An excellent helping tool, enables users to address detectors softly rather than using a dip-switch. Also includes more features - consult manual.   Zeta GSM communicator is an interface that allows a fire alarm panel to send a SMS text message in the event of an alarm or a fault.

The ZT-CP3/AD is the latest addressable call point from Zeta Alarm Systems. It has a modern design, and has been built to EN54 part 11.

Sandwich Sounder   The Fyreye II Sandwich sounder base is a platform sounder that works with the Zeta Fyreye II protocol. The sounder can be triggered from it`s detectors remote LED output, allowing the sounders to be triggered individually. It can also be triggered using the Protocol`s common sounder group command, meaning that it can be triggered even if it`s detector has been removed.   Xtratone Addressable Wall Sounder The Xtratone sounders are small, high output addressable devices which are designed to meet EN54 part 3. The device is a compact unit that fits a standard European back box and can be either surface or semi-flush mounted. The Xtratone sounder has been designed so that field cables can be terminated in the back box as a first fix.

Fyreye MKII Addressable Input/Output Module With Isolator The ZAIO-MI is both an input and output module in a modern enclosure (2 gang box size) with well protected electronic circuit board to minimise any damages during installation.   Fyreye MKII Addressable Input Module With Isolator The ZAI-MI is used to monitor and raise alarm from any ancillary equipment such as sprinkler flow switch, aspiration detectors, secondary fire control panel, beam detectors, external power supplies etc.

Quatro Panels Premier Quatro 4 Loop Analogue Addressable Fire Alarm Panel The Quatro control panel is designed, manufactured and tested to fully meet the requirements of EN54 part 2 and part 4. This panel is of a modular nature and can be supplied in 1, 2, 3, and 4 loop versions. A specially designed Quatro Configuration software is available for configuring the panel or multi-panels and can be downloaded to the system via USB connection. Up to 32 panels/repeaters can be networked over 10, 000m of data cable and a special alarm management system can provide all needs for very large projects such as university campus, hospital complex etc.   Quatro 4 Loop Flush Mount Kits The Quatro 4 loop enclosure is available with two optional flush mounting bezels; first the QT4-FMB bezel which matches the same finish as the standard panel or secondly the QT4-FMB/SS which replaces the entire front with a stainless steel finish.

The Quatro system network has the facility to monitor, indicate and control the functions of a re alarm installation, thus allowing signals to be distributed around a large site. The networking is normally wired in a ring using Fireproof Communication Cable. Each panel will need a network card added to the termination board (when using QT-NC). Optionally the network ring can be wired with bre optic cable (using QT-NC/FP).

Bases For Standard MKII Addressable Detectors   The MkII range of detectors can be mounted on 3 different bases, a shallow base (MKII-CB), a deep base (MKII-CB/D) and an isolator base (MKII-IB).   Bases For MKII Addressable Detectors With Built-In Isolators Fyreye MKII Addressable Common Base for use with MKII-AOPI, MKII-AHRI, MKII-AHFI & MKII-AOHI.
