Product Specifications
| Model | SHLS-L2 |
| Charging Type | Pulse width modulation (PWM) |
| Panel Power | 5Wp |
| Maximum Panel Voltage [VOC] | 21V (Over voltage protection by varistor) |
| Battery Type | SMF |
| Battery Capacity | 4.5 Ah |
| Battery Protection | Active HVD and LVD , Inbuilt BMS circuit |
| High Voltage Protection | 7 V |
| Low Voltage Protection | 6.3 V |
| Efficiency | >95% peak |
| Max Charging Current | 3A |
| Max Discharging Current | 3A |
| DC Load Nominal Voltage | 6 V DC |
| Electronic Protection | PV Reverse polarity, Reverse current flow at night, Surge Transient, Load short, over current, High and Low voltage protection at battery side. |
| LED Indications | Green : Solar, Yellow : Battery SOC, Red : Fault indication |
| Ambient Temperature | 0°c to +50°C while charging ; -200C to +500C while dis-charging |
| Protection | IP 22 |
| USB Connector | USB Type A ; 5.5 V ; 500mA |
| Load | DC jack 6.5mm - 2 output terminals |
| Weight In Kg | 2.50 Kg |
| Dimension (L XW X H) Mm | 350 x 250 x 115 |
| Accessories | Panel with cable - 1No, DC LED Lamp 1.5W - 2 Nos, E-27 Lamp holder assembly and mobile charging connector - 1No . |
| In Built Led Lamp In Unit | Inbuilt Led 3w lamp in unit |
