Our Products
We offer the best product range of Twin Decoiler, Pallet Decoiler, 2500 Kg Compact Decoiler Cum Straightener, Heavy Duty Hydraulic Cradle Decoiler Cum Straightener and Decoiler Straightener with Pneumatic Feeder.
Complete line consists of following.
The Gripper Feeders cum Decoilers & Straighteners, which we deliver, are reckoned for their sturdy make and long service life. Our product is available in nontoxic and industrial-grade packaging materials that ensure the products are safe from damage and reach buyers in brand new conditions. We are backed by a quality control wing that comprises experienced quality inspectors who strictly check all the products before making the final dispatch.
The Pneumatic Feeders cum Motorized Decoilers have power rating of 26KW. With the immense knowledge and experience, our company presents a comprehensive array of Pneumatic Feeder cum Motorized Decoiler in the national market. A capacious warehouse and well-organized Warehouse Management System helps us in loading and unloading of all the products within short time. We keep our inventory updated by recording warehouse transactions and delivery of goods.
Our Pneumatic Feeders cum Straighteners have robust construction. Buyers can order our products in bulk, as we maintain year around availability. In addition, we have reliable transportation system to make timely delivery. We have high-tech and spacious storage unit that is incorporated with all required amenities vital for a safe storage of the products till the final send off. Supervised by efficient personnel, they ensure zero damage to the items to keep up the standards.
Our Pneumatic Decoilers are manufactures using stainless steel. Being a customer-oriented firm, we make available numerous modes of payment and assure them for confidentiality of transaction. Also, our payment modes are authorized. As a dependable name, we source raw materials from the well-known providers who are certified. Thus, we guarantee only quality-approved products at customer's end.
These Economical Decoilers are fitted with a motor of greater horse power. As a trusted name, we make use of only premium packaging material to pack the products in order to ensure their complete safety during transit. Moreover, our packaging experts strictly check the same. We are associated with renowned transportation providers to ensure delivery of consignments is carried out without a glitch and in a timely manner.
We have a good rapport with the leading e-commerce merchants who work for us and assure safe and secure transaction of money. Also, we facilitate our clients to make a transaction in both online and offline modes. In our well-constructed warehouse, we store the entire lot under safe conditions and away from various damaging factors such as direct sunlight, moisture, dust, rain, and others.
Features :
Other Details:
The Control Panel would have following standard parameters:
Features:
We make available Double Head Decoiler with feeding speed of 15m/min. We properly package our products using premium supplies and ultramodern technologies to make sure they endure shipping, handling, mechanical damages etc. We provide customized packaging solutions. We have a team of expert quality analysts that stringently checks each and every stage for ensuring quality products at buyer's end.
Specification
| Model | Max. | Max. | JAW | Expansion | OD. | Power | Centre Height | Occup. Area (mm) |
| Weight kg | Width (mm) | Expansion | Type | Max | (hp) | from Floor | L. W. H. | |
| (mm) | (mm) | (mm) | ||||||
| TD-5 | 500 X 2 | 150 | 300 to 500 | Mech Screw Type | 1000 | 0.5 X 2 | 900 | 2000 X 2000 X 1800 |
| TD-10 | 1000 X 2 | 300 | 330 to 450 | Mech Link Type | 1200 | 0.75 X 2 | 1006 | 1850 X 1850 X 1600 |
| TD-16 | 1600 X 2 | 300 | 330 to 450 | Mech Link Type | 1200 | 1.0 X 2 | 905 | 2100 X 2100 X 1730 |
| TD-25 | 2500 X 2 | 400 | 420 to 530 | Mech Link Type | 1200 | 1.5 X 2 | 1220 | 2250 X 2250 X 1900 |
Motorised Decoiler ( Standard Models )(Vertical )
| Model | Max. Weight kg |
Max. Width (mm) |
JAW Expansion (mm) |
Expansion Type (mm) |
OD. Max (mm) |
Power (hp) |
Centre Height from Floor | Occup. Area (mm) L. W. H. |
|---|---|---|---|---|---|---|---|---|
| VD-1(PNE) | 100 | 100 | 300 to 380 | Mech Link Type | 800 | 6 bar | 600 | 850X800X1100 |
| VD-2 | 200 | 150 | 150 to 350 | Mech Screw Type | 800 | 0.5 | 600 | 850X800X1100 |
| VD-5 | 500 | 150 | 300 to 500 | Mech Screw Type | 1000 | 0.5 | 840 | 1050X950X1400 |
| VD-10 | 1000 | 300 | 330 to 450 | Mech Link Type | 1200 | 0.75 | 1005 | 1250X1100X1650 |
| VD-16 | 1600 | 400 | 330 to 450 | Mech Link Type | 1500 | 1 | 1040 | 1700X1150X1900 |
| VD-25 | 2500 | 400 | 420 to 530 | Mech Link Type | 1500 | 1.5 | 1050 | 1700X1300X1850 |
All above equipments are designed for Line speed of 12-15 Mtrs. Per Minute. Models of higher capacity or Higher or Lower Line speeds are available on request.
