UNIVERSAL OUTDOOR AC UNITS

Sold By : Transcold Appliances

Product Specifications

Rated Volt /Frequency220-240V`/ 50Hz,380V3N` / 50Hz,380V3N`/50Hz
Cooling Capacity33,000 Btu/h ,48,000 Btu/h,60,000 Btu/h
ParameterKF- 75W/B
TCA - 48CRHTCA - 60CRH
Supply TypeManufacturer, Exporter, Supplier, Retailer

Preferred Buyer From : All over the world

Product Overview

worlds famous scroll compressor with quick reactivity, stronger powerand operation stable. Anti-attenuation design and better low-temperature heating performance. Brand- new outdoor unit design, multi-direction piping connection meet different requirement, conveninent installation.

compressor :

worlds famous scroll compressor with quick reactivity, stronger powerand operation stable. Anti-attenuation design and better low-temperature heating performance.
brand- new outdoor unit design, multi-direction piping connection meet different requirement, conveninent installation.

warranty
	1 year warranty on entire unit + 4 years on compressor warranty

disclaimer
	stabilizer cost & installation charges are exclusive and the same has to be payable by customer at actuals. product will be delivered for all urban areas serviceable by major courier agencies.for rural areas the product will be sent by local couriers and may take more time. no deliveries on sunday and national holidays.

Parameter	KF- 75W/B	TCA - 48CRH	TCA - 60CRH

Cooling Capacity	33,000 Btu/h	48,000 Btu/h	60,000 Btu/h

Rated Volt /Frequency	220-240V`/ 50Hz	380V3N` / 50Hz	380V3N`/50Hz

Water of Proof	IP24	IP24	IP24
Colling Cuttent input	13.1A	7.5A	9.5A

Colling power input	2790W	5200W	5200W

Rated current input	---	10.5A	13.6A

Rated power input	---	6550W	6900W

HP. PS	---	2.7MPa	2.7MPa

LP. PS	---	0.7MPa	0.7MPa

Max operating pressure of heat exchanger	2.7MPa	3.0MPa	2.5MPa

Outdoor noise	<58dB(A)	<68dB(A)	<68dB(A)

Refrigerant	R22/1580G	R22/2350G	R22/3800G

Met Weight of outdoor unit	59kg	90kg	118kg
