Technical Specifications :
| Eye piece Magnification | : | 12.5x/18B |
| Objective Focus | : | f=200mm |
| Working Distance | : | 195mm |
| Magnification for Main Microscope | : | 4.6x ~27x zoom magnification |
| Magnification for Assistant Microscope | : | 6.2x, 9.3x, 14x |
| Diameter of Field | : | ∮46mm ~8.5mm |
| Adjustable Diopter | : | ±6D |
| Adjustable Range of Pupil Distance | : | 55mm ~ 75mm |
| Maximal Resolution | : | 126LP/m |
| Illumination Source | : | 15V/150W, Medical cold-reflection Halogen Lamp |
| Illumination Type | : | 6°Coaxial illumination, 6°± 2° Coaxial illumination |
| Filter | : | UV& IR filter, yellow spot protection filter, red free, GG435, GG475 |
| Maximal Illumination | : | ≥ 50000 lx |
| Maximal Height for Microscope | : | 1710mm |
| Reaching Radius of Arm | : | 1320mm |
| Adjustable Vertical Range | : | 710mm ~ 1310mm |
| Fine Focus Speed and Range | : | ≤ 2mm/s, 50mm |
| Speed for X/Y and Range | : | ≤ 2mm/s, 50mm |
| Arthrosis Fixation | : | Electromagnetic Lock |
| Input Voltage | : | AC 220V ± 10% /50HZ ±1HZ, AC 110V±10%/60HZ ±1Hz |
| Power | : | 480VA |
| Fuse | : | AC 250V T5.0A AL (51S-050H), AC 125V T 10.0AL (51S-01DDL_ |
| Electrical Safety Standard | : | Executive to GB 9706.1-2007, Class I |
| Packing Volume | : | 1.494cbm, 5 cartons |
| Total Gross Weight | : | 302kg |
| Optional Objectives | : | F= 250mm/300mm/350mm/400 |
