Our Products
Our Complete range of products are PVC Braided Hose and Chemical Rubber Hose.
Braided Hose Pipe - PVC Braided Hoses made from high quality thermoplastic compound and reinforced (braided) with high tenacity synthetic yarn (crosswise - lengthwise). The excellent ply adhesion and bonding between the inner and upper layer of PVC ensures a durable pipe. The braiding gives the hose high strength and resistance to withstand high pressure and elongation. Our production of hoses meets the most stringent operational requirements. Transparent hoses facilitate the location of blockage in use.
The smooth inner bore prevents any build - up and offers minimum resistance to flow. The working pressure of the hose is dependent on temperature and is lowered with increase in temperature. Available in various grades as Clear Transparent, Super Spray (Car Washing), Agricultural Pesticide, Green Garden Water, Sanitary, Fire Fighting, Rock Drill, Welding etc. Features: Withstand high pressure, Light weight compared to rubber hose, Clear transparent, Working temperature up to 60 o C, High flexibility, Long working life and durability, Chemical and abrasion resistance, Excellent ply adhesion, Crush and kink resistance, Opaque if required, Rodent proof
PVC Braided Hoses made from high quality thermoplastic compound and reinforced (braided) with high tenacity synthetic yarn (crosswise - lengthwise). The excellent ply adhesion and bonding between the inner and upper layer of PVC ensures a durable pipe. The braiding gives the hose high strength and resistance to withstand high pressure and elongation. Our production of hoses meets the most stringent operational requirements.
Transparent hoses facilitate the location of blockage in use. The smooth inner bore prevents any build - up and offers minimum resistance to flow. The working pressure of the hose is dependent on temperature and is lowered with increase in temperature. Available in various grades as Clear Transparent, Super Spray (Car Washing), Agricultural Pesticide, Green Garden Water, Sanitary, Fire Fighting, Rock Drill, Welding etc.
Application : As Chemical Rubber Hose manufacturer Designed to handle a wide range of chemicals, acids, alkalies and alcoholic, mineral acids, aqueous solution of inorganic materials during production and their transferring operations.
Lining : Uniform seamless tube of EPDM, Hypalon, Thiokol, Chloroprene, Butyl, SBR, NBR, natural/synthetic/blend rubber compound or a blend depending on the liquid for which the hose is intended to be used.
Reinforcement : Plies of rubber coated woven textile or braided synthetic yarns with or without helical galvanized steel wire.
Cover : Smooth, fluted or fabric marked finish with suitable rubber compound, resistant to weather.
Types : Type 1 for conveying dilute chemicals. Type 2 for conveying concentrated chemicals.
Pressures : Type 1 W.P. of 1.00 MPa & B.P. min.3.15 MPa . Type 2 W.P. of 1.00 MPa & B.P. min.4.00 MPa Nom
Specification
| Nom. Bore in (mm) | Tolerance on Nom. bore (mm) | Min. Thk. of Lining (mm) | Min. Thk. of Cover (mm) |
|---|---|---|---|
| 10 | ± 0.75 | 2 | 1.3 |
| 12.5 | ± 0.75 | 2 | 1.3 |
| 16 | ± 0.75 | 2 | 1.3 |
| 20 | ± 0.75 | 2 | 1.3 |
| 25 | ± 1.25 | 2 | 1.3 |
| 31.5 | ± 1.25 | 2 | 1.3 |
| 38 | ± 1.50 | 2 | 1.3 |
| 45 | ± 1.50 | 2 | 1.3 |
| 50 | ± 2.00 | 2 | 1.3 |
