabled, app-connected, multi-stage charging
DC-DC Solar Charger For direct DC output to devices or systems
Hybrid Inverter/Charger Combines inverter + solar charger + grid charging

leelavati automation
Main Components

Solar Charge Controller Regulates voltage & current to batteries
Solar Panel Input Accepts voltage from PV array (12V, 24V, 48V)
Battery Bank Output Connects to lead-acid, Li-ion, or tubular batteries
Display/Indicators Shows charging status, fault, battery level
MPPT Tracking Circuit (optional) Boosts performance 1530% over PWM

Compatible Battery Types
Lead-Acid (Tubular/SMF)

Lithium-ion (LiFePO, NMC)

Nickel-based batteries (less common)

Chargers should be selected based on battery voltage (12V/24V/48V) and chemistry (to match charging profile).

Specifications

Input Voltage 12V 150V DC (depending on panel)
Output Battery Voltage 12V / 24V / 48V / 96V DC
Charging Current 5A 80A (based on battery size)
Efficiency 85% 98% (MPPT > PWM)
Temperature Range -10C to +60C (industrial grade)
Protection Features Overvoltage, reverse polarity, short circuit, overheat

leelavati automation
Industrial & Residential Applications
Telecom Towers 48V Li-ion battery charging

Solar Street Lights Compact 12V PWM chargers

Off-grid Homes/Farms 12V/24V MPPT for 15 kW setups

Industrial Inverter Backups Charging large 48V+ batteries

IoT or Remote Monitoring Devices Solar + battery + low-power charger

Features to Look For
Multi-stage charging: Bulk Absorption Float

Battery temperature compensation

LCD display or Bluetooth/app support

Auto battery type detection

MPPT tracking (for high panel efficiency)

RS-485/Modbus communication (for integration with BMS/SCADA)

leelavati automation
IEC 62509 Performance of charge controllers
MNRE (India) Ministry of New & Renewable Energy compliance
IS 16221 Indian solar power controller specs
CE / RoHS Safety and environmental certifications

PWM Charger (basic) 12V / 24V 5A 20A
MPPT Charger (high-efficiency) 12V 48V 10A 60A
Smart MPPT Charger (Bluetooth/App) 12V/24V 20A 40A
Industrial MPPT (48V96V, >60A) 48V/96V 60A 80A
input voltage range, controller type, and smart features.

Features
Bluetooth App Monitoring (e.g., VictronConnect)

Wi-Fi enabled cloud dashboards

Auto cutoff and restart

Load management for DC appliances

Data logging + BMS integration

1kW Solar Off-Grid System
2 330W solar panels (660W total)

1 MPPT charge controller, 24V, 30A

2 12V, 150Ah tubular batteries (in series)

Load: LED lights, fan, mobile charging, water pump
