Flow Controller With Totalizer

Supply TypeManufacturer, Exporter, Supplier, Retailer
Preferred Buyer Location All over the world

low Input :Linear Voltage (0-5V DC OR 1-5V DC, Linear Current (4-20mA), Two Wire Transmitter Input (All Linear inputs can be configured with or without Square Root Extraction) OR Frequency....

View More Details

Send Enquiry

Company Information

Tempsen Devices

Balaji Nagar, Chennai, Tamil Nadu

View Number

Member Since 17 Years
Nature of Business Retailer
Year of Establishment 1987

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

low Input :
Linear Voltage (0-5V DC OR 1-5V DC, Linear Current (4-20mA), Two Wire Transmitter Input (All Linear inputs can be configured with or without Square Root Extraction) OR Frequency Input
Temperature Input :
RTD PT-100 OR Thermocouple (K,E,J) – For Temperature Compensation (Compensation possible with TUPC-FC)
Pressure Input:
Linear Voltage (0-5V DC OR 1-5V DC, Linear Current (4-20mA) –For Pressure Compensation (Compensation possible with TUPC-FC)
Display:
Flow Rate, Accumulated or Total Flow, Pressure & Temperature
Accuracy:
0.2%FS
Output for Batch Control: Relay
Set Point: Set point Range Limit; Dual Set Point Switch; Remote Set point
Alarm: High & Low Alarms for Flow, Temperature and Pressure
Communication: RS485 (Plug-in Module)
Re Transmission O/P: Linear Current or Voltage (SV OR PV)
Power Supply: SMPS100~240VAC/DC‚50Hz OR 24 V DC, Size : 96X96X100mm
