Our Products
Our offered Product range includes 20 TR Energy Efficient Chiller, 30 TR High Efficiency Air Cooled Chiller, 30 TR Air Cooled Chiller for Data Center, 30 TR Air Cooled Centrifugal Chiller and 30 tr air cooled chiller.
Technical Specification
| Sr.No. | Parameter | Details |
| 1 | Model | FMACS-20TR-407 |
| 2 | Cooling Capacity | 20 TR |
| 3 | Refrigeration circuit | 1 |
| 4 | Power Supply | 400V-50Hz |
| 5 | Connecting load | 13.32 KW / 24.9 A |
| 6 | Refrigerant | R407 |
| 7 | Refrigerant Control | Thermostatic Expansion |
| 8 | Evaporating SST | 5C |
| 9 | Condensing SDT | 35C |
| 10 | Ambient Temp | 45C |
| 11 | Chilled water Range | +7 TO +10 |
| 12 | Chilled Flow Of Water | 12000 LPH, T 5C |
| 18 | Compressor Types | Scroll |
| 19 | Compressor Qty | 1 |
| 20 | Compressor power | 12 KW /23 A |
| 21 | Start mode | Regular |
| 22 | Capacity control | 0, 50, 100 % |
| 23 | Evaporator Types | Shell and tube |
| 24 | Evaporator pipe connection | 3 |
| 25 | Evaporator Shell MOC | Carbone steel Powder Coted |
| 26 | Evaporator tube MOC | Copper grooved |
| 27 | Condenser types | Shell and tube |
| 29 | Condenser Tube and shell Moc | Copper tube and Carbone steel |
| 30 | Pump | SS-304/1.5 HP |
| 31 | Safety Protection | Inner Thermostat for compressor motor, unit overload relay, high and low pressure switch, reverse phase protection relay, discharge gas thermostat, flow switch, Anti-Freeze protection |
| 32 | Electric control panel | Controller, protection relay, contactor, MCB, preventer, timer. |
| 33 | Dimension(length/width/height) | After confirmation, we will provide dimensions and drawings- |
| 34 | Running weight | - |
|
| Product | Make |
| 1. | compressor | Danfoss(SZ-240-4) |
| 2. | Evaporator | Fidem |
| 3. | condenser | Fidem |
| 4. | Electric panel | Fidem |
| 5. | Flow switch | Castle |
| 6. | Pressure Switch | Danfoss |
| 7. | Expansion valve | Danfoss |
| 8. | Filter | Dryall |
| 9. | Solenoid valve | Danfoss |
| 10. | Electronic components | Schneider |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
30 TR AIR COOLED SCROLL TYPE GLYCOL / WATER CHILLER
A. GENERAL TECHNICAL DATA| 1 | Equipment Model | FMACS-30TR-R22 |
| 2 | Rated Cooling Capacity | 30 TR (Tons of Refrigeration) |
| 3 | Number of Refrigeration Circuits | Two (2) Independent Refrigeration Circuits |
| 4 | Electrical Power Supply | 400 V, 50 Hz, Three Phase AC |
| 5 | Total Connected Electrical Load | 44.6 kW / 64 A |
| 6 | Working Refrigerant | R-22 |
| 7 | Refrigerant Expansion / Control Device | Thermostatic Expansion Valve (TXV) |
| 8 | Design Evaporating Temperature (SST) | 5 C |
| 9 | Design Condensing Temperature (SDT) | 48 C |
| 10 | Maximum Ambient Design Temperature | 48 C |
| 11 | Operating Glycol Temperature Range | 10 C to +10 C |
| 12 | Design Chilled Water / Glycol Flow Rate | 18, 000 LPH @ T 5 C |
| 13 | Condenser Air Flow Rate | 18, 000 CFM |
| 14 | Condenser Fan Type | Axial Flow Fans with Large Diameter Blades |
| 15 | Number of Fans Installed | Four (4) Nos. |
| 16 | Fan Diameter | 20 Inches |
| 17 | Fan Motor Power Rating | 0.45 kW 4 Nos. |
| 18 | Compressor Design & Type | Hermetically Sealed Scroll Compressors |
| 19 | Number of Compressors | Two (2) Nos. |
| 20 | Total Compressor Power Consumption | 38.4 kW / 69.36 A |
| 21 | Compressor Starting Method | Direct / Regular Start |
| 22 | Capacity Control Method | Not Applicable / Fixed Capacity |
| 23 | Evaporator Configuration | Shell and Tube Type Heat Exchanger |
| 24 | Evaporator Water / Glycol Connection Size | 2 Inch |
| 25 | Evaporator Shell Material of Construction | Carbon Steel |
| 26 | Evaporator Tube Material | Internally Grooved Copper Tubes |
| 27 | Condenser Construction Type | Air Cooled Condenser with Aluminium Fins and Copper Tubes |
| 28 | Condenser Tube Outside Diameter | 3/8 Inch |
| 29 | Condenser Structural Support | Galvanized Steel Framework |
| 30 | Chilled Water / Glycol Pumps | Two (2) Nos., SS-304 Construction, 3 HP / 2.2 kW Each |
| 31 | Safety & Protection Features | Compressor Motor Internal Thermostat, Unit Overload Protection, High & Low Pressure Safety Switches, Phase Reversal / Phase Failure Protection Relay, Discharge Gas Temperature Protection, Water Flow Switch, Anti-Freeze Protection |
| 32 | Electrical Control & Instrumentation Panel | Sub-Zero Micro Chill Controller with Protection Relays, Power Contactors, MCBs, Phase Preventer Relay and Time Delay Relays |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
30 TR AIR COOLED SCROLL TYPE GLYCOL / WATER CHILLER
A. GENERAL TECHNICAL INFORMATION| 1 | Chiller Unit Model | FMACS-30TR-R22 |
| 2 | Rated Cooling Output | 30 TR (Nominal Refrigeration Capacity) |
| 3 | Refrigeration System Layout | Two (2) Separate, Self-Contained Refrigeration Circuits |
| 4 | Incoming Electrical Supply | 400 Volts, 50 Hz, Three-Phase AC System |
| 5 | Maximum Electrical Power Requirement | 44.6 kW / 64 Amps |
| 6 | Refrigerant in Use | R-22 Refrigeration Medium |
| 7 | Refrigerant Flow Regulation Method | Thermostatic Expansion Valve (TXV Type) |
| 8 | Evaporator Design Temperature (SST) | 5 C |
| 9 | Condenser Design Temperature (SDT) | 48 C |
| 10 | Allowable Maximum Ambient Temperature | 48 C |
| 11 | Process Glycol Temperature Working Range | 10 C to +10 C |
| 12 | Required Chilled Water / Glycol Flow | 18, 000 LPH at T of 5 C |
| 13 | Condenser Air Circulation Volume | 18, 000 CFM |
| 14 | Condenser Fan Configuration | Heavy-Duty Axial Flow Fans with Large Blade Diameter |
| 15 | Installed Fan Quantity | Four (4) Numbers |
| 16 | Condenser Fan Size | 20 Inch Diameter |
| 17 | Fan Motor Power Input | 0.45 kW 4 Units |
| 18 | Compressor Design Type | Hermetically Sealed Scroll Type Compressors |
| 19 | Number of Compressors Installed | Two (2) Numbers |
| 20 | Total Compressor Electrical Load | 38.4 kW / 69.36 Amps |
| 21 | Compressor Starting Arrangement | Direct-On-Line (DOL) Starting System |
| 22 | Cooling Capacity Control Philosophy | Constant / Fixed Capacity Operation |
| 23 | Evaporator Heat Exchanger Type | Shell and Tube Type Glycol / Water Evaporator |
| 24 | Evaporator Fluid Connection Dimension | 2 Inch |
| 25 | Evaporator Shell Material of Construction | Carbon Steel Fabrication |
| 26 | Evaporator Tube Material Specification | Internally Grooved / Enhanced Copper Tubes |
| 27 | Condenser Heat Exchanger Construction | Air-Cooled Condenser with Aluminium Fins and Copper Tubing |
| 28 | Condenser Tube External Diameter | 3/8 Inch |
| 29 | Condenser Supporting Structure | Hot-Dip Galvanized Steel Framework |
| 30 | Chilled Water / Glycol Pump Arrangement | Two (2) Nos., SS-304 Stainless Steel Pumps, 3 HP / 2.2 kW Each |
| 31 | Safety, Protection & Interlocks Provided | Compressor Internal Thermal Protection, Electrical Overload Protection, High & Low Pressure Safety Cut-outs, Phase Sequence / Phase Failure Protection, Discharge Gas Temperature Cut-out, Water Flow Interlock, Anti-Freeze Protection System |
| 32 | Electrical Control & Protection Panel | Sub-Zero Micro-Chill Controller Based Panel with Protection Relays, Power Contactors, MCBs, Phase Preventer Relay and Time-Delay Relays |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
30 TR AIR COOLED SCROLL TYPE GLYCOL / WATER CHILLER
A. GENERAL TECHNICAL PARTICULARS| 1 | Chiller Model Reference | FMACS-30TR-R22 |
| 2 | Nominal Refrigeration Capacity | 30 TR (Rated Cooling Output) |
| 3 | Refrigeration Circuit Arrangement | Two (2) Separate and Independent Refrigeration Circuits |
| 4 | Electrical Supply Characteristics | 400 Volts, 50 Hertz, Three-Phase AC Power |
| 5 | Maximum Electrical Connected Load | 44.6 kW / 64 Amperes |
| 6 | Specified Refrigerant | R-22 Refrigerant |
| 7 | Refrigerant Expansion & Control Mechanism | Thermostatic Expansion Valve (TXV Type) |
| 8 | Evaporator Design Saturation Temperature (SST) | 5 C |
| 9 | Condenser Design Saturation Temperature (SDT) | 48 C |
| 10 | Maximum Rated Ambient Operating Temperature | 48 C |
| 11 | Process Glycol Operating Temperature Range | 10 C to +10 C |
| 12 | Required Chilled Water / Glycol Flow Rate | 18, 000 LPH at T of 5 C |
| 13 | Design Condenser Air Volume Flow | 18, 000 CFM |
| 14 | Condenser Fan Construction Type | Axial Flow Fans with Heavy-Duty Large Blades |
| 15 | Total Number of Condenser Fans | Four (4) Units |
| 16 | Fan Diameter Size | 20 Inch |
| 17 | Individual Fan Motor Rating | 0.45 kW 4 Nos. |
| 18 | Compressor Type & Construction | Hermetically Sealed Scroll Type Compressors |
| 19 | Installed Compressor Quantity | Two (2) Units |
| 20 | Combined Compressor Power Consumption | 38.4 kW / 69.36 Amperes |
| 21 | Compressor Starting Arrangement | Direct-On-Line (DOL) / Normal Start |
| 22 | Capacity Modulation Scheme | Fixed Capacity (No Capacity Control) |
| 23 | Evaporator Heat Exchanger Design | Shell & Tube Type Glycol / Water Evaporator |
| 24 | Evaporator Fluid Connection Size | 2 Inch |
| 25 | Evaporator Shell Material Specification | Carbon Steel Construction |
| 26 | Evaporator Tube Material Specification | Internally Enhanced / Grooved Copper Tubes |
| 27 | Condenser Design Configuration | Air-Cooled Condenser with Aluminium Fins and Copper Tubes |
| 28 | Condenser Tube Outer Diameter | 3/8 Inch |
| 29 | Condenser Support Structure | Hot-Dip Galvanized Steel Framework |
| 30 | Chilled Water / Glycol Pump Details | Two (2) Nos., SS-304 Stainless Steel Pumps, 3 HP / 2.2 kW Each |
| 31 | Standard Safety & Protective Arrangements | Compressor Motor Internal Thermal Protection, Electrical Overload Protection, High & Low Pressure Safety Switches, Phase Reversal / Phase Failure Protection, Discharge Gas Temperature Protection, Flow Switch Interlock, Anti-Freeze Safety Protection |
| 32 | Electrical Control & Protection Panel | Sub-Zero Micro-Chill Controller with Protection Relays, Power Contactors, MCBs, Phase Preventer Relay and Time-Delay Relays |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
30 TR AIR COOLED SCROLL TYPE GLYCOL / WATER CHILLER
A. GENERAL TECHNICAL DATA| 1 | Equipment Model | FMACS-30TR-R22 |
| 2 | Rated Cooling Capacity | 30 TR (Tons of Refrigeration) |
| 3 | Number of Refrigeration Circuits | Two (2) Independent Refrigeration Circuits |
| 4 | Electrical Power Supply | 400 V, 50 Hz, Three Phase AC |
| 5 | Total Connected Electrical Load | 44.6 kW / 64 A |
| 6 | Working Refrigerant | R-22 |
| 7 | Refrigerant Expansion / Control Device | Thermostatic Expansion Valve (TXV) |