Technical specifications are indicative and subject to change to suit end application.
Motorised Decoiler (Non Standard Models ) (Vertical )
| Model | Max. Weight | Max. | JAW | Expansion | OD. Max | Power | Centre Height from Floor | Occup. Area |
|---|---|---|---|---|---|---|---|---|
| kg | Width | Expansion | Type (mm) | (mm) | (hp) | (mm) | ||
| (mm) | (mm) | L. W. H. | ||||||
| VD-30 | 3000 | 600 | 460 to 560 | Mech/Hyd Link Type | 1500 | 3 | 905 | 1700X2000X1700 |
| VD-50 | 5000 | 800 | 460 to 560 | Mech/Hyd Link Type | 1500 | 5 | 980 | 1700X2500X1700 |
| VD-50 | 5000 | 1300 | 460 to 520 | Mech/Hyd Link Type | 1500 | 5 | 980 | 1700X3000X1700 |
| VD-100 | 10000 | 1300 | 460 to 520 | Hyd Link / Wedge Type | 1500 | 7.5 | 1205 | 1700X3850X2000 |
| VD-100 | 10000 | 1500 | 460 to 520 | Hyd Link / Wedge Type | 1500 | 7.5 | 1205 | 1700X4050X2000 |
All above equipments are designed for Line speed of 12-15 Mtrs. Per Minute. Models of higher capacity or Higher or Lower Line speeds are available on request.
Technical specifications are indicative and subject to change to suit end application.
Additional Information:
Packaging Details : Depend
Motorised Decoiler ( Standard Models )(Vertical )
| Model | Max. Weight kg |
Max. Width (mm) |
JAW Expansion (mm) |
Expansion Type (mm) |
OD. Max (mm) |
Power (hp) |
Centre Height from Floor | Occup. Area (mm) L. W. H. |
|---|---|---|---|---|---|---|---|---|
| VD-1(PNE) | 100 | 100 | 300 to 380 | Mech Link Type | 800 | 6 bar | 600 | 850X800X1100 |
| VD-2 | 200 | 150 | 150 to 350 | Mech Screw Type | 800 | 0.5 | 600 | 850X800X1100 |
| VD-5 | 500 | 150 | 300 to 500 | Mech Screw Type | 1000 | 0.5 | 840 | 1050X950X1400 |
| VD-10 | 1000 | 300 | 330 to 450 | Mech Link Type | 1200 | 0.75 | 1005 | 1250X1100X1650 |
| VD-16 | 1600 | 400 | 330 to 450 | Mech Link Type | 1500 | 1 | 1040 | 1700X1150X1900 |
| VD-25 | 2500 | 400 | 420 to 530 | Mech Link Type | 1500 | 1.5 | 1050 | 1700X1300X1850 |
All above equipments are designed for Line speed of 12-15 Mtrs. Per Minute. Models of higher capacity or Higher or Lower Line speeds are available on request.
Technical specifications are indicative and subject to change to suit end application.
Additional Information:
Delivery Time : 8-10 WEEKS
Motorised Decoiler (Non Standard Models ) (Vertical )
| Model | Max. Weight | Max. | JAW | Expansion | OD. Max | Power | Centre Height from Floor | Occup. Area |
|---|---|---|---|---|---|---|---|---|
| kg | Width | Expansion | Type (mm) | (mm) | (hp) | (mm) | ||
| (mm) | (mm) | L. W. H. | ||||||
| VD-30 | 3000 | 600 | 460 to 560 | Mech/Hyd Link Type | 1500 | 3 | 905 | 1700X2000X1700 |
| VD-50 | 5000 | 800 | 460 to 560 | Mech/Hyd Link Type | 1500 | 5 | 980 | 1700X2500X1700 |
| VD-50 | 5000 | 1300 | 460 to 520 | Mech/Hyd Link Type | 1500 | 5 | 980 | 1700X3000X1700 |
| VD-100 | 10000 | 1300 | 460 to 520 | Hyd Link / Wedge Type | 1500 | 7.5 | 1205 | 1700X3850X2000 |
| VD-100 | 10000 | 1500 | 460 to 520 | Hyd Link / Wedge Type | 1500 | 7.5 | 1205 | 1700X4050X2000 |
All above equipments are designed for Line speed of 12-15 Mtrs. Per Minute. Models of higher capacity or Higher or Lower Line speeds are available on request.
Technical specifications are indicative and subject to change to suit end application.
