Internal Grinding Machine

Supply TypeManufacturer, Exporter, Supplier, Retailer
Preferred Buyer Location All over the world

We are the known Supplier of a precision engineered Internal Grinding Machine that is exceptionally well in performance and sturdy in construction. Internal Grinding Machine is widely demanded in bearing, bush and sleeve industries. Our Internal Grinding Machine is easy-to-operate and requires very low maintenance, which enhances its working efficiency as well as its service life.

View More Details

Send Enquiry

Product Details

Specifications

Center Height (Mm)	180
Max. Grinding Diameter (bore) (Mm)	100
Table Speed Infinitely Variable (m/min)	0.1-4
Max. Table Stroke (Mm)	250
Internal Grinding Spindle (Mm)	60x250/80x250
Spindle Speed (Rpm)	18000/28000/12500
Grinding Wheel Motor Power (Hp)	3/5
Work Head Swivel (Deg)	30
Rapid Approach / Auto Retraction (Mm)	3 -10 variable