| 8 | Design Evaporating Temperature (SST) | 5 C |
| 9 | Design Condensing Temperature (SDT) | 48 C |
| 10 | Maximum Ambient Design Temperature | 48 C |
| 11 | Operating Glycol Temperature Range | 10 C to +10 C |
| 12 | Design Chilled Water / Glycol Flow Rate | 18, 000 LPH @ T 5 C |
| 13 | Condenser Air Flow Rate | 18, 000 CFM |
| 14 | Condenser Fan Type | Axial Flow Fans with Large Diameter Blades |
| 15 | Number of Fans Installed | Four (4) Nos. |
| 16 | Fan Diameter | 20 Inches |
| 17 | Fan Motor Power Rating | 0.45 kW 4 Nos. |
| 18 | Compressor Design & Type | Hermetically Sealed Scroll Compressors |
| 19 | Number of Compressors | Two (2) Nos. |
| 20 | Total Compressor Power Consumption | 38.4 kW / 69.36 A |
| 21 | Compressor Starting Method | Direct / Regular Start |
| 22 | Capacity Control Method | Not Applicable / Fixed Capacity |
| 23 | Evaporator Configuration | Shell and Tube Type Heat Exchanger |
| 24 | Evaporator Water / Glycol Connection Size | 2 Inch |
| 25 | Evaporator Shell Material of Construction | Carbon Steel |
| 26 | Evaporator Tube Material | Internally Grooved Copper Tubes |
| 27 | Condenser Construction Type | Air Cooled Condenser with Aluminium Fins and Copper Tubes |
| 28 | Condenser Tube Outside Diameter | 3/8 Inch |
| 29 | Condenser Structural Support | Galvanized Steel Framework |
| 30 | Chilled Water / Glycol Pumps | Two (2) Nos., SS-304 Construction, 3 HP / 2.2 kW Each |
| 31 | Safety & Protection Features | Compressor Motor Internal Thermostat, Unit Overload Protection, High & Low Pressure Safety Switches, Phase Reversal / Phase Failure Protection Relay, Discharge Gas Temperature Protection, Water Flow Switch, Anti-Freeze Protection |
| 32 | Electrical Control & Instrumentation Panel | Sub-Zero Micro Chill Controller with Protection Relays, Power Contactors, MCBs, Phase Preventer Relay and Time Delay Relays |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
30 TR AIR COOLED SCROLL TYPE GLYCOL / WATER CHILLER
A. GENERAL TECHNICAL DATA| 1 | Equipment Model | FMACS-30TR-R22 |
| 2 | Rated Cooling Capacity | 30 TR (Tons of Refrigeration) |
| 3 | Number of Refrigeration Circuits | Two (2) Independent Refrigeration Circuits |
| 4 | Electrical Power Supply | 400 V, 50 Hz, Three Phase AC |
| 5 | Total Connected Electrical Load | 44.6 kW / 64 A |
| 6 | Working Refrigerant | R-22 |
| 7 | Refrigerant Expansion / Control Device | Thermostatic Expansion Valve (TXV) |
| 8 | Design Evaporating Temperature (SST) | 5 C |
| 9 | Design Condensing Temperature (SDT) | 48 C |
| 10 | Maximum Ambient Design Temperature | 48 C |
| 11 | Operating Glycol Temperature Range | 10 C to +10 C |
| 12 | Design Chilled Water / Glycol Flow Rate | 18, 000 LPH @ T 5 C |
| 13 | Condenser Air Flow Rate | 18, 000 CFM |
| 14 | Condenser Fan Type | Axial Flow Fans with Large Diameter Blades |
| 15 | Number of Fans Installed | Four (4) Nos. |
| 16 | Fan Diameter | 20 Inches |
| 17 | Fan Motor Power Rating | 0.45 kW 4 Nos. |
| 18 | Compressor Design & Type | Hermetically Sealed Scroll Compressors |
| 19 | Number of Compressors | Two (2) Nos. |
| 20 | Total Compressor Power Consumption | 38.4 kW / 69.36 A |
| 21 | Compressor Starting Method | Direct / Regular Start |
| 22 | Capacity Control Method | Not Applicable / Fixed Capacity |
| 23 | Evaporator Configuration | Shell and Tube Type Heat Exchanger |
| 24 | Evaporator Water / Glycol Connection Size | 2 Inch |
| 25 | Evaporator Shell Material of Construction | Carbon Steel |
| 26 | Evaporator Tube Material | Internally Grooved Copper Tubes |
| 27 | Condenser Construction Type | Air Cooled Condenser with Aluminium Fins and Copper Tubes |
| 28 | Condenser Tube Outside Diameter | 3/8 Inch |
| 29 | Condenser Structural Support | Galvanized Steel Framework |
| 30 | Chilled Water / Glycol Pumps | Two (2) Nos., SS-304 Construction, 3 HP / 2.2 kW Each |
| 31 | Safety & Protection Features | Compressor Motor Internal Thermostat, Unit Overload Protection, High & Low Pressure Safety Switches, Phase Reversal / Phase Failure Protection Relay, Discharge Gas Temperature Protection, Water Flow Switch, Anti-Freeze Protection |
| 32 | Electrical Control & Instrumentation Panel | Sub-Zero Micro Chill Controller with Protection Relays, Power Contactors, MCBs, Phase Preventer Relay and Time Delay Relays |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
30 TR AIR COOLED SCROLL TYPE GLYCOL / WATER CHILLER
A. GENERAL TECHNICAL DATA| 1 | Equipment Model | FMACS-30TR-R22 |
| 2 | Rated Cooling Capacity | 30 TR (Tons of Refrigeration) |
| 3 | Number of Refrigeration Circuits | Two (2) Independent Refrigeration Circuits |
| 4 | Electrical Power Supply | 400 V, 50 Hz, Three Phase AC |
| 5 | Total Connected Electrical Load | 44.6 kW / 64 A |
| 6 | Working Refrigerant | R-22 |
| 7 | Refrigerant Expansion / Control Device | Thermostatic Expansion Valve (TXV) |
| 8 | Design Evaporating Temperature (SST) | 5 C |
| 9 | Design Condensing Temperature (SDT) | 48 C |
| 10 | Maximum Ambient Design Temperature | 48 C |
| 11 | Operating Glycol Temperature Range | 10 C to +10 C |
| 12 | Design Chilled Water / Glycol Flow Rate | 18, 000 LPH @ T 5 C |
| 13 | Condenser Air Flow Rate | 18, 000 CFM |
| 14 | Condenser Fan Type | Axial Flow Fans with Large Diameter Blades |
| 15 | Number of Fans Installed | Four (4) Nos. |
| 16 | Fan Diameter | 20 Inches |
| 17 | Fan Motor Power Rating | 0.45 kW 4 Nos. |
| 18 | Compressor Design & Type | Hermetically Sealed Scroll Compressors |
| 19 | Number of Compressors | Two (2) Nos. |
| 20 | Total Compressor Power Consumption | 38.4 kW / 69.36 A |
| 21 | Compressor Starting Method | Direct / Regular Start |
| 22 | Capacity Control Method | Not Applicable / Fixed Capacity |
| 23 | Evaporator Configuration | Shell and Tube Type Heat Exchanger |
| 24 | Evaporator Water / Glycol Connection Size | 2 Inch |
| 25 | Evaporator Shell Material of Construction | Carbon Steel |
| 26 | Evaporator Tube Material | Internally Grooved Copper Tubes |
| 27 | Condenser Construction Type | Air Cooled Condenser with Aluminium Fins and Copper Tubes |
| 28 | Condenser Tube Outside Diameter | 3/8 Inch |
| 29 | Condenser Structural Support | Galvanized Steel Framework |
| 30 | Chilled Water / Glycol Pumps | Two (2) Nos., SS-304 Construction, 3 HP / 2.2 kW Each |
| 31 | Safety & Protection Features | Compressor Motor Internal Thermostat, Unit Overload Protection, High & Low Pressure Safety Switches, Phase Reversal / Phase Failure Protection Relay, Discharge Gas Temperature Protection, Water Flow Switch, Anti-Freeze Protection |
| 32 | Electrical Control & Instrumentation Panel | Sub-Zero Micro Chill Controller with Protection Relays, Power Contactors, MCBs, Phase Preventer Relay and Time Delay Relays |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
30 TR AIR COOLED SCROLL TYPE GLYCOL / WATER CHILLER
A. GENERAL TECHNICAL DATA| 1 | Equipment Model | FMACS-30TR-R22 |
| 2 | Rated Cooling Capacity | 30 TR (Tons of Refrigeration) |
| 3 | Number of Refrigeration Circuits | Two (2) Independent Refrigeration Circuits |
| 4 | Electrical Power Supply | 400 V, 50 Hz, Three Phase AC |
| 5 | Total Connected Electrical Load | 44.6 kW / 64 A |
| 6 | Working Refrigerant | R-22 |
| 7 | Refrigerant Expansion / Control Device | Thermostatic Expansion Valve (TXV) |
| 8 | Design Evaporating Temperature (SST) | 5 C |
| 9 | Design Condensing Temperature (SDT) | 48 C |
| 10 | Maximum Ambient Design Temperature | 48 C |
| 11 | Operating Glycol Temperature Range | 10 C to +10 C |
| 12 | Design Chilled Water / Glycol Flow Rate | 18, 000 LPH @ T 5 C |
| 13 | Condenser Air Flow Rate | 18, 000 CFM |
| 14 | Condenser Fan Type | Axial Flow Fans with Large Diameter Blades |
| 15 | Number of Fans Installed | Four (4) Nos. |
| 16 | Fan Diameter | 20 Inches |
| 17 | Fan Motor Power Rating | 0.45 kW 4 Nos. |
| 18 | Compressor Design & Type | Hermetically Sealed Scroll Compressors |
| 19 | Number of Compressors | Two (2) Nos. |
| 20 | Total Compressor Power Consumption | 38.4 kW / 69.36 A |
| 21 | Compressor Starting Method | Direct / Regular Start |
| 22 | Capacity Control Method | Not Applicable / Fixed Capacity |
| 23 | Evaporator Configuration | Shell and Tube Type Heat Exchanger |
| 24 | Evaporator Water / Glycol Connection Size | 2 Inch |
| 25 | Evaporator Shell Material of Construction | Carbon Steel |
| 26 | Evaporator Tube Material | Internally Grooved Copper Tubes |
| 27 | Condenser Construction Type | Air Cooled Condenser with Aluminium Fins and Copper Tubes |
| 28 | Condenser Tube Outside Diameter | 3/8 Inch |
| 29 | Condenser Structural Support | Galvanized Steel Framework |
| 30 | Chilled Water / Glycol Pumps | Two (2) Nos., SS-304 Construction, 3 HP / 2.2 kW Each |
| 31 | Safety & Protection Features | Compressor Motor Internal Thermostat, Unit Overload Protection, High & Low Pressure Safety Switches, Phase Reversal / Phase Failure Protection Relay, Discharge Gas Temperature Protection, Water Flow Switch, Anti-Freeze Protection |
| 32 | Electrical Control & Instrumentation Panel | Sub-Zero Micro Chill Controller with Protection Relays, Power Contactors, MCBs, Phase Preventer Relay and Time Delay Relays |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
30 TR AIR COOLED SCROLL TYPE GLYCOL / WATER CHILLER
A. GENERAL TECHNICAL DATA| 1 | Equipment Model | FMACS-30TR-R22 |
| 2 | Rated Cooling Capacity | 30 TR (Tons of Refrigeration) |
| 3 | Number of Refrigeration Circuits | Two (2) Independent Refrigeration Circuits |
| 4 | Electrical Power Supply | 400 V, 50 Hz, Three Phase AC |
| 5 | Total Connected Electrical Load | 44.6 kW / 64 A |
| 6 | Working Refrigerant | R-22 |
| 7 | Refrigerant Expansion / Control Device | Thermostatic Expansion Valve (TXV) |
| 8 | Design Evaporating Temperature (SST) | 5 C |
| 9 | Design Condensing Temperature (SDT) | 48 C |
| 10 | Maximum Ambient Design Temperature | 48 C |
| 11 | Operating Glycol Temperature Range | 10 C to +10 C |
| 12 | Design Chilled Water / Glycol Flow Rate | 18, 000 LPH @ T 5 C |
| 13 | Condenser Air Flow Rate | 18, 000 CFM |
| 14 | Condenser Fan Type | Axial Flow Fans with Large Diameter Blades |
| 15 | Number of Fans Installed | Four (4) Nos. |
| 16 | Fan Diameter | 20 Inches |
| 17 | Fan Motor Power Rating | 0.45 kW 4 Nos. |
| 18 | Compressor Design & Type | Hermetically Sealed Scroll Compressors |
| 19 | Number of Compressors | Two (2) Nos. |
| 20 | Total Compressor Power Consumption | 38.4 kW / 69.36 A |
