Made in year
2005
-
Operation hours
tested, NEWER USED
-
Product capasity
5600 kg / 20 hours
-
Condition
New like
We Offer Cooling Tunnel Hermetel 107 Kw / 5 C. cooling Tunnel is Made By Hermetel in Year 2004 and It Has Been Designed to Cool Down Ready Packed Products Loaded On Galvanized Steel Trolleys After a Processing from 40 Celsius Degree to 5 C. the Complete Unit Was Installed in 2005 and It Has Never Used and It is Thus in New like Condition. cooling Tunnel Consist of 19 Meters Long Double Tunnel Made On Polyurethane Panels Where Product Trolleys are Led Through the In-feed and Out-feed Tunnel with a Floor Mounted Transport Conveyor. the Conveyor is Pneumatically Operated Via Double Acting Rail with Gripping Hooks for the Trolleys. Loading and Unloading of Trolleys is from the Front of the Tunnel and Automatic Direction Change Gear Will Turn Trolleys from In-feed Line to Out-feed Line. Totally 31 Trolleys Fit in the Cooling Tunnel in One Time. Delivery Includes 35 Brand New Galvanized Steel Trolleys. hot Climate Design Water Chiller with Cooling Capacity of 107 Kw and Made By Aermec in 2004 Provides Cooling of the Tunnel. the Water Chiller is Air-cooled, Outdoor Type and the Cooling Transfer Media in Water Glycol Solution. Circulation Air Fan System with a Cooling Heat Exchanger is Located On the Roof of Tunnel, Cooling Air At +3 C Temperature is Directed in Reverse Product Trolley Transportation Direction and It is Circulated in Closed Loop. the Whole Unit is Controlled with Mura Plc System with a Mmi Screen Together with Microprocessor Based Control Unit of the Water Chiller. Tunnel Takes 31 Trolleys with 180 Kg Product Each (totally Approx 5600 Kg Packed Product) and Cooling from +40 C to +5c Will Take 20 Hours if the Product is Packed in No Thicker that 10 Cm Packs . cooling Tunnel Technical Information manufacturer: hermtel, Installation Year 2005cooling Capacity: 107 Kw / +3c Air tunnel Material: polyurethane 20 Cm Panel product Capacity 31 X 180 Kg/20 Hours, No Thicker Than 10 Cmtunnel Dimensions: canal Openings 1.8 X 2.0 Mtotal Width 2.8 Mtotal Length Approx. 19 M height Requirement 4 M circulation Fan Capacity: m3/h - Kw water Chiller Technical Information:manufacturer: aermec Spa. Italymanufacturers Type: nra 550 ***a***01cooling Capacity: 107 Kw / At 35 Ambient and 0 C Media Outlet coolant: r407c compressors: 3 X Hermetic 2 Circuit Scroll Compressors in-built Media Tank: 300 Litersmedia Circulation Pump: 17 M3/h - 3 Barpower Requirement: 39 Kw / 400 V - 3 Phase main Dimensions L X W X H 2950 X 1100 X 1950 Mmweight Without Media: approx 1450 Kg
Additional Information:
Payment Terms :
T/T
Packaging Details : 2 x 40 feet container
