We are leaders in the market for providing best range of 10 TR Industrial Water Cooled Chiller, 10 TR Water Cooled Chiller System, 10 TR Centralized Water Cooled Chiller, 10 TR Water Cooled Condenser Chiller and 10 TR Energy Efficient Chiller
| Description | Specification |
| Actual Cooling Capacity | 10.21 TR(35.9 kW) |
| Nominal Rated Capacity | 10.0 TR |
| Compressor Input Power | 5.75 kW |
| Pump Power | 0.75 kW |
| Total Power Input (Chiller only) | 5.75 kW |
| Compressor Type | Hermetic Scroll |
| Compressor Make / Model | Danfoss |
| Quantity of Compressors | 1 No. |
| Refrigerant Circuits | 1 Circuit |
| Refrigerant | R407C /R-410A |
| Total Heat Rejection | 52 kW |
| Full Load EER | 11.23 Btu/Wh |
| Full Load COP | 3.29 W/W |
| Estimated IPLV (COP) | 3.0 3.2 W/W |
| Estimated IPLV (EER) | 10.5 11.0 Btu/Wh |
| Total Power / TR | 0.57 kW/TR |
| Altitude | 0 m |
2. CONDENSER DETAILS (WATER COOLED SHELL & TUBE)
| Description | Specification |
| Type | Shell & Tube Water Cooled |
| Entering / Leaving Condenser Water | 30 C / 35 C |
| Condenser Water Flow Rate | 10.5 11.0 m/h |
| Design Pressure | 150 psig |
| Fouling Factor | 0.000018 mK/W |
| Tube Material | Copper (C12200) |
| Tube OD | 19 mm |
| Pass Arrangement | 2-Pass |
| Shell Material | Carbon Steel (IS 2062) |
| Water Velocity | 1.0 1.2 m/s |
| Pressure Drop | 0.05 0.10 bar |
| Heat Rejection | 49 52 kW |