| 21 | Compressor Starting Method | Direct / Regular Start |
| 22 | Capacity Control Method | Not Applicable / Fixed Capacity |
| 23 | Evaporator Configuration | Shell and Tube Type Heat Exchanger |
| 24 | Evaporator Water / Glycol Connection Size | 2 Inch |
| 25 | Evaporator Shell Material of Construction | Carbon Steel |
| 26 | Evaporator Tube Material | Internally Grooved Copper Tubes |
| 27 | Condenser Construction Type | Air Cooled Condenser with Aluminium Fins and Copper Tubes |
| 28 | Condenser Tube Outside Diameter | 3/8 Inch |
| 29 | Condenser Structural Support | Galvanized Steel Framework |
| 30 | Chilled Water / Glycol Pumps | Two (2) Nos., SS-304 Construction, 3 HP / 2.2 kW Each |
| 31 | Safety & Protection Features | Compressor Motor Internal Thermostat, Unit Overload Protection, High & Low Pressure Safety Switches, Phase Reversal / Phase Failure Protection Relay, Discharge Gas Temperature Protection, Water Flow Switch, Anti-Freeze Protection |
| 32 | Electrical Control & Instrumentation Panel | Sub-Zero Micro Chill Controller with Protection Relays, Power Contactors, MCBs, Phase Preventer Relay and Time Delay Relays |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
30 TR AIR COOLED SCROLL TYPE GLYCOL / WATER CHILLER
A. GENERAL TECHNICAL DETAILS| 1 | Unit Model Identification | FMACS-30TR-R22 |
| 2 | Cooling Capacity (Nominal) | 30 TR Rated Refrigeration Capacity |
| 3 | Refrigeration System Configuration | Two (2) Fully Independent Refrigeration Circuits |
| 4 | Power Supply Requirements | 400 V, 50 Hz, Three-Phase Alternating Current |
| 5 | Total Electrical Demand | 44.6 kW / 64 A |
| 6 | Refrigerant Type Used | R-22 Working Refrigerant |
| 7 | Refrigerant Metering / Control Device | Thermostatic Expansion Valve (TXV) |
| 8 | Evaporator Design Operating Temperature (SST) | 5 C |
| 9 | Condenser Design Operating Temperature (SDT) | 48 C |
| 10 | Maximum Ambient Design Condition | 48 C |
| 11 | Process Glycol Temperature Operating Band | 10 C to +10 C |
| 12 | Chilled Water / Glycol Circulation Requirement | 18, 000 LPH at 5 C Temperature Difference |
| 13 | Condenser Air Flow Requirement | 18, 000 Cubic Feet per Minute (CFM) |
| 14 | Type of Condenser Fans | Axial Flow Fans with Heavy-Duty Large Diameter Blades |
| 15 | Quantity of Condenser Fans | Four (4) Nos. |
| 16 | Condenser Fan Diameter | 20 Inches |
| 17 | Fan Motor Input Rating | 0.45 kW 4 Nos. |
| 18 | Compressor Design & Sealing | Hermetically Sealed Scroll Compressors |
| 19 | Number of Compressors Provided | Two (2) Units |
| 20 | Total Compressor Electrical Consumption | 38.4 kW / 69.36 A |
| 21 | Compressor Starting Method | Direct-On-Line (DOL) Starting |
| 22 | Cooling Capacity Control Method | Fixed Output Capacity (No Modulation) |
| 23 | Evaporator Heat Exchange Configuration | Shell and Tube Type Glycol / Water Evaporator |
| 24 | Evaporator Connection Size | 2 Inch |
| 25 | Evaporator Shell Construction Material | Carbon Steel |
| 26 | Evaporator Tube Construction Material | Internally Enhanced Grooved Copper Tubes |
| 27 | Condenser Construction Arrangement | Air-Cooled Condenser with Aluminium Fins and Copper Tubes |
| 28 | Condenser Tube Outside Diameter | 3/8 Inch |
| 29 | Condenser Structural Framework | Hot-Dip Galvanized Steel Support Structure |
| 30 | Chilled Water / Glycol Pump Configuration | Two (2) Nos. SS-304 Stainless Steel Pumps, 3 HP / 2.2 kW Each |
| 31 | Integrated Safety & Protection Systems | Compressor Internal Thermal Protection, Electrical Overload Safety, High and Low Pressure Cut-out Switches, Phase Reversal & Phase Failure Protection, Discharge Gas Temperature Protection, Flow Switch Interlock, Anti-Freeze Safety Logic |
| 32 | Electrical Control & Safety Panel | Sub-Zero Micro-Chill Based Control Panel with Protection Relays, Power Contactors, MCBs, Phase Preventer Relay and Time-Delay Relays |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
30 TR AIR COOLED SCROLL TYPE GLYCOL / WATER CHILLER
A. GENERAL TECHNICAL PARTICULARS| 1 | Chiller Model Reference | FMACS-30TR-R22 |
| 2 | Nominal Refrigeration Capacity | 30 TR (Rated Cooling Output) |
| 3 | Refrigeration Circuit Arrangement | Two (2) Separate and Independent Refrigeration Circuits |
| 4 | Electrical Supply Characteristics | 400 Volts, 50 Hertz, Three-Phase AC Power |
| 5 | Maximum Electrical Connected Load | 44.6 kW / 64 Amperes |
| 6 | Specified Refrigerant | R-22 Refrigerant |
| 7 | Refrigerant Expansion & Control Mechanism | Thermostatic Expansion Valve (TXV Type) |
| 8 | Evaporator Design Saturation Temperature (SST) | 5 C |
| 9 | Condenser Design Saturation Temperature (SDT) | 48 C |
| 10 | Maximum Rated Ambient Operating Temperature | 48 C |
| 11 | Process Glycol Operating Temperature Range | 10 C to +10 C |
| 12 | Required Chilled Water / Glycol Flow Rate | 18, 000 LPH at T of 5 C |
| 13 | Design Condenser Air Volume Flow | 18, 000 CFM |
| 14 | Condenser Fan Construction Type | Axial Flow Fans with Heavy-Duty Large Blades |
| 15 | Total Number of Condenser Fans | Four (4) Units |
| 16 | Fan Diameter Size | 20 Inch |
| 17 | Individual Fan Motor Rating | 0.45 kW 4 Nos. |
| 18 | Compressor Type & Construction | Hermetically Sealed Scroll Type Compressors |
| 19 | Installed Compressor Quantity | Two (2) Units |
| 20 | Combined Compressor Power Consumption | 38.4 kW / 69.36 Amperes |
| 21 | Compressor Starting Arrangement | Direct-On-Line (DOL) / Normal Start |
| 22 | Capacity Modulation Scheme | Fixed Capacity (No Capacity Control) |
| 23 | Evaporator Heat Exchanger Design | Shell & Tube Type Glycol / Water Evaporator |
| 24 | Evaporator Fluid Connection Size | 2 Inch |
| 25 | Evaporator Shell Material Specification | Carbon Steel Construction |
| 26 | Evaporator Tube Material Specification | Internally Enhanced / Grooved Copper Tubes |
| 27 | Condenser Design Configuration | Air-Cooled Condenser with Aluminium Fins and Copper Tubes |
| 28 | Condenser Tube Outer Diameter | 3/8 Inch |
| 29 | Condenser Support Structure | Hot-Dip Galvanized Steel Framework |
| 30 | Chilled Water / Glycol Pump Details | Two (2) Nos., SS-304 Stainless Steel Pumps, 3 HP / 2.2 kW Each |
| 31 | Standard Safety & Protective Arrangements | Compressor Motor Internal Thermal Protection, Electrical Overload Protection, High & Low Pressure Safety Switches, Phase Reversal / Phase Failure Protection, Discharge Gas Temperature Protection, Flow Switch Interlock, Anti-Freeze Safety Protection |
| 32 | Electrical Control & Protection Panel | Sub-Zero Micro-Chill Controller with Protection Relays, Power Contactors, MCBs, Phase Preventer Relay and Time-Delay Relays |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
30 TR AIR COOLED SCROLL TYPE GLYCOL / WATER CHILLER
A. GENERAL TECHNICAL PARTICULARS| 1 | Chiller Model Reference | FMACS-30TR-R22 |
| 2 | Nominal Refrigeration Capacity | 30 TR (Rated Cooling Output) |
| 3 | Refrigeration Circuit Arrangement | Two (2) Separate and Independent Refrigeration Circuits |
| 4 | Electrical Supply Characteristics | 400 Volts, 50 Hertz, Three-Phase AC Power |
| 5 | Maximum Electrical Connected Load | 44.6 kW / 64 Amperes |
| 6 | Specified Refrigerant | R-22 Refrigerant |
| 7 | Refrigerant Expansion & Control Mechanism | Thermostatic Expansion Valve (TXV Type) |
| 8 | Evaporator Design Saturation Temperature (SST) | 5 C |
| 9 | Condenser Design Saturation Temperature (SDT) | 48 C |
| 10 | Maximum Rated Ambient Operating Temperature | 48 C |
| 11 | Process Glycol Operating Temperature Range | 10 C to +10 C |
| 12 | Required Chilled Water / Glycol Flow Rate | 18, 000 LPH at T of 5 C |
| 13 | Design Condenser Air Volume Flow | 18, 000 CFM |
| 14 | Condenser Fan Construction Type | Axial Flow Fans with Heavy-Duty Large Blades |
| 15 | Total Number of Condenser Fans | Four (4) Units |
| 16 | Fan Diameter Size | 20 Inch |
| 17 | Individual Fan Motor Rating | 0.45 kW 4 Nos. |
| 18 | Compressor Type & Construction | Hermetically Sealed Scroll Type Compressors |
| 19 | Installed Compressor Quantity | Two (2) Units |
| 20 | Combined Compressor Power Consumption | 38.4 kW / 69.36 Amperes |
| 21 | Compressor Starting Arrangement | Direct-On-Line (DOL) / Normal Start |
| 22 | Capacity Modulation Scheme | Fixed Capacity (No Capacity Control) |
| 23 | Evaporator Heat Exchanger Design | Shell & Tube Type Glycol / Water Evaporator |
| 24 | Evaporator Fluid Connection Size | 2 Inch |
| 25 | Evaporator Shell Material Specification | Carbon Steel Construction |
| 26 | Evaporator Tube Material Specification | Internally Enhanced / Grooved Copper Tubes |
| 27 | Condenser Design Configuration | Air-Cooled Condenser with Aluminium Fins and Copper Tubes |
| 28 | Condenser Tube Outer Diameter | 3/8 Inch |
| 29 | Condenser Support Structure | Hot-Dip Galvanized Steel Framework |
| 30 | Chilled Water / Glycol Pump Details | Two (2) Nos., SS-304 Stainless Steel Pumps, 3 HP / 2.2 kW Each |
| 31 | Standard Safety & Protective Arrangements | Compressor Motor Internal Thermal Protection, Electrical Overload Protection, High & Low Pressure Safety Switches, Phase Reversal / Phase Failure Protection, Discharge Gas Temperature Protection, Flow Switch Interlock, Anti-Freeze Safety Protection |
| 32 | Electrical Control & Protection Panel | Sub-Zero Micro-Chill Controller with Protection Relays, Power Contactors, MCBs, Phase Preventer Relay and Time-Delay Relays |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
TechnicalSpecification
| Sr.No. | Parameter | Details |
| 1 | Model | FMACS-30TR-R22 |
| 2 | CoolingCapacity | 30TR |
| 3 | Refrigerationcircuit | 2Nos |
| 4 | PowerSupply | 400V-50Hz |
| 5 | Connectingload | 44.6 KW/64A |
| 6 | Refrigerant | R22 |
| 7 | RefrigerantControl | ThermostaticExpansion |
| 8 | EvaporatingSST | -5C |
| 9 | CondensingSDT | 48C |
| 10 | AmbientTemp | 48C |
| 11 | WorkingGlycolTemperatureRange | -10TO+10 C |
| 12 | ChilledFlowOfWater | 18000 LPH@ 5 delta |
| 13 | CondenserAirFlow | 18000CFM |
| 14 | Fantypes | AxiallargeBlade |
| 15 | FanQty | 4Nos |
| 16 | FanSize | 20 |
| 17 | FanPower | 0.45*4 |
| 18 | CompressorTypes | Hermetic Scroll |
| 19 | CompressorQty | 2Nos |
| 20 | Compressorpower | 38.4 KW/69.36A |
| 21 | Startmode | Regular |
| 22 | Capacitycontrol | -- |
| 23 | EvaporatorTypes | Shell and tube |
| 24 | Evaporatorpipeconnection | 2 |
| 25 | EvaporatorShellMOC | Carbone steel |
| 26 | EvaporatortubeMOC | Coppergrooved |
| 27 | Condensertypes | AirCooled(AluminumFinsAndCopperTube) |
