Armoured Control and Instrumentation Cable

Sold By : Alankar Cable Industries

Product Specifications

Supply TypeManufacturer, Exporter, Supplier, Retailer

Preferred Buyer From : All over the world

Product Overview

Alankar Cable Industries is counted amidst the top names in the industry, when it comes to buying a reliable range of Underground Armoured Cables. The company is known as a dynamic Control and Instrumentation Cable Manufacturer, Exporter, and Supplier from New Delhi (India). Manufactured from the premium raw materials, our Underground Armoured Cables perform well under adverse conditions. These Underground Armoured Cables work for longer time than ordinary cables and are safe to use. The Underground Armoured Cables are offered by us in varied specifications, at the most competitive prices.

Applications

For fixed installation in most areas and on open deck in ships.
If the cable is exposed to direct sun light protective covering orcable with black outer sheath is recommended

Highlights

Minimum recommended installation temperature -15 ^oC
Lowest operation temperature -40 ^oC
Core Identification : black numbers on white base
Identification : Lot number, cable type, cable size, voltage, temperature, standards, production month, manufacturer's name and meter marking printed on the sheath

Main Characteristics

Rated voltage	150/250V (300V)
Maximum conductor temperature	+ 90 ^oC
Flame-retardant	IEC 60332-1-2 -test for single insulated wire and cable IEC 60332-3-22 -test for bunched wires and cables, category A
Halogen-free	IEC 60754 series
Smoke emission	IEC 61034 series

Specification

LKSM-FRHF 0,6/1kV	Number of conductors & cross-section n x mm²	Crosssection of screen mm²	Nominal outer diameter Mm	Approximate weight kg/km	Current rating A	Min. bending radius fixed installation Mm
Part number		Crosssection of screen mm²	Nominal outer diameter Mm	Approximate weight kg/km	Current rating A	Min. bending radius fixed installation Mm
26402	2x0,75	3,6	7,5	90	11,3	45
26403	3x0,75	3,6	8,0	100	9,8	50
26404	4x0,75	3,6	8,5	110	8,9	50
26405	5x0,75	4,1	9,5	140	8,3	55
26407	7x0,75	4,1	10,0	160	7,4	60
26410	10x0,75	5,1	12,5	220	6,6	70
26412	12x0,75	5,3	13,0	240	6,2	75
26414	14x0,75	5,6	13,5	265	5,9	75
26416	16x0,75	6,1	14,0	295	5,6	80
26419	19x0,75	8,7	14,5	330	5,3	85
26424	24x0,75	11,7	17,5	450	4,9	100
26427	27x0,75	11,7	17,5	480	4,7	100
26432	32x0,75	11,8	18,5	540	4,5	105
26437	37x0,75	11,9	19,5	600	4,3	115
