The 2.4GHz 12dBi Outdoor Patch Panel Antenna with N (F) Straight Connector is designed for robust outdoor wireless applications, providing excellent signal gain and coverage for various networking needs, including point-to-point and point-to-multipoint configurations.

Key Features:

rn
• High Gain: With a 12dBi gain, this antenna significantly enhances signal strength, making it ideal for long-range communications.
rn
• Outdoor Design: Engineered for outdoor use, the antenna is built to withstand harsh weather conditions, ensuring durability and reliability.
rn
• Patch Panel Style: The panel design allows for easy mounting and optimal directional transmission, making it suitable for fixed installations.
rn
• N (F) Straight Connector: The N female connector provides a secure and reliable connection to a variety of devices, ensuring compatibility with most outdoor networking equipment.
rn
• Wide Application: Perfect for Wi-Fi networks, surveillance systems, and other wireless communications that require extended range and stability.
rn

This antenna is an excellent choice for users looking to boost their outdoor wireless performance and achieve a strong, reliable signal over long distances.

The 4G LTE 14dBi MIMO Outdoor Patch Panel with RG58 (L-10CM) Cable + N (F) Straight Connector is a specialized antenna system designed to enhance 4G LTE signal reception and transmission, particularly in outdoor environments. Heres a detailed breakdown of its components and features:

Components and Features

1. 4G LTE Compatibility:

   • Purpose: Specifically designed to work with 4G LTE networks, improving connectivity for devices that operate on these frequencies.

2. 14dBi Gain:

   • Gain: The 14dBi gain indicates a high level of signal amplification, making this antenna suitable for areas where signal strength is weak or where long-range signal reception is needed.
   • MIMO Technology: The antenna is equipped with Multiple Input Multiple Output (MIMO) technology, which enhances data throughput and network reliability by using multiple signal paths.

3. Outdoor Patch Panel Design:

   • Construction: The patch panel design is flat and rectangular, optimized for mounting on walls or poles. Its designed to be durable and weather-resistant for outdoor use.
   • Coverage: Provides a broad coverage area compared to highly directional antennas, though it still offers focused signal gain in its directional pattern.

4. RG58 Cable (L-10CM):

   • Cable Type: RG58 is a coaxial cable used for RF applications. It is relatively flexible and suitable for connecting antennas to equipment.
   • Length: The cable is 10 centimeters long, which is typically used for connecting the antenna directly to nearby equipment or for short cable runs.

5. N (F) Straight Connector:

   • Type: The N Female (F) straight connector is a robust RF connector used for outdoor and high-frequency applications.
   • Usage: The N Female connector connects to devices or cables with an N Male connector, ensuring a secure and reliable connection.

Advantages

• High Gain: The 14dBi gain provides substantial signal amplification, which is beneficial for enhancing connectivity in weak signal areas.
• MIMO Technology: Improves overall data performance and network stability by utilizing multiple signal paths.
• Outdoor Durability: Designed to withstand harsh weather conditions, making it suitable for outdoor installations.
• Flexible Cable: The RG58 cable allows for easy connection and positioning of the antenna.

Typical Applications

• Rural and Remote Areas: Ideal for enhancing 4G LTE signals in areas with limited network coverage.
• Outdoor Installations: Suitable for mounting on outdoor surfaces such as walls, poles, or rooftops to improve signal reception.
• Signal Boosting: Useful for improving the performance of 4G LTE modems or routers, particularly where signal strength is critical.

Installation Tips

• Mounting: Securely mount the antenna in a location with minimal obstructions to maximize signal reception. Ensure it is mounted as high as practical for optimal performance.
• Aiming: If the antenna has a directional pattern, aim it towards the nearest cell tower to enhance signal strength.
• Connector Handling: Ensure the N Female connector is properly connected to the N Male cable or device, and check for a secure and weatherproof connection.

Considerations

• Signal Path: For optimal MIMO performance, ensure that multiple antennas (if part of a MIMO setup) are spaced appropriately to avoid signal interference.
• Cable Quality: While RG58 is flexible, make sure the cable is routed properly to avoid damage and maintain signal quality.