| 28 | CondenserPipesize | 3/8 |
| 29 | CondenserSupporter | Galvanize |
| 30 | 2 PUMPs | SS-304/3HP /2.2 KW |
| 31 | SafetyProtection | Inner Thermostat for compressor motor, unit overloadrelay, highandlowpressureswitch, reverse phase protection relay, discharge gas thermostat, flow switch , Antic Freeze protection |
| 32 | Electriccontrolpanel | Subzero micro chill Controller, protectionrelay, contactor, MCB, preventer, timer. |
|
| Product | Make |
| 1. | compressor | Danfoss (sy-300-4) |
| 2. | Evaporator | Fidem |
| 3. | condenser | Fidem |
| 4. | Electricpanel | Fidem |
| 5. | Flowswitch | Castle |
| 6. | PressureSwitch | Danfoss |
| 7. | Expansionvalve | Danfoss |
| 8. | Filter | Dryall |
| 9. | Solenoidvalve | Danfoss |
| 10. | Electroniccomponents | Schneider |
| 11. | Pump (Condenser) | Lubi (LBI 101-H) |
| 12. | Pump (PHE) | Lubi (LBI 101-H) |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
Technical Specification
| Sr. No. | Parameter | Details |
| 1 | Model | FMACSC-85TR-R407C |
| 2 | Cooling Capacity | 85 TR / 302 kW |
| 3 | Refrigeration Circuit | 1 No |
| 4 | Power Supply | 400V, 3Ph, 50Hz |
| 5 | Connected Load | 73.0 kW / 122 A |
| 6 | Refrigerant | R407C |
| 7 | Refrigerant Control | Thermostatic Expansion Valve |
| 8 | Evaporating SST | 7C |
| 9 | Condensing SDT | 40C |
| 10 | Ambient Temperature | Max. 48C |
| 11 | Working Temperature Range | +7C to +20C |
| 12 | Chilled Water Flow | 50000 LPH (T = 5C) |
| 13 | Condenser Air Flow | 70, 000 CFM |
| 14 | Fan Type | Axial Type, Large Blade |
| 15 | Fan Quantity | 4 Nos |
| 16 | Fan Size | 630 mm (Suction Type) |
| 17 | Fan Power | 1.5 kW 4 Nos = 6.0 kW |
| 18 | Compressor Type | Semi-Hermetic Screw |
| 19 | Compressor Quantity | 1 No |
| 20 | Compressor Make & Model | Bitzer |
| 21 | Compressor Power | 67.0 kW / 102 A @ 50 Hz |
| 22 | Start Mode | Star-Delta Starter |
| 23 | Capacity Control | Step (0, 25, 50, 75, 100%) |
| 24 | Evaporator Type | Shell & Tube Type |
| 25 | Evaporator Shell MOC | Carbon Steel, Powder Coated |
| 26 | Evaporator Tube MOC | Inner Grooved Copper Tubes |
| 27 | Evaporator Baffle & Header | SS-304, TIG Welded |
| 28 | Evaporator Design Pressure | 10 Bar |
| 29 | Evaporator Test Pressure | 15 Bar (Hydrostatic) |
| 30 | Evaporator Pipe Connection | 3 BSP (Inlet & Outlet) |
| 31 | Evaporator Insulation | 40 mm PUF, Closed Cell |
| 32 | Condenser Type | Air Cooled (Copper Tubes & Aluminum Fins) |
| 33 | Condenser Pipe Size | 3/8 |
| 34 | Condenser Support | Galvanized Steel Frame |
| 35 | Pump | SS-304, (5.5 kW), -2 Nos (1W + 1S) |
| 36 | Safety Protections | Inner Thermostat, HP/LP Switch, Overload Relay, Phase Reverse, Flow Switch, Anti-Freeze, Discharge Temp. Protection, Water low levels. |
Additional Information:
Payment Terms : D/P
Packaging Details : standard packaging
Delivery Time : 15 days
Technical Specification
| Sr. No. | Parameter | Details |
| 1 | Model | FMACSC-50TR-R407C |
| 2 | Cooling Capacity | 48.50 TR / 170 kW |
| 3 | Refrigeration Circuit | 1 No |
| 4 | Power Supply | 400V, 3Ph, 50Hz |
| 5 | Connected Load | 53.2 kW / 83.55 A |
| 6 | Refrigerant | R407C |
| 7 | Refrigerant Control | Thermostatic Expansion Valve |
| 8 | Evaporating SST | 5C |
| 9 | Condensing SDT | 45C |
| 10 | Ambient Temperature | Max. 45C |
| 11 | Working Temperature Range | +7C to +20C |
| 12 | Chilled Water Flow | 29300 LPH (T = 5C) |
| 13 | Condenser Air Flow | 20000 CFM |
| 14 | Fan Type | Axial Type, Large Blade |
| 15 | Fan Quantity | 4 Nos |
| 16 | Fan Size | 22 inches (Suction Type) |
| 17 | Fan Power | 0.6 kW 4 Nos = 2.4 kW |
| 18 | Compressor Type | Semi-Hermetic Screw |
| 19 | Compressor Quantity | 1 No |
| 20 | Compressor Make & Model | Bitzer |
| 21 | Compressor Power | 47 kW / 81 A @ 50 Hz |
| 22 | Start Mode | Star-Delta Starter |
| 23 | Capacity Control | Step (0, 25, 50, 75, 100%) |
| 24 | Evaporator Type | Shell & Tube Type |
| 25 | Evaporator Shell MOC | Carbon Steel, Powder Coated |
| 26 | Evaporator Tube MOC | Inner Grooved Copper Tubes |
| 27 | Evaporator Baffle & Header | SS-304, TIG Welded |
| 28 | Evaporator Design Pressure | 10 Bar |
| 29 | Evaporator Test Pressure | 15 Bar (Hydrostatic) |
| 30 | Evaporator Pipe Connection | 3 BSP (Inlet & Outlet) |
| 31 | Evaporator Insulation | 40 mm PUF, Closed Cell |
| 32 | Condenser Type | Air Cooled (Copper Tubes & Aluminum Fins) |
| 33 | Pump power | 3 kw |
| 34 | Pump head(Lift) | 2.2 KG |
| 35 | Condenser Pipe Size | 3/8 |
| 36 | Condenser Support | Galvanized Steel Frame |
| 37 | Safety Protections | Inner Thermostat, HP/LP Switch, Overload Relay, Phase Reverse, Flow Switch, Anti-Freeze, Discharge Temp. Protection, Water low levels. |
| 38 | Electrical Panel | MCB, Contactor, Overload, Timer, Relays, , Pre-wired, PLC, HMI |
| 39 | Dimensions (LWH) | After confirmation we will provide dimension and drawing |
Additional Information:
Payment Terms : D/P
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
TechnicalSpecification
| Sr.No. | Parameter | Details |
| 1 | Model | FMACS-30TR-R22 |
| 2 | CoolingCapacity | 30TR |
| 3 | Refrigerationcircuit | 2Nos |
| 4 | PowerSupply | 400V-50Hz |
| 5 | Connectingload | 44.6 KW/ 64 A |
| 6 | Refrigerant | R22 |
| 7 | RefrigerantControl | ThermostaticExpansion |
| 8 | EvaporatingSST | -5C |
| 9 | CondensingSDT | 48C |
| 10 | AmbientTemp | 48C |
| 11 | Working Glycol TemperatureRange | -10TO +10 C |
| 12 | ChilledFlowOfWater | 18000 LPH @ 5 delta |
| 13 | CondenserAir Flow | 18000CFM |
| 14 | Fantypes | AxiallargeBlade |
| 15 | FanQty | 4Nos |
| 16 | Fan Size | 20 |
| 17 | FanPower | 0.45*4 |
| 18 | CompressorTypes | Hermetic Scroll |
| 19 | CompressorQty | 2Nos |
| 20 | Compressorpower | 38.4 KW/69.36A |
| 21 | Startmode | Regular |
| 22 | Capacitycontrol | -- |
| 23 | EvaporatorTypes | Shell and tube |
| 24 | Evaporatorpipeconnection | 2 |
| 25 | EvaporatorShellMOC | Carbone steel |
| 26 | Evaporator tube MOC | Copper grooved |
| 27 | Condensertypes | AirCooled(AluminumFinsAndCopper Tube) |
| 28 | CondenserPipesize | 3/8 |
| 29 | CondenserSupporter | Galvanize |
| 30 | 2 PUMPs | SS-304/3HP /2.2 KW |
| 31 | SafetyProtection | Inner Thermostat for compressor motor, unit overloadrelay, highandlowpressureswitch, reverse phase protection relay, discharge gas thermostat, flow switch , Antic Freeze protection |
| 32 | Electriccontrolpanel | Subzero micro chill Controller, protectionrelay, contactor, MCB, preventer, timer. |
|
| Product | Make |
| 1. | compressor | Danfoss (sy-300-4) |
| 2. | Evaporator | Fidem |
| 3. | condenser | Fidem |
| 4. | Electricpanel | Fidem |
| 5. | Flowswitch | Castle |
| 6. | PressureSwitch | Danfoss |
| 7. | Expansionvalve | Danfoss |
| 8. | Filter | Dryall |
| 9. | Solenoidvalve | Danfoss |
| 10. | Electroniccomponents | Schneider |
| 11. | Pump (Condenser) | Lubi (LBI 101-H) |
| 12. | Pump (PHE) | Lubi (LBI 101-H) |
Additional Information:
Payment Terms : D/P
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
2. Technical Specifications
| Parameter | Specification |
| Model | FMACA 12 |
| Nominal Cooling Capacity | 43 kW (12.6 TR) |
| At Air outlet temperature | 15 C |
| Design Air Flow Rate | 3000 m/hr |
| Ambient Temperature | 40C |
| Control Range | +5 to +20 C |
| Cooling Circuit | 1 No. |
| Cooling Agent | R22 |
| No. of Compressor | 2 Nos. |
| No. of Gas Circuit | 2 No. |
| No. of Fan / Fan Power | 2 Nos. / 2.63 kW each |
| Compressor Power | 6.32 kW 2 |
| Maximum Air Flow Rate | 3000 m/hr |
| Minimum Air Flow Rate | 1200 m/hr |
| Pressure Drop of Air Through Evaporator | 150 Pa |
| Air Connection IN / OUT | 200 mm |
| Air Temperature IN / OUT | 40C / 15C |
| Relative Humidity |
|
| Electrical Power Supply | 415V, 50 Hz, 3 phase |
| Control Voltage | 24V DC |
| Condenser And Evaporator MOC | Copper And Aluminum |
| Copper tube | Silver Coted |
| Fines | Anticorrosion Coting |
| Total Connected Load | 15.27 kW |
| Main Dimensions (W D H) | 2350 2550 2350 mm |
| Weight | 1300 kg |
| Color | Gray and Off White |
| Air Cooled Air Chiller Require Fresh Air Suction on Condenser side and hot exhaust on top of the chiller | |
Additional Information:
Payment Terms : D/P
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
ParameterTypical Value / RangeNotes
| Cooling capacity | 4 TR 14 kW (for example: 4 TR = 14 kW for model CG-4A)+1 | Scroll type offers simplicity, reliability |
| Refrigerant | R410A or other modern HFC refrigerant (sometimes R22/R407C in older units)Guangdong Tongwei Machinery Co., Ltd.+1 | Confirm voltage, phase compatibility |
| Evaporator / chilled-water circuit | Chilled-water supply/return (for example: 12 C supply / 7 C return)+1 | Ambient temperature influences capacity and performance |
| Water flow rate (when used with chilled-water) | Example: 2.4 m/h for a 4 TR unit | Check exact amount from manufacturer |
| Dimensions / weight | Example: 1140 560 1040 mm; weight 170 kg for one model+1 | If ambient in your location is higher (e.g., Delhi summer), your capacity may dropspecify accordingly |
| Safety & protection features | Over-/under-pressure protection, flow switches, phase-failure protection, etc. |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
ParameterTypical Value / RangeNotes
| Cooling capacity | 4 TR 14 kW (for example: 4 TR = 14 kW for model CG-4A)+1 | Scroll type offers simplicity, reliability |
| Refrigerant | R410A or other modern HFC refrigerant (sometimes R22/R407C in older units)Guangdong Tongwei Machinery Co., Ltd.+1 | Confirm voltage, phase compatibility |
| Evaporator / chilled-water circuit | Chilled-water supply/return (for example: 12 C supply / 7 C return)+1 | Ambient temperature influences capacity and performance |
| Water flow rate (when used with chilled-water) | Example: 2.4 m/h for a 4 TR unit | Check exact amount from manufacturer |
| Dimensions / weight | Example: 1140 560 1040 mm; weight 170 kg for one model+1 | If ambient in your location is higher (e.g., Delhi summer), your capacity may dropspecify accordingly |
| Safety & protection features | Over-/under-pressure protection, flow switches, phase-failure protection, etc. |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
Typical Technical Parameters 4 TR Scroll Chiller (Air / Water Cooled)
Cooling Capacity
4 TR ( 14 kW) at standard AHRI conditions
Capacity varies with ambient temperature and chilled water conditions
Note: Scroll compressors provide high reliability, low noise, and fewer moving parts.