Features :
Other Details :
Double Motorised Decoiler ( Standard Models )(Vertical)
| Model | Max. Weight kg |
Max. Width (mm) |
JAW Expansion (mm) |
Expansion Type (mm) |
OD. Max (mm) |
Power (hp) |
Centre Height from Floor |
Occup. Area (mm) L. W. H. |
|---|---|---|---|---|---|---|---|---|
| TD-5 | 500 X 2 | 150 | 300 to 500 | Mech Screw Type | 1000 | 0.5 X 2 | 900 | 2000 X 2000 X 1800 |
| TD-10 | 1000 X 2 | 300 | 330 to 450 | Mech Link Type | 1200 | 0.75 X 2 | 1006 | 1850 X 1850 X 1600 |
| TD-16 | 1600 X 2 | 300 | 330 to 450 | Mech Link Type | 1200 | 1.0 X 2 | 905 | 2100 X 2100 X 1730 |
| TD-25 | 2500 X 2 | 400 | 420 to 530 | Mech Link Type | 1200 | 1.5 X 2 | 1220 | 2250 X 2250 X 1900 |
Motorised Decoiler ( Standard Models )(Vertical )
| Model | Max. Weight kg |
Max. Width (mm) |
JAW Expansion (mm) |
Expansion Type (mm) |
OD. Max (mm) |
Power (hp) |
Centre Height from Floor | Occup. Area (mm) L. W. H. |
|---|---|---|---|---|---|---|---|---|
| VD-1(PNE) | 100 | 100 | 300 to 380 | Mech Link Type | 800 | 6 bar | 600 | 850X800X1100 |
| VD-2 | 200 | 150 | 150 to 350 | Mech Screw Type | 800 | 0.5 | 600 | 850X800X1100 |
| VD-5 | 500 | 150 | 300 to 500 | Mech Screw Type | 1000 | 0.5 | 840 | 1050X950X1400 |
| VD-10 | 1000 | 300 | 330 to 450 | Mech Link Type | 1200 | 0.75 | 1005 | 1250X1100X1650 |
| VD-16 | 1600 | 400 | 330 to 450 | Mech Link Type | 1500 | 1 | 1040 | 1700X1150X1900 |
| VD-25 | 2500 | 400 | 420 to 530 | Mech Link Type | 1500 | 1.5 | 1050 | 1700X1300X1850 |
All above equipments are designed for Line speed of 12-15 Mtrs. Per Minute. Models of higher capacity or Higher or Lower Line speeds are available on request.
Technical specifications are indicative and subject to change to suit end application.
Motorised Decoiler ( Standard Models )(Vertical )
| Model | Max. Weight kg |
Max. Width (mm) |
JAW Expansion (mm) |
Expansion Type (mm) |
OD. Max (mm) |
Power (hp) |
Centre Height from Floor | Occup. Area (mm) L. W. H. |
|---|---|---|---|---|---|---|---|---|
| VD-1(PNE) | 100 | 100 | 300 to 380 | Mech Link Type | 800 | 6 bar | 600 | 850X800X1100 |
| VD-2 | 200 | 150 | 150 to 350 | Mech Screw Type | 800 | 0.5 | 600 | 850X800X1100 |
| VD-5 | 500 | 150 | 300 to 500 | Mech Screw Type | 1000 | 0.5 | 840 | 1050X950X1400 |
| VD-10 | 1000 | 300 | 330 to 450 | Mech Link Type | 1200 | 0.75 | 1005 | 1250X1100X1650 |
| VD-16 | 1600 | 400 | 330 to 450 | Mech Link Type | 1500 | 1 | 1040 | 1700X1150X1900 |
| VD-25 | 2500 | 400 | 420 to 530 | Mech Link Type | 1500 | 1.5 | 1050 | 1700X1300X1850 |
All above equipments are designed for Line speed of 12-15 Mtrs. Per Minute. Models of higher capacity or Higher or Lower Line speeds are available on request.
Technical specifications are indicative and subject to change to suit end application.
Additional Information:
Packaging Details : Depend.
Motorised Decoiler ( Standard Models )(Vertical )
| Model | Max. Weight kg |
Max. Width (mm) |
JAW Expansion (mm) |
Expansion Type (mm) |
OD. Max (mm) |
Power (hp) |
Centre Height from Floor | Occup. Area (mm) L. W. H. |
|---|---|---|---|---|---|---|---|---|
| VD-1(PNE) | 100 | 100 | 300 to 380 | Mech Link Type | 800 | 6 bar | 600 | 850X800X1100 |
| VD-2 | 200 | 150 | 150 to 350 | Mech Screw Type | 800 | 0.5 | 600 | 850X800X1100 |
| VD-5 | 500 | 150 | 300 to 500 | Mech Screw Type | 1000 | 0.5 | 840 | 1050X950X1400 |
| VD-10 | 1000 | 300 | 330 to 450 | Mech Link Type | 1200 | 0.75 | 1005 | 1250X1100X1650 |
| VD-16 | 1600 | 400 | 330 to 450 | Mech Link Type | 1500 | 1 | 1040 | 1700X1150X1900 |
| VD-25 | 2500 | 400 | 420 to 530 | Mech Link Type | 1500 | 1.5 | 1050 | 1700X1300X1850 |
All above equipments are designed for Line speed of 12-15 Mtrs. Per Minute. Models of higher capacity or Higher or Lower Line speeds are available on request.
Technical specifications are indicative and subject to change to suit end application.
