| Media | Liquid (Conductive) | Process Pressure | 10 kg/cm2 max |
| Conductivity | > 5 p s/cm | Material of Construction | Lining - Rubber / PTFE (Teflon) |
| Viscosity | 200 cp max | Flange - CS / MS /SS | |
| Line Size | 15 NB to 600 NB | Electrode - SS 316L / Hastalloy C / Platinum | |
| Excitation | Pulsed DC Coil | Coil Housing - MS / SS304 | |
| Type of output | 1) 40 to 20 mA DC, Isolated | Power Supply | ) 24V DC, External |
| 2) Pulse | 2) 90-250 VAC, 50 Hz | ||
| Display | 16X2 LCD - 4 digit for Flow Rate & | Power Construction | <10VA |
| 8 digit for Tatalised Flow | Isolation | 1.4 KV between Input, Output & Power Supply | |
| Calibration | As per requirement (Factory Calibrated) | Response Time | < 100mSec |
| Accuracy | +/- 0.5% F.S. (For 20 to 100% Flow) | Temperature Coefficient | +/- 0.1% per OC |
| Linerity | +/- 0.5% | Transmitter Enclosure | Flame proof, IP-65, IIA IIB CMRI certified |
| Repeatability | +/- 1% | Process Connection | ASA 150 flange \, as per table B 16.5 |
| Process Temp. | 70 oC Rubber/1500C PTFE | Mounting | In Line (Horizontal OR Vertical) |
| Communication Port | On Demand | Operating Conditions | Temperature 0 to 550 C, Humidity 5 to 95% on condensing |