Compressor Type
Hermetic Scroll Compressor
Single or tandem configuration (model dependent)
Note: Ideal for small-capacity chillers with low maintenance.
Refrigerant
R410A (standard eco-friendly, zero ODP)
Optional: R407C / R134a (as per customer requirement)
Note: Ensure refrigerant compatibility with local regulations.
Power Supply
415 V / 3 Phase / 50 Hz (India standard)
Optional: 220240 V / 1 Phase for compact models
Note: Confirm voltage & phase before finalizing order.
Evaporator Type
Brazed Plate Heat Exchanger (SS 316)
Shell & Tube (optional for industrial duty)
Note: Plate HX offers compact size and higher heat transfer efficiency.
Chilled Water Temperature (Typical)
Supply: 712 C
Return: 1217 C
Note: Custom temperature ranges available for process cooling.
Chilled Water Flow Rate
Approx. 2.32.5 m/hr for 4 TR
Note: Flow depends on T (typically 5 C).
Condenser Type
Air-cooled condenser with copper tubes & aluminium fins
Axial flow condenser fan(s)
Note: Coil sizing should consider high ambient conditions (up to 45 C).
Design Ambient Temperature
Rated at 35 C
Maximum operating ambient: 4550 C
Note: Capacity deration may occur at peak summer temperatures (Delhi / Rajasthan / Gujarat).
Pump (Optional Packaged Unit)
Inbuilt chilled water circulation pump
Head: 1525 m (application dependent)
Electrical Control Panel
Microprocessor-based controller
Digital temperature display & setpoint control
Auto restart after power failure
Safety & Protection Features
High / Low pressure cut-out
Flow switch protection
Phase failure / phase reversal protection
Compressor overload & motor thermal protection
Anti-freeze protection
Noise Level
Approx. 6268 dB(A) at 1 meter
Note: Low-noise fans available on request.
Construction
Powder-coated MS frame
Weather-proof outdoor enclosure
Compact, skid-mounted design
Approx. Dimensions & Weight
Size: 11001200 (L) 550600 (W) 10001100 (H) mm
Weight: 160180 kg
Note: Final dimensions vary by make & configuration.
Applications
Plastic injection molding
CNC machines
Laser cutting machines
Pharma & laboratory cooling
Food & beverage process cooling
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
EER / COP:
EER: 3.03.4 (air-cooled)
COP: 3.54.2 (water-cooled)
Note: Actual efficiency depends on ambient temperature and water T.
Power Consumption:
Approx. 3.54.5 kW at full load (air-cooled)
Note: Lower power consumption at part load conditions.
Thermostatic Expansion Valve (TXV)
Electronic Expansion Valve (optional for higher efficiency)
Note: EEV provides better part-load performance and tighter temperature control.
Filter drier
Sight glass with moisture indicator
Suction accumulator
Service valves (suction & discharge)
Chilled water inlet / outlet:
1" or 2" BSP / Flanged (model dependent)
Vent & drain connection provided
Note: Flexible hose connection recommended to reduce vibration.
0.5 C (standard controller)
0.3 C (with advanced PID controller optional)
Note: Suitable for precision process cooling applications.
Single compressor ON/OFF control (standard)
VFD on compressor (optional limited models)
Note: VFD improves energy efficiency and reduces starting current.
Direct-On-Line (DOL) starter
Soft starter / VFD (optional)
Note: Recommended where power supply is weak or generator operated.
Full Load Current: 79 A (415 V, 3-phase)
Short Circuit Protection: MCB / MCCB
Control Voltage: 230 V AC / 24 V DC (model dependent)
Designed as per AHRI / ASHRAE guidelines
Electricals as per IEC standards
Pressure vessels tested as per applicable codes
Minimum clearance around unit: 9001000 mm
Level concrete foundation recommended
Proper airflow must be ensured for air-cooled units
Note: Poor ventilation can reduce capacity and increase power consumption.
Minimum ambient: 10 C
Maximum ambient: 50 C
Minimum chilled water inlet temperature: 5 C
Note: Glycol required for lower temperature applications.
SS 304 / SS 316 piping
Glycol compatible design
Remote monitoring via Modbus / RS-485
Heat recovery condenser (water-cooled models)
Acoustic enclosure for ultra-low noise applications
Compressor: 1218 months from commissioning
Complete unit: 12 months
Note: Extended warranty available on request.
Printing & packaging
Chemical & API plants
Rubber & extrusion machines
PET blow molding
Data room / equipment cooling
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
Differential pressure protection across evaporator
Low-flow alarm & auto shutdown logic
Manual air vent on evaporator
Note: Prevents damage due to air locking or insufficient water circulation.
Anti-short cycling timer
Minimum ON / OFF time delay
Automatic restart with fault memory
Note: Extends compressor life and improves system reliability.
Pressure-based fan cycling (standard)
Multi-step fan control for stable condensing temperature
EC fans optional for energy-efficient operation
Note: Improves performance during fluctuating ambient conditions.
Evaporator fouling factor: 0.00010.0002 hrftF/Btu
Approach temperature: 23 C (typical)
Note: Lower approach temperature results in better system efficiency.
Powder-coated CRCA sheet steel enclosure
IP 54 protection class
Internal wiring with ferrules & cable markers
Note: Suitable for industrial indoor/outdoor installations.
Digital water inlet & outlet temperature display
Suction & discharge pressure indication
Alarm indication with fault code display
Note: Enables easy troubleshooting and monitoring.
Low Global Warming Potential (GWP) refrigerant options available
RoHS-compliant electrical components
Designed for reduced carbon footprint
Note: Suitable for green and energy-conscious projects.
Maximum altitude: up to 1000 m above MSL (standard)
Deration applicable above 1000 m altitude
Suitable for tropical climatic conditions
Note: Altitude and humidity affect cooling capacity.
Performance run test at factory
Electrical insulation & continuity test
Refrigerant leak testing using nitrogen
Note: Ensures trouble-free commissioning at site.
Easily accessible service points
Standard make components for easy availability
Nationwide service support (optional)
Note: Reduces downtime and maintenance cost.
Compressor life expectancy: 812 years
Heat exchanger life: 1215 years (with proper water quality)
Note: Life depends on operating conditions and maintenance.
Installation, Operation & Maintenance (IOM) manual
Electrical wiring diagram
GA drawing (on request)
Test & inspection certificate
Continuous power supply
Treated chilled water supply
Drain point near unit location
Adequate ventilation / exhaust airflow
Low-temperature brine chilling (with glycol)
Continuous 247 operation design
High ambient duty version (50 C)
Redundant pump / control philosophy (optional)
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
Additional Technical Parameters & Features Performance Data (Typical) EER / COP: EER: 3.03.4 (air-cooled) COP: 3.54.2 (water-cooled) Note: Actual efficiency depends on ambient temperature and water T. Power Consumption: Approx. 3.54.5 kW at full load (air-cooled) Note: Lower power consumption at part load conditions. Expansion Device Thermostatic Expansion Valve (TXV) Electronic Expansion Valve (optional for higher efficiency) Note: EEV provides better part-load performance and tighter temperature control. Refrigerant Circuit Accessories Filter drier Sight glass with moisture indicator Suction accumulator Service valves (suction & discharge) Water Piping Connections Chilled water inlet / outlet: 1" or 2" BSP / Flanged (model dependent) Vent & drain connection provided Note: Flexible hose connection recommended to reduce vibration. Temperature Control Accuracy 0.5 C (standard controller) 0.3 C (with advanced PID controller optional) Note: Suitable for precision process cooling applications. Part Load Operation Single compressor ON/OFF control (standard) VFD on compressor (optional limited models) Note: VFD improves energy efficiency and reduces starting current. Starting Method Direct-On-Line (DOL) starter Soft starter / VFD (optional) Note: Recommended where power supply is weak or generator operated. Electrical Load (Typical) Full Load Current: 79 A (415 V, 3-phase) Short Circuit Protection: MCB / MCCB Control Voltage: 230 V AC / 24 V DC (model dependent) Standards & Quality Designed as per AHRI / ASHRAE guidelines Electricals as per IEC standards Pressure vessels tested as per applicable codes Installation Requirements Minimum clearance around unit: 9001000 mm Level concrete foundation recommended Proper airflow must be ensured for air-cooled units Note: Poor ventilation can reduce capacity and increase power consumption. Operating Limits Minimum ambient: 10 C Maximum ambient: 50 C Minimum chilled water inlet temperature: 5 C Note: Glycol required for lower temperature applications. Optional Accessories SS 304 / SS 316 piping Glycol compatible design Remote monitoring via Modbus / RS-485 Heat recovery condenser (water-cooled models) Acoustic enclosure for ultra-low noise applications Warranty Compressor: 1218 months from commissioning Complete unit: 12 months Note: Extended warranty available on request. Suitable Industries (Extended) Printing & packaging Chemical & API plants Rubber & extrusion machines PET blow molding Data room / equipment cooling
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
ParameterTypical Value / RangeNotes
| Cooling capacity | 4 TR 14 kW (for example: 4 TR = 14 kW for model CG-4A)+1 | Scroll type offers simplicity, reliability |
| Refrigerant | R410A or other modern HFC refrigerant (sometimes R22/ R407C in older units)Guangdong Tongwei Machinery Co., Ltd.+1 | Confirm voltage, phase compatibility |
| Evaporator / chilled-water circuit | Chilled-water supply/return (for example: 12 C supply / 7 C return)+1 | Ambient temperature influences capacity and performance |
| Water flow rate (when used with chilled-water) | Example: 2.4 m/h for a 4 TR unit | Check exact amount from manufacturer |
| Dimensions / weight | Example: 1140 560 1040 mm; weight 170 kg for one model+1 | If ambient in your location is higher (e.g., Delhi summer), your capacity may dropspecify accordingly |
| Safety & protection features | Over-/under-pressure protection, flow switches, phase-failure protection, etc. |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
Differential pressure protection across evaporator
Low-flow alarm & auto shutdown logic
Manual air vent on evaporator
Note: Prevents damage due to air locking or insufficient water circulation.
