DC Power System 0-64V / 20A

Output Type  -   Single

Output Voltage  -             0-64V

Output Current  -             0-20A

Load regulation(CV)  -    +/- 0.05% +/- 3mV From no load to full load

Load regulation (CC)  -   +/-0.05% +/- 1mA from no load to full load

Line regulation(CV)  -     +/- 0.01% +/-3 mV for +/-10% variation input voltage

Line regulation (CC)  -     +/- 0.01% +/- 1mA for +/-10% variation input voltage

Ripple   Less than  - 1 mV

Meter  -  Two digital meters to monitor the output voltage and current

Protection  -  Against short circuit and over load

DC Regulated Power Supply 0-64V/20A are constant Voltage & Current Constant type supplies, have high regulation for Load & Line Voltage variation. The supply is protected against short circuit & over load. The output current can be controlled to any value from 0 to maximum.
