Bagger Multihead Weigher

Get Latest Price

Filling Capacity (Range)5 gm - 5 Kg
Reel core diameter70-76mm
Electricity Required420V, 3Ph, 50Hz
Output Speed50 - 100 Pouches / min. (Depends on material, Weight and Pouch size)
Supply TypeManufacturer, Exporter, Supplier, Retailer
Preferred Buyer Location All over the world

View More Details

Send Enquiry

Company Information

Phoenix Dison Tec LLC

Andheri East, Mumbai, Maharashtra

View Number

Member Since 7 Years
Nature of Business Retailer

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

Maximum Roll WeightServo driven
Reel core diameter70-76mm
Compressed Air Required2 CFM at 6 bar pressure
ModelIPM900
Machines weight (Approximate)700kg to 1500kg
Roll HoldingPneumatic shaft
Output Speed50 - 100 Pouches / min. (Depends on material, Weight and Pouch size)
ControlCPU motion controlled
Electricity Required420V, 3Ph, 50Hz
Heating systemHot bar induction heating
Dimension (Approximate)1800(W) x 1800(L) x 3600
Filling Capacity (Range)5 gm - 5 Kg
OperationServo driven
Packaging MaterialLaminated Film
Available Models5gm-100gm , 20gm-200gm , 100gm-500gm, 200gm-1Kg, 200gm - 5Kg.

IPM servo machines are very high speed machines of internatonal standards with all precision. The high end CPU motion control technology gives the highest speed up to 100 pouches/min. All operations are handled by individual servo motor. IPM servo machines are designed only for large scale manufacturer. These machines run at high speed with high accuracy & sealing intactness.