Anti-short cycling timer
Minimum ON / OFF time delay
Automatic restart with fault memory
Note: Extends compressor life and improves system reliability.
Pressure-based fan cycling (standard)
Multi-step fan control for stable condensing temperature
EC fans optional for energy-efficient operation
Note: Improves performance during fluctuating ambient conditions.
Evaporator fouling factor: 0.00010.0002 hrftF/Btu
Approach temperature: 23 C (typical)
Note: Lower approach temperature results in better system efficiency.
Powder-coated CRCA sheet steel enclosure
IP 54 protection class
Internal wiring with ferrules & cable markers
Note: Suitable for industrial indoor/outdoor installations.
Digital water inlet & outlet temperature display
Suction & discharge pressure indication
Alarm indication with fault code display
Note: Enables easy troubleshooting and monitoring.
Low Global Warming Potential (GWP) refrigerant options available
RoHS-compliant electrical components
Designed for reduced carbon footprint
Note: Suitable for green and energy-conscious projects.
Maximum altitude: up to 1000 m above MSL (standard)
Deration applicable above 1000 m altitude
Suitable for tropical climatic conditions
Note: Altitude and humidity affect cooling capacity.
Performance run test at factory
Electrical insulation & continuity test
Refrigerant leak testing using nitrogen
Note: Ensures trouble-free commissioning at site.
Easily accessible service points
Standard make components for easy availability
Nationwide service support (optional)
Note: Reduces downtime and maintenance cost.
Compressor life expectancy: 812 years
Heat exchanger life: 1215 years (with proper water quality)
Note: Life depends on operating conditions and maintenance.
Installation, Operation & Maintenance (IOM) manual
Electrical wiring diagram
GA drawing (on request)
Test & inspection certificate
Continuous power supply
Treated chilled water supply
Drain point near unit location
Adequate ventilation / exhaust airflow
Low-temperature brine chilling (with glycol)
Continuous 247 operation design
High ambient duty version (50 C)
Redundant pump / control philosophy (optional)
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
Technical Specification
| Sr. No. | Parameter | Details |
| 1 | Model | FMACSC-80TR-R407C |
| 2 | Cooling Capacity | 80 TR / 280 kW |
| 3 | Refrigeration Circuit | 1 No |
| 4 | Power Supply | 400V, 3Ph, 50Hz |
| 5 | Connected Load | 70.25 kW /114.8A |
| 6 | Refrigerant | R407C |
| 7 | Refrigerant Control | Thermostatic Expansion Valve |
| 8 | Evaporating SST | 7C |
| 9 | Condensing SDT | 50C |
| 10 | Ambient Temperature | 45C |
| 11 | Working Temperature Range | +10C to +20C |
| 12 | Chilled Water Flow | 6000 LPH (T = 35C) |
| 13 | Condenser Air Flow | 30720 CFM |
| 14 | Fan Type | Axial Type, Large Blade |
| 15 | Fan Quantity | 4 Nos |
| 16 | Fan Size | 28 inches (Suction Type) |
| 17 | Fan Power | 0.65kW 4 Nos = 2.6 kW |
| 18 | Compressor Type | Semi-Hermetic Screw |
| 19 | Compressor Quantity | 1 No |
| 20 | Compressor Make & Model | Bitzer |
| 21 | Compressor Power | 63.9 kW / 105.4 A @ 50 Hz |
| 22 | Start Mode | Star-Delta Starter |
| 23 | Capacity Control | Step (0, 25, 50, 75, 100%) |
| 24 | Evaporator Type | Shell & Tube Type |
| 25 | Evaporator Shell MOC | Carbon Steel, Powder Coated |
| 26 | Evaporator Tube MOC | Inner Grooved Copper Tubes |
| 27 | Evaporator Baffle & Header | SS-304, TIG Welded |
| 28 | Evaporator Design Pressure | 10 Bar |
| 29 | Evaporator Test Pressure | 15 Bar (Hydrostatic) |
| 30 | Evaporator Pipe Connection | 3 BSP (Inlet & Outlet) |
| 31 | Evaporator Insulation | 40 mm PUF, Closed Cell |
| 32 | Condenser Type | Air Cooled (Copper Tubes & Aluminum Fins) |
| 33 | Pump power | 3.75 kw/5HP/5.2A/50000LPH |
| 34 | Pump head(Lift) | 2.33 KG |
| 35 | Condenser Pipe Size | 3/8 |
| 36 | Condenser Support | Galvanized Steel Frame |
| 37 | Safety Protections | Inner Thermostat, HP/LP Switch, Overload Relay, Phase Reverse, Flow Switch, Anti-Freeze, Discharge Temp. Protection, Water low levels. |
| 38 | Electrical Panel | MCB, Contactor, Overload, Timer, Relays, Pre-wired, PLC, HMI |
| 39 | Dimensions (LWH) | After confirmation, we will provide the dimensions and drawing |
Additional Information:
Payment Terms : D/P
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
TECHNICAL SPECIFICATION Technical Details / Technical Data Sheet / Product Specification
GENERAL TECHNICAL DATA General Specifications / Technical Overview / System Data
Equipment Model Unit Model / Chiller Model / System Model
Rated Cooling Capacity Nominal Cooling Capacity / Cooling Output / Rated Capacity
30 TR (Tons of Refrigeration) 30 TR Cooling Capacity / 30 Tons Cooling Output
Number of Refrigeration Circuits Refrigeration Circuits / Cooling Circuits
Two (2) Independent Refrigeration Circuits Dual Independent Circuits / Two Separate Cooling Circuits
Working Refrigerant Refrigerant Type / Refrigerant Used
Refrigerant Expansion / Control Device Expansion Valve / Refrigerant Control Valve
Thermostatic Expansion Valve (TXV) TXV Type Expansion Valve
Electrical Power Supply Power Supply Requirement / Electrical Input
Total Connected Electrical Load Total Power Consumption / Connected Load
Three Phase AC 3-Phase AC Supply
Design Evaporating Temperature (SST) Evaporating Temperature / Suction Saturation Temperature
Design Condensing Temperature (SDT) Condensing Temperature / Discharge Saturation Temperature
Maximum Ambient Design Temperature Maximum Ambient Operating Temperature
Operating Glycol Temperature Range Glycol Operating Range / Chilled Fluid Temperature Range
Design Chilled Water / Glycol Flow Rate Required Flow Rate / Circulation Flow Rate
Condenser Air Flow Rate Air Volume Flow / Condenser Air Quantity
Condenser Fan Type Fan Arrangement / Air Circulation Fans
Axial Flow Fans with Large Diameter Blades Heavy-Duty Axial Fans / High-Efficiency Axial Fans
Number of Fans Installed Fan Quantity / Total Fans
Fan Motor Power Rating Fan Motor Capacity / Fan Motor Power
Compressor Design & Type Compressor Configuration / Compressor Type
Hermetically Sealed Scroll Compressors Hermetic Scroll Compressors
Total Compressor Power Consumption Compressor Power Input / Compressor Load
Compressor Starting Method Starting System / Start-Up Method
Capacity Control Method Capacity Regulation / Load Control
Fixed Capacity Constant Capacity / Non-Modulating
Evaporator Configuration Evaporator Type / Heat Exchanger Type
Shell and Tube Type Heat Exchanger Shell & Tube Evaporator
Material of Construction MOC / Construction Material
Internally Grooved Copper Tubes Enhanced Surface Copper Tubes
Condenser Construction Type Condenser Design / Condenser Assembly
Air Cooled Condenser Air-Cooled Heat Rejection System
Aluminium Fins and Copper Tubes Aluminium Fin & Copper Tube Coil
Condenser Structural Support Support Frame / Structural Frame
Chilled Water / Glycol Pumps Circulation Pumps / Process Pumps
SS-304 Construction Stainless Steel 304 Construction
3 HP / 2.2 kW Each Motor Rating: 3 HP Each
Safety & Protection Features Safety Devices / Protective Controls
High & Low Pressure Safety Switches HP & LP Cut-Out Switches
Phase Reversal / Phase Failure Protection Relay Phase Protection Relay
Anti-Freeze Protection Freeze Protection
Electrical Control & Instrumentation Panel Control Panel / Electrical Control Panel
Micro Chill Controller Digital Temperature Controller / Microprocessor Controller
Power Contactors, MCBs Electrical Switching & Protection Devices
Additional Information:
Payment Terms :
Packaging Details : Standard Packaging
Delivery Time : 15 days
TechnicalSpecification
| Sr.No. | Parameter | Details |
| 1 | Model | FMACS-10TR-407 |
| 2 | CoolingCapacity | 10TR |
| 3 | Refrigerationcircuit | 1Nos |
| 4 | PowerSupply | 400V-50Hz |
| 5 | Connectingload | 12KW/20A |
| 6 | Refrigerant | R407C |
| 7 | RefrigerantControl | ThermostaticExpansion |
| 8 | EvaporatingSST | 7C |
| 9 | CondensingSDT | 48C |
| 10 | AmbientTemp | 60C |
| 11 | WorkingTemperatureRange | 7CTO20C |
| 12 | ChilledFlowOfWater | 4500 LPH, T 15C |
| 13 | CondenserAir Flow | 10000CFM |
| 14 | Fantypes | AxiallargeBlade |
| 15 | FanQty | 2Nos |
| 16 | Fan Size | 500MM Suction |
| 17 | FanPower | 0.8*2 |
| 18 | CompressorTypes | Scroll |
| 19 | CompressorQty | 2Nos |
| 20 | Compressorpower | 9KW/16A |
| 21 | Startmode | Regular |
| 22 | Capacitycontrol | 0, 100% |
| 23 | EvaporatorTypes | BPHE |
| 24 | Evaporatorpipeconnection | 1.5 |
| 25 | EvaporatorShellMOC | MS.PowderCoted |
| 26 | EvaporatorMOC | CopperandSS-304 |
| 27 | Condensertypes | AirCooled(Copper Tube) per ton 6 sq Ft |
| 28 | CondenserPipesize | 3/8 |
| 29 | CondenserSupporter and Chiller body | Galvanize |
| 30 | Pump | SS-304/1.5HP |
| 31 | SafetyProtection | Inner Thermostat for compressor motor, unit overloadrelay, highandlowpressureswitch, reverse phase protection relay, discharge gas thermostat, flow switch , Antic Freeze protection |
| 32 | Electriccontrolpanel | Controller, protectionrelay, contactor, MCB, preventer, timer. |
Additional Information:
Payment Terms : D/P
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
| S.No. | Description | Technical Specification |
| 1. | System | AircooledReciprocatingchiller |
| 2. | Modelno. | FMACSR-2TRChiller |
| 3. | Capacity | 2TR |
| 4. | Compressortype | Recip. (Emerson) |
| 5. | Evaporatortype | BPHE (Alfa-Level ) |
| 6. | Condensertype | Aircooled, Finnedtubetype |
| Fins – Aluminum – Coted | ||
| Tube – Copper (Grooved ) | ||
| 7. | Refrigerant | R-407C |
| 8. | Flowrate | 1300 LPH |
| 9. | Chilledwaterinlettemperature | As Per clients Deg.C |
| 10. | Required Temp. | 20 Deg.C |
| 11. | Coolingfantype | Axialflowfan-Low noise |
| 12. | Powerconsumption | 3 KW , 4.6 – 5.2 Amps |
| 13. | Powersupply | 415+10%/50Hz+5% |
| 14. | IPProtection | IP54 |
| 15. | Control | FullyAutomatic |
| 16. | Safety | LP/HPGauge |
| LP/HPSwitch | ||
| Digitaltemperaturecontroller | ||
| Voltagescannerfor UV/OV/SPP/RP | ||
| Chilledwaterflowfailuretrip | ||
| 17. | Chilledwaterpump | 0.5 HP – SS-304, 1300LPHat2.5bar |
| 18. | Chilledwatertank | 100 Liter -insulatedstainlesssteel |
Additional Information:
Payment Terms : L/C, T/T, Western Union,
Packaging Details : special case in wooden packing ,
Delivery Time : 1 week
| Cooling capacity | 4 TR 14 kW (for example: 4 TR = 14 kW for model CG-4A) +1 | Scroll type offers simplicity, reliability |
| Refrigerant | R410A or other modern HFC refrigerant (sometimes R22/R407C in older units) Guangdong Tongwei Machinery Co., Ltd.+1 | Confirm voltage, phase compatibility |
