IMC Automatic Pipe Threading Machine

We offer well designed Threading Machines in India and abroad. The Threading Machines we offer is known for superb efficiency and low operational & maintenance cost. We are counted among the top Hydraulic Pipe Threading Machine Manufacturers, Suppliers, and Exporters. We offer Threading Machines at reasonable prices. The Hydraulic Pipe Threading Machine Consists of Base, Head Stock, Saddle, Bed or Pillar Type Clamping Vice, Die Head, Apron and Vice Jaws.

Pillar Type Hydraulic Threading Machine comes with self opening the die head with head stock gears hardened with power pack, with one hydraulic cylinder for lead screw box nut engaging, one hydraulic clamping cylinder and one hydraulic cylinder for die-head opening with micro switches with automation with control panel.

Suitable For

• Matric
• BSP
• BSPT
• NPT
• UNF
• UNC
• BSW
• Acme threads
• B.S.F. threads

Range

• 1/2″ to 2.1/2″ Capacity Pipe
• 1″ to 4″ Capacity Pipe
• 2.1/2″ to 6″ Capacity Pipe
• 4″ to 8″ Capacity Pipe

About Components

• Head Stock : A heavy duty geared Head Box is of best quality casting providing support to the spindle bearings. The box is of gear type, lubricated, fitted with three extra heavy duty bearings.
• The Bed : The bed is pillar type having two pillars made of best quality steel nicely finished & duly hard chrome plated in the most modern hard chrome plating unit.
• The Saddle : The Saddle is fitted on two pillers very precisely. It runs on pillars very smoothly and accurately to the Head Stock alignment.
• The Apron : The apron gives movement to the saddle with head transfer along with pillars through steel rack and pinion arrangements. It’s all gears are made of best quality steel.
• Vice Jaws : The vice jaws made from the best quality alloy steel are fitted on the saddle well aligned with the head stock center fitted in a heavy duty box type vice. The jaws are heat treated. The movements of jaws are controlled by a screw on the saddle.
