Manual 400 3-6kw SS Multi Mill Machine, For PHARMACEUTICAL MACHINERY, Voltage : 415

₹ 95,000 - ₹ 1.10 Lakh / Bag

MaterialSS
Driven Type3-6kw
Packaging TypeSS
CertificationCE Certified
Supply TypeManufacturer, Exporter, Supplier, Retailer, Trader
Preferred Buyer Location All over the world

Company Information

Member Since 22 Years
Nature of Business Manufacturer
Year of Establishment 2001

Ask for more detail from the seller

Report incorrect details

Product Details
Company Details

Packaging TypeSS
ConditionNew
Automation GradeManual
CertificationCE Certified
Country of Origin415
Number Of FlowerMulti Mill
Availability400
Total Carbohydrate1year
Rotor Diameter95
Rotor Speed750 / 1500 / 2300 / 3000 RPM
Brand NameACUMAC
ApplicationPHARMACEUTICAL MACHINERY
MaterialSS
Driven Type3-6kw
Material Discharging Height760 ± 5 mm
Output *50 to 200 Kgs. / Hr.
Motor3 Hp / 1440 RPM
Material Charging Height1460 ± 5 mm
Rotor Assembly Diameter250 mm Approx.
Screen DimensionInner Diameter 265 mm / Height 140 mm
Beaters12 Nos. with knife and impact edges and 2 nos. scraper blades

The multi mill machine is specially design to grind the material efficiently. The machine is provided with the beaters and scraper blades. The beaters and scraper blades are fabricated by S.S. 304.

S.S. PERFORATED SCREENS :

0.5, 1.0, 1.5 mm Hole Dia.
2, 3, 4, 5, 6 mm Hole Dia.
7, 8, 10, 15, 20, 25 mm Hole Dia.

THE FEATURE :

the machine is provided with reversible switch for the beaters to change the direction of the beaters
All the contact parts quickly and easily dismantled and cleaned.
The machine is very efficient and designed for continuous operation.
Cylindrical screen for more output.
For the mobility, the castor wheels are provided
The flameproof electrical components are provided on demand.
The S.S. 304 is used to fabricate the beaters and scraper blades.