| Evaporator / chilled-water circuit | Chilled-water supply/return (for example: 12 C supply / 7 C return) +1 | Ambient temperature influences capacity and performance |
| Water flow rate (when used with chilled-water) | Example: 2.4 m/h for a 4 TR unit | Check exact amount from manufacturer |
| Dimensions / weight | Example: 1140 560 1040 mm; weight 170 kg for one model +1 | If ambient in your location is higher (e.g., Delhi summer), your capacity may dropspecify accordingly |
| Safety & protection features | Over-/under-pressure protection, flow switches, phase-failure protection, etc. |
Additional Information:
Payment Terms : D/P
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
TechnicalSpecification FIDEM3TRAirCooledHermetic Chiller
| S.No. | Description | Specification |
| 1 | System | AirCooledReciprocatingChiller |
| 2 | ModelNo. | FMACSR-3TRChiller |
| 3 | CoolingCapacity | 10.5KW/3TR@5CEvap.And45C conde. |
| 4 | CompressorType | Reciprocating(Emerson / Danfoss ) |
| 5 | EvaporatorType | Cooling coil 100% Copper |
| 6 | CondenserType | AirCooled, FinnedTubeType |
| 7 | Refrigerant | R-407C |
| 8 | FlowRate | 4000LPH ( As Per Your Requirements Control) |
| 9 | ChilledWaterInletTemp Max | 55C |
| 10 | ChilledWaterOutlet Temp Max | 3C |
| 11 | CoolingFanType | 1Nos - AxialFlowFan (Low Noise ) |
| 12 | PowerConsumption | 3KW |
| 13 | PowerSupply | 415V10%/50Hz5% |
| 14 | IPProtection | IP54 |
| 15 | Control | FullyAutomatic |
| 16 | SafetyDevices | LP/HPSwitches, DigitalTempController, FlowFailure Trip |
| 17 | ChilledWaterPump | 1HP , 4000LPH@2Bar |
| 18 | ChilledWaterTank | SS304, FullyInsulated, 1.2MMthickness |
| 19 | Tankvolume | 200 Liter |
| 20 | Connection size | 1 3 Nos |
| 21 | Inlet / overflow connection | 1 1nos /1nos |
| 22 | Flow meter | 1 Nos |
| 23 | Water level | 1 Nos |
Additional Information:
Payment Terms : D/P
Packaging Details : STANDARD
Delivery Time : 15 days
ParameterTypical Value / RangeNotes
| Cooling capacity | 4 TR 14 kW (for example: 4 TR = 14 kW for model CG-4A)+1 | Scroll type offers simplicity, reliability |
| Refrigerant | R410A or other modern HFC refrigerant (sometimes R22/R407C in older units)Guangdong Tongwei Machinery Co., Ltd.+1 | Confirm voltage, phase compatibility |
| Evaporator / chilled-water circuit | Chilled-water supply/return (for example: 12 C supply / 7 C return)+1 | Ambient temperature influences capacity and performance |
| Water flow rate (when used with chilled-water) | Example: 2.4 m/h for a 4 TR unit | Check exact amount from manufacturer |
| Dimensions / weight | Example: 1140 560 1040 mm; weight 170 kg for one model+1 | If ambient in your location is higher (e.g., Delhi summer), your capacity may dropspecify accordingly |
| Safety & protection features | Over-/under-pressure protection, flow switches, phase-failure protection, etc. |
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
Differential pressure protection across evaporator
Low-flow alarm & auto shutdown logic
Manual air vent on evaporator
Note: Prevents damage due to air locking or insufficient water circulation.
Anti-short cycling timer
Minimum ON / OFF time delay
Automatic restart with fault memory
Note: Extends compressor life and improves system reliability.
Pressure-based fan cycling (standard)
Multi-step fan control for stable condensing temperature
EC fans optional for energy-efficient operation
Note: Improves performance during fluctuating ambient conditions.
Evaporator fouling factor: 0.00010.0002 hrftF/Btu
Approach temperature: 23 C (typical)
Note: Lower approach temperature results in better system efficiency.
Powder-coated CRCA sheet steel enclosure
IP 54 protection class
Internal wiring with ferrules & cable markers
Note: Suitable for industrial indoor/outdoor installations.
Digital water inlet & outlet temperature display
Suction & discharge pressure indication
Alarm indication with fault code display
Note: Enables easy troubleshooting and monitoring.
Low Global Warming Potential (GWP) refrigerant options available
RoHS-compliant electrical components
Designed for reduced carbon footprint
Note: Suitable for green and energy-conscious projects.
Maximum altitude: up to 1000 m above MSL (standard)
Deration applicable above 1000 m altitude
Suitable for tropical climatic conditions
Note: Altitude and humidity affect cooling capacity.
Performance run test at factory
Electrical insulation & continuity test
Refrigerant leak testing using nitrogen
Note: Ensures trouble-free commissioning at site.
Easily accessible service points
Standard make components for easy availability
Nationwide service support (optional)
Note: Reduces downtime and maintenance cost.
Compressor life expectancy: 812 years
Heat exchanger life: 1215 years (with proper water quality)
Note: Life depends on operating conditions and maintenance.
Installation, Operation & Maintenance (IOM) manual
Electrical wiring diagram
GA drawing (on request)
Test & inspection certificate
Continuous power supply
Treated chilled water supply
Drain point near unit location
Adequate ventilation / exhaust airflow
Low-temperature brine chilling (with glycol)
Continuous 247 operation design
High ambient duty version (50 C)
Redundant pump / control philosophy (optional)
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
Differential pressure protection across evaporator
Low-flow alarm & auto shutdown logic
Manual air vent on evaporator
Note: Prevents damage due to air locking or insufficient water circulation.
Anti-short cycling timer
Minimum ON / OFF time delay
Automatic restart with fault memory
Note: Extends compressor life and improves system reliability.
Pressure-based fan cycling (standard)
Multi-step fan control for stable condensing temperature
EC fans optional for energy-efficient operation
Note: Improves performance during fluctuating ambient conditions.
Evaporator fouling factor: 0.00010.0002 hrftF/Btu
Approach temperature: 23 C (typical)
Note: Lower approach temperature results in better system efficiency.
Powder-coated CRCA sheet steel enclosure
IP 54 protection class
Internal wiring with ferrules & cable markers
Note: Suitable for industrial indoor/outdoor installations.
Digital water inlet & outlet temperature display
Suction & discharge pressure indication
Alarm indication with fault code display
Note: Enables easy troubleshooting and monitoring.
Low Global Warming Potential (GWP) refrigerant options available
RoHS-compliant electrical components
Designed for reduced carbon footprint
Note: Suitable for green and energy-conscious projects.
Maximum altitude: up to 1000 m above MSL (standard)
Deration applicable above 1000 m altitude
Suitable for tropical climatic conditions
Note: Altitude and humidity affect cooling capacity.
Performance run test at factory
Electrical insulation & continuity test
Refrigerant leak testing using nitrogen
Note: Ensures trouble-free commissioning at site.
Easily accessible service points
Standard make components for easy availability
Nationwide service support (optional)
Note: Reduces downtime and maintenance cost.
Compressor life expectancy: 812 years
Heat exchanger life: 1215 years (with proper water quality)
Note: Life depends on operating conditions and maintenance.
Installation, Operation & Maintenance (IOM) manual
Electrical wiring diagram
GA drawing (on request)
Test & inspection certificate
Continuous power supply
Treated chilled water supply
Drain point near unit location
Adequate ventilation / exhaust airflow
Low-temperature brine chilling (with glycol)
Continuous 247 operation design
High ambient duty version (50 C)
Redundant pump / control philosophy (optional)
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
Additional Technical Parameters & Features
Performance Data (Typical)
EER / COP:
EER: 3.03.4 (air-cooled)
COP: 3.54.2 (water-cooled)
Note: Actual efficiency depends on ambient temperature and water T.
Power Consumption:
Approx. 3.54.5 kW at full load (air-cooled)
Note: Lower power consumption at part load conditions.
Expansion Device
Thermostatic Expansion Valve (TXV)
Electronic Expansion Valve (optional for higher efficiency)
Note: EEV provides better part-load performance and tighter temperature control.
Refrigerant Circuit Accessories
Filter drier
Sight glass with moisture indicator
Suction accumulator
Service valves (suction & discharge)
Water Piping Connections
Chilled water inlet / outlet:
1" or 2" BSP / Flanged (model dependent)
Vent & drain connection provided
Note: Flexible hose connection recommended to reduce vibration.
Temperature Control Accuracy
0.5 C (standard controller)
0.3 C (with advanced PID controller optional)
Note: Suitable for precision process cooling applications.
Part Load Operation
Single compressor ON/OFF control (standard)
VFD on compressor (optional limited models)
Note: VFD improves energy efficiency and reduces starting current.
Starting Method
Direct-On-Line (DOL) starter
Soft starter / VFD (optional)
Note: Recommended where power supply is weak or generator operated.
Electrical Load (Typical)
Full Load Current: 79 A (415 V, 3-phase)
Short Circuit Protection: MCB / MCCB
Control Voltage: 230 V AC / 24 V DC (model dependent)
Standards & Quality
Designed as per AHRI / ASHRAE guidelines
Electricals as per IEC standards
Pressure vessels tested as per applicable codes
Installation Requirements
Minimum clearance around unit: 9001000 mm
Level concrete foundation recommended
Proper airflow must be ensured for air-cooled units
Note: Poor ventilation can reduce capacity and increase power consumption.
Operating Limits
Minimum ambient: 10 C
Maximum ambient: 50 C
Minimum chilled water inlet temperature: 5 C
Note: Glycol required for lower temperature applications.
Optional Accessories
SS 304 / SS 316 piping
Glycol compatible design
Remote monitoring via Modbus / RS-485
Heat recovery condenser (water-cooled models)
Acoustic enclosure for ultra-low noise applications
Warranty
Compressor: 1218 months from commissioning
Complete unit: 12 months
Note: Extended warranty available on request.
Suitable Industries (Extended)
Printing & packaging
Chemical & API plants
Rubber & extrusion machines
PET blow molding
Data room / equipment cooling
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
Additional Technical Parameters & Features
Performance Data (Typical)
EER / COP:
EER: 3.03.4 (air-cooled)
COP: 3.54.2 (water-cooled)
Note: Actual efficiency depends on ambient temperature and water T.
Power Consumption:
Approx. 3.54.5 kW at full load (air-cooled)
Note: Lower power consumption at part load conditions.
Expansion Device
Thermostatic Expansion Valve (TXV)
Electronic Expansion Valve (optional for higher efficiency)
Note: EEV provides better part-load performance and tighter temperature control.
Refrigerant Circuit Accessories
Filter drier
Sight glass with moisture indicator
Suction accumulator
Service valves (suction & discharge)
Water Piping Connections
Chilled water inlet / outlet:
1" or 2" BSP / Flanged (model dependent)
Vent & drain connection provided
Note: Flexible hose connection recommended to reduce vibration.
Temperature Control Accuracy
0.5 C (standard controller)
0.3 C (with advanced PID controller optional)
Note: Suitable for precision process cooling applications.
Part Load Operation
Single compressor ON/OFF control (standard)
VFD on compressor (optional limited models)
Note: VFD improves energy efficiency and reduces starting current.
Starting Method
Direct-On-Line (DOL) starter
Soft starter / VFD (optional)
Note: Recommended where power supply is weak or generator operated.
Electrical Load (Typical)
Full Load Current: 79 A (415 V, 3-phase)
Short Circuit Protection: MCB / MCCB
Control Voltage: 230 V AC / 24 V DC (model dependent)
Standards & Quality
Designed as per AHRI / ASHRAE guidelines
Electricals as per IEC standards
Pressure vessels tested as per applicable codes
Installation Requirements
Minimum clearance around unit: 9001000 mm
Level concrete foundation recommended
Proper airflow must be ensured for air-cooled units
Note: Poor ventilation can reduce capacity and increase power consumption.
Operating Limits
Minimum ambient: 10 C
Maximum ambient: 50 C
Minimum chilled water inlet temperature: 5 C
Note: Glycol required for lower temperature applications.
Optional Accessories
SS 304 / SS 316 piping
Glycol compatible design
Remote monitoring via Modbus / RS-485
Heat recovery condenser (water-cooled models)
Acoustic enclosure for ultra-low noise applications
Warranty
Compressor: 1218 months from commissioning
Complete unit: 12 months
Note: Extended warranty available on request.
Suitable Industries (Extended)
Printing & packaging
Chemical & API plants
Rubber & extrusion machines
PET blow molding
Data room / equipment cooling
Additional Information:
Payment Terms :
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
| Sr. No. | Parameter | Details |
| 1 | Model | FM2-275X57XH |
| 2 | Cooling Capacity | 274.0 TR / 962 kW |
| 3 | Refrigeration Circuit | 2 No |
| 4 | Power Supply | 3Ph, 415V, 50Hz |
| 5 | Connected Load | 304.0 kW / 490 Amp (Full Load Current) |
| 6 | Refrigerant | R134a |
| 7 | Refrigerant Control | Expansion Valve (Flooded type system) |
| 8 | Evaporating SST | +5.6 C (given LWT 6.07 C) |
| 9 | Condensing SDT | +36 C Ambient / +45 C SDT |
| 10 | Ambient Temperature | Max. 46 C |
| 11 | Working Temperature Range | Chilled Water: 5C 20C |
| 12 | Chilled Water Flow | 415.3 L/s = 1495 m/h , T 5.6C |
| 13 | Condenser Air Flow | 394, 168 CMH |
| 14 | Fan Type | Axial Type, Low Noise |
| 15 | Fan Quantity | 16 Nos |
| 16 | Fan Size | 910 mm (as per standard for 275 TR unit) |
| 17 | Fan Power | 40.0 kW (Total, 16 2.5 kW) |
| 18 | Compressor Type | Semi-Hermetic Flooded Screw |
| 19 | Compressor Quantity | 2 Nos |
| 20 | Compressor Make & Model | Bitzer |
| 21 | Compressor Power | 264 kW (driven, total) |
| 22 | Start Mode | Star-Delta Starter |
| 23 | Capacity Control | Step/Slide Control (Part Load Efficiency IPLV mentioned) |
| 24 | Evaporator Type | Flooded Shell & Tube |
| 25 | Evaporator Shell MOC | Carbon Steel, Powder Coated |
| 26 | Evaporator Tube MOC | Copper Tubes |
| 27 | Evaporator Baffle & Header | Carbon Steel |
| 28 | Evaporator Design Pressure | 15.0 kg/cm (Water Side) |
| 29 | Evaporator Test Pressure | Hydrostatic, typically 22 bar |
| 30 | Evaporator Pipe Connection | DN150 (6 NB approx., for 1500 m/h flow) |
| 31 | Evaporator Insulation | 40 mm PUF |
| 32 | Condenser Type | Air Cooled, Copper Tubes & Aluminum Fins |
| 33 | Condenser Pipe Size | 3/8 |
| 34 | Condenser Support | Galvanized Steel Frame |
| 35 | Pump Power | (Not included external pump required) |
| 36 | Pump Head (Lift) | (Not included site selected) |
| 37 | Safety Protections | Compressor overheating, HP/LP switch, Over-current, Over-temp, Flow Switch, Phase Protection, Oil Safety |
| 38 | Electrical Panel | PLC , HMI , MCCB, Contactors, Overload Relay, Timer, Relays, Pre-Wired |
| 39 | Dimensions (LWH) | 9610 2825 2547 mm |
| 40 | Running Weight | 9860 kg |
| Component | Make / Brand |
| Compressor | Danfoss |
| Evaporator | FIDEM |
| Condenser | FIDEM |
| Electrical Panel | FIDEM |
| Flow Switch | Castle |
| Pressure Switch | Danfoss |
| Expansion Valve | Danfoss |
| Filter Drier | Dry All |
| Solenoid Valve | Danfoss |
| Electrical Components | Schneider Electric |
Additional Information:
Payment Terms : D/P
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
TechnicalSpecification
| Sr. No. | Parameter | Details |
| 1 | Model | FMACS-25TR |
| 2 | CoolingCapacity | 25TR/88kW |
| 3 | CoolingCapacity(Control) | 0, 50, 100% |
| 4 | RefrigerationCircuit | 2No |
| 5 | Power Supply | 400V, 3Ph, 50Hz |
| 6 | TotalConnectedLoad | 30kW/ 48A |
| 7 | Refrigerant | R410A/R407C(Eco-Friendly) |
| 8 | RefrigerantControl | ThermostaticExpansionValve |
| 9 | EvaporatingSST | 7C |
| 10 | CondensingSDT | 54C |
| 11 | AmbientTemperature | Max.50C(High-ambientcompatible) |
| 12 | WorkingTemperatureRange | +7Cto +20C |
| 13 | ChilledWaterFlow | 7500LPH(T=10C) |
| 14 | CondenserAirFlow | 11250CFM |
| 15 | FanType | AxialType, LargeBlade(LowNoise) |
| 16 | FanQuantity | 4Nos |
| 17 | FanSize | 800mm(SuctionType) |
| 18 | FanPower | 0.75kW4Nos=3kW |
| 19 | CompressorType | HermeticScroll |
| 20 | CompressorQuantity | 2No |
| 21 | CompressorMake&Model | Danfoss |
| 22 | CompressorPower | 25 kW@50Hz |
| 23 | StartMode | Regular |
| 24 | CapacityControl | - |
| 25 | EvaporatorType | BPHE |
| 26 | EvaporatorMOC | Cu/SS-304 |
| 27 | EvaporatorTubeMOC | - |
| 28 | EvaporatorBaffle& Header | - |
| 29 | EvaporatorDesignPressure | 16Bar |
| 30 | EvaporatorTestPressure | 24Bar (Hydrostatic) |
| 31 | EvaporatorPipeConnection | 2BSP(Inlet &Outlet) |
| 32 | EvaporatorInsulation | 40mmPUF, ClosedCell |
| 33 | CondenserType | AirCooled(CopperTubes&AluminumFins) |
| 34 | CondenserPipeSize | 3/8 |
| 35 | CondenserSupport | GalvanizedFrame |
| 36 | Pump | Flow-20000LPH@2 Bar, SS-304, (1.2kW), -1 Nos |
| 37 | SafetyProtections | InnerThermostat, HP/LPSwitch, Overload |
|
|
| Relay, Phase Reverse, Flow Switch, Anti- Freeze, DischargeTemp.Protection, Water low levels. |
| 38 | Circulationtank | ClientsScope |
| 39 | ElectricalPanel | MCB, Contactor, Overload, Timer, Relays, , Pre- wired, PLC, HMI |
| 40 | StructureMOC | Galvanized(WithPowderCoted) |
| 41 | Dimensions(LWH) | 3000x1700x2100MM |
| 42 | RunningWeight | 2100Kg |
| Component | Make/Brand |
| FixSpeedCompressor | Danfoss |
| Evaporator | FIDEM |
| Condenser | FIDEM |
| ElectricalPanel | FIDEM |
| FlowSwitch | Castle |
| PressureSwitch | Danfoss |
| ExpansionValve | Danfoss |
| FilterDrier | DryAll |
| SolenoidValve | Danfoss |
| ElectricalComponents | SchneiderElectric |
| Gasket PHE | Fidem |
Additional Information:
Payment Terms : D/P
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
TechnicalSpecification
| Sr.No. | Parameter | Details |
| 1 | Model | FMACS-20TR-407 |
| 2 | CoolingCapacity | 20TR |
| 3 | Refrigerationcircuit | 2Nos |
| 4 | PowerSupply | 400V-50Hz |
| 5 | Connectingload | 28.84 KW/ 41.53A |
| 6 | Refrigerant | R407C |
| 7 | RefrigerantControl | ThermostaticExpansion |
| 8 | EvaporatingSST | -5C |
| 9 | CondensingSDT | 48C |
| 10 | AmbientTemp | 48C |
| 11 | WorkingTemperatureRange | +1TO+10 |
| 12 | ChilledFlowOfWater | 12000 LPH @ 5 delta |
| 13 | CondenserAir Flow | 8000CFM |
| 14 | Fantypes | AxiallargeBlade |
| 15 | FanQty | 4Nos |
| 16 | Fan Size | 16 |
| 17 | FanPower | 1.8*4 |
| 18 | CompressorTypes | Scroll |
| 19 | CompressorQty | 2Nos |
| 20 | Compressorpower | KW/A |
| 21 | Startmode | Regular |
| 22 | Capacitycontrol | 0, 100% |
| 23 | EvaporatorTypes | BPHE |
| 24 | Evaporatorpipeconnection | 2 |
| 25 | EvaporatorShellMOC | MS.PowderCoted |
| 26 | EvaporatorMOC | CopperandSS-304 |
| 27 | Condensertypes | AirCooled(AluminumFinsAndCopper Tube) |
| 28 | CondenserPipesize | 3/8 |
| 29 | CondenserSupporter | Galvanize |
| 30 | PUMP | SS-304/2HP |
| 31 | SafetyProtection | Inner Thermostat for compressor motor, unit overloadrelay, highandlowpressureswitch, reverse phase protection relay, discharge gas thermostat, flow switch , Antic Freeze protection |
| 32 | Electriccontrolpanel | Controller, protectionrelay, contactor, MCB, preventer, timer. |
| 33 | Dimension(length/width/height) | - |
| 34 | Runningweight | - |
|
| Product | Make |
| 1. | compressor | Danfoss (sz-240) |
| 2. | Evaporator | Fidem |
| 3. | condenser | Fidem |
| 4. | Electricpanel | Fidem |
| 5. | Flowswitch | Castle |
| 6. | PressureSwitch | Danfoss |
| 7. | Expansionvalve | Danfoss |
| 8. | Filter | Dryall |
| 9. | Solenoidvalve | Danfoss |
| 10. | Electroniccomponents | Schneider |
Additional Information:
Payment Terms : D/P
Packaging Details : STANDARD PACKAGING
Delivery Time : 15 days
Mr. Yash Badi (Aquatechplus Pvt. Ltd.)
Plot No 74 Shree Khodiyar Park Survey No 91 Behind Ruda Transport Nagar Sokhda Village Near Sat Hanuman Temple, Kuvadva Road, Rajkot, Gujarat - 360003
https://www.aquatechpluspvtltd.co.in
Share us via
